Syp fluid sampler

Product specification

Need help?

Do you have a question about the Syp and is the answer not in the manual?

Page 1 Syp fluid sampler Product specification...
Page 2: Feature Summary
Description The Syp automatic fluid sampler is a portable device that automatically collects fluid samples over time. Up to 58 discrete samples can be collected without user intervention. The unit has a run time of over 12 months on a weekly sample schedule and uses airtight sample containers, allowing long-term deployment in remote locations.
Page 3 Syp fluid sampler Specification Detail Housing 6mm clear acrylic panels ABS fixings Rubber corners Control Graphical user interface Webapp-based configuration via WiFi hotspot Microprocessor control Data logging & sensors Time, temperature, humidity, pressure Full vial & water detection Download via webapp...
Page 4 Overall dimensions Assembled: 356 x 312 x 242 (H x W x D, mm) Top half: 194 x 312 x 242 Bottom half: 160 x 312 x 242 Weight 9.2kg Power supply 16x AA alkaline or lithium batteries Power requirement 10 to 13V DC Ambient temperature Upper bound: 50°C...
Page 5 Carry bags Specification Detail Dimensions 600 x 290 x 250 (H x W x D, mm) Each bag carries one half of the device. Two bags are needed for one complete unit. Materials External: Heavyweight PVC 900g, Polyester 1100dTex Internal: Medium weight PVC 690G, Polyester 1100dTex, 10mm closed-cell foam padding Straps 50mm Polyamide seatbelt webbing...
