- Page 1 Quick Start Guide NT10XXX and NT11XXX Serial LCD Tablet Namirial.com...
- Page 2 Scan the QR code for the latest versions and available languages: support.namirial.com/en/download/tsp/#namirial-pad 1. Plug in Device Correct connecting of NT10XXX/NT11XXX Plugin one-cable USB port into power adapter (only for NT1XXX2 and NT1XXX3) Plugin two-cable USP port into PC Plugin into Namirial device...
- Page 3 Installation of DisplayLink Driver If the signature tablet screen does not show any content after a few seconds you may need to install a DisplayLink. 3. Namirial LCD Tablet Installation Install the driver on your system: Namirial PAD Driver NT10XXX/NT11XXX Download here: support.namirial.com/en/download/tsp/#namirial-pad...
- Page 4 4. Set as extended display a) Open the context menu with a right mouse click on your desktop and click “Display Settings” b) Change to “Extend these displays” under the section “Multiple displays” c) Click “Keep changes” to apply your changes Important: Make sure your NT10XXX/NT11XXX pad and other displays are horizontally aligned at the top.
-
Page 5: Handwriting Area Mapping
5. Handwriting Area Mapping Select “Namirial PAD display” by clicking the arrows to enable the pen on the signature tablet Important: If mapping is set correctly, but the response is still on the wrong display, then use the arrows of the dropdown to deselect and select your NT10XXX/NT11XXX device again. - Page 6 7. Change Pen Holder location based on Device Orientation for NT10XXX a) Open all screws with a screwdriver b) Pull out the pen holder and put the rubber cover into the empty hole which is included in the package c) Mount the pen holder in your preferred orientation position and tighten all screws...
- Page 7 d) Extend the two stands for your preferred orientation 8. Change Pen Holder location based on Device Orientation for NT11XXX...
- Page 8 9. Orientation Mode Change a) Change the orientation mode of the screen itself with the Namirial Pad Manager by selecting “Landscape or Portrait” b) Sample device orientations (portrait or landscape)
- Page 9 We are pleased to receive any requests for clarification, updating and supplementation at any time via e-mail to contacts@namirial.com. This document does not constitute leagal advice. In particular, it cannot replace individual legal advice that takes into account the specifics of each case.
