Round Ladder Handle with wood insert
Code
87H2R1001910xxx
Measurements
*
*mm
Components
Material
SS304
*
#
1
2
3
4
5
6
7
8
9
H
(14'')
(10'')
356 mm
254 mm
(2-3/8'')
60 mm
Ø (3/4'')
19 mm
Name
Exterior Handle
Interior Handle
Metal Washer
Gasket
Plastic Washer
Assembly Screw
Set Screw
Allen Key 3mm
Allen Key 5 mm
C/C
Qty
1
1
4
4
4
2
2
1
1
Advertisement
Related Manuals for Richelieu 87H2R1001910 Series
Summary of Contents for Richelieu 87H2R1001910 Series
- Page 1 Round Ladder Handle with wood insert Code Material (14’’) (10’’) 87H2R1001910xxx SS304 356 mm 254 mm (2-3/8’’) Measurements 60 mm Ø (3/4’’) 19 mm Components Name Exterior Handle Interior Handle Metal Washer Gasket Plastic Washer Assembly Screw Set Screw Allen Key 3mm Allen Key 5 mm...
- Page 2 Round Ladder Handle Installation Install the exterior handle as shown with one gasket and metal washer on each side of the glass. Install the interior handle onto the screws. Install the set screws and tighten with the Allen key to finish the installation...
- Page 3 Poignée échelle ronde Code Matériel (14’’) (10’’) 87H2R1001910xxx SS304 356 mm 254 mm (2-3/8’’) Dimensions 60 mm Ø (3/4’’) 19 mm Composantes Qté Poignée extérieure Poignée intérieure Rondelle en métal Joint Rondelle en plastique Vis d’assemblage Clé Allen 3mm Clé Allen 5 mm...
- Page 4 Poignée échelle ronde Installation Installez la poignée extérieure comme illustré avec un joint et une rondelle métallique de chaque côté du verre. Installez la poignée intérieure sur les vis. Installez les vis de réglage et serrez avec la clé Allen pour terminer l'installation...
