- Page 1 Wine Cellar Installation manual RW51TS338SR/AA...
- Page 2 Installation manual Installation specifications for built-in purposes • Gloves and safety goggles should be worn during installation. • It is not recommended to install the appliance into a corner or directly beside a wall. The door will need to be opened more than 90° to allow full extension of the shelves. If it is necessary to place the unit next to a wall or in a corner, leave at least 2-4 inches (5-10 cm) of space between the wall and the appliance to allow for the door opening.
-
Page 3: Required Tools
Installation manual Required Tools • Safety goggles • Gloves • Tape measure • Carpenter square • Level • Flashlight • Electric drill with hole bit Fixing the TOP Fixing Bracket 1. Remove the 2 pieces of decorative plastic nail (a) from the top of wine cooler; 2. - Page 4 Installation manual Installation guide of bracket 24" min.(610mm) Depth of furniture Two screws to fix on furniture 13 / " (605mm) Top fixing bracket Glass door build-in installation Two screws to fix on product Side fixing bracket installation Side fixing bracket Top fixing bracket "...
-
Page 5: Anti-Tip Bracket Installation
Installation manual Installing the Anti-Tip Bracket for Free Standing WARNING This appliance may tip when shelves are extended, causing damage or injury. If this appliance is used in a FREE STANDING application, the anti-tip bracket must be installed following these instructions! Anti-tip bracket parts List: A : Anti-tip bracket (1pc) - Page 6 Installation manual Installing Instructions - Anti - Tip Bracket IMPORTANT: Determine the final location of the appliance before attempting to install the bracket. You will need to choose one of the three installation methods below. DRYWALL installation: 1. After you have chosen the installation location, Place the bracket on the floor with Loc b against the wall, use Screw (E) (2pcs) to secure the bracket to the wall.
-
Page 7: Reverse Door
Installation manual Reverse Door Do not cover racks with aluminum foil or any other mate- rial that will prevent adequate air circulation within the cabinet. 1. Lower hinge (Right) 2. crews for door axis 3. Door axis 4. Door . crews for actuator . - Page 8 Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG Customer Care Center. Country Contact Center Web Site 1-800-SAMSUNG (726-7864) U.S.A www.samsung.com/us/support 1-844-SAM-PAYS (726-7297)
