- Page 1 USB DIGITAL MICROSCOPE Operating instructions...
-
Page 2: Table Of Contents
TECHNICAL INFORMATION System requirements Technical data SERVICE PROCESSING DISPOSAL DISTRIBUTOR LEUCHTTURM GROUP GMBH & CO. KG Am Spakenberg 45 21502 Geesthacht, Germany Phone: +49 (0) 4152 / 801 - 0 Fax: +49 (0) 4152 / 801 - 222 E-mail: info@leuchtturm.de Internet: www.leuchtturm.com... -
Page 3: Safety Instructions
Dear customer, Thank you for choosing a LEUCHTTURM product. This high-quality USB digital microscope is state of the art with 5 megapixels and up to 300x magnification. It is also compatible with the latest Windows and Mac operating systems. The microscope is easy to use and is ideal for viewing stamps, coins, minerals, fossils, banknotes, plants, small insects and much more. -
Page 4: Use
❒ Do not touch the lens to avoid scratches and fingerprints. ❒ Do not look directly into the LED lamps when they are switched on. The light could damage your eyes. ❒ Do not disconnect the device from the USB port while the LEDs are switched on. This may result in the loss of some information or damage to the circuit. -
Page 5: Software Installation
SOFTWARE INSTALLATION 1. Insert the installation CD into the drive of your computer. 2. For Windows users: The installation wizard opens automatically. Install the software by clicking on the Ihstall MicroCapture Plus button. The wizard will guide you through the rest of the process. If the installation wizard does not o p e n automatically, select the file setup.exe from. - Page 6 For Mac users: Open the mac folder on the installation CD. Copy the MicroCapture_Plus_Package file to your desktop. Open the copied file by double-clicking on it. The installation wizard will start and guide you through the rest of the process. For quicker and easier access to the software, we recommend that you create a shortcut to the program a f t e r installation and place it on your desktop.
-
Page 7: Preparations Before Use
PREPARATIONS BEFORE USE 1. If you have not already done so, connect the USB digital microscope to your computer (via the USB port). 2. Start the software by double-clicking on the icon icon on your desktop / desktop. The following program window opens: 3. -
Page 8: Take Photos And Videos
TAKE PHOTOS AND VIDEOS Setting options The software offers various settings for taking photos and videos. These can be found in the main menu under Options: Resolutioh Selecting the image resolution Date / Time Show / hide date and time (is not saved on the photo / video) Language Selection of the menu language in the software Crosshair Show / hide a crosshair... -
Page 9: Take Photos
Take photos You have various options for taking photos: a. In the main menu, select Capture > Photo. b. Click on the symbol (photo). c. Press the trigger on the connection cable of the device. The captured photos are saved on your computer in the Microcapture_Photo folder. You can also access this folder via File >... -
Page 10: Record Videos
• When the mouse pointer is positioned over a thumbnail, the selected photo is displayed in the main area of the program window. • If you r i g h t - c l i c k on a thumbnail, you will see a submenu with which you can perform various actions for the selected photo: Open Open photo in the image preview (see also chapter Image editing) - Page 11 At the same time, the videos are displayed as thumbnails on the right-hand side of the program window: • If you r i g h t - c l i c k on a thumbnail, you will see a submenu with which you can perform various actions for the selected video: Öflheh Play video in separate window...
-
Page 12: Timer
Timer You have the option of setting a timer for recording photos and videos. To do this, click on the (timer) icon and the following window will open: You can now make the following settings: Photo / Video Select whether photos or videos are to be recorded. Start time Set the start time of the recording Interval (sec.) -
Page 13: Image Processing
IMAGE PROCESSING The software also has an image editing program. To edit a captured photo, open it by double-clicking on the thumbnail or by right-clicking on the thumbnail and then selecting Open. The photo opens in a separate window: You now have various options for editing the photo: Save photo Copy photo to the clipboard for further use Copy photo Select previous photo / Select next photo Undo... - Page 14 Drawing Various drawing tools: Line, arrow, freehand, rectangle You can define the properties of the line in a submenu: Hihweis Selection options for text input: Select font, text color To enter text, click on the place in the photo where you want to enter the text.
-
Page 15: Calibration
Calibration See chapter Calibration CALIBRATION The software offers a calibration function with which you can carry out the most accurate measurements on your photos. BEFORE MEASURING PHOTOS, YOU SHOULD ALWAYS CARRY OUT A CALIBRATION IN ORDER TO OBTAIN CORRECT VALUES WHEN MEASURING. To carry out a calibration, please proceed as follows: 1. - Page 16 A separate window opens: 6. Now manually enter the actual size in mm of the distance you have just defined in the Actual dimension field. In the picture above, a 1 mm distance was measured and therefore the number 1 was entered in the field.
-
Page 17: Exit Software
The magnification value displayed in the top right of the main program is not affected by this. This means that the magnification value displayed there is still set for all photos taken in the future. If the value is also to be reset to zero, select Reset preview magnification. Enlargement To manually set a magnification value for an individual photo, select Image magnification, enter the value in the field and confirm with OK. -
Page 18: Technical Information
TECHNICAL INFORMATION System requirements • Operating system: Windwos 7/8/10, Mac OS 10.12 or higher • min. Processor Pentium 1800 or comparable AMD processor • 100 MB free hard disk space • 512 MB RAM (working memory) (recommended) • 24 bit color video card •... -
Page 19: Service Processing
SERVICE PROCESSING If you have any reason for complaint or if your appliance i s defective, please contact your dealer or contact us directly: LEUCHTTURM GROUP GMBH & CO. KG Am Spakenberg 45 21502 Geesthacht, Germany Phone: +49 (0)4152 / 801 - 0 (Monday to Friday from 8:00 - 17:00) Fax: +49 (0) 4152 / 801 - 222 E-mail: info@leuchtturm.de...
