5' W x 10' L KENNEL ROOF KIT
INSTRUCTION MANUAL
MSP-196
TIPS BEFORE YOU START!
1.
Ensure that all parts are present prior to assembly.
2.
Check all packing material carefully before discarding, as some parts may be encased in the packing material.
3.
For ease and speed of assembly, it is recommended that prior to each step all required parts are identified.
4.
Ensure that you have sufficient space and people to assemble product safely.
5.
During assembly take care not to over-tighten any fittings, as this may damage the product.
6.
Please keep this instruction manual for future reference.
1
Advertisement
Summary of Contents for Mid-States Distributing Main St. Pet MSP-196
- Page 1 5' W x 10' L KENNEL ROOF KIT INSTRUCTION MANUAL MSP-196 TIPS BEFORE YOU START! Ensure that all parts are present prior to assembly. Check all packing material carefully before discarding, as some parts may be encased in the packing material. For ease and speed of assembly, it is recommended that prior to each step all required parts are identified.
- Page 2 PARTS LIST Part # Description Drawing Quantity Cross rail Rafter rail 3-way peak connector 4-way peak connector 3-way side connector Corner connector Clamp M10X50 bolt M10 nut Steel cable Clamp Cover ASSEMBLY INSTRUCTIONS Step 1: Assemble the roof kit Lay out the roof kit parts as shown below and connect together (fig.
- Page 3 Customer Service: For questions or comments, please call 888-376-7375 or visit www.mainstreetpet.com. Main St. Pet ™ is a trademark of Mid-States Distributing, LLC. © Mid-States Distributing LLC. Manufactured for and distributed by Mid-States Distributing, LLC Fort Worth, TX 76137 USA. Made in Vietnam.
