- Page 1 ELECTRIC SCOOTER A6L MAX USER MANUAL...
-
Page 2: Table Of Contents
Contents Package Contents Function Parameters Assembly Charge Your Scooter How to ride Folding Unfolding LEQISMART APP Safety Precautions Cleaning and Storage Tire Inflation Maintenance Battery Maintenance Environmental Protection Warranty Content Limited Warranty Statement Question & Answer... -
Page 3: Package Contents
Package Contents User Manual Power Adapter T-shape Allen Key Screw... -
Page 4: Function
Function Throttle Handle Folding hook Headlight Brake Hook fastening buckle Front Tube Rear lamp Folding Handle Electrical unit Charging port Function mode: Cruise mode, Pedestrian mode, Fault prompt, Light, Bluetooth, Lock. Gear mode: The rated speed is 3 mph for L gear, 9 mph for M gear and 15 mph for H gear. -
Page 5: Parameters
Parameters Name Electric Scooter Product Model A6L MAX Vehicle: L × W × H (in) 44.29×17.32×47.40 Dimensions After Folding: L × W × H (in) 44.29×17.32×21.06 Net Weight Vehicle Net Weight (lb) 37.05 Max. Load (lb) Rider Age (years) Height (in) 4.72~7.87... - Page 6 Model C1387A3 Nominal Voltage (VDC) 36.5 Max. Charge Voltage (VDC) 42 Rated Energy (Wh) 379.6 Battery Pack Intelligent Battery Over-heating, short circuit, over-current, Management System over-discharge, and over-charge protection Normal Charging 0 to 45 Temperature Range (°C) Rated Capacity (Ah) 10.4 Wheel Rated Power (W)
-
Page 7: Assembly
Assembly 1. Pull the folding handle upwards until there is a click sound, andpull the folding handle to confirm whether it is locked. 2.Manually connect the fixing seat and the wire in the front tube.and check whether it is turned on normally. 3.Insert the fixing seat into the front tube, and use a T-shapeAllen Key to tighten the six screws. - Page 8 1.Lift up the rubber flap. 2.Connect the battery charger to the charging port. 3.Disconnect the battery charger from the charging port when charging is completed. 4.Put back the rubber flap.
-
Page 9: How To Ride
Attention: 1. Only use the original power adapter when charging. 2. Keep away from children and animals when charging, and keep away from flammablematerials. 3. Do not charge or use the battery if it emits a peculiar smell, overheats or leaks. 4. - Page 10 3. Stand with your foot on the 4. During the sliding, keep your pedal and thrust against the balance, place the other foot ground with your foot. When on the pedal and lightly press the speed of scooter is ≥3 mph, the acclerator to move forward.
- Page 11 Note: About cruise control mode When the cruise control mode is activated, pressing and holding the throttle in the same position for 5 seconds engages the scooter into cruise control riding mode. The cruise control icon illuminates on the dashboard. In this mode, when the rider releases the throttle, the scooter maintains the same speed.
-
Page 12: Folding
Folding Make sure the scooter is turned off and not being charged before folding. Hold the stem, lift the quick release lever lock, and pull the quick release lever outward. Unfolding Press the red button in the folding hook to remove the folding hook from the hook fixing buckle, straighten the front tube, close thefolding handle until there is a “click"... -
Page 13: Leqismart App
LEQISMART APP Scan the QR code below with your mobile phone or search for "LEQISMART" in the APP market, download and install the APP. If the APP has already been downloaded on your mobile phone, please upgrade the APP to the latest version. STEP 1 Search or scan to download LEQISMART APP, Open the APP. -
Page 14: Safety Precautions
Safety Precautions 1. Please carefully read the user manual, which will assist in explaining the basic working principles and provide tips on how to best enjoy your scooter experience. 2. Please wear all appropriate safety and protective gear as previously mentioned in the User Manual before operating the scooter. - Page 15 the obstruction. 14. Do not ride in inclement weather: snow, rain, hail, sleek, on icy roads or in extreme heat. 15. Do not ride in or near pools or other large bodies of water. 16. Traffic in the city has many obstacles to cross such as curbs or steps.
- Page 16 28. Individuals with lack of balance should not attempt to operate the scooter. 29. Women who are pregnant or are preparing for pregnancy should not operate the scooter. 30. Young children and the elderly should not operate the scooter without proper instruction and supervision from a Certified scooter trainer.
- Page 17 46. This vehicle is not intended for acrobatic use. 47. Caution, the brake may become hot in use. Do not touch after use. 48. Warning aiming to draw the user's attention to any damages related to intensive use and to recommend periodic inspections of the frame, fork and suspension attachments (if any).
- Page 18 non-operational mode. 57. Be sure to keep and read the instructions for your future reference. 58. Persons shall be advised not to allow hands, feet, hair, body parts. clothing, or similar articles to come in contact with moving parts,wheels, or drivetrain, while the engine is funning. Persons with the following conditions shall be cautioned not to operate: Those with heart conditions:Persons with head, back, or neck ailments, or prior surgeries tothose areas of the body.
-
Page 19: Cleaning And Storage
Cleaning and Storage If there are stains on the surface of the scooter, use a soft cloth to dip in a small amount of water to wipe; If there are stains that are difficult to clean, smear them with toothpaste and brush them repeatedly, then clean them with a damp cloth. -
Page 20: Battery Maintenance
Battery Maintenance ● Do not use battery packs of other models or brands, or else there may be safety risks. It is strictly forbidden to disassemble, squeeze, or puncture this product; it is forbidden to throw this product into water, fire(including heat sources such as stove, heater, etc.) or expose it toan environment with a temperature higher than 50°C. -
Page 21: Environmental Protection
cool and dry place, and fully charge it every 30 days.or else the battery may be damaged and such damage is not covered by the warranty. ● lmproper disposal of used batteries may seriously pollute the environment. Please abide by local regulations when disposing of the battery pack. -
Page 22: Limited Warranty Statement
5. All accessories originally included with your purchase must be included with your return. 6. If you return a product to MEGAWHEELS (a) without an RMA from MEGAWHEELS(b) without all parts included in the original package, MEGAWHEELS retains the right to refuse delivery of such return. - Page 23 To obtain warranty service, you must deliver the product, in either its original packaging or packaging providing an equal degree of protection, to the address specified by MEGAWHEELS. In accordance with applicable law, MEGAWHEELS may require the customer to furnish proof of purchase details and/or comply with registration requirements before receiving warranty service.period or thirty (30) days, whichever is...
-
Page 24: Question & Answer
Question & Answer 1. What if the E-Scooter arrived missing accessory or broken part? A: Please take a photo and send it to MEGAWHEELS Support Team by sending an email: m scooter@hotmail.com And MEGAWHEELS Support Team will reply to you soon and send the correct accessory or part replacement. - Page 25 The statements should be displayed in the user manual: changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
