imarflex IRC-800E Instruction Manual

SPECIFICATION:
MODEL NO. :
RATED VOLTAGE :
POWER CONSUMPTION :
BOX DIMENSION :
UNIT DIMENSION :
GROSS WEIGHT :
UNIT WEIGHT :
IMPORTANT SAFEGUARD:
1. Read all instructions carefully.
2. Before using the unit, check if the voltage indicated corresponds with the
convenience outlet (230Va.c.).
3. Do not use two-way socket with another appliance.
4. Do not use any appliance with a damaged cord or plug. If the cord is damage
it should be replaced with the same type and size or bring the unit to the
nearest authorized service center.
5. Do not place the unit near a gas stove, an electric burner, in a heated oven.
6. Place the unit on a stable surface; keep it away from the edge of the counter
to avoid accidents.
7. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning the use of the appliances by a person responsible for their safety.
8. Children should be supervised to ensure that they do not play with the
appliance.
9. Extreme caution must be exercised when using an appliance containing hot
water in the rice cooker when boiling.
10. Do not allow the cord to touch the hot surface of the unit.
11. For protection against electric shock, do not immerse the unit including the
power base in water or any other liquid.
12. Always ensure that the lid is closed and do not lift it while the water in the
multi-cooker is boiling. Scalding may occur if the lid is removed during the
cooking cycle. Do not touch the hot surfaces of the rice cooker.
13. Allow the unit to cool down before cleaning.
14. Not intended for outdoor use.
15. No parts are dishwasher safe.
16. Do not cook food below the recommended minimum level (25 cups) or above
the maximum level (45 cups). Boiling water may come out of the rice cooker.
17. Carry or move the multi-cooker only by its handle.
18. In case of malfunction, please bring the rice cooker to the nearest Authorized
Imarflex Service Center.
19. Avoid water spillage into the socket, connector, cord and alike.
20. Rice cooker body may get very hot, be careful when handling.
21. Use of accessories or equipment not supplied by the manufacturer may
cause damage or malfunctioning of your appliance or result in injuries.
22. For household use only, not intended for any business purposes.
23. Do not use this unit other than its intended use.
24. CAUTION: In order to avoid a hazard due to inadvertent resetting of the
thermal cutout, this appliance must not be supplied through an external
switching device, such as a timer, or connected to a circuit that is regularly
switched on and off by the utility.
IRC-800E
230Va.c. 60Hz
2500W
________________
________________
________________
________________
DESCRIPTION OF PARTS:
HOW TO USE:
I - RICE COOKING
1. Put the rice into the inner pot, measure the desired amount of rice using the
measuring cup supplied with the unit.
2. Wash the rice several times until the water is relatively clear.
3. Measure water on rice for cooking.

One cup of rice measures 0.18L (180ml)

Use water line inside the pot as a cooking guide. The right line corresponds to
the cup capacity of the uncooked rice, the left line corresponds to the liter
capacity of the water

The water line on the inner pot cannot be used for cooking congee, you can
add more or less water depending on your taste or preference

Do not cook food below the recommended minimum level (25 cups) or above
the maximum level (45 cups). Boiling water may come out of the rice cooker
4. Wipe the bottom part of the inner pot and put it inside the unit, turn it slightly from
left to right to ensure that the pot is properly fit into the heater plate, and then level
the rice.

Do not heat the inner pot on the top of the stove, otherwise, it will be deformed
by the high temperature. Use only the pot supplied with the unit.
Plug the unit into the convenience outlet when you're ready to cook rice.
5.
6. Press down the switch. Cook light indicator will lights up and rice will start to cook.

If the switch knob failed to push down, the "warm" light will light up, the rice will
not be cooked
When it's done, the switch will pop-up and a click sound will be heard, and the
7.
warm light indicator will light up.

After the cooking cycle, keep the cover closed for about 10 minutes to make
the rice fluffier
8. Use only the spatula supplied with the unit to avoid scratches.
9. Unplug the unit after every use.
II – FOOD WARMING
1. Place food inside inner pot or leave cooked rice in the inner pot.
Leave the unit in "warm" position.
2.
CLEANING AND MAINTENANCE:
1. Always unplug the unit before cleaning. Make sure that the unit temperature
cools down before cleaning. Do not clean when it is still hot.
2. To protect from electrical hazards, do not immerse the unit and electric cord
in water.
