ring RX PS1 Owner's Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
HOME GYM
OWNER'S MANUAL / ENG
RX PS1

Advertisement

loading
Need help?

Need help?

Do you have a question about the RX PS1 and is the answer not in the manual?

Questions and answers

Summary of Contents for ring RX PS1

  • Page 1 HOME GYM OWNER'S MANUAL / ENG RX PS1...

  • Page 2: Part List

    HOME GYM / ENG PART LIST...
  • Page 3 HOME GYM / ENG PART LIST...
  • Page 4 HOME GYM / ENG PART LIST NUMBER DESCRIPTION QUANTITY MAIN BASE BACK BASE LEFT&RIGHT BASE MAIN VERTICLE BEAM TOP CROSS BEAM RESIST BAR SEAT SUPPORT (A) PRESS BAR RIGHT CHEST SUPPORT LEFT CHEST SUPPORT LEG EXTENSION WEIGHT PLATE TOP PLATE LAP BOW PULL BOW FLOATING PULLEY BLOCK(A)
  • Page 5 HOME GYM / ENG PART LIST NUMBER DESCRIPTION QUANTITY BACK SEAT (630*300) SEAT (310*300) FOAM ROLLER φ45*φ80*250 FOAM ROLLER φ23*φ70*140 CHAIN φ6 CABLE(MIDDLE) CABLE(DOWN) CABLE(UP) PIN φ19*80 HOOK φ7 SCREW M12*160 + TWO WASHERS + LOCK NUT LOCK LEVER TUS SCREW M12*70 + WASHER SCREW M12*25 + BIG WASHER SCREW M10*75 + TWO WASHERS + NUT...
  • Page 6 HOME GYM / ENG ASSEMBLY INSTRUCTIONS 1. Check that the pin holes are all facing the same way. side all the plastic weight stack plates (l) over the weight guide rods (s) one by one. 2. Fit weight selict shaft (t) to weight stack top plate with top plate fix donut. tighten with top plate fix pin.
  • Page 7 HOME GYM / ENG STEP 01 1. Attach right&left bese (c) to main base (a) with two screws m10*75 and four washeres and two nuts (15) as shown. 2. Attach main verticle beam (d) to main base (a) with two screws m10*70 and four washeres and two nuts (17) as shown.
  • Page 8 HOME GYM / ENG STEP 02 1. Attach top cross beam (e) to main verticle beam (d) with two screws m10*70 and four washeres and two nuts (17) as shown. 2. Attach resist bar (f) to main verticle beam (d) with two screws m10*70 and four washeres and two nuts (17) as shown.
  • Page 9 HOME GYM / ENG STEP 03 1. Attach seat support (g) to main verticle base beam (d) with two screws m10*70 and four washers and two nuts (17) as shown. 2. Attach leg extension (k) to seat support (g) with the screw m10*75 and two washers and lock nut (16) as shown.
  • Page 10 HOME GYM / ENG STEP 04 1. Attach press bar (h) to top cross beam (e) with screw m12*160 and two washers and two lock nuts (11) as shown. 2. Attach hand grip (v) to chest support (i&j) with screw m12*25 and big washer (14) as shown.
  • Page 11 HOME GYM / ENG CABLE ASSEMBLY 1. START WITH THE UP CABLE (8) Start by threading the end of the cable without the ball,over pulley no.1, over pulley no.2, down and around pulley no.3 in floating pulley block (q), up and over pulley no.4 and down and attach to weight stack with screw m10*35 and lock nut (18) as shown.
  • Page 12 FITNES CENTAR – GLADIJATOR KORISNIČKO UPUTSTVO / SRB RX PS1...
  • Page 13 FITNES CENTAR – GLADIJATOR / SRB SPISAK DELOVA...
  • Page 14 FITNES CENTAR – GLADIJATOR / SRB SPISAK DELOVA...
  • Page 15 FITNES CENTAR – GLADIJATOR / SRB SPISAK DELOVA OPIS GLAVNA OSNOVA POZADINSKA BAZA LEVA & DESNA BAZA GL. VERT. GREDA GORNJI PRESEČNA GREDA OTPORNA ŠIPKA POTPORA SEDIŠTA (A) ŠIPKA ZA PRITISAK DESNA GRUDNA POTPORA LEVA GRUDNA POTPOR PRODUŽETAK ZA NOGE PLOČA ZA SELEKTOVANU TEŽINU GORNJA PLOČA LUK ZA KRILO...
  • Page 16 FITNES CENTAR – GLADIJATOR / SRB SPISAK DELOVA OPIS SEDIŠTE (630*300) SEDIŠTE (310*300) PENASTI KOTUR Φ45*Φ80*250 PENASTI KOTUR Φ23*Φ70*140 LANAC Φ 6 KABL (SREDNJI) KABL (DONJI) KABL (GORNJI) OSIGURAČ Φ 19* 80 KUKA φ7 VIJAK M12*160 PLUS DVA PODLOŠKA PLUS NAVRTKE KONTRA POLUGA OSIGURAČ...
  • Page 17 FITNES CENTAR – GLADIJATOR / SRB UPUTSTVO ZA SKLAPANJE 1. Proverite da li su rupe osigurača na istoj strani. Poravnajte sve ploče grupe tegova (l) preko štapova za pozicioniranje tegova (s) jednu po jednu. 2. Montirajte dršku za odabir težine (t) na gornju ploču grupe tegova sa fiks. prstenom gornje ploče, pričvrstite sa fiks.
  • Page 18 FITNES CENTAR – GLADIJATOR / SRB KORAK 01 1. Pričvrstite desnu i levu bazu (c) za glavnu bazu (a) sa dva vijka m10*75 i četri podloške i dve navrtke (15) kao na slici. 2. Pričvrstite glavnu vertikalnu gredu (d) za glavnu bazu (a) sa dva vijka m10*70 i četri podloške i dve navrtke (17) kao na slici.
  • Page 19 FITNES CENTAR – GLADIJATOR / SRB KORAK 02 1. Pričvrstite gornju presečnu gredu (e) za glavnu vertikalnu gredu (d) sa dva vijka m10*70 i četri podloške i dve navrtke (17) kao što je prikazano. 2. Pričvrstite otpornu šipku (f) za glavnu vertikalu (d) sa dva vijka m10*70 i četri podloške i dve navrtke (17) kao na slici.
  • Page 20 FITNES CENTAR – GLADIJATOR / SRB KORAK 03 1. Pričvrstite potporu za sedište (g) za osnovu glavne vertikale (d) sa dva vijka m10*70, četri podloške i dve navrtke (17) kao na slici. 2. Pričvrstite produžetak za noge (k) za potporu sedišta (g) sa zavrtnjem m10*75 i dve podloške i kontra navrtkom (16) kao na slici.
  • Page 21 FITNES CENTAR – GLADIJATOR / SRB KORAK 04 1. Pričvrstite šipku za pritisak (h) za gornju presečnu gredu (e) sa vijkom m12*60 i dve podloške i dve kontra navrtke (11) kao što je prikazano. 2. Pričvrstite ručni držač (v) za grudnu potporu (i & j) sa vijkom m12*25 i velikom podloš kom (14) kao što je prikazano.
