Summary of Contents for Brise Audio FUGAKU
- Page 1 UM003 REV1.1 https://briseaudio.com OCT 2024 Brise Audio Ultimate Portable Audio System User Manual English version...
-
Page 2: Table Of Contents
UM003 REV1.1 https://briseaudio.com OCT 2024 1. Introduction ....................2 1.1 For your safety ..................2 1.2 Included Items ..................3 1.3 Precautions for use (*Please be sure to read) ......4 1.4 Product Concept .................7 2. How to use ....................9 2.1 Names and Functions of Parts ............9 2.2 Setting the output level on the player side ....... -
Page 3: Introduction
We hope that you will read 1.Introduction and 2.How to use before using this product. 1.1 For your safety Brise Audio products are designed with due consideration for safety. However, all electrical products are dangerous and can cause fire or electric shock resulting in personal injury if used incorrectly. To prevent accidents, please observe the following precautions ✓If it breaks down, don't use it. -
Page 4: Included Items
UM003 REV1.1 https://briseaudio.com OCT 2024 1.2 Included Items ①Dedicated earphones ②Dedicated amplifier ③Dedicated cable ④1 pair each of 6 sizes of dedicated earpieces (Sedna Earfit XELASTEC II) ⑤Dedicated earphone case (ultra-suede) ⑥Storage bag ⑦AC adapter for charging (5V USB) ⑧USB charging cable (USB Type-A to USB Type-C) ⑨Serial number card ⑩Warranty... -
Page 5: Precautions For Use (*Please Be Sure To Read)
Doing so may damage the amplifier on the balanced output side of the player and cause it to malfunction. ✓The output terminal is for FUGAKU earphones only. Do not connect to other devices. Also, before each set is shipped, the earphones and the dedicated amplifier are paired so that their characteristics are matched. - Page 6 UM003 REV1.1 https://briseaudio.com OCT 2024 ✓If the earpiece comes off and remains in the ear during use, seek medical attention immediately. Do not attempt to remove the earpiece by yourself as it may cause damage to your ear. ✓Discontinue use if you notice anything unusual in your ears or skin that is in direct contact with the earphones or cables ✓Be careful not to turn up the volume of the audio equipment to which the earphones are connected too loud.
- Page 7 UM003 REV1.1 https://briseaudio.com OCT 2024 Points to note when making balanced connections between players and amplifiers Be sure to make GND connections. Failure to make GND connections will result in failure of the amplifier and earphones in the worst case. Be sure to use a balanced mini-mini cable with a 5-wire GND connection.
-
Page 8: Product Concept
OCT 2024 1.4 Product Concept The start of FUGAKU was the "ultimate earphones" that only Bliss Audio could make. The concept was that if we were going to go to the trouble of making a product, we wanted to achieve the quality we most wanted, and we wanted to create a configuration that was not bound by existing frameworks, with sound quality as the top priority. - Page 9 UM003 REV1.1 https://briseaudio.com OCT 2024 The sound quality, which is directly driven by multiple types of drivers with appropriate use, excellent physical characteristics due to optimal structural design, high-performance bandwidth-division circuits, and multiple high-output power amplifiers, overturned our common sense and left a strong impact never experienced before.
-
Page 10: How To Use
UM003 REV1.1 https://briseaudio.com OCT 2024 2. How to use 2.1 Names and Functions of Parts Earphone ① ② Left side Right side ① Ear hanger...made of TPE with memory wire. The fit can be adjusted by bending by hand. Bending it abruptly may cause the wire inside to pop out, so please bend it little by little. - Page 11 UM003 REV1.1 https://briseaudio.com OCT 2024 Dedicated amplifier Front ⑦ ⑥ ⑤ ④ ② ③ ① Rear ⑧ ①Power switch and volume knob...Push the knob in for about 3 seconds or more to turn the power on and off. The microcontroller detects the position of the volume and commands the electronic volume IC to set the attenuation rate.
- Page 12 UM003 REV1.1 https://briseaudio.com OCT 2024 ③5-pole 4.4mmm balanced input (GND connection)...Connect balanced output player. ④Charging status LED...Lights up when charging is in progress. It turns off when charging is completed. When it blinks, a charging error has occurred. →Please refer to 3. Troubleshooting for details. ⑤Battery level LED: 1 blinking (less than 20%), 1 lit (20% to 40%), 2 lights on (40% to less than 60%), 3 lights on (60% to 80%), and 4 lights on (80% to 100%).
-
Page 13: Setting The Output Level On The Player Side
UM003 REV1.1 https://briseaudio.com OCT 2024 DC offset detection function...When DC offset is detected, the amplifier is Shutdown and protect earphones. Overcurrent detection function...shuts down the amplifier when an overcurrent is detected. Overheat protection function...shuts down the battery if the internal temperature exceeds 60°C. -
Page 14: Use While Charging
UM003 REV1.1 https://briseaudio.com OCT 2024 2.3 Use while charging You can also use it while charging without worrying about the remaining battery level. However, there is a condition that the remaining battery charge must be less than 75%. This is because using a fully charged battery while charging accelerates the deterioration of the battery. -
Page 15: Led Behavior When Charging
UM003 REV1.1 https://briseaudio.com OCT 2024 2.4 LED behavior when charging When charging, there are six modes, each with a different LED indication. Transitions sequentially from mode ① to mode ⑥ as it approaches full charge. It is only a mode status and does not indicate the exact percentage of charge. -
Page 16: Troubleshooting
UM003 REV1.1 https://briseaudio.com OCT 2024 Troubleshooting If the following troubleshooting does not resolve the problem, please contact us. 3.1 No sound ✓Turn up the volume of the unit and player. ✓Connect the cable to the unit firmly and check that it is inserted all the way to the back. -
Page 17: Sound Distortion
UM003 REV1.1 https://briseaudio.com OCT 2024 ✓If none of the above apply, or in the case of ②, ③, ④, ⑤, and ⑥, there is a suspicion of a malfunction. In case of ②, there is a possibility of overcurrent due to excessive volume. 3.2 Sound distortion ✓The signal level input to the amplifier may be too high. - Page 18 UM003 REV1.1 https://briseaudio.com OCT 2024 earphones attached. Doing so may result in malfunction or hearing damage. ✓If you are connecting to a player that has the ability to shut down its output after a certain period of inactivity, the shutdown state is equivalent to having the cable disconnected.
-
Page 19: Charging Led Does Not Light Up Or Blinks
UM003 REV1.1 https://briseaudio.com OCT 2024 3.4 Charging LED does not light up or blinks ✓When charging when the power is turned on, the battery cannot be charged unless the remaining charge is less than 75% to reduce battery degradation. ✓USB cable may be disconnected. Please try another cable. ✓The battery may be faulty. -
Page 20: Specifications
UM003 REV1.1 https://briseaudio.com OCT 2024 Specifications Earphone Driver configuration Hybrid 8-driver 5-way Super high frequency : xMEMS MEMS speaker x1 High frequency : Knowles balanced armature drivers x2 Midrange : Knowles balanced armature drivers x2 Low midrange : Sonion balanced armature driver x1 Low-frequency : 8mm LCP diaphragm dynamic drivers x2 Pure titanium (PVD black coating) Housing material... - Page 21 UM003 REV1.1 https://briseaudio.com OCT 2024 Dedicated cable 16 wire (8 wire per side) Number of core wires 1 ： Super high frequency 2 ： High frequency 3 ： Midrange 4 ： Low midrange 5 ： Low frequency Hot 6 ： Low frequency Cold 7 ：...
-
Page 22: Disclaimer
UM003 REV1.1 https://briseaudio.com OCT 2024 5. Disclaimer The manufacturer, importer, or distributor shall not be liable for any damage, including injury or accident, or any other defect resulting from improper use and operation of this product, except to the extent that liability is authorized by law. -
Page 23: Product Warranty And Contact Information
Warranty is governed by the enclosed warranty card. No compensation beyond the product price will be provided. We will not compensate more than the price of the product. 6.2 Contact Information Brise Audio Co., Ltd. 135-5, Yorokubu, Tamamura-machi, Sawa-gun, Gunma 370-1134 Inquiry Form https://briseaudio.com/en/pages/inquiry Repair Acceptance Form https://briseaudio.jp/en/pagesrepair...
