- Page 1 P e r f o r m a n c e , D e l i v e r e d . Smart Entrance Door Lock Made in China/Fabriqué en Chine Lotus Tool Group (Philippines) www.lotustools.ph Lotus ® Tool Group Lotus ®...
-
Page 2: Product Parameters
84.2° field Angle, focusing distance 50cm(35.5-84.7 cm), <1.5% distortion rate Quick unlock time ≤1.5 seconds Face recognition distance 0.3~1 m Operating temperature -10℃ to 60℃ Relative humidity 45% ~ 90% 1.2 Proudct Drawing 65.5 Mortise Fingerprint Square tongue Square tongue Square tongue Square tongue Lotus Tool Group ®... -
Page 3: Product List
1.Battery cover 2.Rear panel (with waterproof rubber pad) 6.#6068 mortise 3.Front panel (with waterproof rubber pad) 7.M5x10 Screws (8 PCS) 4.Hollow studs (2, choose according to door thickness) 8.Cylinder 5.Lithium Battery (1 piece) 9.Cylinder fixing screws Lotus Tool Group ®... -
Page 4: Installation Order
1, The waterproof rubber pad is set on the front lock body, and the two hollow studs are locked on the front lock body 2. Thread the connecting wire of the front panel through the hole in the door, and then close the front panel to the door. Lotus Tool Group ®... - Page 5 3. Insert the mechanical key into the lock hole of the front plate, turn the key accordingly to check whether the mechanical key can open the door normally. 4.Test the function of the door lock after setting the door lock according to the door lock operation guide. Lotus Tool Group ®...
-
Page 6: Restore Factory Settings
When the battery has no power, use 5V power bank +Type C USB cable and connect the Type C USB port of the external emergency power supply to unlock normally, or use the mechanical key to unlock. Mechanical key USB port Lotus Tool Group ®... - Page 7 APP Usage instructions 4.1 Door lock function operation extension map X61 intelligent door lock operation map 1.Add face/palm 2.Add Finger 1.Add user 3.Add Password 4.Add Card Enter the number to delete 2.Delete user 1. Double Verify- Enable/Disabled 2. Anti Attack Alarming -Enable/Disabled 1.Function settings...
-
Page 8: Function And Operation
Verify Please enter a new 1. Local settings ID：001 administrator administrator 2. Wireless settings Add successfully password password 3. Motor settings After entering the menu, voice broadcast: "1. Local settings 2. Wireless settings 3. Motor settings" Lotus Tool Group ®... -
Page 9: Function Setting
1 or key 2 as prompted to adjust, and the volume will increase or decrease accordingly. Press the "#" key to play the voice repeatedly. 1.High Volume 1. Function setting 2.Middle Volume 2. Volume 3.Low Volume 3. Language 4.Mute 4. More Settings Voice broadcasts: "1.High Volume 2.Middle Volume 3.Low Volume 4.Mute" Lotus Tool Group ®... -
Page 10: Time Setting
Note: The ID is automatically added in sequence, and the password contains 6 to 12 digits. There are total 9 administrator users including the 1st admin passoword. Number 1 is the management password entered for the first time. Lotus Tool Group ®... -
Page 11: Motor Settings
Select 3 to set up unlock time, it's used to set up the period of the lock keeps unlocking, the default unlock time is 3s, press 3 again to increase 1S, it recycles from 3s to 9s. Lotus Tool Group... -
Page 12: Other Instructions
◆Press 99# to display the current time of the voice broadcast. ◆In the initial state, press "888#" to quickly enter the installation and setting menu, compatible with the operation mode of the old version, convenient to adjust the motor direction. Lotus Tool Group ®... -
Page 13: App Download
You can also select Try as Guest to use a trial version, but some function is not allowed to use. If you already have an account, log in by mobile phone number / email address and password. “ ” Lotus Tool Group ®... - Page 14 Select the lock type you need, enter the distribution mode, and turn on Bluetooth to search for the required device. After discovering the device, click Add, enter the WIFI you want to connect, and then wait for the connection to succeed. Lotus Tool Group ®...
- Page 15 Compared with the passive intercom, the local log has an additional album. You can find unlock records, alarm records, photos and videos in the album/journal. Videos and pictures are saved locally, and can be saved on the Tuya APP for money. Lotus Tool Group ®...
- Page 16 (See ①) ④ Member management 1. Here you can see what has been recorded and how many there are. You can press + to add a member, either a common user or an administrator. Lotus Tool Group ®...
- Page 17 Cell phone ⑤ Temporary password Tuya APP can set a temporary password, there are several temporary passwords can be set. 1. Time-limited password 2. Single password 3. Dynamic password 4. Clear the password 5. Customize the password Lotus Tool Group ®...
- Page 18 ⑥ Settings 1. Camera You can set the intercom mode 2. Other Settings Lotus Tool Group ®...
- Page 19 Screen quenching time Video viewing Version number Lotus Tool Group ®...
