Prunus J-160BT Manual

Thank you for purchasing the PRUNUS J-160BT radio/Bluetooth speaker/mp3 player. In order
to get the best from the radio please read this manual carefully before using it and take special
notice of the section on maintenance.
Maintenance
◆Don't let the radio get wet and don't use it in a moist environment - keep it out of the rain and
use carefully in bathrooms and kitchens;
◆Do not place potentially damaging objects such as liquid-filled containers or lighted candle on
top of the radio. Keep the radio, and the battery pack, away from sources of heat such as radia-
tors, hot water pipes or fires. Do not leave it in full sunlight;
◆Make sure that solvents, such as white spirit, paraffin or petrol and not spilt onto the radio;
◆Keep it away from magnets and magnetic fields;
◆Position the radio so that air can circulate around it – leave a space of 5 to 10 cm in front of and
behind the radio;
◆Do not cover the radio with cloth or paper and avoid placing it on a bed where it might be
covered by a blanket or duvet;
◆The radio is a sophisticated electronic device - do not attempt to disassemble it or repair it and
take care not to drop it.
Functional Components
(*This unit has no headphone jack)
1.Volume / power knob
2.Band switch
3.Power/Bluetooth indicator
4.Forward
5.Previous
6.Play/Pause/Mode button
7.Flash Drive Slot
8.TF card slot
9.AUX in jack
10.DC5V power slot
11.Charging Indication
12.Speaker
13.Tuning knob
14.Telescopic aerial
Power Supply
1.Charging method : Plug the big end into the USB jack of your computer or USB power adapter,
and plug the small end into the DC5V charging jack of the unit;
2.Charging indicator :
Charging time is 3 to 5 hours and <11. Charge indication> will turn OFF when
charging is complete. (Note: It can be charged with computer or powerbank. If an adapter is import-
ant for you, please send message "PRUNUS Charger" to E-mail: wanwanus@outlook.com (reply in
1 working day), to get PRUNUS quality charger with indicator in 60% discount.)
Please Note:
◆Please use standard DC5V/500-1000Mah charger (or other devices can supply this type of power)
to charge it, or it may damage the radio;
◆In order to make sure the battery has longer using life, you'd better reduce the long continuous
charging, such as 24 hours charging or more.
EN
Radio reception
1. Turn the <2. band switch> to the "FM", "AM" or "SW" position
2. Turn the <1. volume/power knob> to the power-on position.
3. Rotate the <13. tuning knob> to select the station you want to listen to.
4. Turn the <1. volume/power knob> again to adjust the volume.
◆When searching for the FM/AM/SW channels, please extend and rotate the <14. telescopic
aerial> and adjust the position of the radio for the best reception.
◆In order to get better reception, when using the radio indoors, please approach it to the window
and do your best to keep it away from the electronic devices (such as computers, TVs, refrigera-
tors, mobile phones, etc).
Music Playing
1.Play by Bluetooth
(1) Rotate the <2. band switch> to "music" mode, the radio will give a "Bluetooth Mode" sound,
and <3. power/ Bluetooth indicator> starts flashing fast, which implies the Bluetooth connection
is available and ready pair;
(2) Switch on the Bluetooth on your services, such as: mobile phone, iPod, computer, etc., search
for the device named "BT-888", and then connect it, the radio should have a "Dingdong" sound,
and the <3. power/ Bluetooth indicator > be on, which means the device has been connected
successfully.
(3) Open your music player app/software and choose your desired music. When it is in playing
mode, the <3. power/Bluetooth indicator > will be flashing slowly;
(4) Short press <4. Forward /5. previous> to select the song you want to play;
(5) Short press <6. Play/Pause/Mode button > to pause the current play, press this button again to
resume playback.
2. Play by Flash Drive/ TF card
(1) Rotate the <2. band switch> to "music" mode;
(2) Insert the Flash Drive/TF card loaded with MP3 format into the <7.Flash drive slot / 8.TF card
slot >. Once mp3 files are detected, it will play automatically;
(3) Short press the <4. forward/5. previous> button to select the song you want to play;
(4) When playing mp3 tracks pressing the <6. Play/Pause/Mode button> will pause playing the
current track; pressing this button again will resume playing this track.
3. Play by AUX
(1) Rotate the <2. band switch> to "music" mode, long press <6. Play/Pause/Mode button> to
switch the radio mode to AUX mode, then the radio will give a "AUX mode" sound;
(2) Insert one end of the AUX cable into the "AUX" jack of the radio, and insert the other end into
the earphone jack of the mobile phone or computer, and then open the music software/app to
play music;
(3) Short press <6. Play/Pause/Mode button> to mute the radio (!), press it again to resume the
sound.
After Sale Service
If the radio fails, please scan this QR code, click "Ask a
quastion"and log into Amazon to contact us, we will
provide you the best service:
You can also send your messages to our customer service
e-mail: prunus-technik@hotmail.com
