- Page 1 EV-NETCARD-1G Accessories User Guide minutemanups.com | 800.238.7272...
-
Page 3: Table Of Contents
Table of Contents Introduction …………………………………… 1 Installation …………………………………….. 2 Configuration…………………………………. 5 Warranty ……………………………………….. 8 Additional Notes ……………………………. 10 Life Support Policy………………………….. 11 minutemanups.com | 800.238.7272... -
Page 4: Introduction
Introduction Thank you for purchasing this Minuteman power protection product. It has been designed and manufactured to provide many years of trouble-free service. IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS! CONSIGNES DE SÉCURITÉ IMPORTANTES SAUVEGARDEZ CES CONSIGNES! Please read this manual and comply with all warnings and instructions before installing your accessory sensor as it provides important information that should be followed during installation and maintenance of the device, allowing you to... -
Page 5: Installation
The Envision Series accessories can detect variations in environmental conditions including: Temperature, Humidity, Water presence, Smoke and Unauthorized Access. When an event occurs to any of the active and connected sensors, the audible alarm on the EV-PROBE-TH will automatically sound. The EV-PROBE-TH can also be configured to simultaneously send an alarm from the sensors to the EV-NETCARD-1G card. - Page 6 Water Sensor Temperature/Humidity Sensor Audible Alarm RF Transceiver USB (Type A) Connection RFID Switch Setting DIPs Alarm LED Power LED DC Input (Optional) 10) Reset minutemanups.com | 800.238.7272...
- Page 7 When connected to the EV-NETCARD-1G follow the instructions below: EV-PROBE-TH Settings Login to the EV-NETCARD-1G webpage. Under Configuration > EV-PROBE-TH, Select “Active” from the drop-down menu to activate the probe, then click on “Apply”. EV-PROBE-TH Alarm Notification The EV-PROBE-TH and Alarm Status can be monitored under Information >...
-
Page 8: Configuration
Configuration EV-PROBE-SMOKE Settings Each sensor has 2 sets of identifiers that need to be configured: (2) RFID and (4) Sensor ID. These identifiers can be configured by adjusting the jumpers on each sensor. Twist off the cover (1) of the EV-PROBE-SMOKE sensor. −... - Page 9 EV-PROBE-CONTACT Settings Each sensor has 2 sets of identifiers that need to be configured: (1) RFID and (2) Sensor ID. These identifiers can be configured by adjusting the jumpers on each sensor. Remove the back cover (1) of the EV-PROBE-CONTACT sensor. −...
- Page 10 Sensor ID Table Sensor Type ID (Binary) Envision Webpage Display Smoke 0101 (Default) Smoke Status Door/Window 1000 Security Status 1 Door/Window 1001 Security Status 2 Door/Window 1010 Security Status 3 Door/Window 1011 Security Status 4 Door/Window 1100 Security Status 5 Door/Window 1101 Security Status 6...
-
Page 11: Warranty
If a warranty claim is required, the customer pays for shipping the product to Para Systems. Para Systems pays ground freight to ship the product back to the customer. Replacement parts and warranty labor will be borne by Para Systems. - Page 12 800.238.7272 or by e-mail at: support@minutemanups.com. Be ready to provide the information above, along with a description of the problem and Para Systems will provide instructions on how to return the unit for service, if necessary. minutemanups.com | 800.238.7272...
-
Page 13: Additional Notes
Additional Notices: NOTICE: This product complies with the rules for Class B device, pursuant to Part 15 of the FCC rules for radio noise emissions from a digital apparatus. These limits are designed to provide reasonable protection against such interference in a residential installation. This equipment generates and uses radio frequency and if not installed and used properly, in strict accordance with the manufacturer's instructions, may cause interference to radio... -
Page 14: Life Support Policy
Life Support Policy Para Systems does not support the use of any of its products in life support applications where the failure or malfunction of the product can be reasonably expected to cause failure to life support devices or to significantly affect their safety or effectiveness. - Page 15 Para Systems, Inc. 1455 LeMay Drive Carrollton, TX 75007 800.238.7272 www.minutemanups.com 34000576 RevA 202411 minutemanups.com | 800.238.7272...
