Page 1
InStreamer AN: 500032 Quick Installation Guide Technical Data Sources 1x Line-in (3.5mm jack) 1x S/PDIF Optical USB A socket for ash drive Bluetooth Audio Network connections Ethernet WLAN (2.4GHz) Power supply 5V/1A USB-C (not included) Weight 0.17 kg (net) V202407 - Errors and speci cations subject to change without notice.
Page 2
Connect power supply and ethernet network. Connect power supply and ethernet network. Connect power supply and ethernet network. Navigate to the web con guration of your trivum sound system and select „Expand your s 2. Con guration 2. Con guration 2.
Page 3
Select the Instreamer to con gure Select the Instreamer to con gure On the following screen, you can change the device name, update its rmware and adjust the input On the following screen, you can change the device name, update its rmware and adjust the input...
Page 4
WLAN Antenna WLAN/BT InStreamer Ethernet Dig-In Line-In Power Reset Optical-in Network 5V/1A Flash drive Line-in Required components for installation: • USB power supply ≥1A Ethernet cable connected to router or Wi access point trivum sound system (e.g. Rp311v2 or SC344m)
