Ducati 6203 ROL Programming Manual

6203 ROL
D U C O r o l l i n g c o d e
English
DUCATI RADIO ROLLING CODE
REMOTE CONTROLS Models:
6203ROL & 6203 / P = 2-channels radio remote
control 433,96Mhz 6204 & 6206 = 4-channels
radio remote controls 433,96Mhz
Caution: Operate settings with gate in closed position.
A) To memorize a remote control code in the
control board of your automation: 1 - Press the P1
button on the electronic board
- release the button P1
2
- Press on the remote control, the button corresponding to the channel that you want
3
to synchronize with the drive (you may need to hold the button for several seconds or even re-
press it several times until the automation recognizes and stores the remote control code).
After saving the code, theelectronic board should
issue a confirmation light (red LED). The remote control
has been programmed correctly.
Warning: Verify all the procedure with the manual of your automation because every
model of electronic board may have variants or specific functions.
- To operate the automation, press the button on the remote control previously
4
synchronized.
Attention: Electronic boards of automation have a limited memory capacity. (If you need
more memory available is a 4-channel external receiver model
Programming Manual
H O M E
automation
6203/P ROL
http://www.remotecontrol-express.com
DUCATI
6204 6206
