OPERATING INSTRUCTIONS
1. Attach a suitable nozzle to the inflation or deflation connector if necessary and hold pump against
inflation valve on item to be inflated or deflated. See Fig (1).
2. Plug the small end of the USB cable into the USB socket under the pump. See Fig (2).
INFLATION
OR
3. Connect the other end of the USB cable to one of the following external power adapters (not included):
• USB Wall Charger rated 5V
• Portable USB Charger rated 5V
• 12V Car Charger rated 5V
• USB Port rated 5V
USB Wall Charger
FIG (3)
4. Press the switch (5) to turn on, press the switch again to turn it off. See Fig (2).
STORAGE INSTRUCTIONS
Make sure the USB cable is free of twist, kink and knot. Fold the USB cable loosely, and return pump, USB cable
and nozzles to package when not in use.
SAVE THESE INSTRUCTIONS
(56IO) AP616 MINI USB PUMP ENGLISH 3.75" X 3.75" 05/29/2023
FIG (1)
/ 2A or more. See Fig (3).
/ 2A or more. See Fig (4).
/ 2A or more. See Fig (5).
/ 2A or more. See Fig (6).
Portable USB Charger
FIG (4)
Page 3
DEFLATION
OR
12V Car Charger
FIG (5)
56
IO
5
FIG (2)
5V/2A USB Port
FIG (6)
