- Page 1 Uninterruptible Power Supply-Battery User Guide DP-MU2100...
-
Page 2: Before Reading This Manual
• First-time users of Uninterruptible Power Supply-Battery should seek technical assistance from their retailer regarding product installation and use. • Before disassembling the product for functional expansion or repair purposes, contact IDIS Americas for assistance. • Approved for commercial use only. -
Page 3: Fcc Compliance Statement
FCC Compliance Statement THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN RADIATE RADIO FREQUENCY ENERGY AND IF NOT INSTALLED AND USED IN ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL INTERFERENCE TO RADIO COMMUNICATIONS. -
Page 4: Safety Precautions
Safety Precautions Safety Precautions Information contained in this section of the manual serve to prevent accidents and property damage through proper use of the product. Read and follow the instructions. Warning Failure to comply can lead to severe injury or even death. Installation Turn off the product before installation. -
Page 5: Product Use
Safety Precautions Power Do not bend the power cable excessively or place heavy objects on top of it. ● Presents a fire hazard. Do not pull on the power cable or handle the power plug with wet hands. Do not insert the power plug into a loose power outlet. - Page 6 Safety Precautions Failure to comply can lead to minor injury and/or product Caution damage. Installation Do not set up the product in an area that is exposed or susceptible to strong magnetism, radio waves or physical impact. Avoid setting up the product in the vicinity of wireless transmission devices such as a radio and television.
-
Page 7: Table Of Contents
Table of Contents Part 1 - Introduction Product Features Accessories Installation Installing the Uninterruptable Power Supply Installation Verification Power Connector I/O Connector Indicators and Connections Front Panel Indicators Rear Panel Connections Part 2 - Miscellaneous Troubleshooting Specifications... -
Page 8: Part 1 - Introduction
The DP-MU2100 is a short-term, backup power supply specifically designed for mobile applications. It is intended for use with video recorders. Once fully charged, the DP-MU2100 can power the video recorder and all connected cameras for up to fifteen (15) minutes during a vehicle power loss event. -
Page 9: Accessories
Accessories Upon unpackaging the product, check the contents inside to ensure that all the following accessories are included. ● Mounting Bracket (Qty 2) ● User Guide (this document) -
Page 10: Installation
Use the provided drill template to mark the spots on the mounting surface for drilling. Attach the mounting brackets to the selected location. Attach the power connector and the additional connectors (if applicable) to the DP-MU2100. If the video recorder has already been installed, unplug its power before connecting it to the UPS. -
Page 11: Installation Verification
Verify the video recorder remains running. Power Connector The Power connector links the UPS (DP-MU2100) to both the video recorder and vehicle power input. The power cable splits into two connectors; one for the vehicle power, the other connecting to the Video Recorder. -
Page 12: Indicators And Connections
Part 1 - Introduction Indicators and Connections Front Panel Indicators Indicator LED Status Description Power from ignition POWER No power from ignition Flashing Actively charging Batteries fully charged CHARGE Not actively charging Back Up Mode BACKUP Backup inactive (Has input power) Fault has occurred, see section 4.0 for troubleshooting FAULT No fault is detected... -
Page 13: Rear Panel Connections
Part 1 - Introduction Rear Panel Connections Power Connector, DTF13-12PB, TE Connectivity Name PinMap VEHICLE BATT Name Description NOT CONNECTED NC ( GROUND GND ( HEATER, BYPASS HTR( ACC( ACCESSORY BATTERY FROM BUS VEHICLE BATT( PWR( POWER TO RECORDER... - Page 14 Part 1 - Introduction I/O Connector, 43045-0600, Molex Name Description CAN(Controller Area Network) High Do not use CAN_H CAN Low Do not use CAN_L RS-232 Receive Port for NVR Communication 232-RX RS-232 Transmit Port for NVR Communication 232-TX ALARM OUT Do not use GROUND...
-
Page 15: Part 2 - Miscellaneous
Part 2 - Miscellaneous Troubleshooting The rate at which the FAULT LED flashes will indicate which error code exists. The slow-rate flashes indicate the first digit of the error code, while the fast-rate flashes indicate the second digit. For instance, if the FAULT LED flashes slowly, two (2) times, followed by three (3) fast flashes, the error code is 23. -
Page 16: Specifications
Part 2 - Miscellaneous Specifications Model DP-MU2100 Power Input 9-36V , 22A, 200W Battery Charging Voltage 10-36V Output Voltage Bypass(Normal), 24V (Emergency) Backup Output Electrical , 4.2A, 100W Maximum Properties 35mA at Knife SW ON Quiescent Current 3mA at Knife SW OFF... - Page 17 IDIS Co., Ltd. For more information, please visit at www.idisglobal.com...
