SMCBGSSCX1
SMCBGLSCX1
SMCBGZSCX1
TigerAccess™ GBIC
1000BASE-X GBIC transceiver
SMCBGLSCX1
SMCBGSSCX1
PHY type:
1000BASE-SX
•
Connector:
SC
•
Max. Range*:
220 m - 550 m
•
Wavelength:
850 nm
•
Fiber type:
MMF
•
SMCBGLSCX1
PHY type:
1000BASE-LX
•
Connector:
SC
•
Max. Range*:
550 m - 10 km
•
Wavelength:
1300 nm
•
Fiber type:
MMF/ SMF
•
SMCBGZSCX1
PHY type:
1000BASE-ZX
•
Connector:
SC
•
Max. Range*:
70 km - 100 km
•
Wavelength:
1550 nm
•
Fiber type:
SMF
•
* Depending on various factors such as fiber quality, type, core size, modal bandwidth, number of splices, and connectors.
Please refer to the product datasheet for more details.
** STP Cat-5e cabling
11 TigerAccess Transceiver
SMCBGSLCX1
SMCBGLLCX1
SMCBGZLCX1
TigerAccess™ SFP
1000BASE-X SFP transceiver
SMCBGSLCX1
SMCBGSLCX1
PHY type:
1000BASE-SX
•
Connector:
LC
•
Max. Range*:
220 m - 550 m
•
Wavelength:
850 nm
•
Fiber type:
MMF
•
SMCBGLLCX1
PHY type:
1000BASE-LX
•
Connector:
LC
•
Max. Range*:
550 m - 10 km
•
Wavelength:
1300 nm
•
Fiber type:
MMF/ SMF
•
SMCBGZLCX1
PHY type:
1000BASE-ZX
•
Connector:
LC
•
Max. Range*:
70 km
•
Wavelength:
1550 nm
•
Fiber type:
SMF
•
SMC10GXEN-T
SMC10GXEN-SR
SMC10GXEN-LR
SMC10GXEN-ER
TigerAccess™ XENPAK
10GBASE-X XENPAK transceiver
SMC10GXEN-SR
SMC10GXEN-T
PHY type:
10GBASE-T
•
Connector:
RJ-45
•
Max. Range*:
100 m**
•
Wavelength:
-
•
Fiber type:
Copper
•
SMC10GXEN-SR
PHY type:
10GBASE-SR
•
Connector:
SC
•
Max. Range*:
300 m
•
Wavelength:
850 nm
•
Fiber type:
MMF
•
SMC10GXEN-LR
PHY type:
10GBASE-LR
•
Connector:
SC
•
Max. Range*:
10 km
•
Wavelength:
1310 nm
•
Fiber type:
SMF
•
SMC10GXEN-ER
PHY type:
10GBASE-ER
•
Connector:
SC
•
Max. Range*:
10 km - 40 km
•
Wavelength:
1550 nm
•
Fiber type:
SMF
•
SMC10GXFP-SR
SMC10GXFP-LR
SMC10GXFP-ER
TigerAccess™ XFP
10GBASE-X XFP transceiver
SMC10GXFP-LR
SMC10GXFP-SR
PHY type:
10GBASE-SR
•
Connector:
LC
•
Max. Range*:
300 m
•
Wavelength:
850 nm
•
Fiber type:
MMF
•
SMC10GXFP-LR
PHY type:
10GBASE-LR
•
Connector:
LC
•
Max. Range*:
10 km
•
Wavelength:
1300 nm
•
Fiber type:
SMF
•
SMC10GXFP-ER
PHY type:
10GBASE-ER
•
Connector:
LC
•
Max. Range*:
10 km - 40 km
•
Wavelength:
1550 nm
•
Fiber type:
SMF
•
