Talkaphone AHLP-1 Installation Manual

1. Introduction
This installation guide provides instructions for installation, programming, and operation of Model
AHLP-1 when used in conjunction with VOIP-500/VOIP-600 Series IP Call Stations.
This panel allows a VOIP-500/VOIP-600 Series Call Station to transmit to a telecoil-enabled hearing
aid (i.e. bone-anchored hearing aid (BAHA) or cochlear implant via magnetic field)—providing critical
accessibility to a user with hearing loss.
It is recommended that this instruction set be read completely prior to the start of any installation.
2. Contents
Please ensure receipt of each of the included components:
QTY Part Number(s)
1 810-00120
4
1 437-00068
1 115-00052
1 840-00067
1
1 740-00005
3. Requirements
The following equipment and tools required for installation are not provided:
QTY
1
1
1
1
3
1
Page 1 of 8
Copyright 2022-2025 Talk-A-Phone, LLC • 7530 North Natchez Avenue • Niles, Illinois 60714 • Phone 773.539.1100 • info@talkaphone.com • www.talkaphone.com.
All prices and specifications are subject to change without notice. Talk-A-Phone, Talkaphone, ECO TOWER, and WEBS are registered trademarks of Talk-A-Phone, LLC. All
rights reserved. All other trademarks mentioned in this document or website are the property of their respective owners and does not imply or indicate any approval,
endorsement, sponsorship, or affiliation with such owners unless such approval, endorsement, sponsorship, or affiliation is expressly indicated.
Active Induction Hearing Loop Panel
for VOIP-500/VOIP-600 Series Call Stations
Description
AHLP-1 unit
Torx T25 screws (M5x10) for the AHLP-1 cover
Mounting gasket
6 ft. power cable assembly
6 ft. audio Y-cable assembly
Wago terminal tool
Mounting template
Description
12-24VDC power supply
Torx T25 screwdriver
3/32ʺ slotted screwdriver
5/6ʺ (8mm) nut driver
#10 mounting screws
9ʺ level
Conduit between Call Station and Wall/Surface
Mount
AHLP-1
Installation Guide
Document No. 771-00016
Rev. 2/6/2025
