InMode Morpheus8 Quick Reference Manual

Typical Treatment Parameters
• Tips – Morpheus8, Prime and T Resurfacing tips.
• Depth – 1, 2, 3, and 4mm for Morpheus8 and Prime tips. Resurfacing T tip is 0.5mm fixed depth, when the engine is
disabled, and insertion and retraction of the pins is done manually.
–
• RF Energy
Range is from 5-60. Limited range of 5-30 is for Resurfacing T tip and for 1 and 2mm depth of Morpheus8
and Prime tips. Always start with lower settings and gradually increase.
• Cycle Mode - Pins penetrate and retract from the tissue with every pulse.
-
• Fixed Mode
Pins are continuously deployed at programable depth when footswitch is activated. The pins retract back
and energy delivery terminates once the footswitch is released. It is used for stacking pulses on soft and thick skin.
• Burst Mode – Do not use Burst Mode on 12 and 24-pin Morpheus8 tips, as this will damage the handpiece
mechanically.
–
• Repetition
can be set to Single pulse mode or Repetition mode, when pulses are delivered automatically with
predetermined pulse repetition rate: In Cycle Mode – Single, 0.5 and 1pps. In Fixed Mode – 0.5, 1.0 and 1.5pps.
Pins
Tip Name
No.
Morpheus8
24
Tip
Morpheus8
24
Tip
Prime Tip 12
Prime Tip 12
Resurfacing T
24
Tip
Resurfacing T
24
Tip
*Energy levels should be as high as tolerated and according to skin response.
• Treatment may be applied to all skin types. However, when treating dark skin, reduce energy ~20%, following
optional bleaching regimen.
• Avoid treating over superficial injected areas with natural fillers (HA) for ~6months or very recent Botox
injections <1 week.
• Higher RF Energy is used for deeper treatment, and implies longer downtime and longer intervals between sessions.
• When combining depths, always work from deeper to more superficial planes.
• Use lower RF Energy for thin skin, dark skin, bony areas with thin skin.
• Resurfacing T tip can be used for the applications related to skin surface ablation and coagulation as an addition to
sub-dermal invasive or non-invasive remodeling or as a stand-alone treatment. Stacking is NOT recommended!
• Method of Anesthesia: Apply topical cream/ointment/gel, preferably high concentration (e.g. 15-18% Lidocaine +
5% Prilocaine), as prescribed by the manufacturer, exercising caution around the eyes. Apply for 45-60min.
- Nerve block or local anesthesia may be applied for as per physician discretion.
- Higher energy level may be applied following invasive procedures that involve tumescent or IV sedation.
Please Note: Quick Reference Guides are on occasion revised and updated. It is the practitioner's responsibility to
ensure the use of the most current version of the Quick Reference Guide. Current Clinical Updates may be found at
InMode Australia Resource Centre.
Mode Depth *Energy Levels
mm
1
Cycle
2
2
Fixed/
3
Cycle
4
1
Fixed/
Cycle
2
2
Fixed/
Cycle
3
0.5
Manual
Fixed
0.5
Manual
Fixed
QUICK REFERENCE GUIDE – Morpheus8
8 – 10
Thin & delicate Areas, e.g. Periorbital, Forehead,
10 - 15
15- 25
Thick & Soft Tissue, e.g. Cheeks, Sub-Mental
25 - 35
Combine depths (4 – 3 – 2mm or 3 – 2mm according skin thickness)
35 - 45
5 - 10 Small Facial thin & delicate Areas, e.g. Upper and
10 - 15
15 - 25
Small Facial Soft Areas, e.g. Nose, Upper Lip
25 – 30
Combine depths (3 – 2mm according skin thickness)
10 - 20 Bony Areas with Surface Irregularities, e.g. Forehead
20 - 30 Soft Areas with Surface Irregularities, e.g. Cheeks
Date: September 2022
Treatment Areas
Hands Dorsum, decollate
Lower Eyelids
Use either 1 or 2mm – not both
