Page 1 Liebert HPC-S with ® low-GWP refrigerant 2 Compressors Range Air Cooled Chillers with Scroll Compressors Product Documentation English, 10077912MAN_ENG, rev. B.01 - 03.06.2024 This document, written in English, is the original version...
Page 3 Liebert HPC-S with low-GWP refrigerant 2 Compressors Range ® Air Cooled Chillers with Scroll Compressors Liebert HPC-S with low-GWP refrigerant: The Reliable, Efficient and Eco-friendly Freecooling Chiller for Data ® Centers and other different types of end-use applications. New Liebert HPC-S with low-GWP refrigerant 2 Compressors Range ensures top reliability and availability, ®...
Page 5: Table Of Contents
6.5 Check the Operation.............89 2.5.2 Hydraulic Kit..............14 6.6 Stop................90 2.5.3 Variable flow..............14 6.7 Restart................90 2.6 Electrical and Control System........22 6.8 Freecooling..............90 2.6.2 Vertiv iCOM3 ............23 6.9 Microprocessor Control ..........90 2.7 Optional features............25 6.10 Devices Settings and Calibrations......91 2.7.1 Energy Meter (Optional)..........25 6.10.1 Safety devices ............91...
Page 6 The product conforms to European Union directives 2006/42/EC; 2014/30/EU; 2014/35/EU; 2014/68/EU. Units are supplied complete with a test certificate and conformity declaration and control component list. Liebert HPC-S with low-GWP refrigerant 2 Compressors Range units are “CE” marked. ® Each unit is supplied complete with individual test certificate and a certificate of conformity to the European Union Directives. Liebert HPC-S with low-GWP refrigerant 2 Compressors Range units are “UKCA”...
Page 7: General Features And Benefits
• Variable flow The Liebert HPC-S with low-GWP refrigerant water chillers are controlled by the Vertiv™ iCOM3™ mi- ® croprocessor which manages all the operating conditions of the units. The user can vary and / or modify the operating parameters via the display keyboard installed on the electrical panel.
Page 9: Product Range Overview
Do not use in explosive, acid or anyway aggressive atmosphere. conditions Relative humidity is up to 50% at temperature of +40°C. Storage Temperature +0°C - +45°C, ask your Vertiv™ representative for T < 0°C. Conditions Humidity: 5 - 80% non-condensing Water inlet The water inlet temperature must never, under any circumstances, exceed 52°C.
Page 10: Operating Limits
The following graph is a generic indication of the operating limits of the Liebert HPC-S with low-GWP ® refrigerant range, refer to Vertiv™ CRS selection software to get the operation limit of a specific unit running in a specific operative condition. Standard units...
Page 11 Table 2.1 – Models: CS5****SB0E Models: CS5****SB0E 006SB 007SB 009SB 011SB 013SB 015SB 017SB 019SB 022SB Standard operating range Maximum leaving water temperature °C Minimum leaving water temperature °C Maximum air inlet temperature °C Minimum air inlet temperature °C Min fluid flow 4.40 11.33 11.71...
Page 12 Table 2.6 – Models: FS0****SB0E Models: FS0****SB0E 006SB 007SB 009SB 011SB 013SB 015SB 017SB 019SB 022SB Standard operating range Maximum leaving water temperature °C Minimum leaving water temperature °C Maximum air inlet temperature °C Minimum air inlet temperature °C Min fluid flow 4.40 5.62 11.33...
Page 13 Table 2.11 – Models: CS5****SG0C Models: CS5****SG0C 007SG 009SG 011SG 013SG 015SG 017SG 019SG 022SG 025SG Standard operating range Maximum leaving water temperature °C Minimum leaving water temperature °C Maximum air inlet temperature °C Minimum air inlet temperature °C 4.40 11.33 11.71 13.20...
Page 14 Table 2.16 – Models: FS0****SG0C Models: FS0****SG0C 007SG 009SG 011SG 013SG 015SG 017SG 019SG 022SG 025SG Standard operating range Maximum leaving water temperature °C Minimum leaving water temperature °C Maximum air inlet temperature °C Minimum air inlet temperature °C 4.40 5.62 11.33 11.71...
Page 15 Table 2.21 – Models: FS5****SB0Q Models: FS5****SB0Q 006SB 007SB 009SB 011SB 013SB 015SB 017SB 019SB 022SB Standard operating range Maximum leaving water temperature °C Minimum leaving water temperature °C Maximum air inlet temperature °C Minimum air inlet temperature °C 4.40 5.62 11.33 11.71...
Page 16: Construction Frame And Panels
• Variable flow The Liebert HPC-S with low-GWP refrigerant water chillers are controlled by the Vertiv™ iCOM3™ mi- ® croprocessor which manages all the operating conditions of the units. The user can vary and / or modify the operating parameters via the display keyboard installed on the electrical panel.
Page 17: Compressors
2.4.1 Compressors Type Scroll compressors These scroll compressors have been developed specifically for air conditioning. Protection They are characterized by high efficiency, smooth running and reliability. Oil system Integrated PTC motor protection. These compressors have an isolated oil sump design and use highly miscible PVE oil.
Page 18: Electronic Expansion Valve
The superheat setpoint will be automatically adjusted according to the operating conditions and to the application limit of the compressor. The operating parameters and their programming in the microprocessor dedicated to the EEV control are described in the Vertiv™ iCOM3™ User Manual. 2.4.3 Evaporator VertivTM Liebert HPC-S with low-GWP refrigerant 2 ®...
Page 19: Coated Coil Treatment (Optional)
® such as the sea coast and other corrosive environments, an added coating for coil protection is a must. According to environment characteristics, Vertiv™ serves different coating treatment as optional. For not louvered fin coils: • Pre-painted aluminum fin (polyester), which charateristics are summarized below...
Page 20: Hydraulic Kit
If the electronic inverter pump is replaced, all the parameters must be set; this intervention must be carried out by a Vertiv™ expert technician. 2.5.2 Hydraulic Kit If there are no tanks it consists of an expansion vessel (preloaded at 2.5 bar, maximum operating pressure 6 bar) and a safety valve calibrated at 6 bar.
Page 21 The “decoupled” system shown in uses constant water flow through each chiller and variable Figure 1 water flow through each CRAC unit to satisfy the data center loads. This hydronic design requires: • a constant-speed pump (and check valve) for each chiller; •...
Page 22 • A pressure transducer, able read and keep a constant Delta Pressure through the CRAC units, by managing the speed of the primary pumps. • A bypass positioned upstream the CRAC units, able to manage the minimum water flow admitted by the primary loop (which corresponds to the minimum load admitted by the single chiller).
Page 23 Min fluid flow Max fluid flow Model/Version FS*006SB 4.40 FS*007SB 5.62 FS*009SB 5.62 FS*011SB 11.33 FS*013SB 11.33 FS*015SB 11.71 FS*017SB 13.20 FS*019SB 15.69 FS*022SB 18.68 CS*007SG 4.40 CS*009SG 4.40 CS*011SG 4.40 CS*013SG 11.33 CS*015SG 11.33 CS*017SG 11.71 CS*019SG 13.20 CS*022SG 15.69 CS*025SG 18.68...
Page 24 VPF Solution C: • Liebert HPC-S with low-GWP refrigerant with pump; ® • A built-in flow meter reads the variable flow rate in entrance The Liebert HPC-S with low-GWP refrigerant thermal reg- • ® ulation logic adapts automatically under flow conditions; Chiller unit •...
Page 25 Variable Flow Teamwork There are three options available for chillers control in variable flow: Variable Flow Remote, Variable Flow Delta T, and Vari- able Flow Delta P. These options are available with Vertiv™ Lieb- iCOM™ CWM system control. The Vertiv™ Liebert iCOM™...
Page 26 Figure- Variable Flow Remote Request logic representation Variable Flow Delta T This configuration can be used when the plant is equipped with a buffer tank and the following four tempera- ture sensors are connected to the analog input connectors of the Vertiv™ Liebert iCOM™ CWM. ®...
Page 27 Variable Flow Delta P The CWM modulates the flow request for chillers to maintain a given differential pressure at chillers side. Chillers activation is also managed according to this flow request. The pressure measurements can be ac- quired from CWM sensors (if installed) or directly from chillers sensors. Figure - Pressure sensor position in a Variable Flow Delta P configuration Chillers sequencing In both Delta P and Delta T Variable Flow logics, three options are available for the chillers sequencing.
Page 28: Electrical And Control System
Main switch This is a disconnecting switch and cuts OFF the electric power supply to the whole unit. Main control panel See the for details. Vertiv™ iCOM3™ User Manual Touch screen panel (optional) See the for details. Vertiv™ iCOM3™ User Manual The electrical panel is designed and manufactured according to CEI EN 60204-1.
Page 29: Vertiv Tm Icom3 Tm
The Liebert HPC-S with low-GWP refrigerant water ® chillers are controlled by the Vertiv™ iCOM3™ micro- processor, managing all of the unit operating conditions. The user can change and/or modify the operating pa- rameters through the display keyboard installed on the electrical panel.
Page 30 2.6.2.2 Fast Start Ramp and Control Supply The Vertiv™ iCOM3™ for Liebert HPC-S with low-GWP refrigerant control is fed by direct current for ® immunizing from network disturbances. There are 3 possible power supply choices to guarantee reliability and fast start: Option 0 The unit is powered by a single three-phase line.
Page 31: Optional Features
2.7 Optional features 2.7.1 Energy Meter (Optional) For a full description please look at manual available on the unit. Parameters device are set on factory; it can show: - Currents - Powers - Energy values 2.7.2 Water Meter Safety informations WARNING Pressurized System Depressurize and vent system prior to installation or removal.
Page 32: Options: Auto-Monitoring On The Capacity / Efficiency Data Indicative Of The Unit
2.7.3 Options: Auto-monitoring on the capacity / efficiency data indicative of the unit Liebert HPC-S with low-GWP refrigerant can be equipped with the following options: ® • ENERGY METER which provides the reading of the instantaneous consumption of electricity (including the consumption of the pump main if this is integrated in the unit).
Page 33: Digital Nomenclature Description
Digital Nomenclature description The unit is fully defined by twenty-five (25) digits. 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 CS 5 0 0 6 Dig. Feature Value Description Dig. Feature Value Description Variable flow - Twin high head Chiller...
Page 34: Versions
3.1 Versions Digit Option Description Notes Unit is equipped with one refrigerant circuit, which is the Chiller only source of cooling for the user fluid. In addition to the refrigerant circuit, the unit is equipped Free cooling with freecooling coils that directly cool down the user fluid when the ambient conditions allow it.
Page 35: Water Regime
3.7 Water Regime Digit Option Description Notes Standard delta T Unit optimized for a temperature difference of 6K between inlet and outlet. At the design leaving water termperature, the suggested water temperature difference for this configuration is between 5K and 8K. 3.8 Efficiency Digit Option...
Page 36: Pumps
If the electronic inverter pump is replaced, all the parameters must be set; this intervention must be carried out by a Vertiv™ expert technician. Liebert HPC-S with low-GWP refrigerant - PD - 10077912MAN_ENG - 03.06.2024...
Page 37 Table 3.1 – (2 Poles) Low head pressure twin Pump Option Models ***006SB ***007SB ***009SB ***011SB ***013SB ***015SB ***017SB ***019SB ***022SB DPL50/150 DPL65/175 DPL40/130- DPL40/130- DPL40/130- DPL40/130- DPL40/150- DPL50/150 DPL50/150 Pump model (154)-5,5/2- (148)-7,5/2- 2,2/2-N7 2,2/2-N7 2,2/2-N7 2,2/2-N7 3/2-N7 (144)-4/2-N7 (144)-4/2-N7 N31-N7 Nominal motor power...
Page 38: Coil Options
Table 3.6 – (2 Poles) High head pressure twin Pump Option Models ***007SG ***009SG ***011SG ***013SG ***015SG ***017SG ***019SG ***022SG ***025SG DPL40/150- DPL40/150- DPL40/160- DPL40/160- DPL40/160- DPL40/160- DPL50/165- DPL50/175- DPL50/175- Pump model 3/2-N7 3/2-N7 4/2-N7 4/2-N7 4/2-N7 4/2-N7 5,5/2-N7 7,5/2-N7 7,5/2-N7 Nominal motor power Sound power level...
Page 39: Display
3.14 Display Digit Option Description Small graphic display with monitoring Large touch display with monitoring 10” Touch Display • The Touch display featuring a 24h / 7 days graphic record of controlled parameters as well as the last 200 events occurred. •...
Page 40: Low / High Ambient Temperature
3.16 Low / High Ambient temperature Digit Option Description Notes None Unit is not equipped of any heating systems for electrical panel and hydraulic circuit. Heater for Unit is equipped with heater for the electrical panel. electrical panel 3.17 Power supply line option Digit Option Description...
Page 41: Buffer Tank
3.20 Buffer Tank Digit Option Description Notes None Buffer Tank onboard 3.20.1 Power factor Capacitors Caution: Discharge and short circuit capacitor before handling! This option is not available for inverter compressors. Enhancing power quality – improvement of power factor – saves costs and ensures a fast return on invest- ment.
Page 42: Variable Flow Configuration
3.20.4 Variable flow configuration A variable water flow involves changes in the functionality of the chiller because the load changes directly proportionally. Liebert HPC-S with low-GWP refrigerant units with the variable flow option are designed ® for this working condition, provided that the variations in the water flow remain within the defined limits of minimum flow, maximum flow and maximum speed of variation of the flow.
Page 43: Flange Connections
Anti-vibration mount with anti-seismic structure For any further information see "Anti-vibration support Manual". 3.21.4 Flange connections Flanges DN50 (for models with 1 fan) 10073557 Flanges DN65 (for models with 2/3 fans) 10073558 3.21.5 Converter Modbus TCP-IP to RS485 Cod. 10036198 Liebert HPC-S with low-GWP refrigerant - PD - 10077912MAN_ENG - 03.06.2024 ®...
Page 45: Technical Data
Technical Data 4.1 Technical data Table 4.1 – Technical Data - *S****SG0* *S****SG0* Refrigeration circuits Number of refrigeration circuits 13.5 13.5 17.4 17.7 24.5 24.5 25.2 35.4 Refrigerant charge R410A [kg] 12.4 12.4 16.2 16.2 22.4 22.4 32.4 Refrigerant charge R454B [kg] Compressors Number of compressors Scroll...
Page 46 Table 4.2 – Technical Data - *S****SB0* *S****SB0* Refrigeration circuits Number of refrigeration circuits 13.5 13.5 17.4 17.7 24.5 24.5 25.2 35.4 Refrigerant charge R410A [kg] 12.4 12.4 16.2 16.2 22.4 22.4 32.4 Refrigerant charge R454B [kg] Compressors Number of compressors Scroll Scroll Scroll...
Page 47: Performance
(5) : Data refers to the version with Premium fans, for the Base and Quiet versions refer to the specific tables. (6) : The performances indicated refer to the version with Premium fans, for the Base and Quiet versions refer to Vertiv selection software.
Page 48 (5) : Data refers to the version with Premium fans, for the Base and Quiet versions refer to the specific tables. (6) : The performances indicated refer to the version with Premium fans, for the Base and Quiet versions refer to Vertiv selection software.
Page 49 (5) : Data refers to the version with Premium fans, for the Base and Quiet versions refer to the specific tables. (6) : The performances indicated refer to the version with Premium fans, for the Base and Quiet versions refer to Vertiv selection software.
Page 50 (5) : Data refers to the version with Premium fans, for the Base and Quiet versions refer to the specific tables. (6) : The performances indicated refer to the version with Premium fans, for the Base and Quiet versions refer to Vertiv selection software.
Page 51 Water treatment should be based on characteristics of the area’s water. Improper or untreated water can lead to scale build up, erosion and corrosion in the evaporator. Vertiv™ will not accept responsability for poorly or improperly treated water. Sea level: Correction factors Table 4.14 –...
Page 52: Electrical System
4.3 Electrical System Table 4.15 – Electrical Data - FS0_SB0 Models Models FS0_SB0 Power supply V/Ph/Hz 400V / 3Ph + PE / 50Hz Operating Total power input OA (without PFC) Rated power Max. power input Control Control power supply (only for V/Ph/Hz 230V / 1Ph + N + PE / 50Hz option Fast-Start)
Page 53 Control power supply (only for V/Ph/Hz 230V / 1Ph + N + PE / 50Hz option Fast-Start) Pmax 0.59 0.59 0.59 0.59 0.59 0.59 0.59 0.59 0.59 Imax 2.30 2.30 2.30 2.30 2.30 2.30 2.30 2.30 2.30 Compressors Power input 17.8 19.1 24.0...
Page 54 Power input Nominal current Max. Current Pumps Std. head pump model Nominal power Max. current 10.5 14.6 High head pump model Nominal power Max. current 10.0 14.6 14.6 (1) At nominal conditions: water inlet/outet temperatures 26/20°C, outdoor air temperature 35°C. (2) Base EC fans versions.
Page 55 If the unit with EC-FAN or inverter pump is connected to an electric installation where an earthleakage circuit breaker (ELCB) is used as additional protection, the circuit breaker must be of a type marked with the following symbols (This circuit breaker is type B.) Table 4.19 –...
Page 56 Control Control power supply V/Ph/Hz 230V / 1Ph + N + PE / 50Hz (only for option Fast-Start) Pmax 0.59 0.59 0.59 0.59 0.59 0.59 0.59 0.59 0.59 Imax 2.30 2.30 2.30 2.30 2.30 2.30 2.30 2.30 2.30 Compressors Power input 20.3 18.4 23.1...
Page 57 Power input Nominal current Max. Current Pumps Std. head pump model Nominal power Max. current 10.5 14.6 High head pump model Nominal power Max. current 10.0 14.6 14.6 (1) At nominal conditions: water inlet/outet temperatures 13/7°C, outdoor air temperature 35°C. (2) Base EC fans versions.
Page 58: Sound Pressure / Power Level
Avoid positioning in areas with possible reverberation of the sound waves that can adversely effect the noise levels. Note 5 Values valid for Freecooling and No-glycol units, Sound levels of the chillers must be obtained from Vertiv™ CRS selection software. Table 4.23 – Sound Pressure Levels (SPL) - CS/FS with Base EC Fans...
Page 59 Octave Band Frequency [Hz] Total Model [dBA] 63 Hz 125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz ***017SG 50.5 67.7 68.0 74.0 74.1 69.9 62.5 51.4 77.3 ***019SG 50.6 67.8 68.1 74.1 74.2 70.0 62.6 51.5 77.4...
Page 60 Table 4.26 – Sound Power Levels (PWL) - CS/FS with Base EC Fans Octave Band Frequency [Hz] Total Model [dBA] 63 Hz 125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz CS/FS "PWL" Sound power level [dB] ***007SG 65.1 82.3...
Page 61 Octave Band Frequency [Hz] Total Model [dBA] 63 Hz 125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz ***017SB 69.3 86.5 86.8 92.8 92.9 88.7 81.3 70.2 96.1 ***019SB 71.2 88.4 88.7 94.7 94.8 90.6 83.2 72.1 98.0...
Page 63: Handling And Installation
Handling and Installation 5.1 Transport • If the unit is shipped with a container, for extracting, follow the instructions placed on the front panel; • Handle the unit as shown in pictures below. Fig. 1 - Handling with forklift HANDLING WITH TROLLEY FORKLIFT CENTER OF GRAVITY REFERENCE ' During the handling the unit’s center of gravity (indicated by the symbol) must be aligned with the center of the forklift.
Page 64 Fig. 2 - Lifting instructions for HPC-S 2C Lifting instructions with tubes PROTECTION PLANK (NOT SUPPLIED) RIGIT STRUTS (POSSIBLY STEEL) (NOT SUPPLIED) PART. A PART."A" LIFTING SYSTEM WITH TUBES BELT OR CHORD (NOT SUPPLIED) LIFTING TUBE (OPTIONAL KIT) IN CASE OF COLLISION WITH STRAPS/ROPES DISASSEMBLE THE CONTAINMENT AND LOCKING BRACKET (OPTIONAL KIT) CABLE ENTRY BRACKETS DURING THE LIFTING PHASE BLOCKING PEG (OPTIONAL KIT)
Page 65 Fig. 3 - Lifting instructions with straight shackle (barycentric axis) Lifting instructions with shackles N.B.: LIFT IN CORRESPONDENCE OF THE UNIT'S CENTER OF GRAVITY. "G" PART."A" IN CASE OF COLLISION WITH STRAPS/ROPES DISASSEMBLE THE CABLE ENTRY BRACKETS DURING THE LIFTING PHASE "X"...
Page 66 Fig. 4 - Handling with forklift HANDLING WITH TROLLEY FORKLIFT CENTER OF GRAVITY REFERENCE ' Liebert HPC-S with low-GWP refrigerant - PD - 10077912MAN_ENG - 03.06.2024 ®...
Page 67 Shipping weight and unit baricentre position (“G”) Unit baricentre position "G"(without water) With tank and 2 pumps, “X Base“ Without tank and pumps Models ATS and filter coils (mm) “X base“ “Xg“ Weight “X base“ “Xg“ Weight (mm) (mm) (kg) (mm) (mm) (kg)
Page 68 Fig. 5 - Support positions and loads FOOTPRINT ON THE GROUND O 14 Support position dimensions Dimensions (mm) Models - Size n.Fans CS0/5 007-009-011 SG 006-007-009 SB 1810 2000 FS0/5 007-009-011 SG 006-007-009 SB CS0/5 013-015-017-019 SG 011-013-015-017 SB 1350 1460 3000 FS0/5...
Page 69 Weight distribution without tank and pumps Weight distribution - Distribuzione pesi (kg) TOT. Models Fans (kg) CS5 006 SB CS0 006 SB CS5 007 SB CS0 007 SB CS5 009 SB CS0 009 SB CS5 011 SB CS0 011 SB 1202 CS5 013 SB CS0 013 SB 1215...
Page 70 Weight distribution with tank and 2 pumps, ATS and filter coils Weight distribution - Distribuzione pesi (kg) TOT. Models Fans (kg) CS5 006 SB CS0 006 SB 1173 CS5 007 SB CS0 007 SB 1203 CS5 009 SB CS0 009 SB 1225 CS5 011 SB CS0 011 SB 1694...
Page 71 Fig.6 - Instruction to assembly the extension roof of the E.P. Liebert HPC-S with low-GWP refrigerant - PD - 10077912MAN_ENG - 03.06.2024 ®...
Page 72 Fig.7 -Dimension of the extension roof for the E.P. Liebert HPC-S with low-GWP refrigerant - PD - 10077912MAN_ENG - 03.06.2024 ®...
Page 73: Storage
Requirement Storage environment Outdoor environment. Ambient temperature 0°C ÷ +45°C r Vertiv™ representative for T < 0°C. Ask you Ambient humidity 5 ÷ 80% RH non-condensing; all electronic devices inside EP are protected with desiccant bags Storage time The total storage time should not exceed one month; for storage with high R.H ambient or near sea storage time should not exceed 2 weeks.
Page 74: Space Requirements
5.4 Installation Site 5.4.1 Location • The Liebert HPC-S with low-GWP refrigerant units must be installed outdoors. ® • Prepare a level surface suitable to support the weight of the Liebert HPC-S with low-GWP refrigerant unit. ® • The unit produces heat. The installation site must have a good air flow, so to guarantee heat dispersion even in the most demanding operating conditions.
Page 75 NOTICE The maintenance of the unit become extremely difficult if placed too close to walls or other obstacles. The floor level in the maintenance area on the electrical panel side must be aligned with the surface where the unit is placed, ensuring easy and safe access to the electrical panel, complying with applicable safety regulations.
Page 76 Weight distribution without tank and pumps Weight distribution (kg) TOT. Models Fans (kg) CS5 006 SB CS0 006 SB CS5 007 SB CS0 007 SB CS5 009 SB CS0 009 SB CS5 011 SB CS0 011 SB 1202 CS5 013 SB CS0 013 SB 1215 CS5 015 SB CS0 015 SB 1271...
Page 77 Weight distribution with tank and 2 pumps, ATS and filter coils Weight distribution (kg) TOT. Models Fans (kg) CS5 006 SB CS0 006 SB 1173 CS5 007 SB CS0 007 SB 1203 CS5 009 SB CS0 009 SB 1225 CS5 011 SB CS0 011 SB 1694 CS5 013 SB CS0 013 SB 1707...
Page 78: Installation
5.5.1 Preparation of the installation site (by the customer) NOTICE Vertiv™ takes no responsibility for systems not compliant with the specifications given in this manual. Lack of compliance to the specifications given by Vertiv™ voids the warranty. The customer is responsible for the following operations.
Page 79 5.10 Initial Checks 7. Start the unit for the first time 6. Operation 8. Check or set up the operating parameters of the control system Vertiv™ iCOM3™ User Manual Liebert HPC-S with low-GWP refrigerant - PD - 10077912MAN_ENG - 03.06.2024 ®...
Page 80: Safety Instructions
5.6 Safety Instructions Personnel WARNING Only authorized personnel is allowed to do installation operations. All work on pipes or components of the refrigerating circuit under pressure must be exclusively made by qualified staff, competent in such works. The authorized personnel must be properly trained and qualified, wear appropriate personal protective equipment and use adequate tools.
Page 81: Water System Specifications
5.7 Water system specification 5.7.1 Ideal water circuit The Liebert HPC with low-GWP refrigerant unit must be connected to the chilled water circuit. ® The customer is responsible for the water circuit, according to the following example and specifications. The following figure shows an ideal circuit. Ref.
Page 82 Failure to do so could cause breakages of the compressors due to repeated returns of liquid refrigerant. Whenever two or more units are used on the same chilled water loop, Vertiv™ recommends that their operation be coordi- nated with a higher-level system controller for optimum system efficiency and reliability.
Page 83: System Protection
5.7.3 Sizing of the expansion tank C x e where: The total volume of the expansion tank is calculated with the ratio C = quantity of water inside the system expressed in liters; shown on the left. e = water expansion coefficient, water at 10°C as reference; Pi = absolute pressure of initial charging, equivalent to the Use the values of the water expansion coefficient indicated in the tank pre-charge pressure (value 2.5 bar);...
Page 84: Water Supply Specifications
5.7.5 Water supply specifications Analyze the water It is the user’s responsibility to establish the quality of the water and make sure that this is compatible with the materials used in the exchangers. The quality of water significantly affects the operation and the life of the exchangers. The first step in planning the treatment of the water is chemical analysis, which must be performed by quali- fied personnel from specialist organizations.
Page 85 5.7.7 Prevent freezing for chiller or freecooling chiller Prevent freezing In winter, if the system is stopped, the water inside the exchangers can freeze damaging the system by glycol irreparably. Thus, it is recommended to use glycol mixtures: please consider the different outputs and power absorp- tion by the chiller, the pump sizing and the performance of the system terminals/conditioners).
Page 86: Connections
5.8 Connections 5.8.1 Water system piping Joints For welded hydraulic connection use the small pipes supplied with the unit, otherwise directly connect grooved lines with the grooved pipes con- nections joints of the unit, taking care to suitably grease the joint gaskets. Ref.
Page 87: Electrical Power Supply
5.8.2 Electrical power supply Power supply Low voltage connection for the control system Passage for cables Protective Earth Connection • After opening the passage in the structural works (precut), for the sup- ply line inlet, restore the original protection degree with suitable acces- sories for the wiring and junction boxes.
Page 88 Ethernet cable connection. The control can be connected with a remote display (ColdFire) through an Ethernet network cable (see HW user handbook). • Fasten the cable to the clamp - holding plates and make it pass through the hole on the panel (arrange a cable clamp). •...
Page 89: Pressure Relief Valve (Prv)
5.8.3 Pressure Relief Valve (PRV) Refrigerant circuit options: Digit 15 = 0 - Pressure relief valves Digit 15 = 2 - Changeover valve for dual pressure relief valves Digit 15 = 4 - Plumbed shut-off valve for pressure relief valves Digit 15 = 6 - No pressure relief valves (chiller installation in Separate Area as per EN378-3) Convey the discharge Pressure relief valves are installed on the refrigerating circuit on the high pressure side.
Page 90 If several valves are conveyed together, the user must recalculate this ATEX classified zone according to EN60079-10-1, considering a discharge flow rate equal to the sum of the PRVs that are connected to the manifold (contact Vertiv™ for how to consider the simultaneity coefficient of the PRVs under the same manifold).
Page 91: Filling The Water System
5.9 Filling the Water System • Supply water through the fill group. for the amount of water to charge. 5.7.1 Water System Specification • In case of low ambient temperature, add glycol: see 5.7.7 Prevent freezing for chiller or freecooling chiller. •...
Page 92 • Check all water connections. Water system • Open all isolating valves and/or water ball valve. • In case of climates with temperatures below zero degrees C, make sure the chilled water circuit is filled with the correct concentration of water/glycol, see 5.7.7 Prevent freezing for chiller or freecooling chiller.
Page 93: Operation And Maintenance
(control and auxiliary systems) 3. Set the general main switch [B] to the position “I”. • Check that the Vertiv™ iCOM3™ display [C] switches ON. • In case of first start-up or after maintenance on the electric system, check again by a voltmeter or tester if the voltage and phase differ- ence fall within the indicated limits.
Page 94: Preparation
6.3 Preparation NOTE: Follow these instructions at first start-up and also in case of restart after a long stop. Compressor When you set the main supply switch [B] to the position “I”, the compressor oil heaters are automatically pre-heating powered ON. and check NOTICE The pre-heating of the compressor oil takes about 8 hours.
Page 95: Initial Startup (Or Following A Long Interruption)
NOTICE Before starting the unit, make sure that the compressor has been heated for at least 8 hours. • On the Vertiv™ iCOM3™ control panel [A] set the switch to ON. 6.5 Check the Operation NOTICE The following checks must be done: •...
Page 96: Stop
HPC-S ® with low-GWP refrigerant. 6.7 Restart After a short stop • On the Vertiv™ iCOM3™ control panel [C] set the switch to ON (as in 6.4 Initial startup). After a long stop Do the complete procedure as described in: 6.4 Initial...
Page 97: Devices Settings And Calibrations
Before beginning this calibration be sure that the refrigerant charge is correct: do the subcooling measurement. Setting Compressor’s suction pressure, temperature and superheat can be read on Vertiv™ iCOM3 control display as described in the suitable Vertiv™ iCOM3™ User Manual available on the unit.
Page 98: Maintenance
6.11. Maintenance NOTICE Check the unit regularly and solve the problems as they occur. Lack of maintenance could reduce the performance or damage the unit. 6.11.1 Safety Instructions Personnel WARNING Only authorized personnel is allowed to do maintenance operations. All work on pipes or components of the refrigerating circuit under pressure must be exclusively made by qualified staff, competent in such works.
Page 99: Safety Labels
When placing an order refer to "Component List" enclosed with the unit and quote the unit model and serial number. NOTICE If one or more compressors must be replaced, you must contact Vertiv™ Service. 6.11.4 Maintenance Programme 6.11.4.1 Chiller Preventive Maintenance Schedule...
Page 100 month months months months Refrigeration Check the compressor's current absorption, the delivery tem- circuit perature and possible unusual noises. Check the freon charge by means of the sight glass. Check that the safety devices operate correctly. Check the correct operation of the EEV valve (superheat be- tween 5 - 8 K) included the one in the economiser circuit (if installed).
Page 101: Safety And Maintenance Remarks For Liebert ® Hpc-S With Low-Gwp Refrigerant With A2L
Periodic inspections for refrigerant leaks may be required depending on European or local legislation. Please contact Vertiv™ for more information. Repair the leak, detect and recharge the circuit with the total R454B charge, as indicated on the unit name plate. Certain parts of the circuit can be isolated.
Page 102 Component replacement • Gas Detector Sensor has a typical sensor lifetime about 4 years; Compressor box ventilation fans has a typical sensor lifetime about 8 years, Vertiv™ requests to replace it every 4 years. • Liebert HPC-S with low-GWP refrigerant - PD - 10077912MAN_ENG - 03.06.2024...
Page 103: Coils Cleaning
6.12 Coils cleaning The obstructions provided by powder, pollution etc. accumulated between the coils fins can be removed by means of a pressure washer. Particular adverse conditions of the installation site (dust, sand, etc.) may require significant higher frequency of cleaning. Tab.
Page 104: Refrigeration System Maintenance
6.13 Refrigeration system maintenance 6.13.1 Inspection • Check that the refrigeration pipes are firmly fixed. The refrigeration pipes shall not shake with the vibration of wall, earth or equipment frame. Otherwise reinforce the refrigeration pipes with fasteners. • Check that there is no oil on the accessories of all refrigeration pipes, and make sure that the pipes do not leak. 6.13.2 Refrigerant charge Before shipment each unit is charged with the right amount of refrigerant and oil.
Page 105: Oil Charge
• Detect the temperature on the liquid line using a contact thermometer. Measure the sub-cooling • Connect a pressure gauge (by max a 30 cm pipe) with the Schraeder connection on the liquid line and read the corresponding saturated condensing temperature. •...
Page 106: Troubleshooting
6.13.4 Troubleshooting Symptom Possible Cause Check or Remedy The unit does not start No power supply to the unit Check voltage at input terminal block The circuit breaker or fuse for low-voltage transformer Locate the problem in unit electrical panel and in unit is tripped repair Low evaporating...
Page 107: Dismantling The Unit
6.14 Dismantling the Unit The unit has been designed and built to ensure continuous operation. The working life of some of the main components, such as the compressors, depends on the maintenance that they receive. ENVIRONMENT The unit contains substances and components hazardous for the environment (electronic components, refrigerating gases and oils).
Page 108: Operations
6.14.2 Operations Operation Notes 1. Disconnect the main switch from the electric power supply Reverse the procedure from chapter Installation: 5.8.2 Electrical power supply 2. Discharge the water Reverse the procedure from chapter Installation: 5.8.1 Water system piping 3. Remove the refrigerant NOTICE Handle the refrigerant according to regulations about F-Gases and safety data sheet.
Page 109: Fluorinated Greenhouse Gases
6.15.3 Fluorinated Greenhouse Gases Following notes must be considered when operating with the above-mentioned equipment: • Fluorinated greenhouse gases are covered by the Kyoto Protocol. • The fluorinated greenhouse gases in this equipment should not be vented to the atmosphere. •...
Page 110: Labelling
6.16.3 Labelling The label applied on the unit (see Label) is designed to fill-in the relevant amounts of refrigerant according to Regulation Onboard 1494/2007 (2015/2068): Where fluorinated greenhouse gas is foreseen to be added to the equipment outside of the manufacturing site at the point of installation, a dedicated label accommodates notation of both the quantity [kg] pre-charged in the manufacturing plant and of the quantity charged at the installation site as well as the resulting total quantity of F-gas as a combination of the above mentioned quantities, in a manner which conforms to the legibility and indelibility.
Page 111: Record Keeping
5 years NOTICE R454B is classified A2L (mildly flammable) refrigerant; for this reason Vertiv™ recommend to keep the highest frequency of refrigerant leak check for safety issues; for the same reason Vertiv™ recommend to maintain the record keeping as indicated. NOTICE When the unit is subjected to fire, safety devices prevent rupture due to over-pressure by releasing refrigerant.
Page 113: Dimensions And Weights
Dimensions and Weights Fig.1 - Service area (top view) UNIT 1100 1000 Ordinary Extraordinary maintenance area maintenance area Note: Minimum dictance between 2 units on the condesing coil side = 2m . Do not obstruct the air flow exiting the fans for a minimum distance of 2,5m. Liebert HPC-S with low-GWP refrigerant - PD - 10077912MAN_ENG - 03.06.2024 ®...
Page 114 Fig.2 - Overall dimensions HPC-S 1 fan with R410A - CS0 FS0 Liebert HPC-S with low-GWP refrigerant - PD - 10077912MAN_ENG - 03.06.2024 ®...
Page 115 Fig.3 - Overall dimensions HPC-S 1 fan with R454B - CS5 FS5 Liebert HPC-S with low-GWP refrigerant - PD - 10077912MAN_ENG - 03.06.2024 ®...
Page 116 Fig.4 - Overall dimensions HPC-S 1 fan with R454B - CS5 FS5 * NOTE: Dimension "C" only with option pressure relef valves. EC fans Base EC fans Premiun Fans Quiet Model N. Fans (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm) CS0007SG...
Page 117 Fig.5 - Overall dimensions HPC-S 2 fans with R410A - CS0 FS0 Liebert HPC-S with low-GWP refrigerant - PD - 10077912MAN_ENG - 03.06.2024 ®...
Page 118 Fig.6 - Overall dimensions HPC-S 2 fans with R454B - CS5 FS5 Liebert HPC-S with low-GWP refrigerant - PD - 10077912MAN_ENG - 03.06.2024 ®...
Page 119 Fig.7 - Overall dimensions HPC-S 2 fans * NOTE: Dimension "C" only with option pressure relief valves. EC fans Base EC fans Premiun Fans Quiet Model CS Model FS N. Fans (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm) CS0013SG FS0013SG CS0015SG...
Page 120 Fig.8 - Overall dimensions HPC-S 3 fans with R410A - CS0 FS0 Liebert HPC-S with low-GWP refrigerant - PD - 10077912MAN_ENG - 03.06.2024 ®...
Page 121 Fig.9 - Overall dimensions HPC-S 3 fans with R454B - CS5 FS5 Liebert HPC-S with low-GWP refrigerant - PD - 10077912MAN_ENG - 03.06.2024 ®...
Page 122 Fig.10 - Overall dimensions HPC-S 3 fans * NOTE: Dimension "C" only with option pressure relef valves. EC fans Base EC fans Premiun Fans Quiet Model CS N. Fans (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm) CS0022SG CS0025SG CS0019SB CS0022SB CS5022SG...
Page 123 Fig.11 - Dimensions of HPC-S with pallet Liebert HPC-S with low-GWP refrigerant - PD - 10077912MAN_ENG - 03.06.2024 ®...
Page 124 Fig.12 - Instruction to assembly the extension roof of the E.P. Liebert HPC-S with low-GWP refrigerant - PD - 10077912MAN_ENG - 03.06.2024 ®...
Page 125 Fig.13 -Dimension of the extension roof for the E.P. Liebert HPC-S with low-GWP refrigerant - PD - 10077912MAN_ENG - 03.06.2024 ®...
Page 126: Diagram Of Refrigerating Circuit
Diagram of Refrigerating Circuit Liebert HPC-S with low-GWP refrigerant - PD - 10077912MAN_ENG - 03.06.2024 ®...
Page 127: Diagram Of Hydraulic Circuit
Diagram of Hydraulic Circuit Liebert HPC-S with low-GWP refrigerant - PD - 10077912MAN_ENG - 03.06.2024 ®...
Page 129 ® referred to are trade names, trademarks or registered trademarks of their respective owners. While every precaution has been taken to ensure accuracy and completeness herein, Vertiv Co. assumes no responsibility, and disclaims all liability, for damages resulting from use of this information or for any errors or omissions. Specifications are subject to change without notice.
