Related Manuals for Kia Syros 2025

Summary of Contents for Kia Syros 2025

  • Page 1 2025 Syros Owner’s Manual...
  • Page 2 Please drive safely and enjoy your Kia vehicle! 2025 Kia India Private Limited All rights reserved. May not be reproduced or translated in whole or in part without the written consent of Kia India Private Limited. Printed in India...

  • Page 4: How To Use This Manual

    Illustrations complement the words in this manual to best explain how to enjoy CAUTION your Kia. By reading your manual, you A CAUTION indicates a hazardous situa- learn about features, important safety tion which, if not avoided, could result in information and driving tips under vari- minor or moderate injury.

  • Page 6: Table Of Contents

    Table of Contents Introduction Your vehicle at a glance Safety features of your vehicle Features of your vehicle Driving your vehicle Driver assistance system What to do in an emergency Maintenance Specifications & Consumer information Abbreviation Index Kia Warranty Policy...

  • Page 8: Introduction

    Introduction Introduction Fuel requirements ................1-2 僅 Petrol engine ....................... 1-2 僅 Diesel engine.......................1-4 Vehicle modifications..............1-4 Vehicle break-in process .............. 1-5 Risk of burns when parking or stopping vehicle...... 1-5...

  • Page 9: Introduction

    Never add any fuel system cleaning 2. Petrol or gasohol containing metha- agents to the fuel tank other than what nol. has been specified. (Kia recommends to consult an authorised Kia dealer/service 3. Leaded fuel or leaded gasohol. partner for details.)

  • Page 10: Other Fuels

    Additives are available from a profes- mance problem caused by the use of sional workshop along with information these fuels may not be covered by your on how to use them. Kia recommends to New Vehicle Limited Warranty. visit an authorised Kia dealer/service partner.

  • Page 11: 僅 Diesel Engine

    Introduction Vehicle modifications Vehicle modifications Diesel engine Diesel fuel This vehicle should not be modified. Diesel engines must be operated only on Modification of your vehicle could affect commercially available diesel fuel that its performance, safety or durability and complies with EN 590 or comparable may even violate governmental safety standard.

  • Page 12: Vehicle Break-In Process

    Introduction Vehicle break-in process Vehicle break-in process Risk of burns when parking or stopping vehicle. By following a few simple precautions for the first 1,000 km (600 miles) you WARNING may add to the performance, economy 僅 Do not park or stop the vehicle near and life of your vehicle.

  • Page 14: Your Vehicle At A Glance

    Your vehicle at a glance Your vehicle at a glance Exterior overview ................2-2 Interior overview ................2-4 Instrument panel overview ............2-6 Engine compartment..............2-8...

  • Page 15: Your Vehicle At A Glance

    Your vehicle at a glance Exterior overview Your vehicle at a glance Exterior overview Front view OAYI014001 * The actual shape of your Kia may differ from the illustration. 1. Bonnet 4-27 2. Wide-front view camera 6-3, 6-31 3. Front windscreen wiper blades 4-72, 8-30 4.
  • Page 16 Your vehicle at a glance Exterior overview 12.Wheel and tyre 8-34, 9-8 Rear view OAYI014002 * The actual shape of your Kia may differ from the illustration. 1. Door 4-15 2. Roof rack 4-103 3. Fuel filler door 4-29 4. Tail lamp 8-60 5.

  • Page 17: Interior Overview

    Your vehicle at a glance Interior overview 13.Reversing Lamp 8-60 Interior overview OAYI014003_2 * The actual shape of your Kia may differ from the illustration. 1. Shift lever 5-14, 5-17, 5-23 2. Seat 3. Tilt Steering Control Lever 4-40 4. Steering wheel 4-39 5.
  • Page 18 Your vehicle at a glance Interior overview 13.Power window lock button 4-23 14.Fuel filler door open lever 4-29 15.Instrument panel fuse 8-45 16.Bonnet release lever 4-27 17.Inside door handle 4-17 18.Front seat air ventilation switch 4-97...

  • Page 19: Instrument Panel Overview

    Your vehicle at a glance Instrument panel overview Instrument panel overview OAYI014004_2 * The actual shape of your Kia may differ from the illustration. 1. Passenger's front air bag 3-32 2. Glove box 4-94 3. Infotainment system 4. Climate control system 4-77 5.
  • Page 20 Your vehicle at a glance Instrument panel overview 14.USB port / USB charger 4-99 15.USB charger 4-99 16.Power outlet 4-98 17.Wireless charging system 4-100 18.ENGINE START/STOP button 19.Parking Safety button 6-50 20.Parking/View button 6-46 21.Cup holder 4-96 22.Centre console storage 4-94 23.Rear USB charger 4-99...

  • Page 21: Engine Compartment

    Your vehicle at a glance Engine compartment Engine compartment (Petrol) 1.0 T-GDi OAYI074014 * The actual engine compartment in your Kia may differ from the illustration. 1. Windscreen washer fluid reservoir 8-26 2. Engine coolant reservoir 8-22 3. Brake/clutch fluid reservoir 8-25 4.
  • Page 22 Engine compartment Open the bonnet to see the engine compartment. (Petrol) 1.0 T-GDi OAYI074014 * The actual engine compartment in your Kia may differ from the illustration. 1. Windscreen washer fluid reservoir 2. Engine coolant reservoir 3. Brake/clutch fluid reservoir 4.
  • Page 23 Maintenance Engine compartment (Diesel) 1.5 VGT OAYI074015 * The actual engine compartment in your Kia may differ from the illustration. 1. Windscreen washer fluid reservoir 2. Engine coolant reservoir 3. Brake/clutch fluid reservoir 4. Engine oil filler cap 5. Engine oil dipstick 6.

  • Page 24: Maintenance Services

    Kia dealers meet Kia's high service injury to yourself whenever performing quality standards and receive technical any maintenance or inspection proce- support from Kia in order to provide you dures. with a high level of service satisfaction. Should you have any doubts concerning...

  • Page 25: Owner Maintenance

    Do not touch metal parts (including strut performed by the owner or an autho- bars) whilst the vehicle is operating or rised Kia dealer. They should be per- hot. Doing so could result in serious formed at the indicated frequencies to bodily injury.

  • Page 26: At Least Monthly

    Maintenance Owner maintenance Whilst operating your vehicle: blades with clean cloth dampened with washer fluid. 僅 Check for vibrations in the steering 僅 Check the headlight alignment. wheel. Notice any increased steering effort or looseness in the steering 僅 Check the lap/shoulder belts for wear wheel, or change in its straight-ahead and function.

  • Page 27: Scheduled Maintenance Service

    Maintenance Scheduled maintenance service Scheduled maintenance service Follow the Normal maintenance sched- ule if the vehicle is usually operated where none of the following conditions apply. Follow the Maintenance Under Severe Usage Conditions if any of the following conditions apply. 僅...

  • Page 28: Normal Maintenance Schedule

    Inspect for excessive valve noise and/or engine vibration and adjust if necessary. In Valve clearance this case, have the system checked by a professional workshop. Kia recommends to visit an authorised Kia dealer/service partner. For your convenience, it can be replaced prior to it's interval when you do mainte- Spark plug nance of other items.
  • Page 29 Maintenance Scheduled maintenance service I: Inspect and if necessary, adjust, correct, clean or replace. R: Replace or change Number of months or driving distance, whichever comes first Months Miles X 1,000 Km X 1,000 Petrol (Petrol) 1.0 T-GDi Replace every 10,000 km (6,500miles) or 12 months Engine oil and engine *1*2 oil filter...
  • Page 30 - If there safety risks such as fuel flow restriction, surging, loss of power, hard starting problem etc, replace the fuel filter immediately regardless of mainte- nance schedule and consult an authorised Kia dealer for details.

  • Page 31: Maintenance Under Severe Usage Conditions

    Maintenance Scheduled maintenance service Maintenance under severe usage conditions The following items must be serviced more frequently on cars mainly used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. I: Inspect and if necessary, adjust, correct, clean or replace R: Replace Maintenance Maintenance item...
  • Page 32 Maintenance Scheduled maintenance service Severe driving conditions A: Repeatedly driving short distance of less than 8 km (5 miles) in normal tempera- ture or less than 16 km (10 miles) in freezing temperature. B: Extensive engine idling or low speed driving for long distances. C: Driving on rough, dusty, muddy, unpaved, gravelled or saltspread roads.

  • Page 33: Explanation Of Scheduled Maintenance Items

    Fuel filter (for petrol) hoses and connections be replaced by a professional workshop. Kia recommends Kia petrol vehicle is equipped with a life- to visit an authorised Kia dealer/service time fuel filter that is integrated with the partner.

  • Page 34: Vacuum Crankcase Ventilation Hoses

    Hoses should be replaced immediately if there is any evidence of deterioration or dam- age. Air cleaner filter We recommend that the air cleaner filter be replaced by a professional workshop. Kia recommends to visit an authorised Kia dealer/service partner.

  • Page 35: Brake/Clutch Fluid

    DOT 4 specification. shop according to the maintenance schedule. Kia recommends to visit an authorised Kia dealer/service partner. Parking brake NOTICE Inspect the parking brake system includ-...

  • Page 36: Steering Gear Box, Linkage & Boots/Lower Arm Ball Joint

    Maintenance Engine oil and filter (for petrol) Engine oil and filter (for pet- Steering gear box, linkage & boots/lower arm ball joint rol) With the vehicle stopped and off, check Engine oil is used for lubricating, cooling, for excessive free-play in the steering and operating various hydraulic compo- wheel.

  • Page 37: Changing The Engine Oil And Filter

    Engine oil and filter (for petrol) Changing the engine oil and filter (Petrol) 1.0 T-GDi We recommend that the engine oil and filter be replaced by an authorised Kia dealer according to the Maintenance Schedule at the beginning of this chap- ter.

  • Page 38: Checking The Engine Oil Level

    Required action according to the respective Range engine oil level Contact an authorised Kia dealer/service partner. Do not refill oil. You may add oil as long as the oil level does not go above C-range.
  • Page 39 We recommend that the engine oil and You must add oil and make sure that the oil filter replaced by a professional work- level is in the C-Range. shop. Kia recommends to visit an autho- WARNING rised Kia dealer/service partner. 僅 If the maintenance schedule to...

  • Page 40: Engine Coolant

    Maintenance Engine coolant Engine coolant NOTICE The high-pressure cooling system has a Never add any additives to the engine reservoir filled with year round anti- oil. Engine oil additives can change the freeze coolant. The reservoir is filled at properties of engine oil and may cause the factory.

  • Page 41: Checking The Coolant Level

    Maintenance Engine coolant whilst the engine is operating or hot. Doing so might lead to cooling system Mixture Percentage (volume) Ambient Tem- damage and could result in serious per- perature Antifreeze Water sonal injury from escaping hot coolant or -15 °C steam.

  • Page 42: Changing The Coolant

    Bring the level to F, but do not overfill. If frequent additions are required, we recommend that the system be inspected by a professional workshop. Kia recommends to visit an authorised Kia dealer/service partner. Changing the coolant We recommend that the coolant be...

  • Page 43: Checking The Brake/Clutch Fluid Level

    Brake/clutch mend that the system be checked by a fluid must be maintained periodically to professional workshop. Kia recommends ensure that the brakes operate to visit an authorised Kia dealer/service smoothly. partner. Checking the brake/clutch fluid level...

  • Page 44: Checking The Washer Fluid Level

    Maintenance Washer fluid Washer fluid and avoid contacting windscreen washer fluid. Serious injury or death Washer fluid is used when wiping the could occur. windscreen of the vehicle with a wind- screen wiper. You should check and refill washer fluid periodically to make sure that it doesn't run out.

  • Page 45: Checking The Parking Brake

    Also, the parking brake alone check the system. Kia recommends to should securely hold the vehicle on a visit an authorised Kia dealer/service fairly steep grade. If the stroke is more partner.

  • Page 46: Replacing Air Cleaner Filter

    僅 Use only Kia Genuine Parts or those OAYI074028 of an equivalent standard part. If not, 2. Wipe the inside of the air cleaner.

  • Page 47: Inspecting And Replacing Climate Control Air Filter

    Maintenance Climate control air filter Climate control air filter The climate control air filter should be replaced according to the maintenance schedule. If the vehicle is operated in severely air-polluted cities or on dusty rough roads for a long period, it should OQYi073025 be inspected more frequently and 5.

  • Page 48: Wiper Blades

    Maintenance Wiper blades Wiper blades CAUTION When the wipers no longer clean ade- To prevent damage to the wiper blades, quately, the blades may be worn or do not use petrol, kerosene, paint thin- cracked, and require replacement. ner, or other solvents on or near them. To prevent damage to the wiper arms or other components, do not attempt to Front windscreen wiper blade...

  • Page 49: Replacing Rear Window Wiper Blade

    Maintenance Wiper blades To prevent damage to the wiper arms or other components, have an autho- rised Kia dealer/service partner replace the wiper blade. OQYi073029 3. Lift it off the arm. OQYi073030 4. Install the blade assembly in the reverse order of removal.

  • Page 50: For Best Battery Service

    After then ensure that tighten the cell caps. We recommend that you con- The battery powers the engine in order tact an authorised Kia dealer/service to move the vehicle as well as supplying partner. power to the various devices installed in the vehicle.

  • Page 51: Battery Capacity Label

    The battery contains lead. Do OAYI074069 not dispose of it after use. 1. CMF45L-DIN: The Kia model name of Please return the battery to an battery authorised Kia dealer to be 2. 12V: The nominal voltage recycled.

  • Page 52: Tyres And Wheels

    Maintenance Tyres and wheels Tyres and wheels 僅 Do not allow cigarettes, sparks, or flame near the battery. For proper maintenance, safety, and 僅 Watch the battery during charging, maximum fuel economy, you must and stop or reduce the charging rate always maintain the recommended tyre in following cases: inflation pressures and stay within the...

  • Page 53: Checking Tyre Inflation Pressure

    Maintenance Tyres and wheels Checking tyre inflation pressure risk of an accident. This risk is much higher on hot days and when driving for Check your tyres once a month or more. long periods at high speeds. Use a good quality gauge to check tyre pressure.

  • Page 54: Tyre Rotation

    Maintenance Tyres and wheels on the tyre label located on the driver's WARNING side centre pillar. Mixing tyres Tyre rotation Do not mix bias ply and radial ply tyres To equalize tread wear, it is recom- under any circumstances. This may mended that the tyres be rotated every cause unusual handling characteristics.

  • Page 55: Tyre Replacement

    Wheels NOTICE Wheels that do not meet Kia specifica- tions may fit poorly and result in dam- We recommend that when replacing age to the vehicle or unusual handling tyres, use the same originally supplied and poor vehicle control.

  • Page 56: Tyre Maintenance

    Maintenance Tyres and wheels Tyres should be replaced when tread explains what the letters and numbers in wear indicators appear. Slow down the tyre size designation mean. whenever there is rain, snow or ice on Example tyre size designation: the road to reduce the possibility of los- (These numbers are provided as an ing control of the vehicle.

  • Page 57: Maximum Permissible Inflation Pressure

    Maintenance Tyres and wheels 4. Tyre ply composition and material Speed Rating Maximum Speed Symbol The number of layers or plies of rubber- 180 km/h coated fabric in the tyre. Tyre manufac- 190 km/h turers also must indicate the materials in 210 km/h the tyre, which include steel, nylon, poly- 240 km/h...
  • Page 58 Maintenance Tyres and wheels Temperature -A, B & C that tyres be replaced after approxi- mately six (6) years of normal service. The temperature grades are A (the high- Heat caused by hot climate or frequent est), B, and C, representing the tyre's high loading conditions can accelerate resistance to the generation of heat and the aging process.
  • Page 59 Maintenance Tyres and wheels Intended Outboard Sidewall The side Air pressure is expressed in pounds per square inch (psi) or kilopascal (kPa). of an asymmetrical tyre that must always face outward when mounted on Accessory Weight The combined a vehicle. weight of optional accessories.

  • Page 60: All Season Tyres

    Rim A metal support for a tyre and upon All season tyres which the tyre beads are seated. Kia specifies all season tyres on some Sidewall The portion of a tyre between models to provide good performance for the tread and the bead.

  • Page 61: Summer Tyres

    M+S (Mud and Snow) on the tyre side wall. if you plan to operate your vehicle in snowy or icy conditions, Kia recom- mends the use of snow tyres or all sea- son tyres on all four wheels.

  • Page 62: Tyre Chains

    Maintenance Tyres and wheels Tyre chains ply or bias belted tyres when used on the same vehicle will seriously deterio- Tyre chains, if necessary, should be rate vehicle handling. The best rule to installed on the front wheels. follow is: Identical radial-ply tyres should Be sure that the chains are installed in always be used as a set of four.
  • Page 63 If the replacement fuse blows, this indi- cates an electrical problem. Avoid using the system involved and immediately consult a professional workshop. Kia recommends to visit an authorised Kia dealer/service partner. Three kinds of fuses are used: blade OQYi073039 type for lower amperage rating, car-...
  • Page 64 Remodelling Prohibited a professional workshop. Kia recom- Do not rewire your vehicle in any way as mends to visit an authorised Kia dealer/ doing so may affect the performance of service partner. several safety features in your vehicle.

  • Page 65: Replacing Inner Panel Fuse

    If it fits loosely, we recommend 4. Check the removed fuse; replace it if that you consult a professional work- it is blown. shop. Kia recommends to visit an Spare fuses are provided in the authorised Kia dealer/service partner. engine compartment fuse panel.

  • Page 66: Main Fuse (Multi Fuse)

    Maintenance Fuses Main fuse (Multi fuse) NOTICE If the multi fuse is blown, consult a pro- fessional workshop. Kia recommends to consult an authorised Kia dealer/service partner. Driver's side fuse panel OAYI074038 If the multi fuse is blown, it must be removed as follows: 1.
  • Page 67 Maintenance Fuses Refer to the following table for a description of the fuse.
  • Page 68 Maintenance Fuses PDC Junction Block Fuse Name Symbol Fuse rating Circuit Protected P/WINDOW Power Window Relay A/C3 7.5A MTC,FATC, A/CON BRAKE 7.5A Stop lamp Switch, BDC SWITCH A/CON(MTC/FATC), FATC PANEL, SAL UNIT, MOOD LAMP, ADAS MEMORY1 PRK ECU A/BAG IND 7.5A OHCL TCU3...
  • Page 69 Maintenance Fuses Fuse Name Symbol Fuse rating Circuit Protected MULTIMEDIA CCNC (Connected Car Navigation Cockpit) CONSOLE SW, FATC PANEL, CRASH PAD SW, IS MIRR, CCNC, A/ MODULE5 CON(MTC/FATC), CDU, PIO DASH CAM, RR USB, AIR PURIFIER, AMP, SEAT VENT, PWR SEAT, HEAD LAMP(HLLD) CLUSTER 7.5A CLUSTER...
  • Page 70 Maintenance Fuses Fuse Name Symbol Fuse rating Circuit Protected A/C2 7.5A MTC, FATC USB CHAR- USB CHARGER P/WINDOW POWER WINDOW MOTOR MODULE6 7.5A AMP (Amplifier) SUNROOF2 SUNROOF(BLIND MTR) CRASH PAD SW, FRT CAMERA, MUT, ADAS PRK ECU, FRT MODULE4 RADAR, DCU(U2) POWER SEAT PWR SEAT P/WINDOW...

  • Page 71: Engine Compartment Fuse Panel

    Maintenance Fuses Engine compartment fuse panel OAYI074064 OAYI074041 Refer to the following table for a description of the fuse.
  • Page 72 Maintenance Fuses Engine room Junction Block Fuse Name Symbol Fuse rating Circuit Protected MAIN FUSE [(Petrol) 1.0 T-GDi] 150A+80A+80A (ALT+MDPS ALT+MDPS +COOLING FAN/GLOW OOLING FAN/ [(Diesel) 1.5 VGT] GLOW) 180A+80A+100A ABS (Anti-lock Brake System) / ESC Only ABS1 40A/60A ESC + EPB ABS (Anti-lock Brake System) / ESC Only ABS2 ESC + EPB...
  • Page 73 Maintenance Fuses Fuse Name Symbol Fuse rating Circuit Protected A/C1 A/CON COOLING FAN [(Diesel) 1.5 VGT] 50A [(Diesel) 1.5 VGT] DSL DCU1 DCU, ECU START FUEL PUMP FUEL PUMP ECU2 ECU3 ECU3 DCT3 DCT (Dual Clutch Transmission) 10 A ECU1 [(Petrol) 1.0 T-GDi] IG- Coil [(Petrol) 1.0T-GDi] IG-Coil...
  • Page 74 Maintenance Fuses Fuse Name Symbol Fuse rating Circuit Protected ECU5 [(Petrol) 1.0T-GDi] 15A [(Petrol) 1.0T-GDi] ECU TCU2 [(Diesel) 1.5] 25A [(Diesel) 1.5] TCU2 SNSR1 SENSOR SNSR2 SENSOR SNSR3 SNSR3 WIPER FRT2 WIPER HORN HORN DCT1 DCT ECU DCT2 DCT ECU DCT3 DCT ECU WIPER FRT1...
  • Page 75 Maintenance Fuses Fuse Name Symbol Fuse rating Circuit Protected HEAD LAMP Head Lamp LH HEAD LAMP Head Lamp RH *1: MDPS (Motor Driven Power Steering) is the same as EPS (Electric Power Steering). Refer to the following table for the relay type.
  • Page 76 Maintenance Fuses Relay Relay Name Symbol Circuit Protected BLOWER BLOWER MOTOR, ICU A/CON A/CON, ECU C/FAN COOLING FAN, ECU or DCU ECU START START SOLENOID, ECU FUEL PUMP FUEL PUMP, ECU ECU, PCU, TCU (Transmission Control MAIN Unit), SENSOR FRT WIPER HIGH WIPER MOTOR FRT WIPER LOW WIPER MOTOR...
  • Page 77 Maintenance Fuses Relay Name Symbol Circuit Protected Power Window Up Power Window Power Window Down Power Window...

  • Page 78: Light Bulbs

    Otherwise, it may cause damage to the We recommend that the headlight aim- fuse or electric wiring system. ing be adjusted by an authorised Kia dealer/service partner after an accident Fully install light bulbs and any parts or after the headlight assembly is rein- used to secure them.

  • Page 79: Light Bulb Position (Front)

    If you don't have the necessary tools, the correct bulbs and the expertise, consult a professional workshop. Kia recom- mends to visit an authorised Kia dealer/ OAYI074002 service partner. In many cases, it is diffi- Headlamp - Type C...

  • Page 80: Light Bulb Position (Rear)

    Maintenance Light bulbs Light bulb position (Rear) back up lamp Rear combination lamp - Type A OAYI074050 1 Tail lamp/Stop lamp (Bulb type) OAYI074004 2 Rear reflector Rear combination lamp – Type B 3 Turn signal lamp (Bulb type) 4 Tail lamp (LED type) 5 Stop lamp (LED type) 6 License plate lamp (Bulb type) 7 High mounted stop lamp (Bulb type)

  • Page 81: Headlamp Bulb

    Maintenance Light bulbs Headlamp bulb To prepare replacing the lamp bulb: 1. Open the bonnet. To replace the headlamp (low/high) bulb: 1. Remove the front bumper. 2. Remove the headlight from vehicle by unscrewing the 2 bolts on top of the OQYi073057 headlight.
  • Page 82 6. Reassemble the socket and the lens part. 7. Connect the bulb electrical connector. 8. Reinstall the lamp assembly to the body of the vehicle. If it does not operate, Kia recommends to visit an authorised Kia dealer/service partner or a professional workshop.

  • Page 83: Replacing Side Repeater Lamp (Led Type) Bulb

    Kia recommends to visit an assembly. authorised Kia dealer/service partner. 6. Remove the bulb from the socket by...
  • Page 84 If the tail lamp (1) or tail and stop lamp OAYI074050 (2) does not operate, we recommend that the system be checked by a profes- sional workshop. Kia recommends to visit an authorised Kia dealer/service partner. Tail lamp – Type B OAYI074066 1.
  • Page 85 Maintenance Light bulbs Replacing high mounted stop lamp (LED type) 1. Open the tailgate. OAYI074068 5. Pull out the bulb from socket. 6. Insert a new bulb in the socket. 7. Install the high mounted stop lamp in OAYI074045 the reverse order of removal. Replacing license plate lamp (bulb type) OAYI074059...
  • Page 86 If the map lamp (LED) (1) does not oper- OAYI074053 ate, have your vehicle checked by a pro- WARNING fessional workshop. Kia recommends to Prior to working on the Interior lamps, visit an authorised Kia dealer/service ensure that the "OFF" button is partner.
  • Page 87 Prior to working on the Interior lamps, have your vehicle checked by a profes- ensure that the "OFF" button is sional workshop. Kia recommends to depressed to avoid burning your fingers visit an authorised Kia dealer/service or receiving an electric shock.
  • Page 88 2. Remove the bulb by pulling it straight professional workshop. Kia recommends out. to visit an authorised Kia dealer/service 3. Install a new bulb in the socket. partner. 4. Align the lens cover tabs with the...

  • Page 89: Appearance Care

    Maintenance Appearance care Appearance care Finish maintenance Use the information in the following sec- Washing tions to keep the exterior and interior of your vehicle clean. To help protect your vehicle's finish from rust and deterioration, wash it thor- Exterior care oughly and frequently at least once a Use the information in the following sec- month with lukewarm or cold water.

  • Page 90: High-Pressure Washing

    Maintenance Appearance care 僅 To prevent damage to the plastic trical circuits located in the engine parts and lamps, do not clean with compartment. chemical solvents or strong deter- 僅 Never allow water or other liquids to gents. come in contact with electrical/elec- tronic components and air duct inside the vehicle as this may damage them.

  • Page 91: Corrosion Protection

    Maintenance Appearance care and may develop into a major repair removing it. The lower edges of the expense. doors, rocker panels, and frame mem- bers have drain holes that should not NOTICE clog with dirt; trapped water in these If your vehicle is damaged and requires areas can cause rusting.

  • Page 92: Common Causes Of Corrosion

    Maintenance Appearance care Common causes of corrosion to the visible surfaces but particularly to the underside of the vehicle. The most common causes of corrosion on your vehicle are: To help prevent corrosion 僅 Road salt, dirt and moisture that is You can help prevent corrosion from allowed to accumulate underneath beginning by observing the following:...

  • Page 93: Interior Care

    Maintenance Appearance care Keep your garage dry Interior general precautions Don't park your vehicle in a damp, Prevent chemicals such as perfume, cos- poorly ventilated garage. This creates a metic oil, sun cream, hand cleaner, and favorable environment for corrosion. air freshener from contacting the interior This is particularly true if you wash your parts because they may cause damage...

  • Page 94: Cleaning The Upholstery And Interior Trim

    Maintenance Appearance care to read the instructions and consult a a large wiping motion and moderate specialist when using leather coating pressure using a soft sponge or microfi- or protective agents. ber cloth. 僅 Leather with bright colours (beige, Velcro closures on clothing or sharp cream beige) is easily contaminated objects may cause snagging or and clear in appearance.

  • Page 95: Cleaning The Lap/Shoulder Belt Webbing

    CAUTION rised Kia dealer/service partner in accor- Rear window dance with the maintenance schedule in Do not scrape or scratch the inside of this manual.

  • Page 96: Purge Control Solenoid Valve (Pcsv)

    Maintenance Emission control system crankcase, the fresh air mixes with blow- exhaust emissions whilst maintaining by gases, which then pass through the good vehicle performance. Positive Crankcase Ventilation (PCV) valve into the induction system. Engine exhaust gas precautions 2. Evaporative emission control (carbon monoxide) (including Onboard Refuelling 僅...
  • Page 97 (if equipped) system. All inspections and adjust- WARNING ments must be made by a profes- sional workshop. Kia recommends to Catalytic converter visit an authorised Kia dealer/service Keep away from the catalytic converter partner.

  • Page 98: Diesel Particulate Filter (If Equipped)

    "check exhaust sys- professional workshop and check the tem" pops up even though the vehicle DPF system. Kia recommends to visit an was driven as mentioned above, we rec- authorised Kia dealer/service partner. If ommend that you have the PPF system...
  • Page 99 Maintenance Emission control system Selective Catalytic Reduction (if Low urea solution warning mes- equipped) sage (if equipped) The Selective Catalytic Reduction (SCR) system is to catalytically convert NOx to Nitrogen and Water by using the reduc- tion agent, the urea solution. WARNING 僅...
  • Page 100 Maintenance Emission control system the driving pattern, environmental con- dition and road profile, the deducted remaining mileage may differ from the actual travel distance. When "Low Urea" or "Refill Urea" message is displayed, a sufficient amount of urea solution must be added.

  • Page 101: Malfunction With The Scr System

    Otherwise, the vehicle can't be restarted once the engine is turned off by the ENGINE START/STOP button. In this case, have your vehicle inspected by a professional workshop. Kia recommends to contact an authorised Kia dealer/service partner.

  • Page 102: Clearing The Vehicle-Restarting Restriction

    Maintenance Emission control system Clearing the vehicle-restarting restriction No restart Low urea solution level OMQ4073035L A: Refill urea tank or vehicle will not start Urea solution system failure (= no urea solution injection) OMQ4073031L A: Service Urea system in 0km or vehicle will not start Refill with correct urea in 000km...
  • Page 103 Maintenance Emission control system solution level, have your vehicle inspected by a professional workshop. Kia recom- mends to contact an authorised Kia dealer/service partner. Adding urea solution Refilling urea solution with a refill bottle Refilling urea solution with a refill 僅...
  • Page 104 Maintenance Emission control system profile, driving pattern and environmen- vehicle components, including the tal condition) DPF system. Any unverified additives in the urea solution may clog the SCR * It takes some time to update the cluster catalyst and cause other malfunc- gauges after the urea solution injec- tions, which require the expensive tion.
  • Page 105 When the bottle of urea solution con- workshop. Kia recommends to contact tainer is opened, pungent smelling an authorised Kia dealer/service part- fumes may escape.
  • Page 106 A: Diesel filter regeneration required. After adding incorrect urea solution, See owner’s manual please visit the nearby authorised Kia dealer/ service partner as early as possible. 僅 Liquid that are not recommended such as diesel, petrol, and alcohol...
  • Page 107 (MIL) appears with DPF indicator in spite can restart the self regeneration mode of the procedure, please visit an autho- again. (Self regeneration conditions rised Kia dealer/service partner and then should be satisfied.) check the Diesel Catalyst and engine system including oil level inspection.

  • Page 108: Service Check

    (MIL) appears with DPF indicator in spite to about 2000 and it continues for of the procedure, please visit an autho- 30~60 minutes. After the end of rised Kia dealer/service partner and then regeneration, engine RPM drop to idle check the Diesel Catalyst and engine automatically.

  • Page 109: Features Of Your Vehicle

    Features of your vehicle Panorama sunroof Power sunshade 僅 Push the sunroof switch upward, the sunroof glass tilts open. However, if the power sunshade is close, the sun- shade will open first. 僅 Push the sunroof switch upward or forward when the sunroof glass is tilt opened, the sunroof glass automati- cally closes.

  • Page 110: Automatic Reversal

    Features of your vehicle Panorama sunroof Automatic reversal Open the sunroof and remove dust regularly using a clean cloth. 僅 Do not try to open the sunroof when the temperature is below freezing or when the sunroof is covered with snow or ice.

  • Page 111: Sunroof Open Warning

    Features of your vehicle Panorama sunroof Sunroof open warning Sunroof resetting procedure: 1. It is recommended to perform the reset procedure with the vehicle engine running. Start the vehicle in P (Park). 2. Make sure the power sunshade and sunroof glass are in the fully closed position.

  • Page 112: Steering Wheel

    The steering wheel vehicle operation, have the system may become difficult to control or checked by a professional workshop. Kia operate abnormally. In this case, have recommends to visit an authorised Kia the system inspected by a profes- dealer/service partner.

  • Page 113: Tilt Steering Wheel

    Features of your vehicle Steering wheel Tilt steering wheel NOTICE A tilt steering wheel allows you to adjust After adjustment, sometimes the lock- the steering wheel before you drive. You release lever may not lock the steering can also raise it to give your legs more wheel.

  • Page 114: Inside Rear View Mirror

    Features of your vehicle Mirrors Mirrors Day/night rearview mirror (if equipped) This vehicle is equipped with inside and outside rearview mirrors to provide views of objects behind the vehicle. Inside rearview mirror Adjust the rearview mirror so that the centre view through the rear window is seen.

  • Page 115: Outside Rearview Mirror

    2 Roadside assist button mirror, do not force the mirror for adjustment. To remove ice, use a deicer 3 Virtual assist button (Kia Connect) spray, or a sponge or soft cloth with 4 Sensor warm water.
  • Page 116 Features of your vehicle Mirrors Adjusting the outside rearview Folding the outside rearview mir- mirrors The electric remote control mirror switch allows you to adjust the position of the Manual type left and right outside rearview mirrors. To fold the outside rearview mirror: 僅...
  • Page 117 Features of your vehicle Mirrors CAUTION In case it is an electric type outside rear- view mirror, don't fold it by hand. It could cause motor failure.

  • Page 118: Instrument Cluster

    Features of your vehicle Instrument cluster Instrument cluster Type A OAYI034104 Type B OAYI034105 * The actual cluster in the vehicle may differ from the illustration. 1 Warning and indicator lights 2 Transmission shift indicator (if equipped) 3 Distance to empty 4 Speedometer 5 Tachometer 6 Fuel gauge...
  • Page 119 Features of your vehicle Instrument cluster Gauges Tachometer The gauges display various information Type A such as the speed of the vehicle, and so Speedometer Type A OMQ4033105 Type B OMQ4033103 Type B OMQ4033104 The tachometer indicates the approxi- mate number of engine revolutions per minute (rpm).

  • Page 120: Engine Coolant Temperature Gauge

    Features of your vehicle Instrument cluster Engine coolant temperature Fuel gauge gauge Type A Type A OAYI034108 Type B OAYI034106 Type B OAYI034109 This gauge indicates the approximate OAYI034107 amount of fuel remaining in the fuel This gauge indicates the temperature of tank.

  • Page 121: Distance To Empty

    Features of your vehicle Instrument cluster Distance to empty light comes on or when the gauge indi- cator comes close to the "E" level. Type A CAUTION Avoid driving with a extremely low fuel level. Running out of fuel could cause the engine to misfire damaging the cata- lytic converter.

  • Page 122: Outside Temperature Gauge

    Features of your vehicle Instrument cluster Transmission shift indicator gallons) of fuel are added to the vehi- cle. Transmission shift indicator displays 僅 The fuel economy and distance to gear information depending on your empty may vary significantly based vehicle's transmission type. on driving conditions, driving habits, and condition of the vehicle.

  • Page 123: Warning Lights

    僅 When there is a malfunction with the SRS. In this case, have the vehicle inspected by a professional workshop. Kia recommends to visit an authorised Kia dealer/service partner. Seat belt warning light This warning light informs the driver that the seat belt is not fas- tened.
  • Page 124 1. Drive carefully to the nearest safe by a professional workshop. Kia recom- location and stop your vehicle. mends to visit an authorised Kia dealer/ 2. With the engine stopped, check the service partner. brake fluid level immediately and add fluid as required (For more details, refer to "Brake fluid"...

  • Page 125: Electronic Parking Brake (Epb) Warning Light (If Equipped)

    In this case, have the vehicle 僅 When there is a malfunction with the inspected by a professional workshop. EPS. Kia recommends to visit an authorised In this case, have the vehicle Kia dealer/service partner. inspected by a professional workshop.
  • Page 126 In this case, have the vehicle inspected by a professional This warning light appears: workshop as soon as possible. Kia rec- 僅 When the fuel tank is nearly empty. ommends to visit an authorised Kia dealer/service partner.

  • Page 127: Master Warning Light

    Instrument cluster In this case, have the vehicle Master warning light inspected by a professional workshop as soon as possible. Kia recommends This indicator light appears: to visit an authorised Kia dealer/ser- 僅 This warning light informs the driver vice partner.
  • Page 128 DPF system can be damaged and the vehicle inspected by a profes- fuel consumption can worsen. sional workshop as soon as possible. Kia recommends to visit an authorised Kia dealer/ service partner. SCR warning light (Diesel Engine) Exhaust system (DPF or LNT)

  • Page 129: Electronic Stability Control (Esc) Indicator Light

    Electronic stability control (ESC) In this case, have the vehicle inspected by a professional workshop. Kia recom- indicator light mends to visit an authorised Kia dealer/ service partner. This indicator light appears: This warning light blinks: 僅 Once you set the ignition switch or ENGINE START/STOP button to the 僅...
  • Page 130 In this case, have the vehicle In this case, have the vehicle inspected by a professional workshop. inspected by a professional workshop. Kia recommends to visit an authorised Kia recommends to visit an authorised Kia dealer/service partner. Kia dealer/service partner.

  • Page 131: Glow Indicator Light (Diesel Engine)

    僅 Yellow: When Lane Safety is disabled, cle inspected by a professional or a malfunction is detected. workshop. Kia recommends to visit an If the yellow warning light remains on authorised Kia dealer/service partner. after the sensor has been uncovered or...
  • Page 132 Features of your vehicle Instrument cluster mends to visit an authorised Kia dealer/ pedal with the auto hold system acti service partner. vated. 僅 Yellow: When there is a malfunction NOTICE with the auto hold system. Engine preheating In this case, have your vehicle If the engine does not start within 10 inspected by a professional workshop.

  • Page 133: Lcd Display Control

    Control Action unblocked, we recommend that your Mode (1) vehicle be inspected by an authorised Short Press Changing view modes Kia dealer/service partner. Up/Down (2) Short Roll Searching Utility information This indicator light blinks: Short Press Operating additional functions 僅 Yellow: Driver Attention Warning rec-...

  • Page 134: Navigation View

    Features of your vehicle Instrument cluster LCD display modes Instant Fuel Economy 僅 This mode displays the instant fuel economy during the last few seconds View Description when the vehicle speed is more than 8 km/h (5 MPH). Driving Assist Displays information related to Driver assis- view tance system...
  • Page 135 Features of your vehicle Instrument cluster Utility information view Information since refuelling This display shows the trip distance, the Low tyre pressure warning dis- average fuel efficiency, and the instant play fuel efficiency (or the total driving time) since refuelling. OAYI034111 Information related to tyre pressure.
  • Page 136 Features of your vehicle Instrument cluster Other view modes 1 Trip 2 Timer Service mode 3 Avg. This mode reminds you of scheduled 僅 Accumulated information is calculated maintenance information. after the vehicle has run for more than 300 metres. 僅...
  • Page 137 Features of your vehicle Instrument cluster Driver Assistance settings (info- LCD display messages tainment system) Door, bonnet, trunk, sunroof open OAYI034121 select Settings → Vehicle → Driver OAYI034118 assistance on the infotainment system 僅 This warning is displayed indicating screen to set the Driver Assistance func- which door, the bonnet, the trunk or tion.

  • Page 138: Engine Overheated

    Features of your vehicle Instrument cluster Wiper mode Press START button whilst turn- ing wheel (for smart key system) 僅 This warning message illuminates if the steering wheel does not unlock normally when the ENGINE START/ STOP button is pressed. 僅...

  • Page 139: Battery Saver Function

    Daytime Running Light (DRL) (if a professional workshop. Kia recom- equipped) mends to visit an authorised Kia The Daytime Running Light (DRL) can dealer/service partner. make it easier for others to see the front...

  • Page 140: Lighting Control

    Features of your vehicle Lighting * When the DRL is on, the position and When the light switch is in the head light tail lamps will also be on. position, head light (low beam), tail, license light will turn ON. Lighting control NOTICE The light switch has a headlight and a...

  • Page 141: Operating High Beam

    Features of your vehicle Lighting Operating turn signals and lane Operating high beam change signals OAYI034039 To turn on the high beam headlamp: OAYI034041 The ignition switch or ENGINE START/ 僅 Push the lever away from you. STOP button must be ON for the turn The lever will return to its original signals to function.

  • Page 142: Headlight Levelling Device

    Features of your vehicle Lighting High Beam Assist (HBA) (if NOTICE equipped) If an indicator flash is abnormally quick or slow, a bulb may be burned out or have a poor electrical connection in the circuit. Headlight levelling device OAYI034043 High Beam Assist is a function that auto- matically adjusts the headlamp range (switches between high beam and low...

  • Page 143: Display And Control

    Features of your vehicle Lighting High Beam Assist Setting - The High Beam indicator light ( ) will appear on the cluster when high beam is on. 僅 When High Beam Assist is operating, if the headlamp lever or switch is used, the function operates as follows: - If the headlamp lever is pulled towards you when the high beam is...
  • Page 144 Master warning light ( ) will ward Collision-Avoidance Assist (FCA) appear on the cluster. Have the function (Front Camera Only) (if equipped)" on inspected by an authorised Kia dealer/ page 6-3. service partner. Limitations of High Beam Assist...

  • Page 145: Wipers And Washers

    Features of your vehicle Wipers and washers Wipers and washers until the snow and/or ice is removed before using the windscreen wipers to The wipers and washers remove foreign ensure proper operation. If you do not substances from the windscreen and remove the snow and/or ice before rear window, helping to maintain visibil- using the wiper and washer, it may dam-...

  • Page 146: Operating Rear Window Wiper And Washer Switch

    Features of your vehicle Wipers and washers The reservoir filler neck is located in the front of the motor compartment on the driver side. CAUTION To prevent possible damage to the washer pump, do not operate the OAYI034047 washer when the fluid reservoir is - HI - Normal wiper operation empty.

  • Page 147: Interior Lights

    Features of your vehicle Interior lights Interior lights The lamps go out after approxi- mately 30 seconds. This vehicle is equipped with lights - The map lamp and room lamp throughout the vehicle to illuminate the come on for approximately 30 sec- interior.

  • Page 148: Welcome System (If Equipped)

    Features of your vehicle Welcome system Room lamp Welcome system (if equipped) The welcome system is a function that illuminates the surroundings or the inte- rior when the driver approaches or exits the vehicle. Headlight (headlamp) escort OAYI034072 function (if equipped) 僅...
  • Page 149 Features of your vehicle Defroster Defroster (if equipped) 僅 Press the rear window defroster but- ton. The vehicle is equipped with a defroster The indicator on the rear window for removing frost or fog from the rear defroster button illuminates when the window.

  • Page 150: Climate Control System

    4. Set the fan speed control to the desired speed. Air conditioning (A/C) Kia air conditioning systems are filled Heating with R-134a refrigerant. 1. Start the vehicle. Press the A/C but- 1. Set the mode to the position.

  • Page 151: Air Conditioning System Operation Tips

    僅 Operating the air conditioning system a professional workshop. Kia recom- in the recirculated air position pro- mends to visit an authorised Kia dealer/ vides maximum cooling; however, service partner. continual operation in this mode may cause the air inside the vehicle to become stale.

  • Page 152: Checking The Amount Of Air Conditioner Refrigerant And Compres- Sor Lubricant

    OGL3034405L professional workshop. Kia recommends * The actual air conditioning refrigerant to visit an authorised Kia dealer/service label in the vehicle may differ from the partner. illustration. Each symbol and specification on the air...
  • Page 153 To prevent damage, the air condi- tioning system in your vehicle should only be serviced by trained and certified Kia technicians. Sunroof inside air recirculation (if equipped) The outside (fresh) air position is auto- matically selected, when the sunroof is opened.

  • Page 154: Manual Climate Control System (If Equipped)

    Features of your vehicle Manual climate control system Manual climate control system (if equipped) The manual climate control system uses cooling and heating to help maintain a pleasant environment inside the vehicle. OAYI034302 1 Temperature control button 2 Front windscreen defroster button 3 Rear window defroster (if equipped) 4 Mode selection button 5 Air intake control button...

  • Page 155: Heating And Air Conditioning Manually

    Features of your vehicle Manual climate control system Heating and air conditioning manually OAYI034303 1. Start the engine. 2. Set the mode to the desired position. For improving the effectiveness of heating and cooling; 僅 Heating: 僅 Cooling: 3. Set the temperature control to the desired position. 4.

  • Page 156: Mode Selection

    Features of your vehicle Manual climate control system Mode selection Controlling the vents The mode selection buttons control the direction of the air flow through the ven- tilation system. OCL4M034314N Air can be directed to the floor, dash- board outlets, or windscreen. Five sym- OAYI034304 bols are used to represent Face, Bi- Level, Floor, Floor-Defrost and Defrost...

  • Page 157: Controlling Air Intake

    Features of your vehicle Manual climate control system 僅 Cool air: The blue indicator begins to In addition, prolonged use of the air con- illuminate in the middle and moves to ditioning with the recirculated air posi- the left as the temperature decreases. tion selected will result in excessively dry air in the passenger compartment.

  • Page 158: Controlling Fan Speed

    Features of your vehicle Manual climate control system Controlling fan speed Air conditioning (A/C) The fan speed control button allows you to control the fan speed of the air flow- ing from the ventilation system. The ENGINE START/STOP button must be in the ON position for fan operation.

  • Page 159: Automatic Climate Control System (If Equipped)

    Features of your vehicle Automatic climate control system Automatic climate control system (if equipped) The automatic climate control system uses cooling and heating to help maintain a pleasant environment inside the vehicle. Climate control display OAYI034310 Instrument panel OAYI034311 1 Infotainment system screen on/off 8 Fan speed control/off button button 9 Fan speed control/off lever...

  • Page 160: Heating And Air Conditioning Automatically

    Features of your vehicle Automatic climate control system 2. Press the temperature control lever NOTICE up or down to the desired tempera- Operating the blower when the ignition ture. switch or ENGINE START/STOP button is in the ON position could cause the bat- tery to discharge.
  • Page 161 Features of your vehicle Automatic climate control system Heating and air conditioning manually The heating and cooling system can be controlled manually by pressing buttons other than the AUTO lever. OAYI034312 In this case, the system works sequentially according to the order of buttons selected. 1.
  • Page 162 Features of your vehicle Automatic climate control system Mode selection Most of the air flow is directed to the floor and the windscreen with a small The mode selection button controls the amount directed to the side window direction of the air flow through the ven- defrosters and side air vents.
  • Page 163 Features of your vehicle Automatic climate control system Temperature control Outside (fresh) air position With the outside (fresh) air position selected, air enters the vehicle from out- side and is heated or cooled according to the function selected. The indicator light will turn off.

  • Page 164: Turning Off The Front Air Climate Control

    Features of your vehicle Automatic climate control system Controlling fan speed Turning off the front air climate control The fan speed can be set to the desired speed by operating the Fan speed con- Climate control display trol lever. To change the fan speed: 僅...

  • Page 165: Windscreen Defrosting And Defogging

    Features of your vehicle Windscreen defrosting and defogging Windscreen defrosting and Defogging inside windscreen with manual climate control sys- defogging The windscreen defrosting and defog- ging removes the frost and moisture on the windscreen for better visibility. WARNING Windscreen heating Do not use the position during cooling operation in extremely...
  • Page 166 Features of your vehicle Windscreen defrosting and defogging Defrosting outside windscreen 3. Press the defroster button ( with manual climate control sys- 4. The outside (fresh) air position will be selected automatically and the air conditioning will turn on according to the detected ambient temperature.

  • Page 167: Storage Compartment

    Features of your vehicle Storage compartment Storage compartment Glove box These compartments can be used to store small items required by the driver or passengers. CAUTION 僅 To avoid possible theft, do not leave valuables in the storage compart- OAYI034051 ment.

  • Page 168: Sunglass Holder

    Features of your vehicle Storage compartment Sunglass holder Luggage board You can place first aid kit, reflector trian- gle, etc. under the luggage board. OAYI034052 To open the sunglass holder: OAYI034053 僅 Press the cover and the holder will slowly open. Place your sunglasses with the lenses facing out.

  • Page 169: Interior Features

    Features of your vehicle Interior features Interior features Front - Type B There are various features inside the vehicle for the convenience of the occu- pants. Ambient light (if equipped) The ambient lights are applied to the front instrument panel, centre console OAYI034056 and front door.
  • Page 170 Features of your vehicle Interior features electrical/electronic system and dam- The temperature setting of the seat age electrical/electronic parts. changes according to the button posi- tion. 僅 When cleaning spilled liquids, do not dry the cup holder at high tempera- 僅...

  • Page 171: Sun Visor

    WARNING inspected by a professional workshop. 僅 Use the power outlet only when the Kia recommends to visit an authorised vehicle is on and remove the acces- Kia dealer/service partner. sory plug after use. Using the acces-...

  • Page 172: Usb Charger

    Features of your vehicle Interior features touch with a wet hand. You may get an get heated up whilst charging. For the electric shock. safety reason, charging can be stopped if the battery gets heated up to a certain point of temperature that the devices CAUTION can be negatively affected.

  • Page 173: Wireless Smartphone Charging System (If Equipped)

    Features of your vehicle Interior features 僅 If the charger is connected incorrectly, turn off. In such cases, remove the it can cause serious damage on the smartphone from the pad and replace devices. Please note that damages it on the pad again, or double-check due to incorrect usage are not cov- the charging status.
  • Page 174 Features of your vehicle Interior features 僅 The wireless charging will stop when mobile phones, which are not verified the smartphone is not in complete for the Qi specification ( ). contact with the wireless charging 僅 For certain mobile phones with their pad.

  • Page 175: Floor Mat Anchor(S) (If Equipped)

    Features of your vehicle Interior features Floor mat anchor(s) (if equipped) CAUTION Hanging clothing Do not hang heavy clothes, since they may damage the hook. WARNING OAYI034066 Do not hang other objects such as hang- When using a floor mat on the front floor ers or hard objects except clothes.

  • Page 176: Removal And Installation

    To remove the cargo area cover: Cargo and accessories can be attached 1. Whilst lifting the cover up, hold the directly to the roof rack or to Kia cross area near the front slots. Then, pull up members (available from an authorised the cover at approximately 45 °...

  • Page 177: Load Limits

    Load limits rack. This is especially true when car- The Kia roof rack can support up to 400 rying large, flat items such as wood kg. (880 lbs.), evenly distributed (i.e., panels or mattresses. This could...
  • Page 178 Before installing an accessory such as a and to other road users. It could also cargo carrier or roof tent, make sure that result in an accident and in serious injury the item is compatible with your Kia's and death. roof racks. Check the accessory manufacturer's manual and online information.

  • Page 179: Infotainment System

    Features of your vehicle Infotainment system Infotainment system 僅 To postpone the update, press Later (2). NOTICE Preparing software update When attaching metallic tinted paper to the glass, the communication function of the radio reception function, connected car service, and automatic headlight turn-on function may not work normally.

  • Page 180: Updating Software

    For more information, see "Over-The-Air Software Update" page on the Kia webpage, scan the QR code on the infotainment screen or refer to the user manual in the Cus- tomer centre → Download centre.

  • Page 181: Shark Fin Antenna

    OBD terminal and then restarting the vehicle. 僅 If the update is not complete success- fully, contact Kia. 僅 Vehicle reception must be identified to safely install any downloaded soft- OAYI034070 ware.

  • Page 182: How Vehicle Radio Works

    Features of your vehicle Infotainment system How vehicle radio works AM reception FM reception OGL3061070L AM broadcasts can be received at greater distances than FM broadcasts. OGL3061067L This is because AM radio waves are AM and FM radio signals are broadcast transmitted at low frequencies.
  • Page 183 Features of your vehicle Infotainment system This can lead to undesirable or unpleas- ant listening conditions which might lead you to believe a problem exists with your radio. The following conditions are normal and do not indicate radio trouble: 僅 Fading - As your vehicle moves away from the radio station, the signal will weaken and sound will begin to fade.
  • Page 184 Features of your vehicle Infotainment system WARNING Cell phone use Do not use a mobile phone whilst driv- ing. Stop at a safe location to use a mobile phone.
  • Page 186 Driving your vehicle Driving your vehicle Be sure the exhaust system does not leak......... 5-3 Before driving ................5-3 Key positions.................. 5-5 僅 Ignition switch position .................. 5-5 僅 Starting the engine..................5-5 僅 Stopping the petrol engine/diesel engine (Manual Transmission)................... 5-8 ENGINE START/STOP button ............5-9 僅...
  • Page 187 Driving your vehicle 僅 Electronic Stability Control (ESC) system..........5-41 僅 Vehicle Stability Management (VSM) system ........5-44 僅 Brake Assistant System (BAS) ..............5-45 僅 Hill-start Assist Control (HAC) ..............5-45 僅 Emergency Stop Signal (ESS)..............5-45 僅 Good braking practices................5-46 Drive mode integrated control system ........5-47 僅...

  • Page 188: Driving Your Vehicle

    僅 Check the condition of the tyres. checked as soon as possible by a profes- sional workshop. Kia recommends to 僅 Check under the vehicle for any sign visit an authorised Kia dealer/service of leaks.

  • Page 189: Before Starting

    Driving your vehicle Before driving Before starting fere with the operation of the foot ped- als, possibly causing an accident. 僅 Close and lock all doors. 僅 Position the seat so that all controls WARNING are easily reached. 僅 Buckle your seat belt. Driving whilst intoxicated 僅...

  • Page 190: Key Positions

    Driving your vehicle Key positions Key positions (if equipped) warning light can be checked in this position. Ignition switch position WARNING Ignition switch 僅 Never turn the ignition switch to LOCK or ACC whilst the vehicle is moving. This would result in loss of directional control and braking function, which could cause an accident.
  • Page 191 Driving your vehicle Key positions 僅 Do not start the vehicle with the accel- erator pedal depressed. The vehicle can move and lead to an accident. 僅 Wait until the engine rpm is normal. The vehicle may suddenly move if the brake pedal is released when the rpm is high.

  • Page 192: Starting The Diesel Engine

    Driving your vehicle Key positions Starting the diesel engine speeds. (Steep accelerating and decelerating should be avoided.) To start the diesel engine when the engine is cold, it has to be pre-heated Glow indicator light before starting the engine and then have to be warmed up before starting to drive.

  • Page 193: Starting And Stopping The Engine For Turbocharger Intercooler

    Driving your vehicle Key positions Starting and stopping the engine Stopping the petrol engine/diesel for turbocharger intercooler engine (Manual Transmission) 1. Do not race or accelerate the engine 1. Make sure the vehicle is completely immediately after starting. stopped and keep the clutch pedal (for manual transmission) and brake If the engine is cold, idle for several pedal depressed.

  • Page 194: Engine Start/Stop Button

    OAYI044001 by a professional workshop. Kia recom- The light will go off after about 30 sec- mends to visit an authorised Kia dealer/ onds when the door is closed. It will also service partner. go off immediately when the theft-alarm In addition, if the ENGINE START/STOP system is armed.
  • Page 195 Driving your vehicle ENGINE START/STOP button button for more than 2 seconds or 3 times successively within 3 seconds. With manual transmission If the vehicle is still moving, to restart the vehicle: Press the ENGINE START/STOP button 僅 Manual transmission - Press the when the button is in the ACC position ENGINE START/STOP button with without depressing the clutch pedal.

  • Page 196: Starting The Engine With Smart Key

    Driving your vehicle ENGINE START/STOP button Starting the engine transmission vehicles, the engine will not start and the ENGINE START/STOP but- WARNING ton changes as follow: 僅 Do not start the vehicle with the accel- OFF → ACC → ON → OFF or ACC erator pedal engaged.

  • Page 197: Starting The Petrol Engine

    Driving your vehicle ENGINE START/STOP button and road conditions permit, you may put 僅 Do not turn the ignition switch to the the shift lever in the N (Neutral) position START position with the engine run- whilst the vehicle is still moving and ning.
  • Page 198 Driving your vehicle ENGINE START/STOP button You can also start the engine when the shift lever is in the N (Neutral) position. 4. Press the ENGINE START/STOP but- ton. It should be started without depress- OAYI054096 ing the accelerator pedal. A: Shift to neutral for auto start 5.

  • Page 199: 僅 Stopping The Petrol Engine/Diesel Engine

    Driving your vehicle Manual transmission Manual transmission (if NOTICE equipped) If the ENGINE START/STOP button is The manual transmission has 5 forward pressed once more whilst the engine is gears and 1 reverse gear. pre-heating, the engine may start. Manual transmission operation Starting and stopping the engine for turbocharger intercooler 1.
  • Page 200 Driving your vehicle Manual transmission lever sideways in such a manner that WARNING the second gear is engaged. Such a 僅 Before leaving the driver's seat, drastic downshift may cause the always set the parking brake fully and engine speed to increase to the point shut the engine off.

  • Page 201: 僅 Good Driving Practices

    Driving your vehicle Manual transmission again before it returns to the normal 僅 Slow down when you encounter cross position. winds. This gives you much better control of your vehicle. If the pedal is repeatedly depressed before returning to its normal position, 僅...

  • Page 202: Automatic Transmission

    Driving your vehicle Automatic transmission Automatic transmission (if ule) or PCM (Powertrain Control Mod- ule). equipped) For smooth operation, depress the brake pedal when shifting from N (Neutral) to a forward or reverse gear. WARNING Automatic transmission 僅 Always check the surrounding areas near your vehicle for people, espe- cially children, before shifting a vehi- cle into D (Drive) or R (Reverse).

  • Page 203: Transmission Ranges

    Kia recom- sudden acceleration, the transmis- mends to visit an authorised Kia sion may overheat, and a warning dealer/service partner to prevent sound and a warning message appear unexpected accidents.
  • Page 204 Driving your vehicle Automatic transmission P (Park) on the slightest incline unless the park- ing brake or service brakes are applied. Always come to a complete stop before shifting into P (Park). This position locks WARNING the transmission and prevents the front Do not drive with the shift lever in N wheels from rotating.

  • Page 205: Paddle Shifter (If Equipped)

    Driving your vehicle Automatic transmission Paddle shifter (if equipped) 僅 When the vehicle speed decreases below 9 km/h (5 mph) The paddle shift function is available when the shift lever is in the D (Drive) NOTICE position or the manual mode. 僅...
  • Page 206 Driving your vehicle Automatic transmission To shift the transmission from P (Park) 僅 Slow down before shifting to a lower into R (Reverse): gear. Otherwise, the lower gear may not be engaged. 1. Depress and hold the brake pedal. 僅 Always use the parking brake. Do not 2.

  • Page 207: Moving Up A Steep Grade From A Standing Start

    Driving your vehicle Automatic transmission 僅 The risk of rollover is greatly brake pedal, the car may roll backward, increased if you lose control of your resulting in a fatal accident. vehicle at highway speeds. Always come to a complete stop before 僅...

  • Page 208: Dual Clutch Transmission (Dct)

    Driving your vehicle Dual clutch transmission (DCT) Dual clutch transmission (DCT) the P (Park) position, then set the parking brake, and place the ignition (if equipped) switch in the LOCK/OFF position. Unexpected and sudden vehicle movement can occur if these precau- tions are not followed.

  • Page 209: 僅 Dct Warning Messages

    Driving your vehicle Dual clutch transmission (DCT) 僅 The dual clutch transmission incorpo- 僅 When driving downhill, you may wish rates a dry-type dual clutch mecha- to move the gear shift lever to Manual nism, which allows for better Shift mode and downshift to a lower acceleration performance and gear in order to control your speed increased fuel efficiency whilst driv-...
  • Page 210 Driving your vehicle Dual clutch transmission (DCT) time, a warning message will appear running, apply the parking brake after on the LCD display. shifting the vehicle to N (Neutral) with the brake pedal depressed, and allow 僅 If the LCD warning is active, the foot the transmission to cool.
  • Page 211 R (Reverse) whilst the vehicle is smoothly. in motion. If any of the warning messages in the LCD display continue to blink, for your safety, Kia recommends to visit an N (Neutral) authorised Kia dealer/service partner. The wheels and transmission are not Transmission ranges engaged.

  • Page 212: 僅 Shift Lock System

    P (Park) to keep the car from moving. workshop. Kia recommends to visit an 僅 Exercise extreme caution when driv- authorised Kia dealer/service partner. ing on a slippery surface. Be espe-...
  • Page 213 Driving your vehicle Dual clutch transmission (DCT) ing operation the vehicle may suddenly WARNING move forward of backward as it 僅 When driving uphill or downhill, becomes unstuck, causing injury or always shift to D (Drive) for driving damage to nearby people or objects. forward or shift to R (Reverse) for driving backwards, and check the Paddle shifter (if equipped)
  • Page 214 Driving your vehicle Dual clutch transmission (DCT) Shift lock system 僅 When the accelerator pedal is gently depressed for more than 6 seconds For your safety, the automatic transmis- whilst driving (not available in sport sion has a shift lock system which pre- mode) vents shifting the transmission from P 僅...
  • Page 215 Driving your vehicle Dual clutch transmission (DCT) 僅 Never take the vehicle out of gear and 僅 Always buckle-up! In a collision, an coast down a hill. This may be unbelted occupant is significantly extremely hazardous. Always leave more likely to be seriously injured or the vehicle in gear when moving.

  • Page 216: Brake System

    Driving your vehicle Brake system Brake system release the parking brake. Depress the accelerator gradually whilst releasing Your vehicle has power-assisted brakes, the service brakes. parking brake, and various braking sys- When accelerating from a stop on a tems for safe driving. steep hill, the vehicle may have a ten- Power brakes dency to roll backwards.

  • Page 217: Brake Over Accelerator

    If none are found and the condition per- applied. Applying the brakes lightly will sists, Kia recommends to visit an autho- indicate whether they have been rised Kia dealer/service partner. affected in this way. Always test your...

  • Page 218: Parking Brake (If Equipped)

    Driving your vehicle Brake system Parking brake (if equipped) CAUTION After parking the vehicle, apply the park- Replace brake pads ing brake to prevent the vehicle from Do not continue to drive with worn brake being moved by the external force. pads.

  • Page 219: Releasing The Parking Brake

    Kia recommends to visit an autho- rised Kia dealer/service partner. 僅 Be cautious when parking on a hill. Firmly engage the parking brake and...

  • Page 220: Electronic Parking Brake (Epb)

    Driving your vehicle Brake system Electronic Parking Brake (EPB) Applying the parking brake OGL3044025L A: Parking brake automatically applied 僅 If the driver turns the engine off by mistake whilst Auto Hold is operating, EPB will be automatically applied. But if the driver turns the engine off and pushes the EPB switch in 1 second, OAYI044014_2...
  • Page 221 Kia recommends to visit an authorised once and a message will appear. Kia dealer/service partner. Releasing the parking brake OGL3034124L...
  • Page 222 EPB may have malfunctioned. If this occurs, have the system inspected by a professional CAUTION workshop. Kia recommends to visit an 僅 To prevent unintentional movement authorised Kia dealer/service partner. when stopped and leaving the vehicle,...
  • Page 223 Driving your vehicle Brake system AUTO HOLD green indicating the AUTO HOLD is engaged. The vehicle will remain at a The AUTO HOLD is designed to maintain standstill even if you release the brake the vehicle in a standstill even though pedal.
  • Page 224 Take your vehicle to a professional HOLD light remains white and the workshop and have the system checked. EPB automatically applies): Kia recommends to visit an authorised - The driver's door is opened. Kia dealer/service partner. - The engine bonnet is opened.

  • Page 225: 僅 Anti-Lock Brake System (Abs)

    Driving your vehicle Brake system At this moment, press the [AUTO HOLD] button after closing the driver's door and engine bonnet. Anti-lock Brake System (ABS) The Anti-lock Brake System (ABS) pre- vents the wheels from locking. So the OMQ4033163L vehicle remains stable and can still be A: AUTO HOLD turning Off! Press steered.

  • Page 226: Electronic Stability Control (Esc) System

    NOTICE Otherwise, you may have a problem A click sound may be heard in the vehi- with the ABS. Contact an authorised Kia cle compartment when the vehicle dealer/service partner as soon as possi- begins to move after the vehicle is ble.

  • Page 227: Esc Operation

    Driving your vehicle Brake system that cause the vehicle to lose traction. and indicate that the Electronic Stability Even with ESC installed, always follow all Control system is functioning properly. the normal precautions for driving - including driving at safe speeds for the conditions.

  • Page 228: Indicator Light

    Driving your vehicle Brake system Indicator light vehicle, the ESC will automatically turn on again. ESC indicator light ESC OFF indicator light ONQ5041438N A: Traction Control disabled When ENGINE START/STOP button is turned to ON, the indicator light ESC off state 1 appears, then goes off if the ESC system To turn off the traction control function is operating normally.

  • Page 229: Vehicle Stability Management (Vsm) System

    Driving your vehicle Brake system If ESC is turned off whilst ESC is operat- Steering)). This is only the effect of brake ing, the vehicle may slip out of control. and MDPS control and indicates nothing unusual. NOTICE The VSM does not operate when: 僅...

  • Page 230: Driving Your Vehicle

    Brake system Hill-start Assist Control (HAC) your vehicle checked by an authorised Kia dealer/service partner. A vehicle has the tendency to roll back The VSM is not a substitute for safe driv- on a steep hill when it starts to go after ing practices but a supplementary func- stopping.

  • Page 231: 僅 Good Braking Practices

    P and normal, stop as soon as it is safe to do block the rear wheels so the vehicle so and call an authorised Kia dealer/ cannot roll. Then release the parking service partner for assistance.

  • Page 232: Drive Mode Integrated Control System

    Driving your vehicle Drive mode integrated control system Drive mode integrated control When ECO mode is activated: system (if equipped) 僅 The acceleration response may be slightly reduced if the accelerator The drive mode may be selected accord- pedal is engaged moderately. ing to the driver's preference or road 僅...

  • Page 233: Operation

    Driving your vehicle Drive mode integrated control system Traction mode operation NOTICE Traction mode offers special traction In SPORT mode, the fuel efficiency may tuning for SNOW/MUD/SAND, optimiz- decrease. ing available traction in adverse condi- tions. Traction mode adjusts left and Traction Mode (if equipped) right wheel slip control, engine torque Traction Control is a system that achieve...
  • Page 234 Resume driving" appears you can continue to drive your vehicle. If the warning messages in the LCD dis- play continue to blink, for your safety, Kia recommends to visit an authorised Kia dealer/service partner. OAYI034126 A: Cooling... Remain parked for 00 min.

  • Page 235: Economical Operation

    Driving your vehicle Economical operation Economical operation 僅 Be sure that the wheels are aligned correctly. Improper alignment can Your vehicle's fuel economy depends result from hitting kerbs or driving too mainly on your style of driving, where fast over irregular surfaces. Poor you drive and when you drive.

  • Page 236: Special Driving Conditions

    僅 Do not pump the brake pedal on a vehicle equipped with ABS. Kia recommends to visit an authorised Kia dealer/service partner. 僅 If stalled in snow, mud, or sand, use the second gear. Accelerate slowly to WARNING avoid spinning the drive wheels.

  • Page 237: Smooth Cornering

    Driving your vehicle Special driving conditions 僅 Slow down and keep more distance WARNING between you and other vehicles, as it Sudden Vehicle Movement may be more difficult to see at night, Do not attempt to rock the vehicle if especially in areas where there may people or objects are nearby.

  • Page 238: Highway Driving

    Driving your vehicle Special driving conditions 僅 Driving too fast through large puddles WARNING can affect your brakes. If you must go Under/over inflated tyres through puddles, try to drive through Always check the tyres for proper infla- them slowly. tion before driving.

  • Page 239: Winter Driving

    M+S (Mud and Snow) on the dealer for maximum speed recommen- tyre side wall. if you plan to operate your dations. vehicle in snowy or icy conditions, Kia WARNING recommends the use of snow tyres or all season tyres on all four wheels.
  • Page 240 Driving your vehicle Winter driving Tyre chains the steering wheel fully to one side) when driving the vehicle. (If you are making a full turn, drive with the speed below 10 km/h.) Chain installation When installing chains, follow the manu- OQYi043016 facturer's instructions and mount them Since the sidewalls of radial tyres are...

  • Page 241: Change To "Winter Weight" Oil If Necessary

    Driving your vehicle Winter driving aren't sure what weight oil you should CAUTION use, Kia recommends to consult an 僅 Chains that are the wrong size or authorised Kia dealer/service partner. improperly installed can damage your vehicle's brake lines, suspension, Check spark plugs and ignition body and wheels.

  • Page 242: Don't Let Ice And Snow Accumulate Underneath

    Driving your vehicle Winter driving Don't let your parking brake Drive your vehicle when water freeze vapour condenses and accumu- lates inside the exhaust pipes Under some conditions your parking brake can freeze in the engaged posi- When the vehicle is stopped for a long tion.

  • Page 243: Vehicle Weight

    Driving your vehicle Vehicle weight Vehicle weight cargo). The GVWR is shown on the certi- fication label located on the driver's door This section will guide you in the proper sill. loading of your vehicle and/or trailer, to keep your loaded vehicle weight within CAUTION its design rating capability, with or with- Do not use replacement tyres with lower...
  • Page 244 Driver assistance system Driver assistance system Forward Collision-Avoidance Assist (FCA) (Sensor Fusion)..6-3 僅 Forward Collision-Avoidance Assist settings ........6-4 僅 Forward Collision-Avoidance Assist operation ........6-6 僅 Forward Collision-Avoidance Assist malfunction and limitations......................6-9 Lane Keeping Assist (LKA)............6-14 僅 Lane Keeping Assist settings ..............6-14 僅...
  • Page 245 Driver assistance system 僅 Rear View Monitor settings ...............6-46 僅 Rear View Monitor operation..............6-47 僅 Rear View Monitor malfunction and limitations.......6-49 Surround View Monitor (SVM)..........6-50 僅 Surround View Monitor settings............. 6-50 僅 Surround View Monitor operation............6-51 僅 Surround View Monitor malfunction and limitations .....6-54 Forward/Side/Reverse Parking Distance Warning (PDW)..

  • Page 246: Driver Assistance System

    Driver assistance system Forward Collision-Avoidance Assist (FCA) (Sensor Fusion) Driver assistance system Junction Turning function INFORMATION The description of the driver assistance system displayed on the screen may dif- fer from the content of the owner's man- ual depending on the infotainment software version.
  • Page 247 Do not spray pressurized water sors. directly on the sensor or sensor cover. CAUTION 僅 The genuine Kia front radar sensor covers are parts with quality and per- 僅 Never disassemble the detecting sen- formance ensured. If arbitrarily apply-...
  • Page 248 Driver assistance system Forward Collision-Avoidance Assist (FCA) (Sensor Fusion) 2 Driving Safety Safety → Forward Safety Warning Timing on the infotainment system to 3 Forward Safety change the initial warning activation tim- With the vehicle on, select Settings → ing of Forward Collision-Avoidance Vehicle →...

  • Page 249: Collision Warning

    Driver assistance system Forward Collision-Avoidance Assist (FCA) (Sensor Fusion) 僅 Warning Volume: Adjusts the volume The collision warning operates under the of the warning sound. following vehicle speed conditions, depending on the vehicle in front. 僅 Driving Safety Priority: Lowers all other audio volumes when the Driving 僅...
  • Page 250 Driver assistance system Forward Collision-Avoidance Assist (FCA) (Sensor Fusion) may be temporarily limited or may not blinking ( ), warning message, and an work. audible warning. Collision warning will be activated in the Stopping vehicle and ending following conditions: brake control 僅...
  • Page 251 Driver assistance system Forward Collision-Avoidance Assist (FCA) (Sensor Fusion) When the vehicle is stopped due to 僅 Oncoming vehicle or powered two- emergency braking, the warning mes- wheeler speed: Approximately above sage will appear on the cluster. 10 km/h (6 mph) For your safety, the driver should Emergency braking depress the brake pedal immediately...

  • Page 252: 僅 Forward Collision-Avoidance Assist Malfunction And Limitations

    Safety warning light ( ), and the from the rear bumper), Kia recommends Master warning light ( ) will appear on that you visit an authorised Kia dealer/ the cluster. Kia recommends that you service partner. visit an authorised Kia dealer/service WARNING partner.
  • Page 253 Driver assistance system Forward Collision-Avoidance Assist (FCA) (Sensor Fusion) 僅 Even after starting the vehicle again, 僅 The brightness outside is low, and the Forward Collision-Avoidance Assist headlamps are not on or are not may not function properly when the bright obstruction or malfunction condition 僅...
  • Page 254 Driver assistance system Forward Collision-Avoidance Assist (FCA) (Sensor Fusion) 僅 The cyclist in front is on a bicycle as a vehicle, powered two-wheeler, made of material that does not reflect pedestrian and cyclist. on the front radar 僅 The pedestrian or cyclist is wearing 僅...
  • Page 255 Driver assistance system Forward Collision-Avoidance Assist (FCA) (Sensor Fusion) - Driving through a roadside with if necessary, steer the vehicle and trees or streetlights depress the brake pedal to reduce your driving speed in order to main- - Driving through a narrow road tain a safe distance.
  • Page 256 Driver assistance system Forward Collision-Avoidance Assist (FCA) (Sensor Fusion) 僅 Changing lanes tain a safe braking distance, and if necessary, steer your vehicle and depress the brake pedal to reduce your driving speed in order to main- tain a safe distance. When a vehicle (2) in front of you merges out of the lane, Forward Colli- sion-Avoidance Assist may not imme-...

  • Page 257: Lane Keeping Assist (Lka) (If

    Driver assistance system Lane Keeping Assist (LKA) Lane Keeping Assist (LKA) (if 僅 When you are towing a trailer or another vehicle, we recommend that equipped) Forward Collision-Avoidance Assist is Whilst driving over a certain speed, Lane turned off due to safety reasons. Keeping Assist detects lane markings (or 僅...
  • Page 258 Driver assistance system Lane Keeping Assist (LKA) With the vehicle on, select Settings → 僅 Warning Volume: Adjusts the volume Vehicle → Driver Assistance → Driving of the warning sound. Safety on the infotainment system. 僅 Driving Safety Priority: Lowers all 僅...

  • Page 259: Lane Departure Warning

    Driver assistance system Lane Keeping Assist (LKA) Warning and control Hands-off warning The Lane Keeping Assist function is warned and controlled in the following way. 僅 Lane Departure Warning 僅 Lane Keeping Assist Lane Departure Warning (left side) OAYI054071 A: Keep hands on steering wheel If the driver takes their hands off the steering wheel for several seconds, the warning message will appear on the...

  • Page 260: 僅 Lane Keeping Assist Malfunction And Limitations

    ( ) indicator light will appear on the cluster. If this occurs, have the function inspected by a professional workshop. Kia recommends that you visit an authorised Kia dealer/service partner. OAYI054079 Lane detected Lane Keeping Assist disabled...
  • Page 261 僅 There are more than two lane mark- vehicle inspected by an authorised Kia ings (or road edges) on the road dealer/service partner. 僅 The lane markings (or road edges) are...
  • Page 262 Driver assistance system Lane Keeping Assist (LKA) depending on road conditions and - The vehicle is not driven in the surroundings. Always be cautious centre of the lane when Lane Keep- whilst driving. ing Assist is turned on or right after changing a lane.

  • Page 263: Manual Speed Limit Assist (Msla)

    Driver assistance system Manual Speed Limit Assist (MSLA) Manual Speed Limit Assist (MSLA) (if equipped) OAYI054035 3. The set speed limit will be displayed on the cluster. If you would like to drive over the pre- OGL3054223L 1 Speed Limit indicator set speed limit, depress the accelera- tor pedal.
  • Page 264 Driver assistance system Manual Speed Limit Assist (MSLA) Resuming Manual Speed Limit 僅 Manual Speed Limit Assist does not substitute for proper and safe driving. Assist It is the responsibility of the driver to always drive safely and should always be aware of unexpected and sudden situations from occurring.

  • Page 265: Driver Attention Warning (Daw)

    Driver assistance system Driver Attention Warning (DAW) Driver Attention Warning Driver Attention Warning set- tings (DAW) (if equipped) With the vehicle on, select Settings → Inattentive Driving Warning func- Vehicle → Driver Assistance→ Driver tion Attention Warning on the infotainment Driver Attention Warning monitors your system.
  • Page 266 Driver assistance system Driver Attention Warning (DAW) 僅 Warning Volume: Adjusts the volume time is shorter than 4 minutes or 4 of the warning sound. minutes has not passed after the last break was suggested. 僅 Driving Safety Priority: Lowers all other audio volumes when the Driving WARNING Safety system sounds a warning.
  • Page 267 (snow, rain, or foreign material) is removed (including trailer, carrier, etc. from the rear bumper), Kia recommends OAYI054090 that you visit an authorised Kia dealer/ A: Check Driver Assistance system. service partner. When Driver Attention Warning is not working properly, the warning message...
  • Page 268 Driver assistance system Driver Attention Warning (DAW) terrain), where there is nothing to If a vehicle cuts in front of your vehi- detect, or detecting sensor is covered cle, Leading Departure Alert may not in foreign material after turning ON operate properly.
  • Page 269 Driver assistance system Driver Attention Warning (DAW) 僅 When the vehicle ahead abruptly 僅 When driving at a tollgate or intersec- departures tion OAYI054040 OAYI054043 If the vehicle in front abruptly depar- If you pass a tollgate or intersection tures, Leading Vehicle Departure Alert with lots of vehicles or you drive may not operate properly.

  • Page 270: Blind-Spot View Monitor (Bvm)

    Driver assistance system Blind-Spot View Monitor (BVM) Blind-Spot View Monitor Blind-Spot View Monitor opera- tion (BVM) (if equipped) Turn signal lever Blind-Spot View Monitor displays the rear blind spot area of the vehicle in the cluster uses a wide-angle camera amounted on the vehicle, when the turn signal is turned on to help safely change lanes.

  • Page 271: Cruise Control (Cc) (If

    Cruise Control operation display normally, have Blind-Spot View Monitor be inspected by a professional Setting speed workshop. Kia recommends visiting an authorised Kia dealer/service partner. WARNING 僅 Blind-Spot View Monitor may display objects at a different distance from...
  • Page 272 OAYI054047 If Cruise Control pauses during a situa- 僅 Push the (-) switch down and release tion that is not mentioned, Kia recom- it immediately. The set speed will mends that you visit an authorised Kia decrease by 1 km/h increments.To dealer/service partner.

  • Page 273: Resuming Cruise Control

    Driver assistance system Cruise Control (CC) Resuming Cruise Control NOTICE If your vehicle is equipped with Manual Speed Limit Assist, press and hold the Driving Assist button to turn off Cruise Control. However, Manual Speed Limit Assist will turn on. OAYI054049_3 WARNING Operate the (+), (-) or ( ) switch.

  • Page 274: Smart Cruise Control (Scc) (If

    Driver assistance system Smart Cruise Control (SCC) Smart Cruise Control (SCC) (if CAUTION equipped) 僅 Always keep the front view camera and front radar in good condition to Basic function maintain optimal performance of Smart Cruise Control. Smart Cruise Control detects a vehicle 僅...
  • Page 275 Driver assistance system Smart Cruise Control (SCC) 僅 Forward Collision-Avoidance Assist INFORMATION brake control is operating 僅 Ensure that Warning Method you NOTICE have set may apply to the Warning Method of other driver assistance When stopped behind another vehicle, systems.
  • Page 276 Driver assistance system Smart Cruise Control (SCC) driving direction, always check the Each time the button is pressed, the road conditions at all times. headway changes as follows: Turning on Smart Cruise Control For example, if you drive at 90 km/h (56 mph), the distance is maintained as fol- lows: 僅...
  • Page 277 Driver assistance system Smart Cruise Control (SCC) Resuming Smart Cruise Control 僅 You can increase the set speed to 170 km/h (105 mph). WARNING Check the driving condition before using the (+) switch. Driving speed may sharply increase when you push up and hold the (+) switch.
  • Page 278 Driver assistance system Smart Cruise Control (SCC) Turning off Smart Cruise Control 1. Whether there is a vehicle ahead and the selected distance level 2. Whether there is a vehicle ahead and the target vehicle distance 3. Set speed 僅 When temporarily cancelled 1.

  • Page 279: In Traffic Situation

    Driver assistance system Smart Cruise Control (SCC) WARNING WARNING Be careful when accelerating temporar- When Smart Cruise Control is temporar- ily, because the speed and distance is ily cancelled, distance with the front not controlled automatically even if vehicle will not be maintained. Always there is a vehicle in front of you.
  • Page 280 Driver assistance system Smart Cruise Control (SCC) Depress the accelerator pedal or operate 僅 Smart Cruise Control may not the (+) switch, (-) switch or ( ) switch to recognise unexpected and sudden sit- start driving. uations or complex driving situations, so always pay attention to driving Warning road conditions ahead conditions and control your vehicle...
  • Page 281 Have Smart Cruise Control be inspected 僅 If any other function's warning mes- by a professional workshop. Kia recom- sage is displayed or warning sound is mends that you visit an authorised Kia generated, Smart Cruise Control dealer/service partner. warning message may not be dis-...
  • Page 282 Driver assistance system Smart Cruise Control (SCC) Smart Cruise Control will operate prop- 僅 The surrounding is very dark, such as erly when snow, rain or foreign material in a tunnel, etc. is removed. Always keep it clean. 僅 The brightness changes suddenly, for example when entering or exiting a WARNING tunnel...
  • Page 283 Driver assistance system Smart Cruise Control (SCC) 僅 The vehicle in front is suddenly 僅 Driving through a tunnel or iron blocked by an obstacle bridge 僅 The vehicle in front suddenly changes 僅 Driving near areas containing metal a lane or suddenly reduces speed substances, such as a construction zone, railroad, etc.
  • Page 284 Driver assistance system Smart Cruise Control (SCC) Check to be sure that the road condi- Cruise Control may not immediately tions permit safe operation of Smart detect the vehicle when the vehicle Cruise Control and if necessary, changes lanes abruptly. In this case, depress the brake pedal to reduce you must maintain a safe braking dis- your driving speed in order to main-...
  • Page 285 Driver assistance system Smart Cruise Control (SCC) 僅 When a vehicle in front of you merges out of the lane OAYI054052 When a vehicle in front of you merges out of the lane, Smart Cruise Control may not immediately detect the new OAYI054019_2 vehicle that is now in front of you.

  • Page 286: Lane Following Assist (Lfa) (If

    Driver assistance system Lane Following Assist (LFA) Lane Following Assist (LFA) (if Method from the settings menu in the infotainment system to change the fol- equipped) lowing settings: Lane Following Assist detects lane mark- 僅 Warning Volume: Adjusts the volume ings and/or a vehicle ahead on the road, of the warning sound.
  • Page 287 Driver assistance system Lane Following Assist (LFA) Warning and control Lane Following Assist OAYI054078 A: LFA (Lane Following Assist) can- celled OAYI054073 If the driver still does not have their If the vehicle ahead and/or both lane hands on the steering wheel after the markings are detected and Your driving hands-off warning the warning message speed is below 170 km/h (105 mph), the...
  • Page 288 If this occurs, have Lane Following Assist be inspected by a professional work- OAYI054077 shop. Kia recommends that you visit an 僅 The images and colours in the instru- authorised Kia dealer/service partner. ment cluster may differ depending on...

  • Page 289: Rear View Monitor (Rvm) (If

    Driver assistance system Rear View Monitor (RVM) Rear View Monitor (RVM) (if Method of other driver assistance systems. equipped) 僅 Warning Method will maintain its last Rear View Monitor displays the area setting even if the vehicle is restarted. behind your vehicle to help with safe 僅...
  • Page 290 Driver assistance system Rear View Monitor (RVM) NOTICE 僅 The setting menu may not be avail- able for your vehicle depending on the vehicle specifications. 僅 The horizontal lines of the Rear View Parking Guidelines indicate dis- OAYI054057 tances of 0.5 m (20 in), 1 m (40 in) and 2.3 m (92 in) from the vehicle Operating conditions based on the empty vehicle condition.
  • Page 291 Driver assistance system Rear View Monitor (RVM) Extended Rear View Monitor The rear top view shows an image of the vehicle looking down from above, allow- Extended Rear View Monitor function ing you to determine the distance from maintains the rear view of the vehicle the rear vehicle or object when parking.

  • Page 292: 僅 Rear View Monitor Malfunction And Limitations

    (petrol, acetone etc.). camera image does not display properly, This may damage the camera lens. Kia recommends that you visit an 僅 Driving with the trunk open is not rec- authorised Kia dealer/service partner. ommended. Please exercise extreme Limitations of Rear View Monitor caution to ensure safety.

  • Page 293: Surround View Monitor (Svm)

    Driver assistance system Surround View Monitor (SVM) Surround View Monitor (SVM) Method from the settings menu in the infotainment system to change the fol- (if equipped) lowing settings: The surround view monitor uses cam- 僅 Parking Safety Priority: Lowers all eras mounted on the vehicle and dis- other audio volumes when Surround plays images around the vehicle through...

  • Page 294: Front View

    Driver assistance system Surround View Monitor (SVM) Top View Parking GuideLines Auto On from the infotainment system screen to use the function. If the Top View Parking Guidelines are selected, the Top View Parking Guide- NOTICE lines are displayed in the top view on For more details on Surround View Mon- the right side of the surround view moni- itor Auto On, refer to "Surround View...
  • Page 295 Driver assistance system Surround View Monitor (SVM) Rear view pressing the switch view button (2) on the surround view monitor screen. Operating conditions The front view function of the surround view monitor operates under the follow- ing conditions: OAYI054110 僅 shift from R (Reverse) to N (Neutral) or D (Drive) at 15 km/h or less.
  • Page 296 Driver assistance system Surround View Monitor (SVM) 僅 Press the back button (3) on the sur- 僅 When driving below 15 km/h, press round view monitor screen in P (Park- the Switching view button (2) on the ing). surround view monitor screen. 僅...
  • Page 297 The 3D view function of the Surround normally, Kia recommends visiting an View Monitor whilst parking will be authorised Kia dealer/service partner. turned off under the following condi-...

  • Page 298: Forward/Side/Reverse Parking Distance Warning (Pdw)

    Driver assistance system Forward/Side/Reverse Parking Distance Warning (PDW) Forward/Side/Reverse Park- image in the screen my not look cor- rect. ing Distance Warning (PDW) 僅 Always keep the camera lens clean. If (if equipped) the lens is covered with foreign mate- Forward/Side/Reverse Parking Distance rial, it may adversely affect camera Warning uses the front, side and rear...

  • Page 299: 僅 Forward/Side/Reverse Parking Distance Warning Settings

    Driver assistance system Forward/Side/Reverse Parking Distance Warning (PDW) Rear side ultrasonic sensors the vehicle features and specifica- tions. Parking Distance Warning Auto You can set the parking distance warn- ing to always be on at low speeds. To OAYI054062 use Parking Distance Warning Auto On Refer to the picture above for the function, select Settings →...
  • Page 300 Driver assistance system Forward/Side/Reverse Parking Distance Warning (PDW) Forward Parking Distance Warn- Warning indication and warning sound Forward Parking Distance Warning will operate when one of the condition is sat- Warning indicator Distance Warning isfied. from object sound Cluster Infotainment 僅...
  • Page 301 Driver assistance system Forward/Side/Reverse Parking Distance Warning (PDW) (If Settings → Vehicle → Driver side-way warning is not displayed on Assistance → Parking Safety → the cluster. Parking Distance Warning Auto On 僅 The shape of the indicator may differ on the infotainment system selected) from the actual vehicle.

  • Page 302: 僅 Forward/Side/Reverse Parking Distance Warning Malfunction And Precautions

    If it still does not work properly even after you have removed the contamina- tion, we recommend you visit an authorised Kia dealer/service partner. NOTICE An warning light ( ) is displayed in the target direction if a malfunction or ultra-...
  • Page 303 僅 Sharp or slim objects, such as ropes, mal, or object. chains or small poles. 僅 If the Parking Distance Warning does 僅 Narrow objects, such as corners of a not operate properly, Kia recom- square column mends that you visit an authorised Kia dealer/service partner.

  • Page 304: Reverse Parking Collision-Avoidance Assist (Pca)

    Driver assistance system Reverse Parking Collision-Avoidance Assist (PCA) Reverse Parking Collision- 僅 Driving with the trunk open is not rec- ommended. Please exercise extreme Avoidance Assist (PCA) (if caution to ensure safety. equipped) Reverse Parking Collision-Avoidance Assist helps to prevent collisions by warning or braking when nearby objects or pedestrians are detected whilst driv- ing at low speeds.
  • Page 305 Driver assistance system Reverse Parking Collision-Avoidance Assist (PCA) 3 Rear Safety 僅 The setting menu may not exist based on vehicle specification. With the vehicle on, touch Settings → Vehicle → Driver Assistance → Park- ing Safety on the infotainment system. Reverse Parking Collision- Avoid- 僅...

  • Page 306: 僅 Reverse Parking Collision- Avoidance Assist Settings

    If it still does NOTICE not work properly, Kia recommends that 僅 The Parking Collision-Avoidance you visit an authorised Kia dealer/ser- Assistant operates once when shifted vice partner.
  • Page 307 If it still does not work of a different size is installed properly even after decontamination is - Wide view camera(s) or ultrasonic removed, Kia recommends that you visit sensor(s) is damaged an authorised Kia dealer/service partner. - Wide view camera(s) or the ultra-...
  • Page 308 Driver assistance system Reverse Parking Collision-Avoidance Assist (PCA) - An object that generates ultrasonic - There is a large object such as a waves is nearby wall is behind the pedestrian or the object - A wireless device with a transmis- sion function operates near the rear - The object is not located at the ultrasonic sensor...
  • Page 309 僅 A pedestrian is standing behind the the ultrasonic sensor(s) is forcibly vehicle moved out of proper alignment. Kia 僅 A large obstacle, such as a vehicle, is recommends that you visit an parked in the rear centre of your vehi- authorised Kia dealer/service partner.
  • Page 310 What to do in an emergency What to do in an emergency Road warning................. 7-3 僅 Hazard warning flasher................. 7-3 In case of an emergency whilst driving........7-3 僅 If the engine stalls at a crossroad or crossing........7-3 僅 If you have a flat tyre whilst driving ............7-3 僅...

  • Page 311: What To Do In An Emergency

    What to do in an emergency 僅 Triangle reflector.................... 7-23...

  • Page 312: What To Do In An Emergency

    What to do in an emergency Road warning What to do in an emergency In case of an emergency whilst driving Road warning If an emergency situation occurs whilst When in an emergency situation occurs driving, stay calm and take the following whilst driving or when you park by the steps.

  • Page 313: If The Engine Stalls Whilst Driving

    Kia recommends 4. Do not push or pull the vehicle to start to consult an authorised Kia dealer/ it. See instructions for "Jump starting" service partner. on page 7-5.

  • Page 314: Emergency Starting

    What to do in an emergency Emergency starting Emergency starting CAUTION When the vehicle will not start because Use only a 12-volt jumper system. You of low battery power, you may need to can damage a 12-volt starting motor, jump start the vehicle. ignition system, and other electrical parts beyond repair by use of a 24- volt Jump starting...

  • Page 315: Jump-Starting Procedure

    僅 Do not allow the (+) and (-) jumper your vehicle checked by a profes- cables to touch. It may cause sparks. sional workshop. Kia recommends to 僅 The battery may rupture or explode visit an authorised Kia dealer/service when you jump start with a low or fro- partner.

  • Page 316: Push-Starting

    What to do in an emergency If the engine overheats Push-starting If the engine overheats Your Manual Transmission-equipped If your temperature gauge indicates vehicle should not be push-started overheating, you will experience a loss because it might damage the emission of power, or hear loud pinging or knock- control system.
  • Page 317 Kia recom away from moving parts, such as mends to visit an authorised Kia the fan and drive belts, to pre dealer/service partner. vent injury. 僅 When the engine overheats from low 7.

  • Page 318: Tyre Pressure Monitoring System (Tpms)

    What to do in an emergency Tyre Pressure Monitoring System (TPMS) Tyre Pressure Monitoring Sys- by the vehicle manufacturer on the vehi- cle placard or tyre inflation pressure tem (TPMS) label. The Tyre Pressure Monitoring System (If your vehicle has tyres of a different (TPMS) detects the pressure of vehicle's size than the size indicated on the vehi- tyres and displays it on the LCD display.

  • Page 319: 僅 Low Tyre Pressure Telltale

    If any of the below happens, have the A: Low tyre pressure system checked by a professional work- The low tyre pressure position telltale shop. Kia recommends to visit an autho- light will indicate which tyre is signifi- rised Kia dealer/service partner. cantly under-inflated by illuminating the 1.

  • Page 320: 僅 Tyre Pressure Monitoring System (Tpms) Malfunction Indicator

    In this case, have the system checked by lowering of tyre pressure. a professional workshop to determine the cause of the problem. Kia recom- 僅 When you drive your vehicle from a mends to visit an authorised Kia dealer/ warm area to a cold area or from a service partner.

  • Page 321: 僅 Tyre Replacement With Tpms

    Tyre Pressure Monitoring CAUTION System (TPMS). We recommend that you use the sealant approved by Kia if your vehicle is Tyre replacement with TPMS equipped with a Tyre Pressure Monitor- If you have a flat tyre, the low Tyre Pres- ing System.

  • Page 322: If You Have A Flat Tyre (With Spare Tyre)

    What to do in an emergency If you have a flat tyre (with spare tyre) If you have a flat tyre (with never use the bumpers or any other part of the vehicle for jacking support. spare tyre) 僅 The vehicle can easily roll off the jack Jack and tools causing serious injury or death.

  • Page 323: Changing Tyres

    What to do in an emergency If you have a flat tyre (with spare tyre) Changing tyres son remain in a vehicle that is being jacked. 1. Park on a level surface and apply the parking brake firmly. 6. Loosen the wheel lug nuts counter- clockwise one turn each, but do not remove any nut until the tyre has been raised off the ground.
  • Page 324 What to do in an emergency If you have a flat tyre (with spare tyre) If this is difficult, tip the wheel slightly and get the top hole in the wheel lined up with the top stud. Then jiggle the wheel back and forth until the wheel can be slid over the other studs.

  • Page 325: Wheel Nut Tightening Torque

    Then double-check each nut for tight- recommends to consult an authorised ness. After changing wheels, have the Kia dealer/service partner. system checked by a professional workshop. Kia recommends to visit an WARNING authorised Kia dealer/service partner. Wheel studs Wheel nut tightening torque: If the studs are damaged, they may lose Steel wheel &...
  • Page 326 What to do in an emergency If you have a flat tyre (with spare tyre) 僅 The operation of this vehicle is not ventional tyre and reduces the ground recommended with more than one clearance approximately 2.5 cm (1 compact spare tyre in use at the same inch), which could result in damage to time.

  • Page 327: Jack Label

    What to do in an emergency If you have a flat tyre (with spare tyre) Jack label OQYi063025 * The actual jack label in the vehicle may differ from the illustration. For more detailed specifications, refer to the label attached to the jack. 1 Jack type 2 Maximum allowable load 3 When using the jack, set your parking brake.

  • Page 328: Towing

    Kia dealer/service partner or a dolly under the driven wheels. commercial tow-truck service. 僅 Do not tow the vehicle backwards...

  • Page 329: 僅 Removable Towing Hook

    OAYI064011 OAYI064013 If towing is necessary, we recommend you to have it done by an authorised Kia dealer/service partner or a com- mercial tow truck service. If towing service is not available in an emergency, your vehicle may be tempo-...
  • Page 330 僅 If the disabled vehicle is unable to be other than the driver must not be moved, do not forcibly continue the allowed to be on board. towing. We recommend that you con- tact an authorised Kia dealer/service partner or a commercial tow truck service for assistance.

  • Page 331: Emergency Towing Precautions

    What to do in an emergency Towing Emergency towing precautions CAUTION 僅 Turn the ignition switch to ACC so the Automatic transmission/Dual clutch steering wheel isn't locked. transmission 僅 Shift the gear to N (Neutral). 僅 If the car is being towed with all four 僅...

  • Page 332: Emergency Commodity

    What to do in an emergency Emergency commodity Emergency commodity (if equipped) There are some emergency commodi- ties in the vehicle to help you respond to the emergency situation. First aid kit There are some items such as bandage and adhesive tape and etc. in the kit to give first aid to an injured person.

  • Page 334: Maintenance

    Maintenance Maintenance Engine compartment..............8-4 Maintenance services..............8-6 Owner maintenance ..............8-7 Scheduled maintenance service ..........8-9 僅 Normal maintenance schedule..............8-10 僅 Maintenance under severe usage conditions ........8-13 Explanation of scheduled maintenance items......8-15 Engine oil and filter (for petrol)..........8-18 僅 Checking the engine oil level..............8-18 僅...

  • Page 335: Maintenance

    Maintenance 僅 Inspecting and replacing climate control air filter......8-29 Wiper blades................8-30 僅 Front windscreen wiper blade..............8-30 僅 Replacing front windscreen wiper blade..........8-30 僅 Replacing rear window wiper blade ............8-31 Battery..................8-32 Tyres and wheels ................ 8-34 僅...
  • Page 336 Maintenance 僅 Replacing side repeater lamp (LED Type) bulb....... 8-65 僅 Replacing rear turn signal lamp/tail and stop lamp (bulb type)......................8-65 僅 Replacing back up lamp (bulb type) ............ 8-66 僅 Replacing tail lamp/tail and stop lamp (LED type) (rear combination lamp type B) ..............

  • Page 337: Engine Compartment

    Engine compartment Open the bonnet to see the engine compartment. (Petrol) 1.0 T-GDi OAYI074014 * The actual engine compartment in your Kia may differ from the illustration. 1. Windscreen washer fluid reservoir 2. Engine coolant reservoir 3. Brake/clutch fluid reservoir 4.
  • Page 338 Maintenance Engine compartment (Diesel) 1.5 VGT OAYI074015 * The actual engine compartment in your Kia may differ from the illustration. 1. Windscreen washer fluid reservoir 2. Engine coolant reservoir 3. Brake/clutch fluid reservoir 4. Engine oil filler cap 5. Engine oil dipstick 6.

  • Page 339: Maintenance Services

    Kia dealers meet Kia's high service injury to yourself whenever performing quality standards and receive technical any maintenance or inspection proce- support from Kia in order to provide you dures. with a high level of service satisfaction. Should you have any doubts concerning...

  • Page 340: Owner Maintenance

    Do not touch metal parts (including strut performed by the owner or an autho- bars) whilst the vehicle is operating or rised Kia dealer. They should be per- hot. Doing so could result in serious formed at the indicated frequencies to bodily injury.
  • Page 341 Maintenance Owner maintenance Whilst operating your vehicle: blades with clean cloth dampened with washer fluid. 僅 Check for vibrations in the steering 僅 Check the headlight alignment. wheel. Notice any increased steering effort or looseness in the steering 僅 Check the lap/shoulder belts for wear wheel, or change in its straight-ahead and function.

  • Page 342: Scheduled Maintenance Service

    Maintenance Scheduled maintenance service Scheduled maintenance service Follow the Normal maintenance sched- ule if the vehicle is usually operated where none of the following conditions apply. Follow the Maintenance Under Severe Usage Conditions if any of the following conditions apply. 僅...

  • Page 343: 僅 Normal Maintenance Schedule

    Inspect for excessive valve noise and/or engine vibration and adjust if necessary. In this case, Valve clearance have the system checked by a professional workshop. Kia recommends to visit an authorised Kia dealer/service partner. For your convenience, it can be replaced prior to it's interval when you do maintenance of other Spark plug items.
  • Page 344 I: Inspect and if necessary, adjust, correct, clean or replace. R: Replace or change KIN proposed for QY PE (new) Number of months or driving distance, whichever comes first Months Km X 1,000 Smartstream G1.2 Petrol Engine oil and engine oil (Petrol) 1.0 T-GDi *1*2 filter...
  • Page 345 - If there are some important safety matters like fuel flow restriction, surging, loss of power, hard starting problem etc, replace the fuel filter immediately regard - less of maintenance schedule and consult an authorized Kia dealer/service part - ner for details.
  • Page 347 Maintenance Scheduled maintenance service Severe driving conditions A: Repeatedly driving short distance of less than 8 km (5 miles) in normal tempera - ture or less than 16 km (10 miles) in freezing temperature. B: Extensive engine idling or low speed driving for long distances. C: Driving on rough, dusty, muddy, unpaved, gravelled or saltspread roads.

  • Page 348: Explanation Of Scheduled Maintenance Items

    Fuel filter (for petrol) hoses and connections be replaced by a professional workshop. Kia recommends Kia petrol vehicle is equipped with a life- to visit an authorised Kia dealer/service time fuel filter that is integrated with the partner.
  • Page 349 Hoses should be replaced immediately if there is any evidence of deterioration or dam- age. Air cleaner filter We recommend that the air cleaner filter be replaced by a professional workshop. Kia recommends to visit an authorised Kia dealer/service partner.

  • Page 350: Brake/Clutch Fluid

    DOT 4 specification. shop according to the maintenance schedule. Kia recommends to visit an authorised Kia dealer/service partner. Parking brake NOTICE Inspect the parking brake system includ-...

  • Page 351: Engine Oil And Filter (For Petrol)

    Maintenance Engine oil and filter (for petrol) Engine oil and filter (for pet- Steering gear box, linkage & boots/lower arm ball joint rol) With the vehicle stopped and off, check Engine oil is used for lubricating, cooling, for excessive free-play in the steering and operating various hydraulic compo- wheel.

  • Page 352: 僅 Changing The Engine Oil And Filter

    Engine oil and filter (for petrol) Changing the engine oil and filter (Petrol) 1.0 T-GDi We recommend that the engine oil and filter be replaced by an authorised Kia dealer according to the Maintenance Schedule at the beginning of this chap- ter.

  • Page 353: Engine Oil (For Diesel)

    Required action according to the respective Range engine oil level Contact an authorised Kia dealer/service partner. Do not refill oil. You may add oil as long as the oil level does not go above C-range.

  • Page 354: 僅 Changing The Engine Oil And Filter

    We recommend that the engine oil and You must add oil and make sure that the oil filter replaced by a professional work- level is in the C-Range. shop. Kia recommends to visit an autho- WARNING rised Kia dealer/service partner. 僅 If the maintenance schedule to...

  • Page 355: Engine Coolant

    Maintenance Engine coolant Engine coolant NOTICE The high-pressure cooling system has a Never add any additives to the engine reservoir filled with year round anti- oil. Engine oil additives can change the freeze coolant. The reservoir is filled at properties of engine oil and may cause the factory.

  • Page 356: 僅 Checking The Coolant Level

    Maintenance Engine coolant whilst the engine is operating or hot. Doing so might lead to cooling system Mixture Percentage (volume) Ambient Tem- damage and could result in serious per- perature Antifreeze Water sonal injury from escaping hot coolant or -15 °C steam.

  • Page 357: 僅 Changing The Coolant

    Bring the level to F, but do not overfill. If frequent additions are required, we recommend that the system be inspected by a professional workshop. Kia recommends to visit an authorised Kia dealer/service partner. Changing the coolant We recommend that the coolant be...

  • Page 358: Brake/Clutch Fluid

    Brake/clutch mend that the system be checked by a fluid must be maintained periodically to professional workshop. Kia recommends ensure that the brakes operate to visit an authorised Kia dealer/service smoothly. partner. Checking the brake/clutch fluid level...

  • Page 359: Washer Fluid

    Maintenance Washer fluid Washer fluid and avoid contacting windscreen washer fluid. Serious injury or death Washer fluid is used when wiping the could occur. windscreen of the vehicle with a wind- screen wiper. You should check and refill washer fluid periodically to make sure that it doesn't run out.

  • Page 360: Parking Brake

    Also, the parking brake alone check the system. Kia recommends to should securely hold the vehicle on a visit an authorised Kia dealer/service fairly steep grade. If the stroke is more partner.

  • Page 361: Air Cleaner Filter

    僅 Use only Kia Genuine Parts or those OAYI074028 of an equivalent standard part. If not, 2. Wipe the inside of the air cleaner.

  • Page 362: Climate Control Air Filter

    Maintenance Climate control air filter Climate control air filter The climate control air filter should be replaced according to the maintenance schedule. If the vehicle is operated in severely air-polluted cities or on dusty rough roads for a long period, it should OQYi073025 be inspected more frequently and 5.

  • Page 363: Wiper Blades

    Maintenance Wiper blades Wiper blades CAUTION When the wipers no longer clean ade- To prevent damage to the wiper blades, quately, the blades may be worn or do not use petrol, kerosene, paint thin- cracked, and require replacement. ner, or other solvents on or near them. To prevent damage to the wiper arms or other components, do not attempt to Front windscreen wiper blade...

  • Page 364: 僅 Replacing Rear Window Wiper Blade

    Maintenance Wiper blades To prevent damage to the wiper arms or other components, have an autho- rised Kia dealer/service partner replace the wiper blade. OQYi073029 3. Lift it off the arm. OQYi073030 4. Install the blade assembly in the reverse order of removal.

  • Page 365: Battery

    After then ensure that tighten the cell caps. We recommend that you con- The battery powers the engine in order tact an authorised Kia dealer/service to move the vehicle as well as supplying partner. power to the various devices installed in the vehicle.
  • Page 366 The battery contains lead. Do OAYI074069 not dispose of it after use. 1. CMF45L-DIN: The Kia model name of Please return the battery to an battery authorised Kia dealer to be 2. 12V: The nominal voltage recycled.

  • Page 367: Tyres And Wheels

    Maintenance Tyres and wheels Tyres and wheels 僅 Do not allow cigarettes, sparks, or flame near the battery. For proper maintenance, safety, and 僅 Watch the battery during charging, maximum fuel economy, you must and stop or reduce the charging rate always maintain the recommended tyre in following cases: inflation pressures and stay within the...

  • Page 368: 僅 Checking Tyre Inflation Pressure

    Maintenance Tyres and wheels Checking tyre inflation pressure risk of an accident. This risk is much higher on hot days and when driving for Check your tyres once a month or more. long periods at high speeds. Use a good quality gauge to check tyre pressure.
  • Page 369 Maintenance Tyres and wheels on the tyre label located on the driver's WARNING side centre pillar. Mixing tyres Tyre rotation Do not mix bias ply and radial ply tyres To equalize tread wear, it is recom- under any circumstances. This may mended that the tyres be rotated every cause unusual handling characteristics.

  • Page 370: 僅 Compact Spare Tyre Replacement

    Wheels NOTICE Wheels that do not meet Kia specifica- tions may fit poorly and result in dam- We recommend that when replacing age to the vehicle or unusual handling tyres, use the same originally supplied and poor vehicle control.

  • Page 371: 僅 Tyre Sidewall Labeling

    Maintenance Tyres and wheels Tyres should be replaced when tread explains what the letters and numbers in wear indicators appear. Slow down the tyre size designation mean. whenever there is rain, snow or ice on Example tyre size designation: the road to reduce the possibility of los- (These numbers are provided as an ing control of the vehicle.
  • Page 372 Maintenance Tyres and wheels 4. Tyre ply composition and material Speed Rating Maximum Speed Symbol The number of layers or plies of rubber- 180 km/h coated fabric in the tyre. Tyre manufac- 190 km/h turers also must indicate the materials in 210 km/h the tyre, which include steel, nylon, poly- 240 km/h...

  • Page 373: 僅 Tyre Terminology And Definitions

    Maintenance Tyres and wheels Temperature -A, B & C that tyres be replaced after approxi- mately six (6) years of normal service. The temperature grades are A (the high- Heat caused by hot climate or frequent est), B, and C, representing the tyre's high loading conditions can accelerate resistance to the generation of heat and the aging process.
  • Page 374 Maintenance Tyres and wheels Intended Outboard Sidewall The side Air pressure is expressed in pounds per square inch (psi) or kilopascal (kPa). of an asymmetrical tyre that must always face outward when mounted on Accessory Weight The combined a vehicle. weight of optional accessories.

  • Page 375: 僅 All Season Tyres

    Rim A metal support for a tyre and upon All season tyres which the tyre beads are seated. Kia specifies all season tyres on some Sidewall The portion of a tyre between models to provide good performance for the tread and the bead.
  • Page 376 M+S (Mud and Snow) on the tyre side wall. if you plan to operate your vehicle in snowy or icy conditions, Kia recom- mends the use of snow tyres or all sea- son tyres on all four wheels.

  • Page 377: 僅 Radial-Ply Tyres

    Maintenance Tyres and wheels Tyre chains ply or bias belted tyres when used on the same vehicle will seriously deterio- Tyre chains, if necessary, should be rate vehicle handling. The best rule to installed on the front wheels. follow is: Identical radial-ply tyres should Be sure that the chains are installed in always be used as a set of four.

  • Page 378: Fuses

    If the replacement fuse blows, this indi- cates an electrical problem. Avoid using the system involved and immediately consult a professional workshop. Kia recommends to visit an authorised Kia dealer/service partner. Three kinds of fuses are used: blade OQYi073039 type for lower amperage rating, car-...
  • Page 379 Remodelling Prohibited a professional workshop. Kia recom- Do not rewire your vehicle in any way as mends to visit an authorised Kia dealer/ doing so may affect the performance of service partner. several safety features in your vehicle.

  • Page 380: 僅 Replacing Inner Panel Fuse

    If it fits loosely, we recommend 4. Check the removed fuse; replace it if that you consult a professional work- it is blown. shop. Kia recommends to visit an Spare fuses are provided in the authorised Kia dealer/service partner. engine compartment fuse panel.
  • Page 381 Maintenance Fuses Main fuse (Multi fuse) NOTICE If the multi fuse is blown, consult a pro- fessional workshop. Kia recommends to consult an authorised Kia dealer/service partner. Driver's side fuse panel OAYI074038 If the multi fuse is blown, it must be removed as follows: 1.
  • Page 382 Maintenance Fuses Refer to the following table for a description of the fuse.
  • Page 383 Maintenance Fuses PDC Junction Block Fuse Name Symbol Fuse rating Circuit Protected P/WINDOW Power Window Relay A/C3 7.5A MTC,FATC, A/CON BRAKE 7.5A Stop lamp Switch, BDC SWITCH A/CON(MTC/FATC), FATC PANEL, SAL UNIT, MOOD LAMP, ADAS MEMORY1 PRK ECU A/BAG IND 7.5A OHCL TCU3...
  • Page 384 Maintenance Fuses Fuse Name Symbol Fuse rating Circuit Protected MULTIMEDIA CCNC (Connected Car Navigation Cockpit) CONSOLE SW, FATC PANEL, CRASH PAD SW, IS MIRR, CCNC, A/ MODULE5 CON(MTC/FATC), CDU, PIO DASH CAM, RR USB, AIR PURIFIER, AMP, SEAT VENT, PWR SEAT, HEAD LAMP(HLLD) CLUSTER 7.5A CLUSTER...
  • Page 385 Maintenance Fuses Fuse Name Symbol Fuse rating Circuit Protected A/C2 7.5A MTC, FATC USB CHAR- USB CHARGER P/WINDOW POWER WINDOW MOTOR MODULE6 7.5A AMP (Amplifier) SUNROOF2 SUNROOF(BLIND MTR) CRASH PAD SW, FRT CAMERA, MUT, ADAS PRK ECU, FRT MODULE4 RADAR, DCU(U2) POWER SEAT PWR SEAT P/WINDOW...
  • Page 386 Maintenance Fuses Engine compartment fuse panel OAYI074064 OAYI074041 Refer to the following table for a description of the fuse.
  • Page 387 Maintenance Fuses Engine room Junction Block Fuse Name Symbol Fuse rating Circuit Protected MAIN FUSE [(Petrol) 1.0 T-GDi] 150A+80A+80A (ALT+MDPS ALT+MDPS +COOLING FAN/GLOW OOLING FAN/ [(Diesel) 1.5 VGT] GLOW) 180A+80A+100A ABS (Anti-lock Brake System) / ESC Only ABS1 40A/60A ESC + EPB ABS (Anti-lock Brake System) / ESC Only ABS2 ESC + EPB...
  • Page 388 Maintenance Fuses Fuse Name Symbol Fuse rating Circuit Protected A/C1 A/CON COOLING FAN [(Diesel) 1.5 VGT] 50A [(Diesel) 1.5 VGT] DSL DCU1 DCU, ECU START FUEL PUMP FUEL PUMP ECU2 ECU3 ECU3 DCT3 DCT (Dual Clutch Transmission) 10 A ECU1 [(Petrol) 1.0 T-GDi] IG- Coil [(Petrol) 1.0T-GDi] IG-Coil...
  • Page 389 Maintenance Fuses Fuse Name Symbol Fuse rating Circuit Protected ECU5 [(Petrol) 1.0T-GDi] 15A [(Petrol) 1.0T-GDi] ECU TCU2 [(Diesel) 1.5] 25A [(Diesel) 1.5] TCU2 SNSR1 SENSOR SNSR2 SENSOR SNSR3 SNSR3 WIPER FRT2 WIPER HORN HORN DCT1 DCT ECU DCT2 DCT ECU DCT3 DCT ECU WIPER FRT1...
  • Page 390 Maintenance Fuses Fuse Name Symbol Fuse rating Circuit Protected HEAD LAMP Head Lamp LH HEAD LAMP Head Lamp RH *1: MDPS (Motor Driven Power Steering) is the same as EPS (Electric Power Steering). Refer to the following table for the relay type.
  • Page 391 Maintenance Fuses Relay Relay Name Symbol Circuit Protected BLOWER BLOWER MOTOR, ICU A/CON A/CON, ECU C/FAN COOLING FAN, ECU or DCU ECU START START SOLENOID, ECU FUEL PUMP FUEL PUMP, ECU ECU, PCU, TCU (Transmission Control MAIN Unit), SENSOR FRT WIPER HIGH WIPER MOTOR FRT WIPER LOW WIPER MOTOR...
  • Page 392 Maintenance Fuses Relay Name Symbol Circuit Protected Power Window Up Power Window Power Window Down Power Window...

  • Page 393: Light Bulbs

    Otherwise, it may cause damage to the We recommend that the headlight aim- fuse or electric wiring system. ing be adjusted by an authorised Kia dealer/service partner after an accident Fully install light bulbs and any parts or after the headlight assembly is rein- used to secure them.

  • Page 394: Daytime Running Lamp (Led Type) (Headlamp Type C/Type B)

    If you don't have the necessary tools, the correct bulbs and the expertise, consult a professional workshop. Kia recom- mends to visit an authorised Kia dealer/ OAYI074002 service partner. In many cases, it is diffi- Headlamp - Type C...

  • Page 395: (Rear Combination Lamp Type B)

    Maintenance Light bulbs Light bulb position (Rear) back up lamp Rear combination lamp - Type A OAYI074050 1 Tail lamp/Stop lamp (Bulb type) OAYI074004 2 Rear reflector Rear combination lamp – Type B 3 Turn signal lamp (Bulb type) 4 Tail lamp (LED type) 5 Stop lamp (LED type) 6 License plate lamp (Bulb type) 7 High mounted stop lamp (Bulb type)
  • Page 396 Maintenance Light bulbs Headlamp bulb To prepare replacing the lamp bulb: 1. Open the bonnet. To replace the headlamp (low/high) bulb: 1. Remove the front bumper. 2. Remove the headlight from vehicle by unscrewing the 2 bolts on top of the OQYi073057 headlight.
  • Page 397 6. Reassemble the socket and the lens part. 7. Connect the bulb electrical connector. 8. Reinstall the lamp assembly to the body of the vehicle. If it does not operate, Kia recommends to visit an authorised Kia dealer/service partner or a professional workshop.
  • Page 398 Kia recommends to visit an assembly. authorised Kia dealer/service partner. 6. Remove the bulb from the socket by...
  • Page 399 If the tail lamp (1) or tail and stop lamp OAYI074050 (2) does not operate, we recommend that the system be checked by a profes- sional workshop. Kia recommends to visit an authorised Kia dealer/service partner. Tail lamp – Type B OAYI074066 1.

  • Page 400: 僅 Replacing High Mounted Stop Lamp (Led Type)

    Maintenance Light bulbs Replacing high mounted stop lamp (LED type) 1. Open the tailgate. OAYI074068 5. Pull out the bulb from socket. 6. Insert a new bulb in the socket. 7. Install the high mounted stop lamp in OAYI074045 the reverse order of removal. Replacing license plate lamp (bulb type) OAYI074059...

  • Page 401: 僅 Replacing Map Lamp (Led Type)

    If the map lamp (LED) (1) does not oper- OAYI074053 ate, have your vehicle checked by a pro- WARNING fessional workshop. Kia recommends to Prior to working on the Interior lamps, visit an authorised Kia dealer/service ensure that the "OFF" button is partner.

  • Page 402: 僅 Replacing Room Lamp (Led Type)

    Prior to working on the Interior lamps, have your vehicle checked by a profes- ensure that the "OFF" button is sional workshop. Kia recommends to depressed to avoid burning your fingers visit an authorised Kia dealer/service or receiving an electric shock.

  • Page 403: 僅 Replacing Personal Lamp (Led Type)

    2. Remove the bulb by pulling it straight professional workshop. Kia recommends out. to visit an authorised Kia dealer/service 3. Install a new bulb in the socket. partner. 4. Align the lens cover tabs with the...

  • Page 404: Appearance Care

    Maintenance Appearance care Appearance care Finish maintenance Use the information in the following sec- Washing tions to keep the exterior and interior of your vehicle clean. To help protect your vehicle's finish from rust and deterioration, wash it thor- Exterior care oughly and frequently at least once a Use the information in the following sec- month with lukewarm or cold water.
  • Page 405 Maintenance Appearance care 僅 To prevent damage to the plastic trical circuits located in the engine parts and lamps, do not clean with compartment. chemical solvents or strong deter- 僅 Never allow water or other liquids to gents. come in contact with electrical/elec- tronic components and air duct inside the vehicle as this may damage them.
  • Page 406 Maintenance Appearance care and may develop into a major repair removing it. The lower edges of the expense. doors, rocker panels, and frame mem- bers have drain holes that should not NOTICE clog with dirt; trapped water in these If your vehicle is damaged and requires areas can cause rusting.
  • Page 407 Maintenance Appearance care Common causes of corrosion to the visible surfaces but particularly to the underside of the vehicle. The most common causes of corrosion on your vehicle are: To help prevent corrosion 僅 Road salt, dirt and moisture that is You can help prevent corrosion from allowed to accumulate underneath beginning by observing the following:...
  • Page 408 Maintenance Appearance care Keep your garage dry Interior general precautions Don't park your vehicle in a damp, Prevent chemicals such as perfume, cos- poorly ventilated garage. This creates a metic oil, sun cream, hand cleaner, and favorable environment for corrosion. air freshener from contacting the interior This is particularly true if you wash your parts because they may cause damage...
  • Page 409 Maintenance Appearance care to read the instructions and consult a a large wiping motion and moderate specialist when using leather coating pressure using a soft sponge or microfi- or protective agents. ber cloth. 僅 Leather with bright colours (beige, Velcro closures on clothing or sharp cream beige) is easily contaminated objects may cause snagging or and clear in appearance.

  • Page 410: Emission Control System

    CAUTION rised Kia dealer/service partner in accor- Rear window dance with the maintenance schedule in Do not scrape or scratch the inside of this manual.

  • Page 411: Vapour Recovery (Orvr)) System

    Maintenance Emission control system crankcase, the fresh air mixes with blow- exhaust emissions whilst maintaining by gases, which then pass through the good vehicle performance. Positive Crankcase Ventilation (PCV) valve into the induction system. Engine exhaust gas precautions 2. Evaporative emission control (carbon monoxide) (including Onboard Refuelling 僅...
  • Page 412 (if equipped) system. All inspections and adjust- WARNING ments must be made by a profes- sional workshop. Kia recommends to Catalytic converter visit an authorised Kia dealer/service Keep away from the catalytic converter partner.
  • Page 413 "check exhaust sys- professional workshop and check the tem" pops up even though the vehicle DPF system. Kia recommends to visit an was driven as mentioned above, we rec- authorised Kia dealer/service partner. If ommend that you have the PPF system...

  • Page 414: 僅 Selective Catalytic Reduction

    Maintenance Emission control system Selective Catalytic Reduction (if Low urea solution warning mes- equipped) sage (if equipped) The Selective Catalytic Reduction (SCR) system is to catalytically convert NOx to Nitrogen and Water by using the reduc- tion agent, the urea solution. WARNING 僅...
  • Page 415 Maintenance Emission control system the driving pattern, environmental con- dition and road profile, the deducted remaining mileage may differ from the actual travel distance. When "Low Urea" or "Refill Urea" message is displayed, a sufficient amount of urea solution must be added.
  • Page 416 Otherwise, the vehicle can't be restarted once the engine is turned off by the ENGINE START/STOP button. In this case, have your vehicle inspected by a professional workshop. Kia recommends to contact an authorised Kia dealer/service partner.
  • Page 417 Maintenance Emission control system Clearing the vehicle-restarting restriction No restart Low urea solution level OMQ4073035L A: Refill urea tank or vehicle will not start Urea solution system failure (= no urea solution injection) OMQ4073031L A: Service Urea system in 0km or vehicle will not start Refill with correct urea in 000km...
  • Page 418 Maintenance Emission control system solution level, have your vehicle inspected by a professional workshop. Kia recom- mends to contact an authorised Kia dealer/service partner. Adding urea solution Refilling urea solution with a refill bottle Refilling urea solution with a refill 僅...
  • Page 419 Maintenance Emission control system profile, driving pattern and environmen- vehicle components, including the tal condition) DPF system. Any unverified additives in the urea solution may clog the SCR * It takes some time to update the cluster catalyst and cause other malfunc- gauges after the urea solution injec- tions, which require the expensive tion.
  • Page 420 When the bottle of urea solution con- workshop. Kia recommends to contact tainer is opened, pungent smelling an authorised Kia dealer/service part- fumes may escape.

  • Page 421: 僅 4. Self Regeneration Mode

    A: Diesel filter regeneration required. After adding incorrect urea solution, See owner’s manual please visit the nearby authorised Kia dealer/ service partner as early as possible. 僅 Liquid that are not recommended such as diesel, petrol, and alcohol...
  • Page 422 (MIL) appears with DPF indicator in spite can restart the self regeneration mode of the procedure, please visit an autho- again. (Self regeneration conditions rised Kia dealer/service partner and then should be satisfied.) check the Diesel Catalyst and engine system including oil level inspection.
  • Page 423 (MIL) appears with DPF indicator in spite to about 2000 and it continues for of the procedure, please visit an autho- 30~60 minutes. After the end of rised Kia dealer/service partner and then regeneration, engine RPM drop to idle check the Diesel Catalyst and engine automatically.

  • Page 424: Specifications & Consumer Information

    Specifications & Consumer information Specifications & Consumer information Dimensions ..................9-2 Engine .....................9-3 Gross vehicle weight ..............9-4 Luggage volume ................9-5 Air conditioning system..............9-6 Bulb wattage .................. 9-7 Tyres and wheels ................9-8 Recommended lubricants and capacities ........9-9 僅 Recommended SAE viscosity number..........9-10 Vehicle Identification Number (VIN).........
  • Page 425 Specifications & Consumer information Dimensions Specifications & Consumer information Dimensions KIAPB001 Item mm (in) A Overall length 3,995 (157.3) Overall width 1,805 (71.1) 195/65R15 1,625 (64) Without Roof rack 215/60R16 1,640 (64.6) 215/55 R17 C Overall height 195/65R15 1,665 (65.6) With Roof rack 215/60R16 1,680 (66.1)

  • Page 426: Specifications & Consumer Information

    Specifications & Consumer information Engine Engine Item (Petrol) 1.0 T-GDi (Diesel) 1.5 VGT Displacement: cc (cu in) 1,493 Bore x Stroke: mm (in) 71 x 84 75 X 84.5 Firing order 1-2-3 1-3-4-2 No. of cylinders 3, In-Line 4, In-line...

  • Page 427: Gross Vehicle Weight

    Specifications & Consumer information Gross vehicle weight Gross vehicle weight (Petrol) 1.0 T-GDi (Diesel) 1.5 VGT Item Gross vehicle weight [kg 1,680 (3,704) 1,730 (3,814) 1,780 (3,924) 1,830 (4,034) (lbs.)]...

  • Page 428: Luggage Volume

    Specifications & Consumer information Luggage volume Luggage volume Item (Petrol) 1.0 T-GDi (Diesel) 1.5 VGT Min: 390 (13.8) Luggage volume (VDA): l (cu ft) Max: 1,434 (50.6) 僅 Min: Behind rear seat to upper edge of the seat back. 僅 Max: Behind front seat to roof.

  • Page 429: Air Conditioning System

    Specifications & Consumer information Air conditioning system Air conditioning system Item Weight of volume (g) Classification Refrigerant 450±25 R-134a Compressor lubricant 100 (+15/-0) PAG 30 Please contact a professional workshop for more details. Kia recommends to contact an authorised Kia dealer/service partner.

  • Page 430: Bulb Wattage

    Specifications & Consumer information Bulb wattage Bulb wattage Light Bulb Bulb type Wattage Low beam High beam Head lamp Type A Turn signal lamps PY21W Position lamps Low beam High beam Head lamp Type B Position lamps Turn signal lamps PY21W Front Daytime running lamps...

  • Page 431: Tyres And Wheels

    Specifications & Consumer information Tyres and wheels Tyres and wheels Inflation pressure [bar (psi, kPa)] Load Speed Wheel lug nut Tyre Wheel capacity capacity Normal load Maximum load Item torque kgf・m size size (lbf・ft, N・m) km/h Front Rear Front Rear 195/ 6.0Jx15 65R15...

  • Page 432: Recommended Lubricants And Capacities

    * 3. Different type of coolant or water may damage the electrical component. * 4. To maintain your vehicle’s best brake and ABS/ESC performance, use Kia genuine brake fluid or those of an equivalent standard brake fluid as in the specification.

  • Page 433: 僅 Recommended Sae Viscosity Number

    Specifications & Consumer information Recommended lubricants and capacities Recommended SAE viscosity number CAUTION Always be sure to clean the area around any filler plug, drain plug, or dipstick before checking or draining any lubricant. This is especially important in dusty or sandy areas and when the vehicle is used on unpaved roads.
  • Page 434 Specifications & Consumer information Recommended lubricants and capacities Temperature Range for SAE Viscosity Numbers A: (Petrol) 1.0 T-GDi A: (Diesel) 1.5 VGT An engine oil displaying this American Petroleum Institute (API) Certifica- tion Mark conforms to the International Lubricant Specification Advisory Committee (ILSAC).

  • Page 435: Vehicle Identification Number (Vin)

    Specifications & Consumer information Vehicle Identification Number (VIN) Vehicle Identification Number Vehicle certification label (VIN) The Vehicle Identification Number (VIN) is the number used in registering your vehicle and in all legal matters pertain- ing to its ownership, etc. The number is punched on the floor OAYI084001 under the driver or passenger seat.

  • Page 436: Tyre Specification And Pressure Label

    Specifications & Consumer information Tyre specification and pressure label Tyre specification and pres- Engine number sure label The engine number is stamped on the engine block as shown in the drawing. (Petrol) 1.0 T-GDi OAYI084002 The tyres supplied on your new vehicle are chosen to provide the best perfor- OAYI084005 mance for normal driving.

  • Page 437: Air Conditioner Compressor Label

    Further information including the manu- OQYi083006 facturer's declaration of conformity is A compressor label informs you the type available on Kia web site as follows; of compressor your vehicle is equipped http://www.kia-hotline.com with such as model, supplier part num- ber, production number, refrigerant (1)

  • Page 440: Abbreviation

    Abbreviation Abbreviation...
  • Page 441 Abbreviation Abbreviation Downhill Brake Control Anti-lock Brake System Digital Centre Mirror Accessory Dual Clutch Transmission Airbag Control Unit Diesel Particulate Filter Automatic Locking Retractor Daytime Running Light DRVM Brake Assistant System Driving Rear View Monitor Blind-Spot Collision-Avoidance Assist Electronic Brake force Distribution Blind-Spot Collision Warning Electronic Chromic Mirror Blind-Spot View Monitor...
  • Page 442 Abbreviation Hill-start Assist Control Malfunction Indicator Lamp MSLA High Beam Assist Manual Speed Limit Assist Highway Driving Assist Near Field Communication NSCC High-Intensity Discharge Navigation-based Smart Cruise Con- trol HMSL High Mounted Stop Lamp Occupant Detection System PCA-R Head-Up Display Reverse Parking Collision-Avoidance IC/JC Assist...
  • Page 443 Abbreviation RCCA Rear Cross-Traffic Collision-Avoid- Tyre Identification Number ance Assist T-GDI RCCW Turbocharger Petrol Direct Injection Rear Cross-Traffic Collision Warning RSPA Tyre Mobility Kit Remote Smart Parking Assist TPMS Tyre Pressure Monitoring System Rear View Monitor Trailer Stability Assist Shift-by-wire Ultra Wide Band Smart Cruise Control Vehicle Identification Number...
  • Page 444 Index Index...
  • Page 445 Index battery 8-32 battery saver function 4-66 air bag 3-32 blind-spot view monitor (BVM) 6-27 air bag collision sensors 3-44 malfunction 6-28 air bag warning label 3-49 operation 6-27 curtain air bag 3-43 settings 6-27 driver’s and passenger’s front air bonnet 4-27 3-38...
  • Page 446 8-45 economical operation 5-50 replacing engine compartment fuse 8-47 electric chromic mirror (ECM) replacing inner panel fuse 8-47 with Kia Connect service 4-42 electronic parking brake (EPB) 5-35 electronic stability control gauges 4-46 (ESC) 5-41 engine coolant temperature gauge...
  • Page 447 good braking practices luggage room lamp 4-75 5-46 map lamp 4-74 room lamp 4-75 ISOFIX anchorage system 3-27 hazardous driving conditions 5-51 securing a CRS with ISOFIX 3-28 headlight levelling device securing a CRS with top tether 3-28 4-69 suitability of seating position headrest (with ISOFIX - for 5 seats) 3-30...
  • Page 448 4-43 rocking the vehicle 5-51 day/night rearview mirror 4-41 roof rack 4-103 electric chromic mirror (ECM) with room lamp Kia Connect service 4-42 4-75 folding the outside rearview mirror 4-43 inside rearview mirror 4-41 outside rearview mirror 4-42 scheduled maintenance items...
  • Page 449 sun visor armrest 3-14 4-98 front seat adjustment for power seat sunglass holder 4-95 rear seat adjustment 3-11 sunroof 4-31 rear seat headrest 3-13 surround view monitor (SVM) 6-50 seat belt restraint system 3-15 malfunction and limitations 6-54 seat belt warning 3-16 operation 6-51...
  • Page 450 wipers and washers tyre maintenance 8-38 4-72 tyre replacement 8-37 operating rear window wiper and tyre rotation 8-36 washer switch 4-73 tyre sidewall labeling 8-38 operating windscreen washers 4-72 tyre terminology and definitions 8-40 wireless smartphone charging tyre traction 8-37 system 4-100 wheel alignment and tyre balance...

Table of Contents

Save PDF
