A
2'x2' Corner (x2)
E
2-Pin Connector (x14)
2'x4' Pure Impact Turf Panel (x1)
FiberbuiltGolf.com
Player preferred series COMBO mat
Right-hitting - 8'x10'
PPS-COMBO-8X10-RH
B
2'x2' Corner with Hole (x2)
F
4-Pin Connector (x8)
J
C
2'x2' Edge (x9)
G
Tee Holder (x2)
Stance & Putting Turf (x1)
Parts & assembly
Please check your box for accuracy.
All of these pieces should be included.
ITEM
PART NUMBER
A
TLCM-C-2
B
TLCM-C-2/H
C
TLCM-E-2
D
TLCM-M-2
E
TLCM-P-2
F
TLCM-P-4
G
651-BLACK
H
P-760CUPS
I
TLCM-PINS50
J
PPS-PANEL-2X4-1
K
760-8X10-PPS-13RH
D
2'x2' Middle (x5)
H
Cup (x2)
Pins (x2 Bags)
K
833.328.3218
QTY.
2
2
9
5
14
8
2
2
2 Bags
1
1
I
[Images not to scale]
Advertisement
Related Manuals for Fiberbuilt PPS-COMBO-8X10-RH
Summary of Contents for Fiberbuilt PPS-COMBO-8X10-RH
- Page 1 Player preferred series COMBO mat Parts & assembly Right-hitting - 8’x10’ PPS-COMBO-8X10-RH Please check your box for accuracy. All of these pieces should be included. ITEM PART NUMBER QTY. TLCM-C-2 TLCM-C-2/H TLCM-E-2 TLCM-M-2 TLCM-P-2 TLCM-P-4 651-BLACK P-760CUPS TLCM-PINS50 2 Bags...
- Page 2 Ensure the ground is properly prepared for placement of the rubber base. The surface should be firm, packed and level. Concrete, asphalt, patios or decking are ideal. (Do not place on grass.) Place the rubber base pieces (A, B, C, D) and Pure Impact Turf panel (J) on the ground together as shown.
- Page 3 Assembly Instructions Secure rubber base pieces (A, B, C, D) and Pure Impact Turf (J) together by pushing Connectors into adjacent holes in the sections. 2-Pin Connectors (E) for side connections 4-Pin Connectors (F) for center connections. Optional Step: For increased security and stability, install and secure Connectors with pins from underneath as you assemble the base pieces.
- Page 4 For a free one-year extension to our standard warranty, exclusive access to insider deals, new product information and much more, register your mat today at: FiberbuiltGolf.com/register Be sure to select the following: Player preferred series COMBO mat RIGHT-hitting - 8’x10’ SKU#: PPS-COMBO-8X10-RH FiberbuiltGolf.com 833.328.3218...
