Summary of Contents for Orien CF2027B
- Page 1 SKU# 1011 949 220 Model #CF2027B USE AND CARE GUIDE 54in INDOOR/COVERED OUTDOOR CEILING FAN THANK YOU Thank you for choosing Orein! We hope you will continue to choose Orein in the future. Visit us online at www.iorein.com to see our full line of lighting products.
-
Page 2: Table Of Contents
Table of Contents Table of Contents ..............2 Assembly................7 Safety Information ............... 2 Remote Operation ............. 13 Warranty ................3 Troubleshooting..............15 Care and Cleaning............. 16 Pre-Installation ..............4 Installation................6 WARNING: To reduce the risk of personal injury, do not bend the blade brackets (also referred to as 1. -
Page 3: Safety Information
Safety Information FCC Warning Changes or modi cations to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 4: Pre-Installation
Pre-Installation SPECIFICATIONS Gross Size Speed Voltage Amps Watts Cu. Ft. Weight Weight 1800 2500 0.15 13.67 lbs 18.74 lbs 3100 1.46 54 in. (6.2 KG) (8.5KG) 3700 0.25 4500 0.35 5500 NOTE These are approximate measures. They do not include the amps and wattage used by the light kit. TOOLS REQUIRED 5003280 Phillips... - Page 5 Pre-Installation (continued) ON / OFF ON / OFF 6 SPEED BRIGHTNESS NIGHT LIGHT COLOR TEMP. TIMER SUMMER WINTER FAN DIRECTION HOLD 3 SEC. Part Description Quantity Part Description Quantity Mounting bracket LED module Canopy Plastic shade Canopy cover Blade Hanger ball (preassembled) Remote control receiver Downrod (preassembled) Remote control...
-
Page 6: Installation
Installation MOUNTING OPTIONS WARNING: NOTE: You may need a longer downrod to maintain proper blade clearance when installing on a steep, sloped personal injury, mount to outlet box marked “acceptable for fan support of 35 lbs. (15.9 Kg) or less” using the ceiling. -
Page 7: Assembling Fan Blades
Assembly - Hanging the Fan Turn off Electrical Power Assembling Fan Blades □ □ Place the motor assembly (G) upside down on the table. Turn OFF the electrical power at the main fuse or circuit breaker. DANGER: Failure to disconnect the power supply prior to installation may result in serious injury or death. - Page 8 Assembly - Hanging the Fan (continued) Install the light housing Install the LED module □ □ Remove one screw from the connecting plate (Q) of fan-motor Remove 3pcs pre-installed screws from the inside of the light assembly (G). And loosen the remaining 2 screws, leaving about kit pan (H).
- Page 9 Assembly - Hanging the Fan (continued) Attaching the downrod to the fan motor assembly □ Loosen the two fan motor assembly coupling set screws (RR) from the fan motor assembly (G) coupling. □ Remove the hitch pin (QQ) and lock pin (PP) from the downrod (E).
-
Page 10: Making The Electrical Connections
Assembly - Hanging the Fan (continued) Making the electrical connections Outlet Box WARNING: To avoid possible electrical shock, ensure the 120V Line electricity is turned off at the circuit breaker or main fuse box voltage-Black 120V Group-Green before wiring. 120V Neutral voltage-White WARNING: Check to see that all connections are tight,... -
Page 11: Turn On Power
Assembly - Hanging the Fan (continued) Securing the canopy to the mounting Install the Plastic shade bracket □ □ Loosen two mounting bracket screws (SS) away from the Rotate the Plastic shade (J) clockwise until it is secure. mounting bracket (A) leaving about 3/4 spacing. □... - Page 12 Assembly - Hanging the Fan (continued) Mount the remote control cradle NOTE: The remote wall cradle is designed to allow you to access an existing switch. The remote wall cradle can be mounted on the wall or to the face plate of a standard toggle switch or a paddle switch. Follow the instructions below for the option that best suits your needs.
-
Page 13: Remote Operation
Remote Operation Remote control Preparing the Remote Control Your fan is equipped with a remote control to operate the speed and lights of your new ceiling fan. NOTE: The remote and fan that come in the box are already paired. Install new fans and their accompanying remotes. - Page 14 Remote Operation Icon Button Name Action Notes Change the fan speed will light 6 Speed LED up different quantity of indicators Short press to turn the Fan and light All ON/OFF on/off Short press to turn the fan on/off ON / OFF ON / OFF Fan ON/OFF Long press for 5 seconds to reset factory...
-
Page 15: Troubleshooting
Troubleshooting Problem Solution The fan will not start. 1. Check to make sure the wall switch is in the on position if applicable. 2. Check the main and branch circuit fuses or breakers. 3. Make sure your device is connected to a power source. 4. -
Page 16: Care And Cleaning
Care and Cleaning WARNING: Make sure the power is off before cleaning your fan. □ Because of the fan’s natural movement, some connections may become loose. Check the support connections, brackets, and blade attachments twice a year. Make sure they are secure. It is not necessary to remove the fan from the ceiling. □...
