HD FLAME TECH MULTI-SIDED ELECTRIC FIREPLACE
We appreciate the trust and confidence you have placed in Paramount through the purchase of this Outdoor Heater. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank
ActiveFlame
USE AND CARE GUIDE
INSTRUCTION MANUAL
Questions, problems, missing parts? Before returning to the store,
please contact customer service at customercare@jrhome.com or
call 1-800-561-5550 7 a.m. - 4 p.m., PST, Monday – Friday
WWW.JRHOME.COM
you for choosing Paramount!
1-800-561-5550
THANK YOU
Item Number : EF10192
Model Number : JRLCD-EF10192
Advertisement
Table of Contents
Related Manuals for ActiveFlame JRLCD-EF10192
Summary of Contents for ActiveFlame JRLCD-EF10192
- Page 1 ActiveFlame Item Number : EF10192 Model Number : JRLCD-EF10192 USE AND CARE GUIDE HD FLAME TECH MULTI-SIDED ELECTRIC FIREPLACE INSTRUCTION MANUAL Questions, problems, missing parts? Before returning to the store, please contact customer service at customercare@jrhome.com or call 1-800-561-5550 7 a.m. - 4 p.m., PST, Monday – Friday 1-800-561-5550 WWW.JRHOME.COM...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Table of Contents ........2 Pre-Installation (continued) Safety Information . - Page 3 IMPORTANT SAFETY INSTRUCTIONS - continued use. To avoid burns, do not touch hot surfaces with fireplaces. bare skin. If handles are provided, use them when □ MANUAL HANDLING moving the appliance. □ The heater must not be moved while in use. Allow □...
-
Page 4: General Instructions
IMPORTANT SAFETY INSTRUCTIONS - continued ELECTRICAL SAFETY - continued and used in accordance with the instructions, may cause harmful interference to radio communications. However, □ Important: Any cut-off plug should be disposed of safely to there is no guarantee that interference will not occur in a prevent a hazard. -
Page 5: Listing Approvals
VOLTAGE: 120V/240V 60Hz POWER: 1500Watts MADE IN CHINA For Indoor Use Only NOM DU PRODUIT : ELECTRIC LCD FIREPLACE NUMÉRO DE MODÈLE : JRLCD-EF10192 TENSION : 120V/240V 60Hz PUISSANCE : 1500Watts FABRIQUÉ EN CHINE POUR UNE UTILISATION EN INTÉRIEUR UNIQUEMENT The rating plate must always remain in place on the appliance. -
Page 6: Package And Hardware Contents
PACKAGE AND HARDWARE CONTENTS UNPACKING THE LCD FIREPLACE- HARDWARE CONTENTS ENSURE TO UNPACK THIS APPLIANCE WITH 2 PEOPLE. NOTE: Use the media kit provided to create a preferred look. Use of all media may not be required. ________ ________ ________ ________ ________ ________... -
Page 7: Dimensions
DIMENSIONS Top View Top View Front View Side View Dimensions Model No. JRLCD-EF10192 1397mm / 55” 1370mm / 53.94” 262mm / 10.31” 77mm / 3.03” 130mm / 5.10” 55mm / 2.17” 578mm / 22.76” 67mm / 2.64” 96mm / 3.78”... -
Page 8: Label Location
LABEL LOCATION Labels are placed on the surfaces of your fireplace to draw attention to potential dangers and operating features. Familiarize yourself with their locations and specific warnings or features prior to use. DO NOT REMOVE UNLESS SPECIFIED. Label list: Hard Wiring Diagram Model #, Safety, Rating Plate Serial Number... -
Page 9: Pre-Installation
PRE-INSTALLATION PREPARING THE FIREPLACE FOR INSTALLATION Measurements are taken from the top of the appliance: Bottom, Sides, and Back 0” 0” recessed into wall and 3 9/16” (90mm) to mantel Appliance is NOT load-bearing. Carefully consider the weight of finishing materials when constructing rough framing. NOTE: Ensure the installation complies with all local building codes and requirements Dimensions Installation Type... -
Page 10: Pre-Installation (Continued)
PRE-INSTALLATION (continued) ENTERTAINMENT WALL REQUIREMENTS □ When planning the construction of your entertainment wall, several key factors must be considered to ensure a successful installation. It is recommended that you carefully review the installation instructions and fully understand the process before designing or building your entertainment wall. - Page 11 PRE-INSTALLATION (continued) NOTE: It is recommended that two people assist with Pre-Installation the installation. The fireplace should be tested prior to installation. 1. Remove the silver shipping brackets. They are no longer required. (Figure 1) The side panels can now either be left removed or re-installed, NOTE: Place the the appliance on a stable surface prior to depending upon your installation type (see page 12-14 for details).
-
Page 12: Dispaly Types
PRE-INSTALLATION (continued) Pre-Installation Display Type These fireplaces come with side covers, a llowing you the flexibility to either display the sides of the fireplace within your media wall or to enclose them for 3 viewing styles. Front View Fig. 3-2 Fig. - Page 13 PRE-INSTALLATION (continued) Pre-Installation Side Panel Display Type - continued desired ide uncovered Three Sided View desired Remove the side panels from both sides of the Fig. 3-3 Fig. 3-4 side covered appliance by removing the 8 screws. Safety store the side panels and the screws for future use. Side Panel Side Panel de Panel...
- Page 14 PRE-INSTALLATION (continued) Side Panel Pre-Installation Display Type - continued keep both sides covered desired ide uncovered Corner View For desired open side, remove desired Fig. 3-3 Fig. 3-4 the side panel of the fireplace by side covered removing the 4 screws. Safety store the side panel and the screws for desired side open / close future use.
-
Page 15: Recessed Installation Styles
PRE-INSTALLATION (continued) Installation Style 1. For best visual results, we reccomend a recessed installation: The fireplace is recessed into the media wall, so the wall covers the body of the fireplace, leaving only the front visible. Wooden Studs Drywall Wooden Studs Drywall JRHOME.COM Please contact customercare@jrhome.com or 1-800-561-5550 for further assistance. -
Page 16: Glass Removal
PRE-INSTALLATION (continued) PREPARING THE FIREPLACE FOR INSTALLATION STEP 1 - Remove the 8 screws holding the top glass screen bracket in place and set aside. Step 2: Front Glass Removal. To remove the front glass panel, tilt the glass carefully and remove. Place the glass on a soft, flat surface, ready for reinstallation. - Page 17 PRE-INSTALLATION (continued) PREPARING THE FIREPLACE FOR INSTALLATION Step 3: Place log set, stones and glass media into the fireplaces. Arrange the log set and rocks on top of the glass chips to achieve your desired look. Wear gloves and carefully place the 2 types of glass chips along the media bed. Mix them together to create a realistic burning appearance once fireplace is turned on.
- Page 18 PRE-INSTALLATION (continued) PREPARING THE FIREPLACE FOR INSTALLATION STEP 5 - Reattach the fixing bracket using the screws removed in step 2. OPTIONAL STEP STEP 6: If you choose to enclose one or both sides of the fireplace, reattach the side panels as needed after installation.
-
Page 19: Installation And Assembly
INSTALLATION AND ASSEMBLY PREPARING THE FIREPLACE FOR INSTALLATION STEP 1 - Loosely fix the L-shaped brackets [A] into the mounting points (front or rear) on the top of the fireplace using SCREWS (B) and SHAKEPROOF WASHER (F). 1 - Attaches to the front of the batten (see step 2) 2 - Attaches to ear of the batten (see step 2) STEP 2 - Slide the fireplace into the position of the entertainment wall. -
Page 20: Installation
INSTALLATION (continued) Three-sided viewing, Corner viewing, and Front viewing post-installation 1. Complete wiring (see “electrical information” section). 2. Secure and test the appliance (see “securing and testing” section). 3. Install finishing materials (see “finishing” section) ELECTRICAL - HARDWIRING OPTION FOR 120V Electrical Information It is necessary to hard-wire this appliance. - Page 21 ELECTRICAL - OPTION FOR 120V (continued) IMPORTANT - continued □ Inspect that the correct voltage is selected on the selector switch located inside the unit. Failure to do so could damage the fireplace. □ Reattach the power cord cover plate and install the screws. Electrical Information - Hard Wiring 120V The following instructions must be followed to install a 3-wire Romex cable to the terminal.
- Page 22 ELECTRICAL - HARDWIRING OPTION FOR 240V IMPORTANT - continued □ Inspect that the correct voltage (240V) is selected on the selector switch located inside the unit. Failure to do so could damage the fireplace. Reattach the power cord cover plate and install the screws. Electrical Information - Hard Wiring 240V The following instructions must be followed to install a 4-wire Romex cable to the terminal.
-
Page 23: Wiring Diagram
WIRING DIAGRAM CAUTION: Turn off the appliance completely and let cool before servicing. Only a qualified service person should service and repair this electric appliance. PART NAME Ember Light Strips Ember Light Connector Main Board Push Button Panel Remote Receiver Ceiling Light Strips Fan Blower Heater... -
Page 24: Operation
OPERATIONS Pre-Operation CAUTION: Do not attempt to operate this appliance until you have read and understand all Safety Information in this manual and all assembly is complete and leak tests have been performed. After reading all the instructions, make sure that all the fireplace controls are in the OFF position. Plug the fireplace into a 15A/120V grounded circuit with a circuit breaker is on outlet. -
Page 25: Remote Control
REMOTE CONTROL Remote Command Button, Event, and Operation status Function Button Icon Function Command Event Sound Operating Status Main Power Power Setting Short One Short Main Power Off Press Beep sound Once will be trig- To power off the device, press the button gered once. - Page 26 REMOTE CONTROL - continued Remote Command Button, Event, and Operation status Function Button Icon Function Command Event Sound Operating Status Flame Flame Short Short Beep Repeat press the Flame Change but- ton to adjust the flame options. changing Setting Press Once There are 6 flame options available to Once...
- Page 27 REMOTE CONTROL - continued Remote Command Button, Event, and Operation status Function Button Function Command Event Sound Operating Status Icon Set Timer Timer Set- Short Press Short Beep Activate the timer. ting Once Once Set the timer to 1hour Cancel Timer Long Press Long Beep Deactivate the timer.
-
Page 28: Maintenance, Care & Cleaning
REMOTE CONTROL - continued Battery insertion /removal 1. Using the included screwdriver, remove and set aside the 6 screws holding the remote control back plate in place. 2. Insert 2 AAA batteries into the battery chamber. 3. Reattach the back plate using the 6 screws set aside from Step 1. CARE AND MAINTENANCE WARNING:ALWAYS TURN THE HEATER OFF AND UNPLUG THE POWER CORD FROM THE OUTLET BEFORE CLEANING, PERFORMING MAINTENANCE, OR... -
Page 29: Replacement Parts
REPLACEMENT PARTS ONLY PARTS SPECIFICALLY APPROVED FOR USE WITH THIS APPLIANCE MAY BE USED. FAILURE TO POSITION OR USE MANUFACTURER PARTS IN ACCORDANCE WITH THIS MANUAL MAY RESULT IN PROPERTY DAMAGE OR PERSONAL INJURY. Part No. Description Description Quantity LCD55-AP02 Front Glass LCD55-AP01 LCD Screen... -
Page 30: Troubleshooting
Reminder : You may use the the reset button to TROUBLESHOOTING recover factory defaults. PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION LCD Fireplace is not plugged into an electrical outlet. Check plug. Plug in the LCD fireplace if necessary. Hardwire connections are not correct. See "Hardwiring Installation"... -
Page 31: Limited 2 Year Warranty
IMPORTANT LIMITED 2 YEAR WARRANTY For questions, concerns or problems with our product please Si vous éprouvez si vous avez des questions ou des email our customer service department: préoccupations, prière de faire parvenir un courriel à notre service à la clientèle customercare@jrhome.com customercare@jrhome.com DATED PROOF OF PURCHASE REQUIRED FOR WARRANTY SERVICE... - Page 32 ® ActiveFlame Questions, problems, missing parts? Before returning to the store, please contact customer service at customercare@jrhome.com or call 1-800-561-5550 7 a.m. - 4 p.m., PST, Monday – Friday JRHOME.COM Retain this manual for future use.
