MESSAGE LIST (メッセージ一覧) ........68/72 MIDI IMPLEMENTATION CHART .......... 76 MIDI DATA FORMAT ............. 77 PARTS LIST BLOCK DIAGRAM (ブロックダイアグラム) CIRCUIT BOARD LAYOUT & WIRING (ユニットレイアウト&結線図) OVERALL CIRCUIT DIAGRAM (総回路図) 001764 20060425-270900 Copyright (c) Yamaha Corporation. All rights reserved. PDF M ’06.04...
CP300 IMPORTANT NOTICE This manual has been provided for the use of authorized Yamaha Retailers and their service personnel. It has been assumed that basic service procedures inherent to the industry, and more specifically Yamaha Products, are already known and understood by the users, and have therefore not been restated.
CP300 PANEL LAYOUT(パネルレイアウト) Front Panel (フロントパネル) i !0 !2 !7 !9 @0 TRACK ZONE 1 ZONE 2 ZONE 3 ZONE 4 SONG FILE MIDI OUT PANEL LOCK MASTER TRANSPOSE PERFORMANCE 3-16 SONG SELECT STOP PLAY/PAUSE MASTER EDIT PERFORM.FILE SONG SETTING...
Page 5
CP300 @7 @8 #0 #2 #4 GRAND GRAND MONO LO-MID HI-MID HIGH CONTRAST VOICE EDIT SPLIT REVERB CHORUS SPEAKER MIDI SETTING PIANO 1 PIANO 2 PIANO CLAVI. E. PIANO 1 E. PIANO 2 E. PIANO 3 VIBES DEMO VARIATION MASTER EQ EDIT...
Page 6
CP300 Rear Panel (リアパネル) AC INLET ASSIGNABLE FOOT PEDAL MIDI OUTPUT OUTPUT INPUT THRU L/MONO L/MONO SUSTAIN SOFT SOSTENUTO q [AC INLET] jack q [AC INLET] (エーシーインレット) 端子 w [ASSIGNABLE FOOT PEDAL] jacks w [ASSIGNABLE FOOT PEDAL] (アサイナブルフットペダル) 端子 e MIDI [IN][OUT][THRU] connectors e MIDI ...
CP300 DISASSEMBLY PROCEDURE(分解手順) Caution: 注意事項 Be sure to attach the removed filament tape just フィラメントテープは、 取り外す前と同じように取り as it was before removal. 付けてください。 Pay attention not to insert and install the cable to フラットケーブルの表 ・ 裏を逆に差し込まないように the connector inversely. (Fig. A) 注意して取り付けてください。...
Page 8
CP300 Circuit Boards & Assemblies 基板とアッセンブリ (Time required: About 4–5 minutes each) (所要時間 : 各約4〜5分) Remove the control panel unit. (See procedure 1) CPユニットを外します。 ( 1項参照) Each circuit board and assembly can be removed by 次のネジを外すことにより、 基板 ・ アッセンブリを外 removing its fixing screws as listed below.
Page 9
CP300 Main Unit (メインユニット) ● Speaker box assembly L Power transformer Speaker box assembly R MA80S assembly (SP. Box Ass'y L) (電源トランス) (SP. Box Ass'y R) [180A] [180A] [170B] [170B] [180B] [180B] [170A] MA cover [170A] [220B], [330] Fig. 3 (図3) Control Panel Unit (CPユニット) ●...
Page 10
CP300 <Rear view> ( 背面) [300E] [300E] [280] [300C] FU60 assembly DJACK [300D] A-JACK assembly ( Aジ ャ ッ クAss'y) Fig. 5 (図5) AJACK Circuit Board AJACKシート (所要時間 : 約5分) (Time required: About 5 minutes) CPユニットを外します。 ( 1項参照) Remove the control panel unit. (See procedure 1) AジャックAss yを外します。...
Page 11
CP300 Remove the screw marked [D2A]. The WMH circuit [D2A]のネジ1本を外し、 コネクタを外してWMH board can then be removed by pulling it out from the シートを外します。 ( 図8) connector. (Fig. 8) [D2B]のネジ1本を外し、 コネクタを外してWML Remove the screw marked [D2B]. The WML circuit シートを外します。 ( 図8)...
Page 12
CP300 Speakers スピーカ (所要時間 : 約5分) (Time required: About 5 minutes) CPユニットを外します。 ( 1項参照) Remove the control panel unit. (See procedure 1) SP. Box Ass y LまたはRを外します。 ( 2項参照) Remove the speaker box assembly L or R. [40]のネジ4本を外し、 スピーカを外します。 ( 図10) (See procedure 2) ※...
CP300 Power Switch Assembly PSW束線 (電源スイッチ付) (所要時間 : 約5分) (Time required: About 5 minutes) CPユニットを外します。 ( 1項参照) Remove the control panel unit. (See procedure 1) 腕木Lを外します。 ( 2項参照) Remove the side cover L. (See procedure 2) [610d]のネジ2本を外し、 PSW束線 (電源スイッチ付)...
CP300 Keyboard Assembly GHD EBUS鍵盤 (所要時間 : 約5分) (Time required: About 5 minutes) 11-1 CPユニットを外します。 ( 1項参照) 11-1 Remove the control panel unit. (See procedure 1) 11-2 [170C]のネジ1本と[220C]のネジ1本を外し、 左右ど 11-2 After removing the screw marked [170C] and the screw ちらかの鍵盤取付横金具Ass yを外します。 ( 図14)...
Page 15
CP300 GHD H Circuit Board GHD Hシート (所要時間 : 約7分) 12-3 12 ‐ 3 (Time required: About 7 minutes) [260C]のネジ4本と[262]のネジ1本を外し、 GHD H Remove the four (4) screws marked [260C] and the シートを外します。 ( 図16) screw marked [262]. The GHD H circuit board can ※...
CP300 White key 12-5 12 ‐ 5 白鍵 In order to release the white key from the stopper, insert 白鍵をストッパーから外すために、 薄い金尺状のも a thin plate between the white keys (gap in the direction のを鍵盤の間に挿入して (三角マークの示す方向側 indicated by the triangle mark, near the fulcrum of the の隙...
Page 17
CP300 Spring 13-2 13-2 スプリング Place the keyboard assembly right side up. Fix key GHD EBUS鍵盤を表側にして、 端が二本に分かれて springs on the frame by setting one at each slit and いるスプリングの先をハンマー白鍵 (黒鍵) の切り込 pushing down once on each key spring. (Fig. 24) みに合わせて、 一度下に押し込んでフレームのフッ...
CP300 LSI PIN DESCRIPTION(LSI 端子機能表) AK4393VF-E2 (XW029A00) DAC (Digital to Analog Converter) ......22 HD6417709SHF200B (X2687A00) CPU (SH3) .
Page 19
CP300 HD6417709SHF200B (X2687A00) CPU (SH3) HD6417709SHF200BV (X2687B00) CPU (SH3) DM: IC014 NAME FUNCTION NAME FUNCTION CK enable / Port K CKE/PTK5 Mode control RAS3L/PTJ0 DRAM row address strobe / Port J Vcc(RTC) Power supply +1.8 V RAS2L/PTJ1 DRAM row address strobe / Port J...
Page 20
CP300 T8F02TB-0102 (X0060A00) SWP50 (Tone Generator) DM: IC012 OUTER OUTER NAME FUNCTION NAME FUNCTION VSS2 Ground VSS2 Ground VDDC Power supply +1.5 V VDDC Power supply +1.5 V CD15 HMA15 CD13 HMA16 Wave memory address bus CD14 HMA22 HMA25 VDDS...
Page 21
CP300 OUTER OUTER NAME FUNCTION NAME FUNCTION AB22 VSS2 Ground VSS2 Ground AC23 VDDC Power supply +1.5 V VDDC Power supply +1.5 V AD24 DMAL1 Address bus (DIMM, SDRAM) MELI6 MEL wave data input AE25 DCSL2 MELI7 AF26 DRAS0 ADLR...
Page 22
CP300 M66291GP (X2156A00) USB Controller DM: IC002 NAME FUNCTION NAME FUNCTION Core Vcc Core power supply Ground USB data (-) USB data (+) Vbus V bus input Data bus Tr ON Tr ON output TEST TEST input D8/P0 /Dack1 DMA reception signal 1...
CP300 DM Circuit Board A SETUP OF LANGUAGE DIP switch (言語設定) English Japanese to AJACK-CN11 to AJACK-CN1 to AJACK-CN2 not installed not installed not installed to DJACK-CN2 Component side not installed to DJACK-CN1 (部品側) to PNL-CN1, GHD EBUS L-CN1 * Install either IC30 or IC31.
Page 25
CP300 DM Circuit Board Pattern side (パターン側) Note : See parts list for mounting of parts. (注:部品実装は、パーツリストを参照してください。 ) 2NA-V755310-5...
CP300 PNR Circuit Board to LCD to DM-CN1 to DM-CN2 to PNL-CN4 GRAND GRAND MONO E.PIANO 1 E.PIANO 2 E.PIA PIANO 1 PIANO 2 PIANO CONTRAST CHOIR ORGAN 1 ORGAN 2 HARPSI. STRINGS GUIT EXIT VOICE/PERFORMANCE C93 : not installed...
CP300 AJACK Circuit Board to DM-CN24 L/MONO INPUT L/MONO OUTPUT Component side (部品側) to XLR-CN401 to MA80S-CN3 to MA80S-CN4 to DM-CN8 to DM-CN9 Pattern side (パターン側) 2NA-WG41670...
Page 33
CP300 DJACK Circuit Board ASSIGNABLE FOOT PEDAL SUSTAIN SOSTENUTO SOFT MIDI MIDI MIDI THRU Pattern side Component side to DM-CN7 (パターン側) (部品側) 2NA-WG41640 1...
CP300 FU60 Circuit Board XLR Circuit Board L1, L2 : Jumper wire to AJACK-CN6 to Power Transformer (Primary) to POWER Switch Component side OUTPUT (部品側) Component side VOLTAGE SELECTOR AC INLET (部品側) not installed Pattern side (パターン側) WMH Circuit Board...
Page 35
CP300 GHD EBUS L Circuit Board 2NAK8-V646930...
Page 36
CP300 GHD M Circuit Board 2NAK8-V852140...
Page 37
CP300 GHD H Circuit Board 2NAK8-V852150...
When using the MIDI mode After turning on the power to CP300, wait for a few seconds and confirm that the play mode screen (normal mode) appears. Then input the test code “F0 43 73 01 60 00 F7”, and the TEST program will start.
Page 39
Proceeding through the Test Program When using the manual mode When the test program is activated, the sign “TEST CP300” appears on the LCD display. Select the test program item by pressing the [UP] or [DOWN] button of [TEMPO]. Press the [MIDI OUT] button to execute testing.
Page 40
CP300 MIDI test code Test Function and Judgment criteria 005: FlashRom Chk1 A0 05 00 Checks wire connection of the flash memory that is connected to the CPU bus. Display while testing: (simple check) [DM: IC40] “FlashRom Chk1 --” Outputs the C4 sine wave when the check result is OK and “Flash Chk1 OK”...
Page 41
CP300 MIDI test code Test Function and Judgment criteria 013: EQ Mid A0 0D 00 <Usually, this test can be omitted.> Checks the EQ-MID frequency. Display while testing: Check that the sine wave of about 523 Hz (C4) sounds. (PAN = Center) “EQ Mid --”...
Page 42
CP300 MIDI test code Test Function and Judgment criteria 025: Pedal1 Chk A0 19 00 Checks the sustain pedal. Display while testing: Connect foot pedal (FC3 or FC4) to the FOOT PEDAL 1 [SUSTAIN] terminal. • “Pedal 1 Max” when the pedal Perform the test.
Page 43
CP300 MIDI test code Test Function and Judgment criteria 032: EQ Slider Chk A0 20 00 Checks the master equalizer slider (with center click). Example of display while testing: Place the [LOW]–[HIGH] MASTER EQUALIZER sliders in the center position • “LOW Min” when waiting for (CENTER) before starting the test.
Page 44
CP300 MIDI test code Test Function and Judgment criteria 032: Keyboard Type Chk A0 24 00 Checks the keyboard type. Perform the test and confirm that C4 sounds and that “KeyType OK (GHD)” is displayed on the LCD display. Display for NG: “Keyboard Type Chk NG”...
Page 45
CP300 Table 1 Order Switch Name Note Order Switch Name Note MASTER GRAND PIANO1 PERFORMANCE GRAND PIANO2 TRANSPOSE MONO PIANO MASTER EDIT E.PIANO1 PERFORM.FILE E.PIANO2 SONG SELECT T ( REW ) E.PIANO3 SONG SELECT Y ( FWD ) CLAVI. TRACK 1...
Page 51
CP300 LCD 表示 MIDI テストコード テスト内容及び判定条件など 032: EQ Slider Chk A0 20 00 EQスライダー (センタークリック付) チェック テスト中の表示例: テストに入る前に、MASTER EQUALIZERの[ LOW ], [ LO-MID ], [ MID ], ・LOW Min 検出待ち [ HI-MID ], [HIGH ] スライダーを中央 (センター) にしておきます。 LOW Min テストを実行し、[ LOW ]スライダーを手前側 (Min) にするとC3 を発 ・LOW Min 検出時 音し、奥側 (Max) にするとG3 を発音し、中央 (Center) にするとC4を LOW Max 発音します。続いて[ LOW ]と同様のチェック方法で[ LO-MID ], [ MID ], ・LOW Max 検出時 [ HI-MID ], [ HIGH ]の順番でチェックを行います。 LOW Center [ HIGH ]まで終わると、LCD に EQ Slider Chk OK と表示されるこ ・LOW Center 検出時 とを確認します。...
Page 52
CP300 LCD 表示 MIDI テストコード テスト内容及び判定条件など 036: Keyboard Type Chk A0 24 00 鍵盤種類をチェック テストを実行すると、C4 を発音して、LCD に KeyType OK (GHD) と表示されることを確認します。 NGの場合の表示: Keyboard Type Chk NG 037: Main Rom Chk2 A0 25 00 <通常、 この検査は省略可能です。 > テスト中の表示: CPU のバスに接続されているROM をチェックします。 Main Rom Chk2 -- チェックの結果がOKの場合は、C4の正弦波を発音して、LCD に Main Rom Chk2 OK と表示されます。 NGの場合の表示: Main Rom Chk2 NG 038: Main Ram Chk2 A0 26 00 <通常、 この検査は省略可能です。 > テスト中の表示: CPU のバスに接続されているすべてのRAM をチェックします。 Main Ram Chk2 -- チェックの結果がOKの場合は、C4の正弦波を発音して、LCD に Main Ram Chk2 OK と表示されます。 (約5 秒かかります。) NGの場合の表示: Main Ram Chk2 NG 039: FlashRom Chk2...
CP300 表1 Order Switch Name Note Order Switch Name Note MASTER GRAND PIANO1 PERFORMANCE GRAND PIANO2 TRANSPOSE MONO PIANO MASTER EDIT E.PIANO1 PERFORM.FILE E.PIANO2 SONG SELECT T ( REW ) E.PIANO3 SONG SELECT Y ( FWD ) CLAVI. TRACK 1...
This lets you restore the CP300’s default Voices and Performances, as well as its System and other settings. There are two ways you can restore the CP300’s memory to the factory default settings: 1) Set the “Factory Set” parameter in the Other Settings menu, or 2) Turn the power off and turn the power on again while holding the C7 key (rightmost key on the keyboard).
Page 55
If you wish to erase Memory files at this time, simultaneously hold down the rightmost white key (C7) and black key (B b 6) together and press the [POWER] switch to turn on the power to the CP300. (Same as the Test program 42 “Factory Set”)
Page 58
USB cable (A-B type) USB connector CP300 Computer with a USB interface Connection between CP300 and MIDI data filer (MDF3) (Example) When using a MIDI data filer (MDF3), make connection as shown below. MIDI cable (Reproduction) MIDI cable (Recording) MIDI OUT connector...
Page 59
CP300 Preparation Start up “SQ01”. Select MIDI. Select Set up, MIDI and Device in that order. Select [YAMAHA USB IN 0-1] for Input and [YAMAHA USB OUT 0-1] for Output and click...
Click Rec(R) to activate the function (lighting in red). Click (Record) and then (Play). Use the following procedure to send the bulk data from CP300. -1 Press the [MIDI SETTING] button to call up the MIDI Settings menu. MIDI SETTING MidiOutChannel Main -2 Press the [MIDI SETTING] button repeatedly or by use the A [–][+] buttons to call up “Bulk Dump”...
Page 61
CP300 -4 Press the B [+ (YES)] button to execute the job. Press the B [+ (YES)] button to call up the confirmation prompt (“Sure?”). Press the B [+ (YES)] button once again to actually execute the job. An “Executing” message appears and the data is saved. When the operation is complete, a “Completed”...
Page 62
Confirm that the power to CP300 is turned on. Click (Play). The bulk data is received by CP300. The operation is complete when “BulkDataReceiving Completed” message appears on the LCD display of CP300. BulkDataReceiving Completed Bulk data cannot be received in the following situations: •...
CP300 MESSAGE LIST The messages are listed in alphabetical order. Message Description Bulk data reception has been completed. BulkDataReceiving This is shown following the “Bulk Data Receiving Voice” message. This indicates that the Completed instrument finished receiving bulk data, and that you can go on to the next step.
Page 69
CP300 Message Description The instrument’s flash memory (storage memory) has expired. FlashMemoryLifeTime If this message appears, the instrument will not be able to back up the Songs, Performance Exit--> files and settings in memory. Press the [EXIT] button to return to the original display.
Page 70
CP300 Message Description Do you want to overwrite the data? OverWrite? This message prompts you to select whether you wish to overwrite the existing data with new data. Press the B [+ (YES)] button to allow overwriting. Press the B [– (NO)] button to cancel.
Page 71
CP300 Message Description MIDI Bulk data is being transmitted. Transmitting This message appears when the instrument receives a bulk request from a computer. The Error instrument has failed to transmit Voice bulk data. Check the cable connection and repeat the procedure from the beginning.
CP300 MIDI DATA FORMAT Many MIDI messages listed in the MIDI Data Format are expressed in decimal numbers, binary numbers and hexadecimal numbers. Hexadecimal numbers may include the letter “H” as a suffix. Also, "n" can freely be defined as any whole number. To enter data/values, refer to the table below.
Page 78
CP300 MIDI CHANNEL MESSAGE (1) Status byte 1st Data byte 2nd Data byte MIDI Reception (respond/ignore) MIDI Transmission (generated data) Main Panel Recorded MIDI Events Layer Status Data (HEX) Parameter Data (HEX) Parameter Song Keyboard (main generation Song Midi from...
CP300 Status byte 1st Data byte 2nd Data byte MIDI Reception (respond/ignore) MIDI Transmission (generated data) Main Panel Recorded MIDI Events Layer Status Data (HEX) Parameter Data (HEX) Parameter Song Keyboard (main generation Song Midi from Left method) panel Left Layer Ø...
CP300 MIDI PARAMETER CHANGE TABLE *Not Received when Receive Parameter SysEx is set to off. *Not transmitted when Transmit Parameter SysEx is set to off. MIDI Parameter Change table (XG SYSTEM) MIDI Reception (respond/ignore) MIDI Transmission (generated data) Main Address...
Page 81
CP300 MIDI Reception (respond/ignore) MIDI Transmission (generated data) Main Address Size Data XG Default Panel Recorded Parameter Description Layer Song Keyboard (main generation Song Midi from Left method) panel Left Layer 00-7F CHORUS TYPE MSB Refer to Effect Parameter List 41 (=CHORUS1) Ø...
CP300 MIDI Parameter Change table (MULTI EQ) MIDI Reception (respond/ignore) MIDI Transmission (generated data) Main Address Size Data Panel Recorded Parameter Description Layer Song Keyboard (main generation Song Midi from Left method) panel Left Layer 00-04 EQ TYPE flat, jazz, pops, rock, classic Ø...
CP300 MIDI Parameter Change table (DRUM SETUP) MIDI Reception (respond/ignore) MIDI Transmission (generated data) Main Address Size Data XG Default Panel Recorded Parameter Description Layer Song Keyboard (main generation Song Midi from Left method) panel Left Layer 00-7F PITCH COARSE -64...0...+63...
Page 86
Song Midi Left method) Left Layer hh mm = Exclusive status 11110000 = YAMAHA ID 01000011 = Device Number n = always 0 (when transmit), 0001nnnn n = 0-F (when receive) 01001100 = Model ID Ø Ø XG Parameter *Refer to Parameter Change –...
Page 87
Panel (main Layer Song Keyboard panel) generation Song Midi Left method) Left Layer 11110000 = Exclusive status = YAMAHA ID 01000011 = Clavinova ID 01110011 00000001 = Model ID (Clavinova common ID) String Ø Ø Resonance = Sub ID Ø Ø...
Page 88
Left Layer F0 43 0n xx yy zz aa bb cc dd hh mm ll dd ... dd sum F7 = Exclusive status 11110000 01000011 = YAMAHA ID = Device Number n = always 0 0000nnnn = Model ID High 0xxxxxxx...
CP300 OVERALL ASSEMBLY (総組立) Wheel assemblly: See page 10. (ホイールAss'y) Control panel unit: See page 6. W12a (CPユニット) U only W09a A-JACK assembly (AジャックAss'y) DM assembly (DM Ass'y) 660c 660b 660a U only Headphones jack assemblly (H.P. Ass'y) 610c 610a...
Page 126
<Page 4> CP300 CP300 OVERALL CIRCUIT DIAGRAM 2/4 (GHD EBUS L, GHD H, GHD M, MK SUB, WMH, WML) F # 2) (A-1 GHD EBUS L MK SUB to DM-CN4 <Page 3 A-5> not installed not installed 28CC1-8819224 28CC1-8819027 to DM-CN14 (WML) <Page 3 I-8>...
Page 127
<Page 5> CP300 CP300 OVERALL CIRCUIT DIAGRAM 3/4 (DJACK, MV2, PN-EQ, PNL, PNR) 1SS372 (V9424900) DIODE ARRAY DJACK: DA1, 2 DJACK Photo Coupler VOICE/PERFORMANCE 1: ANODE1 2: CATHODE2 3: CATHODE1, ANODE2 GRAND GRAND MONO PIANO 1 PIANO 2 PIANO E.PIANO 1 E.PIANO 3...
Page 128
<Page 6> CP300 CP300 OVERALL CIRCUIT DIAGRAM 4/4 (AJACK, FU60, HP, MA80S, XLR) POWER MA80S OP AMP AJACK U, J E, B, A, K not installed FU60 POWER TRANSFORMER AC CORD DC-DC CONVERTER OUTPUT GREEN YELLOW L1, L2: Jumper Wire...
