Summary of Contents for Carmanah M660
- Page 1 M660 USER MANUAL Technical Support: Email: customerservice@flashtechnology.com Toll Free: 1.800.821.5825 Web: sabik-marine.com 79285 M660 Manual RevD ©2019 Sabik Marine...
-
Page 2: Table Of Contents
M660 USER MANUAL Table of Contents Safety Warnings ..........3 Introduction ............. 3 Applications ............ 3 Installation ............3 3-Hole Flange Mount ..........4 Pole Mount ............4 Bird Deterrents ............. 5 Operation ............5 Programming ............5 Setting the Flash ..........6 Setting the Intensity .......... -
Page 3: Safety Warnings
Year-round, unrestricted solar exposure is critical to long-term performance. Shade dramatically reduces the ability of the light to charge its battery. The M660 can be mounted to a flat surface or pole. Ensure the correct mounting method is selected before lantern installation. ©2019 Flash Technology, LLC... -
Page 4: 3-Hole Flange Mount
M660 USER MANUAL 3-Hole Flange Mount To attach the 3-hole flange mount: 1. Ensure the flange mount is aligned correctly. 2. Attach the flange mount to the light unit using the provided 3 screws (1). Do not over tighten. 3. For extra security use 3 more screws to attach the flange mount to the light unit (2). -
Page 5: Bird Deterrents
30 seconds. For example, 30 seconds of dark is needed for the lantern to switch to night operation. Programming The M660 is configured using the Infrared (IR) Programmer or Bluetooth control app. Contact your distributor for app access and registration details. -
Page 6: Setting The Flash
Turning On/Off In “on” mode, the M660 LED turns on at night and off during the day. In “off” mode, the lantern charges in sunlight, but the LED remains off. When turned on again, the lantern activates at its last programmed settings. -
Page 7: Checking Battery State Of Charge (Soc)
Enable ALC: Disable ALC: Battery Charging The M660 can recharge low batteries back to full charge (4.1V). Approximate charging times: Summer sunlight: 8-12 hours (single) 16 -24 hours (dual) -
Page 8: Troubleshooting
M660 USER MANUAL Troubleshooting Batteries are very low and lantern cannot turn on Charge the lantern. Confirm with code 810 using IR programmer. Batteries are low and LVD is active Charge lantern. Decrease effective intensity to sustainable level. LED is off during Switch is off Switch to on. - Page 9 M660 USER MANUAL l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. CAN ICES-3 (B)/NMB-3(B) – This Class B Digital Apparatus Complies with Canadian ICES-003. Cet Appareil numerique de la classe (B) est conforme a la norme NMB-003 du Canada.
-
Page 10: Flash Codes
M660 USER MANUAL Flash Codes The M660 supports more than 270 flash codes. A partial list is shown below. For a complete list, see the Marine Selector Tool at www.sabik-marine.com or the Bluetooth Control app. Maximum effective intensity varies by flash code and color. -
Page 11: Maintenance
M660 USER MANUAL Maintenance Although the M660 is maintenance-free, performance gains can be made. Clean with water and a soft sponge or cloth. A mild non-abrasive cleanser can be used for more stubborn residue. Clean more frequently during drier months as dust accumulates more quickly.
