Summary of Contents for Antec Scientific 250.0180
- Page 1 Antec Scientific Industrieweg 12 2382 NV Zoeterwoude The Netherlands LAN connection kit installation guide 250.7018, Edition 2, 2019 T +31 71 5813333 | info@AntecScientific.com | https://AntecScientific.com...
- Page 2 Copyright ©2019, Antec, The Netherlands. Contents of this publication may not be reproduced in any form or by any means (including electronic storage and retrieval or translation into a foreign language) without prior agreement and written consent from the copyright of the owner. Antec reserves the right to make changes to the design and specifications of the instrument and this manual without prior notice.
-
Page 3: Symbols
Introduction Symbols Explanations of symbols & labels on the device or in user manual: The following symbols are used in this guide: The danger sign warns about a hazard. It calls attention to a procedure or practice which, if not adhered to, could result in injury or loss of life. -
Page 4: Safety Practices
Installation guide, edition 2 Safety practices It is assumed that the individual using this manual has sufficient training in the service of Personal Computers/installation of peripherals and is aware of the potential hazards including (but not limited to) electrical hazards. Make certain that you are familiar with the contents of this manual before working on the Personal Computer. -
Page 5: Table Of Contents
Introduction Table of contents Symbols Safety practices Spare parts and service availability CHAPTER 1 Introduction ..................... 4 Kit content CHAPTER 2 Preparation ..................... 5 Unpacking Optional: set-up the alternative internet connection CHAPTER 3 Installation ....................6 Adjust the IP address of the LAN-port on the computer Install the switch box Connect the instruments to the switch box... -
Page 6: Introduction
195_7000). Kit content The LAN connection kit 250.0180 contains this manual with instructions and all additional cables to set up the communication with the PC. Most PC’s are equipped with only one LAN-port, and as this will be used to connect with the ALEXYS system, an additional USB-LAN adapter is provided with this kit to be able to stay connected to the net. -
Page 7: Preparation
Preparation C H A P T E R Preparation Unpacking Inspect the transport box for possible damage as it arrives. Immediately inform the transport company in case of damage, otherwise she may not accept any responsibility. Carefully unpack the items and inspect them for completeness and possible damage. -
Page 8: Installation
Installation guide, edition 2 C H A P T E R Installation Adjust the IP address of the LAN-port on the computer Each instrument of the ALEXYS system has a fixed IP address starting with numbers 192.168.5. To enable communication between the computer and the instruments through the switch, the IP address of the LAN port should first be set to the same first set of numbers. - Page 9 Installation 4. Double click in the menu on 'Internet Protocol Version 4 (TCP/IPv4)' to open its properties window. 5. Set the properties as in the screendump below - IP address: 192.168.5.10 - Subnet mask: 255.255.255.0 - Gateway and DNS fields empty 6.
-
Page 10: Install The Switch Box
Installation guide, edition 2 Install the switch box The switch box extends the number of LAN-ports for the ALEXYS to 4. To install the switch, do the following: 1. Connect the switch to a power source with the power adapter. 2.
