Casio XD-SA Series Quick Manual


CASIO Electronic Dictionary
Quick Guide
(XD-SA Series)
 MA2412-A Published:12/2024
The contents of this Quick Guide apply to CASIO
XD-SA Series Electronic Dictionaries. Most
illustrations and screen shots show the
XD-SA20000.
• The screen shots and product illustrations shown
in this manual may be different from those of the
actual product. Also note that some keys and
screen indicators are shown in simplified form.
→
Example:
→
Quick Palette
Loading Batteries for the First Time
Load the two AA-size batteries that come with
the electronic dictionary before trying to use it.
1
Remove the battery cover on the back of
the product.
• Pressing down on the
two marks shown in
the nearby figure, slide
the cover in the
direction indicated by
the arrows.
2
Load two batteries.
• Load each battery with
the minus (–) pole
facing as shown in the
nearby illustration.
• With the battery on
top of the ribbon,
press down on the
plus (+) end of the
battery.
• Make sure the (+) and
(–) ends are facing
correctly and that the
spring is pressed
straight down.
3
Replace the battery cover.
4
Remove the
stylus from the
side of the
electronic
dictionary and
then press the
RESET button.
• Do not use a
toothpick, lead
RESET button
pencil, or other
object with a breakable tip.
5
Unfold the electronic dictionary.
Display
Arrow keys
Recording microphone
Speaker
This causes the 電池設定 (Battery Setting) screen
to appear.
液晶保護フィルムが正しく貼られて
• If the message
いない． ． ．
(Display screen protective film may
not be affixed properly． ． ． ）appears on the
display, remove the protective film (option)
from the display screen. If there is no
protective film on the display screen, refold
the electronic dictionary panels and then
repeat steps 4 and 5 again.
EN 6
Touch
batteries [AA-size LR6]).
• When using batteries other than those that
come with the electronic dictionary, select one
of the options below.
- Commercially available eneloop rechargeable
batteries:
Touch
- Commercially available alkaline batteries:
Touch
7
Configure date
and time settings.
• Use the
and
buttons for each
setting to scroll
through values and change the current date
and time settings.
• Touch
• To toggle between 12-hour and 24-hour
timekeeping, touch 【12/24】 in the upper right
【ホーム】
button
corner of the screen.
• To display the Home screen without changing
the date and time settings, touch 【
】 (Do not configure settings now).
い
8
【上記日時で決定】
Touch
and time).
• Wi-Fi settings screen appears.
9
Touch 【設定をはじめる】 (Configure settings) to
configure the Wi-Fi settings.
10
Touch 【接続先 1 未登録】 (Connected router 1
not registered).
• You can register up to 3 routers to connect to.
• A list appears showing the available routers.
11
Touch the router you want to connect to.
• Enter the password (encryption key) for the
router.
• If the name of the router you want to connect
to is not listed, touch 【再検索】 (Redo search)
to update the list.
• If the Product Update screen appears, follow
the on-screen instructions to update your
product.
• Once Wi-Fi connection is completed, the login
screen appears.
• To use another connection method, touch
whichever of the following is correct for your
system:
【詳細設定接続】 (Connection using detailed
–
settings)
This allows you to connect by specifying
the IP address and proxy.
【ルーターのボタンを押して接続】
–
(Connection using the router button)
Touch this option if your router has a WPS
button (the button name may differ
depending on your device). Follow the
on-screen instructions to complete the
connection.
• When the Wi-Fi settings are completed, the
Home screen appears.
Stylus
Turning Power On and Off
Power turns on and off
automatically whenever
you open or close the
electronic dictionary
panels.
• You also can use the
following key operation to
turn power on or off.
1
Press the
turn on power.
2
Press
アルカリ乾電池 単
[ 3 LR6] (Alkaline
充電池 単3
[ eneloop].
アルカリ乾電池 単３ 6
[ LR ].
to scroll a value forward or
to scroll back.
今は設定しな
(Apply above date
Power key
s
'
key to
again to turn off power.
General Guide
Display
You can touch the screen to select an on-screen item,
swipe it to scroll to another screen, or input characters
by handwriting them on the screen.
Quick Palette
Touch the Quick Palette icons
to perform operations or display
function menus.
①
②
③ ④ ⑤
①
(Power) Key
②
(Page Scroll) Keys
• Scroll the screen contents upwards or
downwards.
• While a definition screen is displayed, pressing
and releasing and then one of these keys
will display the definition of the previous or
following term.
③
(Shift) Key
• To use "?", "*" and other functions with the
same frame or same color as this key, press
, release it, and then press the key you
want to use.
④
(Back) Key
• Back-steps to the previous screen.
⑤
(Select) Key
• Executes an operation after you input a term,
select an item, etc.
⑥
(Arrow) Keys
• Use these keys to move between selected
items, or to move the cursor.
⑦
(Delete) Key
• Deletes a character after an input mistake, etc.
⑧ Character Keys
• Use these keys to input characters.
⑨
【 機能メニュー 】
(Function Menu) Icon
• Displays the function menu.
⑩
【 戻る 】
(Back) Icon
• Same function as ④ .
⑪
【 音声 】
(Audio) Icon
• Touch to hear audio.
⑫ 【履歴】(History) Icon
• Re-looks up something you looked up
previously.
⑬ 【ホーム】(Home) Icon
• Displays the Home screen.
⑬
⑫
⑪
⑩
⑨
⑧
⑦
⑥
1
