- Page 1 Beluga UPV/S flush-mounted Hair dryer / Warm air shower Installation and operation...
-
Page 2: Table Of Contents
Read these instructions carefully before use and keep them in a safe place. Pass the instructions on to a subsequent user where appropriate. Accessibility Customer service and warranty Warranty 15.1 Warranty declaration and conditions 15.2 Content and scope of the warranty Spare parts Beluga UPV/S www.rez-ag.ch... -
Page 3: Safety Instructions
Material damage (equipment damage, consequential damage, environmental damage) Do not insert any objects into the appliance openings. Disposal of appliances This symbol indicates that you need to do something. The required actions are described step by step. Beluga UPV/S www.rez-ag.ch... -
Page 4: Appliance Description
Do not cover the appliance to avoid overheating it. Ensure that no moisture or water penetrates into the appliance. The height adjuster should also not come into contact with water. Do not wash walls with sprayed water where Rez height adjusters are fitted. 2.3 Test mark Damage Unsuitable cleaning agents can damage the appliance housing. -
Page 5: Installation
The appliance is intended exclusively for indoor installation. Exposing the appliance to the effects of weather may damage it. Note The appliance must be mounted on a wall with a sufficient load-bearing capacity. Mount the appliance on a vertical wall only. 1000 1000 1000 Beluga UPV/S www.rez-ag.ch... -
Page 6: Reference Values For Mounting Height
– Torx screwdrivers, T20 and T25 – Electric flat-blade screwdriver – Electrical pliers – Drilling machine (drills / dowels, depending on wall construction) – Cordless screwdriver (including inserts) – Spirit level – Pencil – Scraper (cover removed) Beluga UPV/S www.rez-ag.ch... -
Page 7: Mounting The Wall Attachment
Preparation niche (recess to be made on site) W x H x D 270 x 1269 x 87 mm If required, the mounting box can be insulated against noise in the cavities caused by the tolerances. Beluga UPV/S www.rez-ag.ch Tolerances according to DIN 18202 Preparazione della nicchia (nicchia da costruire) L x A x P 270 x 1269 x 87 mm Se necessario, la scatola di montaggio può... - Page 8 Position the cover (frame) and click it in firmly at the without the power unit and cover. the customer and connect it to the connection termi- top first (noticeable click!). nal in accordance with the labelling. Simply push the remaining cable down at the back. Beluga UPV/S www.rez-ag.ch...
-
Page 9: Electrical Connection
The power supply is connected directly to the appliance or, optionally, via an electrical connection cable with a mains plug. Note Ensure that the length of the mains connection cable is sufficient to be routed correctly through the wall mounting to the connection terminal. Beluga UPV/S www.rez-ag.ch... -
Page 10: Commissioning
Only now may the lower outlet grille and the print control cover be removed. Risk of electric shock! Remove the motor protection grille, dusting out the fan louvres with a round brush and vacuum cleaner. Turn the fan blades until the dust falls Beluga UPV/S www.rez-ag.ch... -
Page 11: Technical Data
The take-back system achieves high recycling rates for materials in order to reduce the burden on landfill sites and the environ- Dimensions ment. Together, we are making an important contribution to environmental protection. Height 1259 Width 13.3 Disposal outside Switzerland Depth flush wall Dispose of this appliance properly and in accordance with local regulations and laws. Beluga UPV/S www.rez-ag.ch... -
Page 12: Customer Service And Warranty
General Terms and Conditions Spare parts are guaranteed to be available for 20 years. We refer to the General Terms and Conditions (GTC) of Rez AG, which can be viewed or downloaded at any time at www. rez-ag.ch/service. Guarantor 15.2 Content and scope of the warranty... -
Page 13: Spare Parts
Motor protection grille Heater 1915 W incl. connection cable Main isolation plug N / E / L Power cable to plug Cover screw Hinge pin Print conrol cover Print control / HF radar sensor Discharge grille Adhesive Rez logo Beluga UPV/S www.rez-ag.ch... - Page 14 Beluga UPV/S www.rez-ag.ch...
