VDO VRM 6200 Installation Manual

Operating System Software
New Operating System Software for VRM 6200
B45.03.070822

How to perform the update

The files required for the update are stored as compressed data in a Zip file for free download
from. Once unpacked the files provide a so-called OS image which shall be copied to an empty
CD-ROM into its root directory
Note: Do not add, modify or delete any files
Please follow the below-mentioned steps:
§
Download the Zip file "B45-03-070822.zip" to the HDD of your computer
Unzip the file into an empty folder
o
Note: Do not use other decompression software than WinZip since it may cause errors
§
If not already available, create MP3 files in a total capacity of min. 45MB
Note: Due to the very small file size of the OS image, the MP3 files are required to keep
VRM 6200 DVD drive spinning.
§
Insert an empty CD-ROM to your PC's CD-ROM writer
§
Start your CD burning software.
Create a folder "MP3" in the root directory of the CD-ROM
o
Copy the MP3 files into the folder "MP3"
o
Copy the OS image files into the root directory of the CD-ROM
o
Start burning
o
Note: Recommended writing speed = x8
Disc status = Close session
§
Power on VRM 6200 and insert the completed disc. The disc will now be read.
§
On appearance of the selection screen chose "MCU". The update process will start automatic.
Note: Do not turn off power! The unit will perform an auto-restart after approx. 2min.
§
After re-start, remove and re-insert disc.
§
On appearance of the selection screen chose "MPEG". The update process will start automatic.
Note: Do not turn off power! The unit will NOT perform an auto-restart
§
After approx. 3min. the "VDO Dayton" screen appears and stays. Now power-off VRM 6200.
§
Power on again and remove disc.
§
Power off again. The update is now finished!
Installation guide
