REPUBLIC OF GAMERS GX601 Service Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Doc. No:
Date: 2023/12
Rev.:
Chassis Service Manual
Model: GX601
Authorize by
Review by
Originator by
Form No :

Advertisement

loading
Need help?

Need help?

Do you have a question about the GX601 and is the answer not in the manual?

Questions and answers

Summary of Contents for REPUBLIC OF GAMERS GX601

  • Page 1 Doc. No: Date: 2023/12 Rev.: Chassis Service Manual Model: GX601 Authorize by Review by Originator by Form No :...

  • Page 2: Copyright Information

    COPYRIGHT INFORMATION No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except documentation kept by the purchaser for backup purposes, without the express written permission of ASUSTeK COMPUTER INC.
  • Page 3 Contents 90DC0020-B0000C Black left side door  90DC0020-B0010C White left side door  90DC0020-B0001C Black right side door  90DC0020-B0011C White right side door  90DC0020-B0004C FIO module  90DC0020-B0005C Front panel  90DC0020-B000AC Light strip  90DC0020-B0025C Black front right aluminum component ...
  • Page 4 90DC0020-B0000C GX601 LEFT SIDE DOOR/CSC｜Black left side door Fully-assembled. (Consists of Left side glass*1, Warning sticker*1, Upper steel strip*1, Lower steel strip*1, Mylar insulation*1) 90DC0020-B0010C GX601 LEFT SIDE DOOR/WT/CSC｜White left side door Fully-assembled. (Consists of Left side glass*1, Warning sticker*1, Upper steel strip*1, Lower...
  • Page 5 GX601 RIGHT SIDE DOOR/CSC｜Black right side door Fully-assembled. (Consists of Right side glass*1, Upper steel strip*1, Lower steel strip*1, Mylar insulation*1) 90DC0020-B0011C GX601 RIGHT SIDE DOOR/WT/CSC｜White right side door (White Edition) Fully-assembled. (Consists of Right side glass*1, Upper steel strip*1, Lower steel strip*1, Mylar insulation*1)
  • Page 6 Disassembly method: *Please handle with care when disassembling and assembling the glass side panel to avoid collision/drop/heavy pressure. 1. Press the rear switch and lift the damaged glass panel. 2. Align the lower edge of the new glass panel with the groove on the footstand and insert it. 3.
  • Page 7 90DC0020-B0004C GX601 FIO MODULE/CSC｜FIO module FAQ: FIO buttons and ports not working, Case lighting not working Disassembly method: 1. Remove both side glass panels. 2. Remove the two screws on the cable cover panel, open it up to a 90-degree angle, and...
  • Page 8 3. Disconnect the cables connected to the motherboard. 4. Remove the cable ties and straps. 5. Remove the black signal cables.
  • Page 9 6. Disconnect the LED cables. 7. Lift the handle to remove the top cover, and then remove the two screws. 8. Press the front latch to remove and replace the FIO module. 9. After confirming that the appearance and buttons are normal, reassemble them back.
  • Page 10 90DC0020-B0005C GX601 FRONT PANEL/CSC｜Front panel Disassembly method: 1. Remove both side glass panels.
  • Page 11 2. Remove the two screws on the cable cover panel, then open it up to a 90-degree angle. 3. Lift the cable cover panel upwards to remove.
  • Page 12 4. Remove three screws to pull out the front panel. 5. Separate the panel from the front glass (be careful to hold the front glass to prevent it from falling).
  • Page 13 6. Remove the other two screws on the opposite side while holding the front glass to prevent it from falling, then take out the front glass for replacement. 7. Reassemble front panel, cable cover panel and both side glass panels back. 90DC0020-B000AC GX601 FRONT ARGB LIGHT BRD/CSC｜Light strip FAQ: Case lighting not working...
  • Page 14 Disassembly method: 1. Detach the front filter from the chassis. 2. Disconnect the LED cables. 3. Unscrew the three long screws on the left side panel from inside the chassis.
  • Page 15 4. Gently push the hook on the upper side of the left side panel towards the outside of the chassis to loosen and detach the plastic hook from the metal piece. 5. Remove the left side panel from the chassis and pull out the left LED cable through the hole on the top of the chassis.
  • Page 16 7. Place the ASUS accessory box under the glass to prevent the glass from suddenly detaching or getting damaged. 8. Separate the two plastic pieces by hand without the need for tools. 9. Tear off the LED light strip, after the wire head pass through the square hole in the plastic piece, the light strip can be torn to the end.
  • Page 17 10. Install the new LED strip by aligning the end of the strip with the side wall and gradually sticking it upwards after removing the backing paper. 11. Once the strip is properly attached, pass the LED wire head through the square hole. 12.
  • Page 18 90DC0020-B0025C GX601 AL FRONT RIGHT/CSC｜Black front right aluminum component Fully-assembled. (Consists of Outer plastic part*1, Inner plastic part*1, Aluminum panel*1, M3 hexagon washer screws*4, ROG fabric label*1, Rubber gaskets for glass*2) Disassembly method: Unscrew the screws. 90DC0020-B0065C GX601 AL FRONT RIGHT/WT/CSC｜White front right aluminum component Fully-assembled.
  • Page 19 90DC0020-B0095C GX601 AL FRONT LEFT/CSC｜Black front left aluminum component Fully-assembled. (Consists of Outer plastic part*1, Inner plastic part*1, Light pipe*1, Light strip*1, Aluminum panel*1, M3 hexagon washer screws*3, Rubber gaskets for glass*2) Disassembly method: Unscrew the screws. 90DC0020-B0055C GX601 AL FRONT LEFT/WT/CSC｜White front left aluminum component Fully-assembled.
  • Page 20 90DC0020-B0045C GX601 AL TOP RIGHT/CSC｜Black upper right aluminum handle Disassembly method: Unscrew the screws. 90DC0020-B0085C GX601 AL TOP RIGHT/WT/CSC｜White upper right aluminum handle Disassembly method: Unscrew the screws.
  • Page 21 90DC0020-B0035C GX601 AL TOP LEFT/CSC｜Black upper left aluminum handle Disassembly method: Unscrew the screws. 90DC0020-B0075C GX601 AL TOP LEFT/WT/CSC｜White upper left aluminum handle Disassembly method: Unscrew the screws.
  • Page 22 90DC0020-B001LC GX601 MISC/CSC｜Footstand Contents: ①Left footstand*1 ②Right footstand*1 Disassembly method: Unscrew the screws. 90DC0020-B000EC GX601 TOP FILTER/CSC｜Top filter Fully-assembled. (Consists of Upper cover base*1, Upper filter*1, Upper cover mesh*1, Upper cover latch*1)
  • Page 23 Disassembly method: Press the rear side tab upward and pull it backward to remove. 90DC0020-B001EC GX601 FILTER/CSC｜Front and bottom filters Fully-assembled. (Consists of Cover base*1, Filter*1) *The front filter and the bottom filter are the same component. Disassembly method: Simply pull them out. They have a specific orientation, so make sure...
  • Page 24 90DC0020-B0003C GX601 SYSTEM FAN/CSC｜140mm fan Disassembly method: Unscrew the four corner screws to remove it. FAQ: Fan not spinning, noise, Unable to control fan speed...
  • Page 25 90DC0020-B003LC GX601 MISC/CSC｜Fan bracket Contents: ①Top water-cooling radiator bracket*1 ②Front window water-cooling radiator bracket*1...
  • Page 26 90DC0020-B0006C GX601 HUB/CSC｜Fan hub Disassembly method: Unscrew the three screws to remove it. FAQ: Fan not spinning, Unable to control fan speed...
  • Page 27 90DC0020-B000JC GX601 HIDE/CSC｜Cable cover panel Contents: Plastic panel*1, Suspension screws*2...
  • Page 28 90DC0020-B0009C GX601 VGA HOLDER/CSC｜Black VGA holder Fully-assembled. (Consists of Function bracket*1, GPU swing arm*2, M3 nuts*2, VGA support tube*2, Flat round head M3 chassis screws*4, Suspension screws*2) Disassembly method: Unscrew the 2 screws on the rear side. 90DC0020-B0019C GX601 VGA HOLDER/WT/CSC｜White VGA holder Fully-assembled.
  • Page 29 90DC0020-B000KC GX601 PCI/CSC｜Black PCI vertical GPU bracket Fully-assembled. (Consists of PCI slot cover*2, Vertical GPU bracket*1, Chassis screws 6#32*6) 90DC0020-B001KC GX601 PCI/WT/CSC｜White PCI vertical GPU bracket Fully-assembled. (Consists of PCI slot cover*2, Vertical GPU bracket*1, Chassis screws 6#32*6)
  • Page 30 90DC0020-B002KC GX601 SINGLE PCI/CSC｜Vertical PCIE bracket Contents: Black PCIE bracket*1, White PCIE bracket*1 *Can be replaced with PCI vertical GPU bracket.
  • Page 31 90DC0020-B001JC GX601 HIDE/CSC｜PSU cover Contents: ①Front cover plate*1 ②Rear cover plate*1 ③Transparent side cover*1...
  • Page 32 90DC0020-B000LC GX601 MISC/CSC｜Repair kits Contents: ①Fabric handles*1 ②PSU transparent side cover*1 ③PSU bracket*1 ④PCI slot cover*8 ⑤HDD tray*2 Chassis foot pad*4, 6*5 thin flat round head screw*1, Motherboard standoff*1, Motherboard pillar*1, M4 countersunk head hexagon socket screws*5, Thumb suspension screws*2,...
  • Page 34 90DC0020-B002LC GX601 MISC/CSC｜HDD tray Contents: Tray*2, Tray bracket*1 90DC0020-B000DC GX601 CPU 8 PIN CABLE/CSC｜CPU 8pin cable 90DC0020-B001DC GX601 19 PIN CABLE/CSC｜19pin cable...
  • Page 35 90DC0020-B0007C GX601 ACCESSORY/CSC｜Black accessory box Contents: Vertical GPU Kit*1, Pump bracket*1, Pump bracket captive thumb screw*1, Cable ties*10, USB type A (3.0) dust cover*2, USB type C (3.1) dust cover*1, Flat round head M3 chassis screws*40, Standoff tool*1, Motherboard standoffs*3, Chassis screws 6#32*4 90DC0020-B0017C GX601 ACCESSORY/WT/CSC｜White accessory box...
  • Page 36 90DC0020-B000CC GX601 COLOR BOX/CSC｜Black box 90DC0020-B001CC GX601 COLOR BOX/WT/CSC｜White box...
  • Page 37 ◆Low-speed fan operates at a DC voltage of +6.3V (greater than the 5V start voltage to ensure fan startup) ◆High-speed fan operates at a DC voltage of +12V ④If a user replaces the DC fans in GX601 and finds that the low-speed mode fails to start,...
  • Page 38 RGB header of the motherboard. ③Two types of lighting control of GX601 (1) Self-control (2) Sync up with MB Lighting If the LED button on the FIO panel is unable to switch the lighting control, please...
