Summary of Contents for Ocean V150
- Page 1 Ocean Ocean V150 Robust Reliable Proven Competitive eeeceRobust » Operating Manual « Ocean V150 - 1 - www.oceanmachines.com...
- Page 2 Ocean V150 - 2 - www.oceanmachines.com...
-
Page 3: Table Of Contents
Ocean V150 Contents: 1. Overview 2. Features 3. Machine Layout 4. Technical Specification 5. Preparation & Operations 6. Adjustments & Operations 7. PLC Screen & Operations 8. Maintenance 9. Troubleshooting 10. Electrical Schematic 11. Spare parts - 3 - www.oceanmachines.com... -
Page 4: Overview
Ocean V150 1. Overview The MODEL V150 is a full-automatic packaging machine, which is manufactured with worldwide advanced technology. It has been developed several years and been widely used around the World. The machines features are PLC program-control, touch-control and digital temperature control. -
Page 5: Machine Layout
Ocean V150 3. Machine Layout The machine can be supported by auto weighing machine, meter glass dosing machine, manual batch conveyor and spiral dosing machine. It has an extensive range of package, suitable for packing of various kinds of item such as grains, blocks, bars and powder, etc. - Page 6 Ocean V150 - 6 - www.oceanmachines.com...
-
Page 7: Technical Specification
Ocean V150 4. Technical specification： Speed: 5~60bag/min Size of bag: W50~150mm; L: 80~200mm Weight: 150kg Dimension: 910（w）×1000(L)×1000(H)mm 5. Preparation & Operation 5.1 Power supply AC220V（±10%） 、50-60HZ、3KW Attention: Make sure the ground is connected 5.2 Compressed air supply Compressed Air: 6 bar Air flow: 0.25m³/min... -
Page 8: Adjustment And Operation
Ocean V150 6. Adjustment & operation 6.1 Film Loading The film Holder is driven by a motor. Depends on the position of the tensioning roll, the motor will turn to unwind the film. Measure the width of the film and adjust the fixed pulley, then put in the film roll and lock it with the adjustable pulley as show in the diagram below. - Page 9 Ocean V150 Check the edge on both sides of the film after entering the forming tube. If not equal the “Error Correct” function ( see Chapter 7.2 ) may be used to make it equal. With the Error Correction the whole frame where the rolls are connected is moving either to the left or right side.
- Page 10 Ocean V150 6.2.2. Change of print data Second turn the handle and then pull it First push the handle forward in and hold it Loosen these screws - 10 - www.oceanmachines.com...
- Page 11 Ocean V150 Change the numbers and Letters inside to the desired combination. Make sure all is in the same height, tighten the screws again. Put it back into the machine, push handle and turn, check if it is locked. 6.2.3 Print positioning...
-
Page 12: Adjustment Of Sensor
Ocean V150 6.3 Adjustment of Sensor The Photocell sensor will detect the color mark which marks the length of the film. Color mark on Film To adjust the sensitivity of the sensor turn regulator To adjust position, loosen the screw and move To adjust the sensor first move into the right position. -
Page 13: Plc Screen & Operations
Ocean V150 6.4 Film Pulling Belt Pressure adjustment The accuracy of the bag length depends on the movement of the film pull belt Compressed Air is used to pull the Film pull belt forward onto the film. Adjust the air pressure to 3 bar, the regulator can be found on the backside 7. - Page 14 Ocean V150 Picture 2 – Work screen (7.1) AUTOMATIC – Manual functions (7.2) MANUAL – Additional functions (7.3) FUNCTION – Parameter adjustment (7.4) PARAMETER – Alarm description ALARM (7.5) - 14 - www.oceanmachines.com...
- Page 15 Ocean V150 7.1 AUTOMATIC PAGE show the program number show the weight of bag show bag size Full See chapter automatic mode Show actual Packing Speed Show total without Bag counter filling Film Pull belt Show Forward amount of (close)
-
Page 16: Manual Page
Ocean V150 7.2 MANUAL PAGE 7.3 FUNCTION PAGE Turn the color mark sensor on/off To turn gusset parts on/off Buttons to go to designated pages - 16 - www.oceanmachines.com... - Page 17 Ocean V150 7.4 Parameter Setting 7.4.1 Parameter Setting 1/3 page Save to program Program number next page Length of Delay of film Speed of transport Film pulling belt Delay time for sealing Duration time for sealing Buttons to go to designated pages 7.4.2 Parameter Setting 2/3 page...
-
Page 18: Alarm Page
Ocean V150 7.4.3 Parameter Setting 3/3 page Buttons to go to designated pages 7.5 Alarm Page Buttons to go to designated pages - 18 - www.oceanmachines.com... -
Page 19: Maintenance
Ocean V150 8. Maintenance 8.1. Film pulling belt replacement The film pull belt should be checked everyday. If it wares out the film tends to slip, it must be replaced. First open the cover, loosen the M12 bolt and nut, turn the M6 screw to make the up pulley move down. -
Page 20: Troubleshooting
Ocean V150 9. Troubleshooting Problem Possible Cause Solution Machine does not work when Emergency stop has been Reset the emergency stop press the “ON” button on the pressed button touch screen Breaker trip 1. Heater element defective 1. Check the elements one 2. -
Page 21: Electrical Schematic
Ocean V150 10. Electrical Schematic 10.1. Main Circuit - 21 - www.oceanmachines.com... -
Page 22: Spare Parts
Ocean V150 10.2. PLC connection 11. Spare Parts Please visit www.oceanmachines.com/catalog to view the latest available spare parts and pricing for this machine. - 22 - www.oceanmachines.com...
