Summary of Contents for VDO MD 4000

  • Page 2: General Information

    USER INSTRUCTIONS English C O N T E N T S General information ............................... Installation .................................... Basic function ..................................The MD4000 menu function ............................Guarantee ..................................... GENERAL INFORMATION This DAB receiver MD4000 is designed to be used with the MR4000 head unit. This user manual refers directly to the use and function of the MD4000 when connected to the approved head unit.
  • Page 3 GREATER USABILITY WITH DAB As well as providing enhanced reception and CD comparable sound quality, DAB also allows for the transmission of additional data alongside the audio broadcast. This additional information allows for selection of programs by type (PTY). PTY places programs into categories by subject and content, allowing the user easier and simplified selection of the desired subject matter e.g.

  • Page 4: Installation

    INSTALLATION Refer to the separate installation card. Before installation and mounting please ensure that all parts needed are present, and that you have the correct tools needed to complete the task. As the MD4000 DAB Receiver has initially to be connected to the MR4000 Radio, it is strongly recommended that the negative car battery terminal be disconnected until the receiver has been mounted and fully installed.

  • Page 5: Basic Function

    BASIC FUNCTION PUSH TURN POWER SOUND MUTE REPEAT DISPLAY DAB or AUXILIARY RADIO LEGEND: Press the button. Turn the button. U S I N G T H E D A B M E N U • DAB Mode: Listen to DAB service. PUSH TURN •...

  • Page 6: T O R E C A L L A P R E S E T

    U S I N G T H E L E A R N F U N C T I O N When utilising the DAB function, the Learn procedure will automatically update the DAB ensembles. This utility is also useful if you move out of a DAB zone and need to retune the DAB frequencies within a certain area.
  • Page 7 P A D ( P R O G R A M A S S O C I A T E D D A T A ) Program Associated Data is a service provided by DAB stations, it is the broadcast of additional associated data.
  • Page 8 S E L E C T I N G F R O M T H E P R O G R A M M E L I S T PUSH TURN PUSH TURN PUSH TURN T H E D A B / F M S W I T C H The DAB/FM Switch is a unique function that allows the best quality of reception possible.
  • Page 9 PTY SELECTION LIST Program Type Description None No Program Type selected News News and news orientated programs Affairs Current Affairs Information General information services and advice Sport Sport and sport orientated programs Education Educational programs Drama serialised radio programs and plays Culture All programs concerned with aspects of national or regional culture...
  • Page 10 3111 115 34190...
