EYELA MMS-120 Instruction Manual

Multi-shaker

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Shaking

Multi-shaker

Apparatus

Model MMS-120

Model MMS-220

Model MMS-320

Model MMS-3020

This instruction manual is designed to use the product efficiently and safely

with keeping its best performance.

IMPORTANT

Please keep this manual in a place easily accessible to every user.

Be sure to read "Safety precautions"

before use.

Tokyo Rikakikai Co., Ltd.

取扱説明書

R01

Table of Contents

Need help?

Do you have a question about the MMS-120 and is the answer not in the manual?

Questions and answers

Summary of Contents for EYELA MMS-120

Page 1 取扱説明書 Shaking 取扱説明書 Multi-shaker Apparatus Model MMS-120 Model MMS-220 Model MMS-320 Model MMS-3020 This instruction manual is designed to use the product efficiently and safely with keeping its best performance. Be sure to read “Safety precautions” before use. IMPORTANT Please keep this manual in a place easily accessible to every user.
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION 1. Warning signal word To ensure the safety, this manual defines the Because of the function and characteristics, this information on such matters as requiring particular product may cause accidental injury when touched care in the safety as follows in terms of the carelessly during operation.
Page 3 2. Warning Display on the Product For particularly important warning instructions, the warning label is provided to the product main body. The labelling position is shown below. When using the product, be sure to pay due attention to the description of the warning. * If damaged and illegible, be sure to change the warning label to the new one.
Page 4: Table Of Contents
Introduction This instruction manual explains installation, operation, troubleshooting, maintenance and inspection, and discarding procedures for the products below: Multi-shaker Models: MMS-120 MMS-220 MMS-320 MMS-3020 Always read this manual before use to ensure familiarization of the product. Table of contents 5.
Page 5: For Safe Operation
For safe operation The shaking table of the product is shaken forward and backward as well as right and left. Be careful to ensure the safety during use. Always operate within the specified shaking speed range. The product adjust the balance according to the shaking load and has the Caution shaking table specified according to the shaking speed.
Page 6: Product Overview
An electric shock or a malfunction may result if the product is modified or used for any purposes other than that specified. Specifications Shaking apparatus Multi-shaker Name of product MMS-220 MMS-120 Model Shaking method Turning Reciprocal 20～250rpm ※2 ※1 Shaking speed range ※2...
Page 7 Shaking apparatus Multi-shaker Name of product MMS-320 MMS-3020 Model Shaking method Reciprocal/turning 20～250rpm ※2 ※１ Shaking speed range ※2 Amplitude 25mm Shaking speed Dial setting and digital display setting/display Time setting/display Setting with sheet key and digital display Safety function Fuse（500mA）, motor overload protective circuit, etc Auto stop function (up-count and down-count) or cumulative time selection Auxiliary functions...
Page 8: Optional Parts
2-3 Optional Parts ■ Optional composition Angle holder for flask Angle holder for Fit sheet test tubes Flask holder Angle holder for centrifuge tube Spring type universal shaking table Multi-shaking table Sheet shaking table Shaking table for centrifuge Shaking apparatus main body ※...
Page 9 This is the shaking table that holds 15mL centrifuge tubes horizontally. Model MMS BASE-S15 MMS BASE-L15 Code No. 194490 194550 Applicable model MMS-120,220,320 MMS-3020 No. of container racks 22 pieces 36 pieces External size 290× 250× 44 390× 290× 44 Width ×...
Page 10 This is attached to the multi-shaking table or the angle holder for flasks for use. No. of rubbers to be installed to the shaking table Model Flask capacity Code No. Mass MMS-120 MMS-220 MMS- 3020 MMS-320 50mL 140170 Approx.10g Ring spring（R)
Page 11 ● Spring type universal shaking table This table can hold the test tubes, Erlenmeyer flask, and various containers. Model MMS TRAY-S MMS TRAY-L 140090 140100 Code No. MMS-120 Applicable model MMS-220 MMS-3020 MMS-320 Φ16 test tube 120 pieces 204 pieces...
Page 12: Names Of Parts
2-4 Names of parts Model ＭＭＳ-120 ModelＭＭＳ-220 Fuse holder Hold-down spring Power Plug Shaking table base Back face One-touch lever Power switch Control panel Fuse holder ModelＭＭＳ-320 ModelＭＭＳ-3020 Hold-down spring Power Plug Shaking table base Back face One-touch lever Shaking selector lever Grip Power switch...
Page 13: Names And Functions Of Control Assembly
３ Names and functions of control assembly 3-1 Control panel Timer Speed Controller Accumulation Up Count Auto Stop Down Count Clear Stop ① ⑫ ⑪ ② ⑩ ③ ⑨ ④ ⑧ ⑤ ⑦ ⑥ Function Name Used to set the shaking speed. Press the dial to set the speed and turn it to ①...
Page 14: Timer Mode
3-2 Timer Mode ※ For the detailed setting method, refer to “2. Timer Mode Three timer modes shown below can be selected Display and Setting” of p.19 “5-2 Operation Method.” according to the purpose: ・ Accumulation ・ Auto Stop ・ UP count ・...
Page 15: Safety Functions
3-4 Safety Functions This product is provided with the following safety functions. In case of abnormality, refer to “Causes of troubles and solutions.” Safety functions Safety functions Description Cause and reset method Short-circuited power circuit or flow of overcurrent Abnormal current blows the fuse, Fuse shutting off power supply.
Page 16 Safety function Alarm display Cause and reset method ・ The product was operated with the supply voltage exceeding the rated voltage. Over-voltage alarm Confirm that the supply voltage is the rated one, and turn ON power supply again. ・ Shaking stop If the alarm is displayed again, any internal parts of the ・RUN/STOP key and dial product may have developed abnormality.
Page 17: Installation
● Place with minimum dust ● Place free from direct sunshine ● Place where airy or well-ventilated The related products shown below can be installed: ●MMS-120,220,320,3020（one unit）・Low- and constant-temperature chamber for shaking apparatus Models FMC-100 and 1000 ・Constant-temperature chamber for shaking apparatus Models FMS-100 and 1000 ※...
Page 18: Connecting Utilities
4-2 Connecting utilities Warning Warning Confirm the voltage, phase, capacity, Always connect to the outlet with and the type of receptacle of power earth terminal. supply. When connection to the “outlet without earth terminal” is inevitable, be sure to connect the earth wire of the Wrong connection of power supply may cause fire or earth adaptor to the ground, Otherwise, leakage cannot electric shock...
Page 19: Operation
Operation 5-1 Preparation for operation Caution Be sure to set the lever dial to the designated position correctly. When changing the shaking method in Models 320 and 3020, always set the dial of shaking type selector lever to a middle point of indication on the shaking type indication seal.
Page 20 2．Setting the shaking table Various shaking tables and holders are available separately. Prepare the appropriate one while referring to p.4 “2-3 Options.” Caution Fit the spring into the groove Arrange containers in the well- balanced state. When the load on the shaking table is displaced or when the center of gravity of the load is high, excess weight is applied to the product main body even though the weight is less than the allowable load...
Page 21 3．Setting various holders The holders are available separately. All of these holders can be installed to the multi-shaking table for Attached screw use. ● Setting the flask holder The flask holders are available in various sized according to the flask capacity, Note that the number of flasks that can be set to the Flask holder multi-shaking table and angle holder is determined...
Page 22 ● Setting the centrifuge tube angle holder and installing the centrifuge tubes Attached screw ※ Setting the angle holders and adjusting the rotation angle are common procedures for ll models. (1) Install the angle holder rack to the multi-shaker with Centrifuge tube attached four screws.
Page 23: Operation Method
5-2 Operation Method Caution Stop operation in case of any abnormality. In case of abnormality, turn OFF the power switch and refer to p.28 ”Causes of troubles and solutions.” (1) Confirm that the power switch is OFF, and then insert the power plug into the outlet.
Page 24 ２．Timer mode display and setting [Time display screen] Ｔｉｍｅｒ Three timer modes as follows can be selected according to the Ａｃｃｕｍｕｌａｔｉｏｎ purpose: ・ Accumulation ＵｐＣｏｕｎｔＡｕｔｏＳｔｏｐ Accumulated run time displayed ＤｏｗｎＣｏｕｎｔ・Auto Stop・ UP count ▲ ▼ Ｃｌｅａｒ...
Page 25 [Accumulation setting screen] (3) The Accumulation setting screen appears. And the Ｔｉｍｅｒ Accumulation lamp goes ON. Ａｃｃｕｍｕｌａｔｉｏｎ ※To acknowledge the setting her, proceed to (6). ＵｐＣｏｕｎｔＡｕｔｏＳｔｏｐＤｏｗｎＣｏｕｎｔ Press the ▽ key to proceed to the next step. ▲...
Page 26 ③ Auto Stop timer setting The setting method is common for UP-count and DOWN-count. ※ When Accumulation has been selected, timer setting cannot be made. Ｔｉｍｅｒ (1) Press the Set key in the normal time display screen. Ａｃｃｕｍｕｌａｔｉｏｎ The screen shown below indicates that the Ｕｐ...
Page 27 ３．Setting the Power Failure Recovery Function ※ The default is the power failure recovery function By setting the power failure recovery function On or OFF, the operation shown below can be selected. Accumulation continues after power failure ・Power failure recovery function ON…… recovery when the Accumulation mode has been used.
Page 28 [Power failure recovery setting screen] (6) Press the Set key. Ｔｉｍｅｒ The screen with a blinking indication is acknowledged. Ａｃｃｕｍｕｌａｔｉｏｎ The power failure recovery setting screen “-4” appears. ＵｐＣｏｕｎｔＡｕｔｏＳｔｏｐ ※ To confirm acknowledgement, press the Set key. The Ｄｏｗｎ...
Page 29: Operation And Stop
[Shaking speed display screen] 5-3 Operation and Stop Speed Controller (1) Press the Run/Stop key. Ｒｕｎ The “RUN” lamp goes ON and the operation begins with the set conditions. Stop Stop Speed Controller Ｒｕｎ Stop [Time display screen] ① Accumulation mode Ｔｉｍｅｒ...
Page 30 ② Auto Stop UP-count operation [Time display screen] (1) When UP-count has been selected, the “UP-Count” Ｔｉｍｅｒ lamp goes ON. Ａｃｃｕｍｕｌａｔｉｏｎ The time count begins with 0 minute, and the lower ＵｐＣｏｕｎｔ right dot blinks. ＡｕｔｏＳｔｏｐちＤｏｗｎＣｏｕｎｔ ▲...
Page 31 ③ Auto Stop DOWN-count operation [Time display screen] When DOWN-count has been selected, the “DOWN-Count” Ｔｉｍｅｒ lamp goes ON. Ａｃｃｕｍｕｌａｔｉｏｎ When the set time is 30 minutes, DOWN-count begins with ＵｐＣｏｕｎｔ this set time. The lower right dot blinks. Ａｕｔｏ...
Page 32: Causes Of Troubles And Solutions
For any trouble not described in the table below. Causes of troubles and solutions contact the nearest service center. Symptom Causes Solutions Turn OFF the power switch and insert Power plug disconnected from the the power plug firmly into the outlet. outlet or not firmly inserted.
Page 33: Maintenance And Inspection
Maintenance and inspection Warning Caution Never attempt to disassembly the Use a correct method and items for product. cleaning or caring the product. The unit contains parts with high voltage applied or When cleaning or maintaining the main unit and may become hot, and disassembly may cause an shaking table, never splash water to the exterior or electrical shock or an injury.
Page 34: Disposal Of Products
Disposal of product or part must be done according to the specified disposal method. Principal components parts and disposal method Components External dimensions (mm) Model Weight How to discard 356(W)× 329(D)× 150(H) MMS-120 Approx. 14kg 356(W)× 329(D)× 150(H) MMS-220 Approx. 15kg Request the disposal Main body MMS-320 356(W)×...
Page 35: After-Sale Services
９ After-sale Services 1. In case the product does not function satisfactorily, 3. Repair during the guarantee period will be made check first referring page according to the guarantee stipulations. troubleshooting to see if this is actually a trouble. 2. If the product remains unsatisfactory even after 4.
Page 36: List Of Consumable And Replacement Parts Optional Parts
List of Consumable and Replacement parts/ Optional parts ④ Multi-shaking table ③ Angle holder for ① Shaking table for 15mL ② Shaking table for centrifuge tubes centrifuge tubes 50mLcentrifuge tubes Code No. Q'ty Std. Code No. Q'ty Std. Code No. Q'ty Std.
Page 37 ⑬ Sheet shaking table ⑭ Fit sheet ⑯ Fuse 500mA ⑮ Holder for centrifuge tubes Code No. Q'ty Std. Code No. Q'ty Std. Code No. Q'ty Std. Code No. Q'ty Std. 140130 For 120 140150 For 120 188630 For 15mL 500mA 147680 For 220...
