- Page 1 Model No. FCCA10221 FCCA15221 FCCA30221 FCCA52221 Operation Manual Vapor Compression Chiller Please read this operation manual carefully and keep it properly...
-
Page 2: Warning Notice
Preface Thank you very much for purchasing Ferrotec Chiller (herein after referred to as the "product").This manual describes in detail how to operate the product. Before installing or performing operations related to this product, be sure to read this manual carefully to have a thorough understanding of the overview and safety of this product. -
Page 3: Table Of Contents
Contents Page 1. Application 2. Basic parameters 3. Part name 4. Installation precautions 5. Parameter settings 6. Alarm functions and output 7. Refrigeration performance 8. Fault handling... -
Page 4: Application
This type of chiller is suitable for cooling down small power industrial equipments. It can be applied to the cooling of laser marking machine, laser engraving machine, non-metal laser cutting machine, metal laser cutting machine, SLA3D printer, laser drilling machine and other equipments. 2. Basic parameters FCCA10221 FCCA15221 FCCA30221 FCCA52221 Model... -
Page 5: Part Name
3. Part name Temperature controller Alarm output （H1、H2、H3） Water injection port Circulating fluid inlet Circulating fluid outlet Power cord RS485(spare) Air outlet Drain Air inlet Power Switch Air outlet Temperature controller Power Switch Water injection port Circulating fluid inlet Circulating fluid outlet Filter mounting hole Circulating fluid level gauge... -
Page 6: Installation Precautions
4. Installation Precautions The installation of the chiller must be completed by professional technicians and should comply with relevant regulations, standards and product operation manuals. When installing, check the following: 1. After opening the box, the user should carefully check the whole machine to confirm that there is no damage to the product parts during transportation. - Page 7 2. Parameter setting The factory set of temperature controller is constant temperature control mode, the water temperature is 25℃. Users can adjust themselves according to the actual situation. 2.1 Temperature Controller Panel Introduction Displayed in normal state Screen window 1"ActualTemp" indicates actual water temperature. Screen window 2 "Set Temp"...
- Page 8 2.2.Indicator lights and definition Full name Indicator lights State Abbr. Comp Compressor Lights up Starts Lights up Solenoid valve Starts Heating Lights up Electric heating rod Starts Lights up Intelligent mode Intelligent mode INT Ctrl Lights up Constant mode Constant mode CT Ctrl Parameter setting Parameter setting...
- Page 9 2.3 Parameter adjustment method First press and hold down the " " key, then press SET button at the same time for more than 5s, until window 1 shows "00" and window 2 shows "PAS", at this time, press the "...
- Page 10 Note: ①In the parameter setting state, the system operates according to the original parameters; ②In constant control mode, the water temperature is controlled by the "F0" parameter; ③In the intelligent control mode, the water temperature is automatically adjusted according to the temperature change. The temperature difference is controlled by the "F1" parameter.
- Page 11 to enter the parameter setting mode. Then press the " " key to adjust the set temperature to 24.0 ℃, press the RST OK key to save and exit the parameter setting mode, and run according to the newly modified parameters ②Example 2 Setting 3.0°C below ambient temperature.
-
Page 12: Alarm Functions And Output
6.Alarm functions and output 1. Table of alarm causes and operating status Working condition Output port Output port Buzzer Alarm code System indication H1、H2 H2、H3 Water pump works properly Open circuit Turn-on Open circuit High room temperature Buzzing Turn-on Open circuit High water temperature Buzzing Turn-on... -
Page 13: Refrigeration Performance
The performance curves of the chiller at room temperature 20°C, 30°C and 40°C are shown below: Cooling capacity 20℃ Cooling capacity 30℃ Cooling capacity 40℃ FCCA30221 Cooling capacity FCCA10221 Cooling capacity 4600 1200 4400 1100 4200 4000 1000 3800 3600... -
Page 14: Fault Handling
8. Fault handling Failure Treatment Cause of Failure phenomenon Bad contact with power cord Re-plugging the power cord Open the cover of the electrical box inside the machine, check the fuse, replace it with a spare fuse if No power on necessary, and check whether the Blown fuse power supply voltage is stable,... - Page 16 Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © 2023 FerroTec Corporation All Rights Reserved...
