Summary of Contents for syscomtec SCT-UC5-2H
- Page 1 SCT-UC5-2H Ultra 5K 40Gbps USB-C Docking Station w/100W Charging User Manual All Rights Reserved Version: SCT-UC5-2H_2024V1.0...
-
Page 2: Fcc Statement
Preface Read this user manual carefully before using the product. Pictures shown in this manual are for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction, please contact the local distributor for maintenance assistance. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS To ensure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for possible future shipment. Follow basic safety precautions to reduce the risk of fire, electrical shock and ... -
Page 4: Product Introduction
1. Product Introduction The SCT-UC5-2H is a USB4 40G switcher Docking Station w/100W Charging and supports single 5K@60Hz (5120x2880) UHD or dual 4K@60Hz display outputs. The upstream USB-C port provides PD 3.0 100W to the host computer, while the downstream USB-C port provides 15W power for peripherals. It also supports USB power control and device extension (4 ports) by providing three USB 3.2 Gen 2 Type-A... -
Page 5: Specification
2. Specification Video Input Input (1) DP Alt Mode or Thunderbolt 3/4 Input Connector (1) USB-C Input Resolution Up to 8K@30 Video Output Output (2) HDMI Output Connector (2) HDMI 2.0 Female 8K@30/5K@60Hz (5120x2880) UHD in output 1 Output Resolution Or dual 4K@60Hz display outputs HDMI Standard HDMI 2.1... -
Page 6: Panel Description
3. Panel Description Name Description ① Power LED Illuminates green when power is applied. ② Charging LED Illuminates blue when USB-C input is charging. ③ Audio Output 1x 3.5mm for analog audio output. 1x Toggle switch for 3x USB-A Devices power management. ④... -
Page 7: System Connection
4. System Connection The following diagram illustrates typical input and output connections that can be utilized with the unit:... -
Page 8: Panel Drawing
5. Panel Drawing Kontakt: syscomtec Distribution AG Keltenring 11 DE 82041 Oberhaching Telefon: +49 (0) 89 666 109 330 Telefax: +49 (0) 89 666 109 339 E-Mail: post@syscomtec.com Homepage: www.syscomtec.com...
