SpectraLink KIRK 40 Series Manual

Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents

KIRK 40xx manual
A. Initial Operation
1. Requirements
Using this Spectralink IP telephone with your telephone system merely requires a sound broadband
connection.
The base is solely operated with Power over Ethernet (PoE). That means if your Ethernet connection
does not support PoE, you also need a PoE power supply for your base.
2. Adding an extension
All telephones sent to you are preconfigured and connected to the telephone system. If you prefer to
configure the devices yourself, please refer to the administration portal manual.
Register the mobile handset to the base
This is done via the menu on your KIRK handset.
1.
Press "MENU" on your handset keypad.
2.
Then select menu item "REGISTER". Confirm with
3.
Next, please select "NEW LOGIN". Confirm with
4.
Please select the respective base. Confirm with
5.
Lastly, simply enter the required access code. It is: "9876". (Depending on the Firware-
version, the boxes ACD-data and user are required. In this case, please fill out both boxes with
"9876".) Confirm with
(MUTE).
(MUTE).
(MUTE). Bases are now scanned for.
(MUTE).
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KIRK 40 Series and is the answer not in the manual?

Questions and answers

Related Manuals for SpectraLink KIRK 40 Series

Summary of Contents for SpectraLink KIRK 40 Series

  • Page 1 KIRK 40xx manual A. Initial Operation 1. Requirements Using this Spectralink IP telephone with your telephone system merely requires a sound broadband connection. The base is solely operated with Power over Ethernet (PoE). That means if your Ethernet connection does not support PoE, you also need a PoE power supply for your base.

  • Page 2: Operation

    Your KIRK handset is now registered to the base. To cancel the registration of your handset to the base, you have to enter your password. The password for cancelling a registration is:“0000” . To completely cancel the registration of the handset to the base, you also need to delete the device on the administration portal.

  • Page 3: Speed Dial

    Lock keypad - To lock the keypad, press “MENU”, then - To unlock the keypad, press “MENU”, then 2. Speed dial You use the keys 0 to 9 on your handset as speed dials. To access the main menu, press "MENU". Scroll to “SPEED DIAL", then press (MUTE).

  • Page 4: Answering Calls

    assign a telephone number to the key). 4. Answering calls Answering a call - When the handset rings press to answer the call. Muting ring tone - Press “MENU”, then # to mute the ring tone. Hold - After answering a call, press R. The call is now placed on hold. To continue the call, press R again. Toggle calls - Press R to answer another call while in a call.

  • Page 5: Edit Settings

    5. Edit settings Adjusting ring tone volume Open the main menu by pressing "MENU". Scroll to “PROFILE SELECTION", then press (MUTE). Scroll to “ADVANCEDCONFIG.RING TONE VOL." and press (MUTE). Select the desired volume. Press (MUTE) to save the setting. Change ring tone Open the main menu by pressing "MENU".

  • Page 6: Call Forwarding

    Accessing your voicemail (voice menu) Dial *791 to access your voicemail. You can save the telephone number *791 in the phone book on your handset and then assign a speed dial to it. Upon calling the mailbox, you have the following options: "0"...
  • Page 7 Ncontrol manual. The following call forwarding options are available. You can activate or deactivate call forwardings via the telephone menu's call settings. Permanent call forwarding (always) All incoming calls will be forwarded directly to the predefined telephone number. Forward if busy (busy) New calls will be forwarded immediately, when coming in during an active call.
  • Page 8 You can then assign the handsets to the bases as described above. KIRK repeater The Spectralink Repeater extends the coverage of your Spectralink solution. While the Repeater does not increase the number of data traffic channels, it does provide for a greater physical spread...
  • Page 9 D. Where can you find help with your telephone system? You can use various sources for help concerning your issues. Please use them in the order suggested here: Via Modigliani, 20 Promelit Communication 20092 Cinisello Balsamo (MI) Systems Srl Tel.: + 39 02868841 www.promelit.it/ The home page of the service site contains various links to manuals, brief instructions, software downloads and templates.
