Sealey D400T.V2 Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear protective
instructions gloves
1. SAFETY
WARNING! this tank must ONLY be used for diesel fuel.
‰
Place the tank on a flat surface before filling.
9
Secure the tank to strong points with ratchet straps before transporting in or on a vehicle.
9
Maintain the pump in good condition (use an authorised service agent).
9
Replace or repair damaged parts. Use recommended parts only. Non authorised parts may be dangerous and will invalidate the warranty.
9
Keep the pump clean for best and safest performance.
9
Ensure the power supply (vehicle battery) corresponds with the requirements of the pump (12V DC).
9
Disconnect from battery when not in use.
9
Wear protective gloves, and protective clothing when working around fuel. A full range of personal safety equipment is available from your
9
local Sealey Stockist.
Keep children and unauthorised persons away from the working area.
9
DO NOT place the tank near any heat source.
8
DO NOT start or stop the pump by connecting or disconnecting
8
the battery clamps.
DO NOT allow the unit to get wet.
8
DO NOT operate the pump with wet hands.
8
DO NOT use the pump where explosive or flammable vapours
8
may be present.
DO NOT tamper with the pump connections.
8
2. INTRODUCTION
Manufactured from HDPE for the safe transportation and dispensing of
diesel fuel when refilling on site equipment. Complies to ADR 1.1.3.1.C for
exemption from requirements of ADR regulations. Supplied with a 12V
electric pump, 4m electric cable and clamps, and a 4m delivery hose with
automatic fuel nozzle. Can be safely secured and transported on a pick-up
truck or van, using grooves for tie down straps and six handles for
positioning. Supplied with lockable cover. Not suitable for petrol.
3. SPECIFICATION
Model No: . . . . . . . . . . . . . . . . . . . . . . . D400T
Voltage: . . . . . . . . . . . . . . . . . . . . . . . . . . . 12V
Current: . . . . . . . . . . . . . . . . . . . . . . . . . . . .15A
Power: . . . . . . . . . . . . . . . . . . . . . . . . . . . 180W
Tank Capacity: . . . . . . . . . . . . . . . . . . . . . .400L
Flow Rate: . . . . . . . . . . . . . . . . . . . . . . 20L/min
Duty Cycle: . . . . . . . . . . . 30mins on/30mins off
Dimensions (W x D x H): . 1100 x 800 x 720mm
4. FEATURES
Key: (fig.1. & fig.1A).
1.Breather Lid
2. Pump On/Off Switch
3. Battery Clips
4. Automatic Fluid Nozzle
5. Vented Cap
6. Securing Strap Locations
7. Vent Plug
8. Fork Locations
© Jack Sealey Limited
400L PORTABLE DIESEL TANK 12V
MODEL NO:
Wear protective Wear safety
clothing footwear
Original Language Version
D400T.V2
4
fig.1
6
9
fig.1A
5
1
3
2
6
8
7
8
9
D400T.V2 Issue 1 10/11/22
