Sealey CRM10.V6 Instructions

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
instruction
manual
1. SAFETY INSTRUCTIONS
1.1. ELECTRICAL SAFETY
WARNING! It is the user's responsibility to check the following:
‰
Check all electrical equipment and appliances to ensure that they are safe before using.
Inspect power supply leads, plugs and all electrical connections for wear and damage.
Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.
DO NOT use worn or damaged cables, plugs or connectors.
8
Ensure that any faulty item is repaired or is replaced immediately by a qualified electrician.
9
If the cable or plug is damaged during use, switch off the electricity supply and remove from use.
9
Ensure that repairs are carried out by a qualified electrician.
Sealey recommend that an RCD (Residual Current Device) is used with all electrical products.
9
Important: Ensure that the voltage rating on the appliance suits the power supply to be used and that the plug is fitted with the
correct fuse.
DO NOT pull or carry the appliance by the power cable.
8
DO NOT pull the plug from the socket by the cable.
8
1.2. GENERAL SAFETY
Familiarise yourself with the application and limitations of the reel, as well as the specific hazards.
9
WARNING! Isolate the reel from the electrical supply before connecting or disconnecting equipment, servicing or performing any
‰
maintenance.
Maintain the reel in good condition (use an authorised service agent).
9
Replace or repair damaged parts. Use recommended parts only. Unauthorised parts may be dangerous and will invalidate the
9
warranty.
Locate and fix the reel in a suitable work area. Do not position in direct sunlight, or in areas of extreme heat or cold.
9
Keep extended cable away from heat, oil and sharp edges. Check cables for wear before each use and ensure all connections are
9
secure.
Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip shoes.
9
Keep children and unauthorised persons away from the work area.
9
DO NOT use the reel for any purpose other than that for which it is designed.
8
DO NOT operate the reel when you are tired, under the influence of alcohol, drugs or intoxicating medication.
8
When not in use, switch off the electrical supply and retract cable into case.
9
WARNING! DO NOT dismantle the reel casing, or attempt to remove the screws on the sides. To do so may result in damage to the
‰
reel and/or personal injury and will invalidate the warranty. Internal maintenance, which will require the opening of the casing, must
only be undertaken by an authorised service agent.
2. INTRODUCTION
Double socket outlet with individual LED power indicators and rocker on/off switches. Features integral manual thermal trip switch
to prevent overload. Built-in bracket rotates 180° and can be used to mount to a wall or ceiling. Retracting cable reel operated by
simple pull and release action. Hard-wearing composite case prevents damage to the cable and eliminates potential trip hazards.
3. SPECIFICATION
Model No: CRM10.V6
Cable Section: 3 x 1.5mm²
Cable Type: PVC
Capacity Unwound: 3200W
Capacity Wound: 1000W
Fuse Rating: 13A
Length: 10m
© Jack Sealey Limited
RETRACTABLE CABLE REELS 230V
CRM10.V6 & CRM15.V6
MODEL No's:
CRM15.V6
3 x 1.5mm²
PVC
3200W
1000W
13A
15m
Original Language Version
CRM10.V6, CRM15.V6 Issue 4 19/09/24
