Summary of Contents for Norden NFA-T01PT
- Page 1 PROGRAMMING TOOL INSTALLATION AND OPERATION MANUAL www.nordencommunication.com www.nordencommunication.com 1405010829-Rev1.0-0125 Norden Communication UK Ltd.
-
Page 2: Product Safety
Document Improvement General Precautions Do not use the NFA-T01PT Programming tool in any way or for any purpose not described in this manual. Do not put any foreign objects into jack socket or battery compartment. -
Page 3: Table Of Contents
Technical Specification...................4 Names and Location....................4 Operation ..........................5 Installaling Batteries....................5 Connecting to the Device..................6 Programming..........................7 Protocol switching ....................7 To Read ........................8 To Write ......................9 To R/W Config .......................9 Set ........................10 Troubleshooting Guide......................10 Returns and Warranty Policy....................11 www.nordencommunication.com 1405010829-Rev1.0-0125 Norden Communication UK Ltd. -
Page 4: Introduction
The NFA-T01PT is miniature and robust design makes it convenient to bring in the work place. The programming tool is packed with twin 1.5V AA battery and cable, ready for usage once received. -
Page 5: Operation
Make sure the positive and negatives ends are facing the correct directions. Close the battery cover and press down until it clicks into place. Warning: Dispose the used batteries according to the local regulation. www.nordencommunication.com 1405010829-Rev1.0-0125 Norden Communication UK Ltd. -
Page 6: Connecting To The Device
Detector and Sounders Connect the alligator clip to terminal 1 (2) and 6 (5) Figure 2 Signaling Terminal: Manual Call Point Connect the alligator clip to terminal Z1 and Z2 (Marks) Figure 3 www.nordencommunication.com 1405010829 -Rev1.0-0125 Norden Communication UK Ltd. -
Page 7: Programming
Figure 4 3 Programming Note: The Norden device are equipped with variety of features and options that user can select or program onsite according to the project requirement and application. This manual cannot contain all the information’s for each device. We recommend referring to the specific device operation manual for more details. -
Page 8: To Read
ID: Detector serial number Figure 9 Figure 10 3.3 To Write Selecting this feature allow user to write the new address number the device. For example in NFA- T01SD Intelligent Addressable Optical Smoke detector. www.nordencommunication.com 1405010829 -Rev1.0-0125 Norden Communication UK Ltd. -
Page 9: To R/W Config
Press “Exit” key to go back Main Menu. Press “Power” to switch off the programming tool. 1.Read Feedback 2.Write Input Check 3.R/W Config Output Check 5Y 4.Set Figure 13 Figure 14 www.nordencommunication.com 1405010829-Rev1.0-0125 Norden Communication UK Ltd. -
Page 10: Set
Check the connection with the Wrong connection detector Damage the electronic circuit Select the appropriate signal- of the device ing terminal of the device Check the continuity of the programming cable Try to other device www.nordencommunication.com 1405010829 -Rev1.0-0125 Norden Communication UK Ltd. -
Page 11: Returns And Warranty Policy
We will pay for shipping to return any product to you. Once you have obtained the RMA number, please send to us the purchased Norden product with the RMA number clearly marked on the outside of the package and on the shipping slip if you choose to use traceable carrier. - Page 12 Norden Communication UK Ltd. Unit 10 Baker Close, Oakwood Business Park Clacton-On- Sea, Essex POST CODE:CO15 4BD www.nordencommunication.com Tel : +44 (0) 2045405070 | E-mail : salesuk@norden.co.uk www.nordencommunication.com 1405010829 -Rev1.0-0125 Norden Communication UK Ltd.
