  • Page 1 Technical manual...

  • Page 2: Warranty

    Warranty can only be claimed for material- and/or constructional faults which arise during the warranty period. In case of a warranty claim the FlatLine LW unit may not be disassem- bled without written permission of the manufacturer. Warranty on spare parts can only be granted when they are supplied by the factory and are installed by the acknowledged installer.

  • Page 3: General Description

    The aim of this manual This manual is intended to correctly install and maintain the Mark air handling units during its life- time. It is recommended to study this manual well so that the appliance can be maintained correctly.

  • Page 4: Technical Information

    Scale: Units: mm Status: Sheet: 1 of 1 1800/3000 2340 1890 240KG MARK Climate Technology, Beneden Verlaat 87-89, 9645 BM Veendam, tel: +31(0) 598 656 600, www.mark.nl, info@mark.nl FlatLine LW 1200 1500 1800 2400 3000 Max. air volume 1200 1500 1800 2400 3000 Max.
  • Page 5 K. Wijnholds 14-10-2024 Drawn by: Creation date: Damper_Supply_Exhaust 11,28 kg Mass: Description: 1 : 10 Scale: Units: mm Work in Progress Status: Sheet: 1 of 1 MARK Climate Technology, Beneden Verlaat 87-89, 9645 BM Veendam, tel: +31(0) 598 656 600, www...
  • Page 6 Units: mm Status: Sheet: 1 of 1 The heating coil of the FlatLine LW has a 1” ET connection (male thread). MARK Climate Technology, Beneden Verlaat 87-89, 9645 BM Veendam, tel: +31(0) 598 656 600, www.mark.nl, info@mark.nl Type 1500 3000 Code Nr.

  • Page 7: Cooling Section

    Status: Sheet: 1 of 1 MARK Climate Technology, Beneden Verlaat 87-89, 9645 BM Veendam, tel: +31(0) 598 656 600, www.mark.nl, info@mark.nl The cooling coil of the FlatLine LW 1500 and 3000 has a 1” ET connection (male thread). Type 1500 3000 Code Nr.
  • Page 8 Description: Format: 1 : 8 Scale: Units: mm Status: Sheet: 1 of 1 Damper with core MARK Climate Technology, Beneden Verlaat 87-89, 9645 BM Veendam, tel: +31(0) 598 656 600, www.mark.nl, info@mark.nl Type L Weight 800/1500 1200 Ø315 35KG 1800/3000 1200 Ø450...

  • Page 9: Installation

    When selecting and preparing the installation location of the device, consider the following recom- mendations. – Take the weight of the FlatLine LW into account. The weight can be found on the unit nameplate (weight excluding attachments). – Provide sufficient space for removal of the access panel and access for maintenance.
  • Page 10 4.3 Duct connections In an indoor installation, the air ducts of the Mark FlatLine LW must be insulated to prevent condensation on the outside of the duct. It is recommended to install a silencer in the supply and extract air duct. This will prevent any noise from the fans. Besides that, noise transfer (cross-talk) from one room to the other caused by the connecting duct work must be prevented.

  • Page 11: Control System

    OJ user interface with touch panel (article number: 0631374) is a user friendly control panel for commissioning and setting the daily operation of the Mark Airstream. The control panel is very easy to use, thanks to the logical menu’s, easy navigation and recognizable symbols. For more information...
  • Page 12 6.2 Operation with a computer The unit can be operated with a PC or laptop. Connect the PC or laptop through a LAN cable with the master in the junction box. 11:04, Tue 9 10 11 12 13 14 15 16 17 18 19 24VAC FIRE...
  • Page 13 User Installer Service Operation Extended operation Speed Set the program Sceduler base Daily schedule Exeptions Calendar Temperature Select fan speed Time & date Alarm & log Stop Control system info Low speed Internet Medium speed High speed Weekly program Calendar Fan regulation:Weekly program Current operation Manual stop...

  • Page 14: Maintenance

    You can find the article number for the filters on the type plate of the appliance. 7.5 Checking and Cleaning the Siphons The siphons must be checked for contamination and clea- ned if necessary. Drawn by: Mass: 1 : 10 Scale: Status: MARK Clima...
  • Page 15 1 : 14 Scale: Units: mm Status: Sheet: 1 of 1 REVISION DATE REVISION REASON MARK Climate Technology, Beneden Verlaat 87-89, 9645 BM Veendam, tel: +31(0) 598 656 600, www.mark.nl, info@mark.nl Material: Dimensions: MG1E0017029.idw Doc no.: Raw Material: Third angle projection:...
  • Page 16 1 : 17 Scale: Units: mm Status: Sheet: 1 of 1 REVISION DATE REVISION REASON MARK Climate Technology, Beneden Verlaat 87-89, 9645 BM Veendam, tel: +31(0) 598 656 600, www.mark.nl, info@mark.nl Material: Dimensions: MG1E0017029.idw Doc no.: Raw Material: Third angle projection:...
  • Page 17 FLAT_LINE_LW_TEK_DOC Mass: Description: Format: 1 : 5 Scale: Units: mm Status: Sheet: 1 of 1 MARK Climate Technology, Beneden Verlaat 87-89, 9645 BM Veendam, tel: +31(0) 598 656 600, www.mark.nl, info@mark.nl Type Code number 1500 5997422 1791 1303 Material: Dimensions: MG1E0017864.idw...
  • Page 18 EC exhaust air fan Filter EPM10 60% (M5) Return air Work in Progress Status: Sheet: 1 of 1 MARK Climate Technology, Beneden Verlaat 87-89, 9645 BM Veendam, tel: +31(0) 598 656 600, w Exhaust air Supply air Outside air Regulation...
  • Page 20 7.6 Connect and configure options It is possible to connect the options below to the FlatLine LW WTW unit. [5] 06 29 356 External room temperature sensor [6] 06 29 165 CO2 room sensor* [7] 30 04 505 Supply air duct pressure sensor*...
  • Page 21 06.29.356 06.29.165 30.04.505 5997474 800/1200/1500 Room Servomotor temperature outdoor/exhaust air pressure sensor damper room sensor supply air duct 5997477 1800/2400/3000 gnd 24Vdc 24Vdc 24Vdc 24Vdc Room Servomotor open 0-10V 0-10V temperature outdoor/exhaust air pressure sensor damper room sensor supply air duct PT1000 gnd 24Vdc 24Vdc 24Vdc...
  • Page 22 [11] Room sensor instruction 11:04, Tue 11:04, Tue General settings General settings Constant 21,0° 21,0° Fan control Fan control Extract air slave Fan control airflow > > > The unit has not At least one started active alarm Flow unit m³/h Flow unit m³/h...
  • Page 23 [12] CO2 sensor instruction 11:04, Tue 11:04, Tue General settings General settings Constant 21,0° 21,0° Fan control Fan control Extract air slave Fan control airflow > > > The unit has not At least one started active alarm Fan control Constant room Extract air slave Constant VOC/CO2...
  • Page 24 [13] Pressure supply instruction > Schema AIRSTREAM-DISPLAY Diverse tekeningen symbolen chalen naar 0,5 voor in display OJ DISPLAY nummer Get. J.W. Datum 21-11-2024 Groep Klimat Type Gec. Norm Art.nr Versie PTH3202-DF VENTILATION CONTROLLER > > 0-300Pa OK Schema AIRSTREAM-DISPLAY Electrical drawing OJ-Air2-HMI-35T nummer Get.
  • Page 25 [13] Pressure supply instruction Medium speed High speed Low speed Medium speed High speed m³/h m³/h m³/h > > > m³/h m³/h CLOSED Supply air fan General settings General settings General settings Gene Exhaust air fan Exhaust air fan Exhaust air fan Constant Fan control Fan control...
  • Page 26 [13] Pressure supply instruction Low speed Medium speed High speed Supply air fan General settings General settings General settings Exhaust air fan Exhaust air fan Exhaust air fan air slave Fan control Constant VOC/CO2 K-factor K-factor K-factor > > > Low speed 400 m³/h Low speed...

  • Page 27: Electrical Diagrams

    [14] Electrical Diagrams...
  • Page 30 FAX +31 (0)598 624584 TELEFAX +49 (0)2822 97728-10 info@mark.nl info@mark.de www.mark.nl www.mark.de MARK EIRE BV MARK POLSKA Sp. z o.o COOLEA, MACROOM UL. JASNOGÓRSKA 27 CO. CORK 42-202 CZĘSTOCHOWA (POLSKA) P12 W660 (IRELAND) PHONE +48 34 3683443 PHONE +353 (0)26 45334...
