Housegard WA202 User Manual

HOUSEGARD WATER LEAKAGE SENSOR
GB
USER MANUAL
MODEL: WA202
1.
PREPARATIONS
1. Ensure you have a 2.4 GHz Wi-Fi router with an internet connection.
2. Activate Bluetooth and connect your mobile phone to the home Wi-Fi.
INCLUDED
Networking
Button
Sensor Head
LED Indicator
130cm
Sensor Body
Sensor Head
Sensor Body
Tamper Button
Needle
This water leakage sensor is designed for use in domestic
premises. Equipped with Wi-Fi wireless technology, it will send
alarm notifications to the user remotely. With high precision
and sensitivity, the water leakage alarm can operate stably for
extended periods. Place this small water leak sensor near sources
of water in your home, such as bathrooms, water heaters, water
tanks, and near your heating, ventilation, and air conditioning
system or sump pump.
FEATURES
Model No: WAXXX
Working Voltage: DC3V(CR2x1)
Wi-Fi router frequency: 2.4GHz
Supported APP: Smart Life – Smart Living
Operating Temperature: –10 °C to +50 °C
≤95% RH (no condensation)
Operating Humidity:
Sensor Body Dimensions: 72×21×26mm
Sensor Head Dimensions: 28.5×26.7×13.5mm
Battery Life: 2 years
Cable Length: 1.3 meters
Sensor Body IP Class: IP67
HOW IT WORKS
Wi-Fi
Alarms Wi-Fi Router Internet
Congratulations on your purchase of the Housegard Water Leakage Sensor!
This easy-to-use guide will help you set up and make the most of your new device.
2.
INSTALL SMART LIFE APP
You can download the app by searching "Smart Life" in mobile app stores or
scanning below QR code, create an account, and log in.
Note: Due to app upgrades, instructions may vary slightly. Follow in-app
instructions if needed.
DEVICE INFORMATION
Battery level
Log history
SETTINGS OF HUB
Low battery Notification
Water leakage alarm
Notification
Notifications even
Phone
NOTIFICATIONS
• Water Leakage Alarm: This notification is triggered when the
device detects water leakage or moisture. It's essential for
preventing potential damage caused by leaks.
• Low Battery Event: When the device's battery is running low,
you'll receive this notification. Make sure to replace the battery
promptly to ensure continuous functionality.
• Offline Event: If the device loses its connection to the network
(e.g., Wi-Fi), it will send an offline event notification. Check the
device's connectivity and troubleshoot if necessary.
• Tamper event: If someone removes sensor body from its
mounting plate.
• Tamper recovery event: If someone re-mounts sensor body to
its plate.
LED INDICATOR STATUS:
CONDITION
Normal working.
Alarm.
WiFi & Bluetooth networking.
Networking is successful or fails.
OTA.
INSTALLATION PRECAUTIONS
Ensure proper installation by following these guidelines.
Indoor Use Only:
• This product is designed for indoor use exclusively.
Avoid Specific Conditions:
• Do not install the sensor body in places with rain, smoke, or
steam.
Avoid Submersion:
• Ensure that the sensor body is not installed where it has been
submerged in water.
LED Orientation:
• During installation, make sure the LED faces downward.
when offline
GPBM Nordic AB | Sörredsvägen 113 | 418 78 Göteborg | Sweden
+46 31 799 16 00 | info@housegard.com | www.housegard.com
3.
ADD THE HUB TO 2.4GHZ WI-FI NETWORK
1. Open the app.
2. Power up device by remove
battery insulation film to power on
the sensor part.
3. Press the networking button with
the needle for 5 seconds. When
you see a rapid blue LED flash
(2 times per second), the device is
now in networking mode.
2. 3.
5 sec
INSTALLATION
Sensor Body Placement:
• Ensure that the installation surface is smooth, flat, stable, dry,
and clean. Attach the sensor body in the correct position after
removing the double-sided tape from the bracket.
Sensor Head Placement:
• Install the sensor head in areas where water leaks are likely to
occur.
LED Regular Checks:
• After installation, periodically verify that the product is
N/A.
securely attached to the installation surface.
Blue LED flashes once.
Blue LED flashes quickly.
BATTERY REPLACEMENT
1. Detach the sensor body from the
Blue LED goes off.
mounting bracket.
Blue LED keeps on.
2. Remove the used battery.
3. Insert a new battery into the designated
compartment.
4. Reattach the sensor body to the bracket.
Note: Please dispose of the used battery
properly for environmental protection.
WARRANTY
This device comes with a 5-year limited warranty against
manufacturing defects. (Valid from date of purchase.)
Liability under the warranty is limited to the value of an
equivalent hub device. Defective devices should be returned
to the retailer, along with a description of the problem. If the
claim is approved, the faulty goods will be replaced with a
device of the same or an equivalent type. Any claim must be
accompanied by a receipt confirming the date of purchase.
DISPOSAL
In accordance with the WEEE Directive 2012/19/EU, waste electrical
products should not be disposed of with regular household waste.
Ver: 240613
4. The device will automatically appear
in the Smart Life app.
5. Follow the app instructions to add
the device.
Note: You can change the hub's
default name during setup by
clicking on the PEN icon
4.
Battery compartment
