Summary of Contents for Prana Air AMBIENT PM
- Page 1 AMBIENT PM INSTRUCTION MANUAL WiFI Connectivity CONTACT Address Phone Online (+91) 73918-73918 706, 7th floor, Crown Email : info@purelogic.in heights, Rohini Sec-10, Website : www.pranaair.com New delhi-110085, India...
-
Page 2: Table Of Contents
TABLE OF CONTENTS PAGE 4 SECTION 01 GETTING STARTED : KNOW YOUR AMBIENT PM SECTION 02 CONNECTING THE MONITOR PAGE 6 PAGE 11 SECTION 03 ADDING THE MONITOR IN THE AQI APP PAGE 16 SECTION 04 HOW TO LOG IN/ SIGN UP? - Page 3 WHAT’S INSIDE THE BOX DC Power Ambient PM Monitor Adapter...
-
Page 4: Getting Started : Know Your Ambient Pm
Getting Started : Know your Ambient PM General information about the product that explains the basic functionalities of the device. - Page 5 Prana Air PM2.5 : 0050 Temp Humi : 17 PM1.0 : 0028 TVOC : 676 PM10 : 0067 Noise : 53 Air Quality Monitor DC12V WIFI www.pranaair.com 1. Display 2. WIFI Button 3. Power Button (PWR 4. SD Card Slot...
-
Page 6: Connecting The Monitor
Connecting the monitor Establish the connection between the monitor and SIM card network to access monitored data. - Page 7 Use a screwdriver to open the Now, press the Power button (PWR) monitor by unscrewing all screws. once (located underneath the monitor). DC12V WIFI Air Quality Monitor www.pranaair.com...
- Page 8 Locate the SIM slot and open it by sliding the Once the SIM card is inserted properly, you will plate backwards. Then, Insert a SIM card in the observe current time & date and network strength slot as shown below . displaying at top of the screen.
- Page 9 Then, press the Wifi button once After successfully inserting the SIM card (located underneath the monitor). into the slot, close the monitor back using the screwdriver. 05-24, 17:49:12 N45X PM2.5 : 0050 Temp Humi : 17 PM1.0 : 0028 TVOC : 676 PM10 : 0067...
- Page 10 QR code and Device ID will appear on the screen. Device id : XXXXXXXXXXXX Air Quality Monitor www.pranaair.com...
-
Page 11: Adding The Monitor In The Aqi App
Adding the Monitor in the AQI APP Proceed to integrate the monitor with the app after successfully establishing the network connection. Follow these steps to add the monitor to the app and access remote data viewing. - Page 12 Download and install the AQI App on Click on "My Devices" to Sign up for creating your phone (available on Google Play a new account or Log in if you already have Store for Android and the App Store for one.
- Page 13 Once logged in, Go to "My Devices" and Then select “SQUAIR” under the then click on the "Add" button. 'Choose your Device' section. Ambient PM Android TV Android TV...
- Page 14 Enter the device ID manually or Scan Add all the necessary details and then the QR Code displaying in the monitor. click on the "Setup" button. Ambient PM Device id : XXXXXXXXXXXX Air Quality Monitor www.pranaair.com...
- Page 15 Click on the “Edit button” to edit the details status after 5 minutes. If offline, verify the power of the device. source, and WiFi connection. NOTE: Ambient PM Please ensure the device is successfully added to the AQI app and has established an online connection.
-
Page 16: How To Log In/ Sign Up
How to log in/ sign up? To provide access control, track monitored data, personalize the experience, and facilitate communication between users and the devices. - Page 17 Sign up : Install the AQI India app on your Open the app and click on "My Devices" smartphone. from the top right corner of the screen.
- Page 18 Click on the "Create New Add the necessary details. Click on the checkbox after reading all the terms and Account" button. conditions and privacy policies. Then click on the "Sign Up" button.
- Page 19 Login : Your account is created. You will be Open the app and click on "My Devices" from redirected to 'My Devices' section where the top right corner of the screen. you can add different devices.
- Page 20 Enter your credentials and then You have now successfully logged in to click on the "Log in" button. your account. You can easily add devices and check the data remotely 24*7.
-
Page 21: Safety Guide
Safety Guide To ensure safe and proper usage of this product, please refer to the following safety guide before operating the device. - Page 22 When connecting to the wifi network and the AQI app, kindly read the instructions carefully. It is important to only use Prana Air repair services to fix the device. Accessories: The user has the option to use an alternative adapter ( with the same power rating) and USB cable.
-
Page 23: Safety And Maintenance
Safety and maintenance The safety and maintenance section of this product manual provides important information on how to use and maintain the device in a safe and reliable manner. - Page 24 Having a comprehensive understanding of the safety and maintenance instructions for the device can enable you to use the device more safely and efficiently, and help to extend its lifespan as much as possible. Make sure to turn on the device properly. The device is not waterproof.
-
Page 25: Service Guidelines
Service Guidelines This section outlines the recommended maintenance procedures and service requirements for ensuring the optimal performance and longevity of the device. - Page 26 A. Warranty Terms The device comes with 6 Months warranty against manufacturing defects. A valid proof of purchase is required to be eligible for repairs or replacements. Warranty will be void in case of physical damage. B. Sending and Retrieving the Device for Repair The customer must provide the necessary information, such as name, contact number, and fault description, to complete the repair work order.
-
Page 27: Warranty Description
1.7. Normal wear and tear of the device (such as outer cover, buttons, and screen). Both national and international services can be availed only at Prana Air's office. All replaced parts, components, and accessories during warranty services will be kept by the... - Page 28 Visit us : www.pranaair.com...
