TRACTION Harrier 50X User Manual

Hide thumbs

Advertisement

Table of Contents

Harrier 50X and 80X User Guide
Revision 5
www.tractionsound.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Harrier 50X and is the answer not in the manual?

Questions and answers

Related Manuals for TRACTION Harrier 50X

Summary of Contents for TRACTION Harrier 50X

  • Page 1 Harrier 50X and 80X User Guide Revision 5 www.tractionsound.com...

  • Page 2: Manufacturer's Declarations

    Manufacturer’s Declarations 1.1 EU Declaration of Conformity This declaration applies to: • Traction Sound - Harrier 50X • Traction Sound - Harrier 80X Manufactured by Scicoustic Ltd. Studio 6, The Granary, Fairclough Hall Farm, Halls Green, Hitchin, Herts, SG4 7DP United Kingdom This includes production versions of these passive loudspeakers.

  • Page 3: Product Descriptions

    The Harrier 50X is a two-way loudspeaker which features significant performance upgrades and an expanded set of possible applications over the original Harrier 50. The Harrier 50X is comprised of a 12” low frequency transducer with high power handling and a neodymium motor assembly optimised for low distortion performance, and an AMT mounted in a rotatable waveguide.
  • Page 4 M10 fixing points are provided on the top, bottom and sides of the cabinet, as well as M8 fixings on the rear for full installation flexibility. U-brackets and Arraying Hardware can also be supplied which make use of these fixings. The Harrier 50X has been designed to use Traction Engine amplifiers and Traction Control DSP.
  • Page 5 To further adjust the coverage of the Harrier 50/80-X, the HF horn can be unscrewed and rotated 90 degrees to swap the horizontal and vertical nominal coverage. For example, if the cabinet is suspended in landscape orientation but the nominal horizontal dispersion is still required, then the horn should be rotated to achieve this.
  • Page 6 Four output channel preset types are available for the Harrier 50/80-X: Harrier 50/80-X S For partnering with a Traction subwoofer. This preset should be applied when using a Harrier 50/80-X in a system which makes use of one or more subwoofers to augment and extend the response below 100Hz.
  • Page 7 2.3.6 Amplification We recommend using the Traction Engine 4|2700-DSP to power this speaker, either individually or with two units wired in parallel. Care should always be taken not to clip any part of the signal chain including DSP I/O, amplifier inputs or amplifier outputs, as this will lead to degraded sound quality and ultimately damage to loudspeakers and partnering electronics.

  • Page 8: Safety Instructions

    4.3 Associated Equipment Always use these loudspeakers with the correct amplifier and DSP settings. Only use equipment or accessories approved by Traction Sound. 4.4 Safety Checks Perform a safety check before each use of these loudspeakers. Check the product and accessories for visible signs of wear and tear.

  • Page 9: Product Specification

    5.0 Product Specification 5.1 Harrier 50 X T y p e 2 - wa y B i -A mp e d o r P a s s iv e fu ll ra n g e F re q u e n c y R e s p o n s e ( 1) 5 5 H z –...
  • Page 10 Notes: (1) Measured on axis in half (2pi) space at two meters and referred to 1 meter, with DSP preset applied. (2) Tested to AES 2-1984 Rev. 2003. (3) Measured in half (2pi) space at 2 meters with 2.83V input, using band limited pink noise, then referred to 1 meter. (4) Calculated at 1 meter.

  • Page 11: Technical Drawings

    6.0 Technical Drawings 6.1 Harrier 50X www.tractionsound.com...
  • Page 12 6.2 Harrier 80X www.tractionsound.com...

  • Page 13: Rigging Accessories

    7.0 Rigging Accessories 7.1.1 Harrier X U-Bracket 7.1.2 Directions for use This equipment must be used by trained and competent individuals, in accordance with your country’s laws and regulations. Never use this equipment whilst under the influence of drugs or alcohol. Once deployed, always secure the attached speaker with a secondary safety tie rated at 60kg SWL or higher.
  • Page 14 7.2.1 Harrier-X Array Plate 7.2.2 Directions for use This equipment must be used by trained and competent individuals, in accordance with your country’s laws and regulations. Never use this equipment whilst under the influence of drugs or alcohol. Once deployed, always secure the attached speakers with a secondary safety tie rated at 60kg SWL or higher.

  • Page 15: Contact Details

    8.0 Contact Details Web – www.tractionsound.com Email - info@tractionsound.com TRACTION UK Studio 6, The Granary, Fairclough Hall Farm, Halls Green, Hitchin, Herts, SG4 7DP United Kingdom Scicoustic LLC 8475 Murphy Drive Middleton WI 53562, USA +1 608 665 2280 www.tractionsound.com...

This manual is also suitable for:

Harrier 80x
