HA Repair Guide

Refrigerator

SSEDA – RS261*

- 1/47 -

Need help?

Do you have a question about the SSEDA-RS261 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Samsung SSEDA-RS261 Series

Page 1 All manuals and user guides at all-guides.com HA Repair Guide Refrigerator SSEDA – RS261* - 1/47 -...
Page 2 All manuals and user guides at all-guides.com SSEDA-PJT Repair Guide [ RS261M* ] • No Ice / dispensing problem No Ice • Shortage of ice • No Water / Water Dripping No Water • Water Leak Defrost • Evap Defrost build •...
Page 3 All manuals and user guides at all-guides.com ● Ice & Water #1. Symptom : No Ice Repair Schematic Chassis Project Basic Model Type SSEDA RS261M* Plastic Ice Maker ※  Check Display “ICE off” selecting Block Reason Step Check-1 Check-2 Code ...
Page 4 All manuals and user guides at all-guides.com Tip 1-1. Inspect Display Water & Ice selection Inspect “Ice Type” button select operation Check Point Step 1 ① Check “Child Lock” selection ② Inspect “Ice Type” Key operation - Key normal  Inspect Tip 1-2 - Key failure ...
Page 5 All manuals and user guides at all-guides.com Tip 1-2. Inspect Lever S/W & Auger Motor S/W operation Check Point Inspect Dispenser Lever S/W operation. Step 1 ① Check the Auger motor rotation sound which is inside of F room with pushing DISPENSER LEVER.
Page 6 All manuals and user guides at all-guides.com Tip 1-3. Inspect ASSY Auger Motor operation Check Point Inspect Auger Motor. Step 1 ① Disassemble ice Bucket which is in F room. ② Disassemble 3 screws on the top. Step 2 (Single product inspection) ①...
Page 7 All manuals and user guides at all-guides.com Tip 2-1. Inspect Water supply / supply Check Point Inspect Water supply failure ※ Need lever operation for 3 min on initial and after replace Filter ! Step 1 ① Inspect water comes when lever operation after Water selection.
Page 8 All manuals and user guides at all-guides.com Tip 2-2. Inspect Ice Valve operation Check Point Inspect ice maker Water supplying problem Step 1 ① 점ㄱ ① Push the button for 2 sec which is on the bottom of ice maker after disassemble Ice Bucket.
Page 9 All manuals and user guides at all-guides.com Tip 2-3. Inspect ASSY PIPE-WATER (Heater) freezing Check Point Inspect ice maker Water supply problem Step 1 Connector ① Disassemble the Ice Maker which is on top of F room. ② Disassemble top PIPE-WATER Heater Wire. - Normal product 1.8 ~ 2.5 KΩ...
Page 10 All manuals and user guides at all-guides.com (※ Must select “Power Freeze” first) Tip 2-4. Inspect Self diagnosis test ※ Fan motor Fan motor displays failure for power on condition. Touch Display “Lighting”+ “Energy Saver” Key for 8 sec at the same time. - Press until all LED blink and “dingdong”...
Page 11 All manuals and user guides at all-guides.com Tip 2-4-1. Inspect self-diagnosis test  Inspect Ice Maker Block Connector ① Disassemble F Ice Maker Screw Top ② Inspect Wire Harness connection which is on Sensor The top part. ※ Ice maker test operates and water does not come, Check TIP 2-2 Test ※...
Page 12 All manuals and user guides at all-guides.com Tip 2-4-2. Inspect self-diagnosis test  F Sensor / Cabinet Fan / Defrost Sensor / Defrost Error Block D-Sensor F-Sensor Fan Motor ① Disassemble F Ice Maker Screw top Heater ② Inspect Cover Multi Front disassemble Defrost ③...
Page 13 All manuals and user guides at all-guides.com Tip 2-4-3. Inspect self-diagnosis test  R Sensor / F Damper Motor Block R-Sensor Damper Damper ① Disassemble R Ice Maker Screw top ② Inspect Cover Multi Front disassembly ③ Inspect Evap Cover disassembly R-Sensor Circuit diagram ①...
Page 14 All manuals and user guides at all-guides.com Tip 2-4-4. Inspect self-diagnosis test  External R Sensor / C-Fan Motor Block C-Fan EXT-Sensor - Inspect external air sensor ① Inspect R top HINGE-UPP Cover disassembled Wire Inspect - Inspect C-Fan Error Connector ①...
Page 15 All manuals and user guides at all-guides.com (※ Must select “Power Tip 2-5. Inspect cooling power Freeze” first) ※ Do not off the power  Measure self-diagnosis test on “TIP 2-4” Step 1 Press Display “Lighting”+ “Energy Saver” Key for 8sec at the same time.
Page 16 All manuals and user guides at all-guides.com Step 4 (Comp single product operation failure) ① Inspect rotation failure by Comp Coil cutting - Measure Common + Sub resistance - Measure Common + Main resistance Normal : 1~50 Ω ∞ Failure : Open Ω...
Page 17 All manuals and user guides at all-guides.com ● Ice & Water #2. Symptom : No Water & other(LEAK) Repair distribution diagram Chassis Project Basic Model Type SSEDA RS261M* Plastic Ice Maker ※ Check Display “Hold” selection Block Reason Step Check-1 Check-2 Code WATER supply...
Page 18 All manuals and user guides at all-guides.com Tip 3-1. Inspect WATER connection / supply Check Point Inspect Water supply failure ※ Need lever operation for 3 min on initial and after filter replacement ! Step 1 ① Inspect lever water coming after Water selecting.
Page 19 All manuals and user guides at all-guides.com Tip 3-2. Inspect WATER VALVE operation Check Point Inspect WATER VALVE failure Step 1 ① Disassemble backside UNIT COVER. Step 2 ① After disassemble ASSY Valve and check WHITE 2-Wire - Normal parts : 350~450 Ω - Failure parts : Open or 0 Ω...
Page 20 All manuals and user guides at all-guides.com Tip 3-3. Inspect WATER Lever S/W operation Check Point Inspect Dispenser Lever S/W operation. Step 1 ① After select DISPENSER WATER and check water coming with pressing LEVER Step 2 MAGNET CHECK ① Inspect F DOOR UPP MAGNET existence ②...
Page 21 All manuals and user guides at all-guides.com Tip 3-4. Inspect WATER HOSE Check Point Inspect WATER HOSE LINE Step 1 ① Disassemble COVER-LEG FRONT. Step 2 ① Check it is the problem of WATER HOSE TUBE FITTING connection and disassemble it if there is no problem.
Page 22 All manuals and user guides at all-guides.com Tip 4-1. Inspect WATER LINE LEAK Check Point Inspect WATER HOSE LINE LEAK Step 1 ① Disassemble COVER-LEG FRONT. - FRONT WATER LEAK - ROOM WATER LEAK - BACK WATER LEAK Step 2 ①...
Page 23 All manuals and user guides at all-guides.com Tip 4-2. Inspect WATER DISPENSER DRIPPING Check Point Inspect WATER HOSE LINE LEAK Step 1 ① Disassemble COVER-LEG FRONT ※ WATER DRIPPING occurs as WATER LINE AIR Step 2 HOSE SCRATCH ① Inspect WATER HOSE SCRATCH ...
Page 24 All manuals and user guides at all-guides.com Tip 4-3. Inspect WATER HOSE NOISE Check Point Inspect WATER HOSE LINE LEAK HOSE Step 1 VIBRATION ① Dispense water with pressing WATER LEVER. - Inspect supply water pressure problem - Inspect CASE-FILTER problem Step 2 ①...
Page 25 All manuals and user guides at all-guides.com ● DEFROST #1. Symptom : EVAP / ICE ROUTE DEFROST Repair Chassis Project Basic Model Type SSEDA RS261M* Plastic Ice Maker ※ Operate self-diagnosis test Block Reason Step Check-1 Check-2 Code DEFROST ERROR / ...
Page 26 All manuals and user guides at all-guides.com (※ Must select “Power Freeze” first) Tip 5-1. Self diagnosis test inspection ※ Fan motor displays failure for power on condition. Press Display “Lighting”+ “Energy Saver” Key for 8sec at the same time. - Press until all LEDs are Blinking and “Dingdong”...
Page 27 All manuals and user guides at all-guides.com Tip 5-1-1. Inspect self-diagnosis test  Inspect Ice Maker Block Connector ① Disassemble F Ice Maker Screw top ② Inspect wire harness contact on the top. Sensor ※ Ice maker test operation but water doesn’t come refer to TIP 2-2 ※...
Page 28 All manuals and user guides at all-guides.com Tip 5-1-2. Inspect self-diagnosis test  F Sensor / cabinet Fan / Defrost Sensor / Defrost Error Block D-Sensor F-Sensor Fan Motor ① Disassemble F Ice Maker Screw top Heater ② Inspect disassembled Cover Multi Front 분해 Defrost ③...
Page 29 All manuals and user guides at all-guides.com Tip 5-1-3. Inspect self-diagnosis test  R Sensor / F Damper Motor Block R-Sensor Damper Damper ① Disassemble F Ice Maker Screw top ② Inspect disassembled Cover Multi Front ③ Inspect disassembled Evap Cover R-Sensor Circuit diagram ①...
Page 30 All manuals and user guides at all-guides.com Tip 5-1-4. Inspect self-diagnosis test  External air R Sensor / C-Fan Motor Block C-Fan EXT-Sensor - Inspect external sensor ① Inspect disassembled R top HINGE-UPP Cover Wire Inspect - Inspect C-Fan Error Connector ①...
Page 31 All manuals and user guides at all-guides.com Tip 5-2. Inspect EVAP DEFROST BUILD ※ Do not off the power and operate self-diagnosis test on “TIP 5-1” first.  Must check the forced defrost operation after defrosting repair. Step 1 Press Display “Lighting”+ “Energy Saver” Key for 8 sec at the same time until “Dingdong”...
Page 32 All manuals and user guides at all-guides.com Step 6 ① When it freezes only EVAP BOTTOM - Improve DRAIN freezing. ② Check the drain hole blocking with removing freezing with STEAMER. (Remove DRAIN freezing and foreign substance) ③ Bend the HATER to bottom with hand. - DRAIN HOLE should be closed.
Page 33 All manuals and user guides at all-guides.com Tip 6-1. Inspect ICE ROUTE DEFROST BUILD Step 1 ① Check frost attachment with ICE ROUTE on F- DOOR OPEN condition. - If the frost appears on ICE ROUTE only, it appears because of ICE dispensing so that is normal.
Page 34 All manuals and user guides at all-guides.com ● NOISE #1. Symptom : Water Hose & UNIT NOISE Repair distribution diagram Chassis Project Basic Model Type SSEDA RS261M* Plastic Ice Maker ※ Operate self-diagnosis test Block Reason Step Check-1 Check-2 Code WATER HOSE ...
Page 35 All manuals and user guides at all-guides.com Tip 7-1. Inspect WATER HOSE NOISE Check Point Inspect Noise when WATER dispensing HOSE Step 1 VIBRATION ① Dispense water with pressing WATER LEVER. - Inspect supplied water pressure problem - Inspect CASE-FILTER problem Step 2 ①...
Page 36 All manuals and user guides at all-guides.com Tip 8-1. Inspect UNIT NOISE Check Point Inspect UNIT NOISE Step 1 ① Disassemble backside UNIT COVER. Step 2 ① Inspect selecting “Power Freeze” and COMP ② Disassemble the part which is friction. PIPE + WIRE PIPE + TRAY PIPE + PIPE...
Page 37 All manuals and user guides at all-guides.com Tip 8-2. Inspect CYCLE NOISE Check Point Inspect NOISE Step 1 ① Disassemble backside UNIT COVER. Step 2 ① When “Pooo~” “growling” sound occurs in the cabinet ② Disassemble EVAP COVER. - Capillary Pipe welding part should be as “-” shape.
Page 38 All manuals and user guides at all-guides.com ● COOLING #1. Symptom : WEAK COOLING & TOO COLD Repair Chassis Project Basic Model Type SSEDA RS261M* Plastic Ice Maker ※ Operate self-diagnosis test Block Reason Step Check-1 Check-2 Code Inspect F WEAK ...
Page 39 All manuals and user guides at all-guides.com (※ Must select “Power Freeze” first) Tip 9-1. Inspect self-diagnosis test ※ Fan motor displays failure only for power On condition. Press Display “Lighting”+ “Energy Saver” Key for 8sec at the same time. - Press until “Dingdong”...
Page 40 All manuals and user guides at all-guides.com Tip 9-1-1. Inspect self-diagnosis test  Inspect Ice Maker Block Connector ① Disassemble F Ice Maker Screw top Sensor ② Inspect Top Wire Harness contact. ※ Water doesn’t come even ice maker operates Test, TIP 2-2 ※...
Page 41 All manuals and user guides at all-guides.com Tip 9-1-2. Inspect self-diagnosis test  F Sensor / cabinet Fan / Defrost Sensor / Defrost Error Block D-Sensor F-Sensor Fan Motor ① Disassemble F Ice Maker Screw top Heater ② Inspect disassembled Cover Multi Front Defrost ③...
Page 42 All manuals and user guides at all-guides.com Tip 9-1-3. Inspect self-diagnosis test  R Sensor / R Damper Motor Block R-Sensor Damper Damper ① Disassemble F Ice Maker Screw top ② Inspect disassembled Cover Multi Front ③ Inspect disassembled Evap Cover R-Sensor Circuit diagram ①...
Page 43 All manuals and user guides at all-guides.com Tip 9-1-4. Inspect self-diagnosis test  External R Sensor / C-Fan Motor Block C-Fan EXT-Sensor - Inspect external sensor ① Inspect disassembled R top HINGE-UPP Cover Wire Inspect - Inspect C-Fan Error Connector ①...
Page 44 All manuals and user guides at all-guides.com (※ Must select “Power Tip 9-2. Inspect cooling power Freeze” first) ※ Do not off the power  Measure self diagnosis test inspection on “TIP 9-1” Step 1 Press Display “Lighting”+ “Energy Saver” Key for 8 sec at the same time.
Page 45 All manuals and user guides at all-guides.com Step 4 (Comp single product operation failure) ① Inspect rotating failure by Comp Coil cutting - Measure Common + Sub resistance - Measure Common + Main resistance Normal : 1~50 Ω ∞ Failure : Open Ω...
Page 46 All manuals and user guides at all-guides.com Tip 9-3. Inspect EVAP DEFROST BUILD ※ Do not off the power and operate self-diagnosis test to“TIP 5-1” first.  Must check the forced defrost operation after defrost repairing. Step 1 Press Display “Lighting”+ “Energy Saver” Key for 8sec at the same time until “Dingdong”...
Page 47 All manuals and user guides at all-guides.com Step 6 ① When EVAP BOTTOM is freezing only - improve DRAIN freezing. ② Check Drain hole blocking with remove freezing with STEAMER. (Remove DRAIN freezing and foreign substance) ③ Bending the HATER to bottom with hand. - DRAIN HOLE Should be closed.
Page 48 All manuals and user guides at all-guides.com Tip 10-1. Inspect R TOO COLD Check Point Inspect COVER DAMPER Step 1 ① Disassemble the R ASSY COVER DAMPER. R-Sensor Damper Damper Step 2 ① Inspect the location fixing condition of R- SENSOR - TOO COLD occurs when separate or cover the front with protection vinyl.
