OIL LEAK DETECTION SYSTEM
Capacitance sensor Model
Oil Leak Detector
Model : CSＨ-3005, ASＨ-40
Operation Manual
Detector
Signal converter
Signal converter storage box
(Option)
Low water guard
(Option)
Before using the product, read carefully and
-
understand well the important precautions described in
this operation manual.
Two types of Apolarm™ C, non-explosion-proof type
-
and explosion-proof type, are available. Note that the
WARNING
area to use is specifically restricted for each of them.
For the explosion-proof type, be sure to read the
-
attached operation manual (SDA-10-3) before
installation and operation.
-
Do not mix the non-explosion-proof type and the
explosion-proof type for the converter and detector.
: CSＨ-3005EX, ASＨ-40EX
Model: CSH-3005 (non-explosion-proof type)
CSH-3005EX (explosion-proof type)
Model: ASH-40 (non-explosion-proof type)
ASH-40EX (explosion-proof type)
Model: ASB-30
Model: TC-SE
Ver. 1.2
Advertisement
Table of Contents
Summary of Contents for Asahi KASEI Apolarm CSH-3005
- Page 1 OIL LEAK DETECTION SYSTEM Capacitance sensor Model Oil Leak Detector Model : CSＨ-3005, ASＨ-40 : CSＨ-3005EX, ASＨ-40EX Operation Manual Detector Model: CSH-3005 (non-explosion-proof type) CSH-3005EX (explosion-proof type) Signal converter Model: ASH-40 (non-explosion-proof type) ASH-40EX (explosion-proof type) Signal converter storage box (Option) Model: ASB-30 Low water guard...
- Page 2 The warranty in this manual covers the product itself and does not define the liability for damages caused by a failure or malfunction of the product. In any case, Asahi Kasei Technosystem Corporation shall not be liable for lost profits of the customer, damages resulting from special circumstances and damages based on a claim for compensation made to the customer by a third party.
-
Page 3: Table Of Contents
Table of contents ■ Safety Precautions of This Product ................<1> Safety Precautions ....................<2> Other Precautions ....................<3> Warranty ........................1. Outline 1-1. Features ......................1-2. Operation principle ....................2. Specifications 2-1. Detector ......................2-2. Signal converter ......................2-3. Signal converter storage box (option) ................ -
Page 4: Safety Precautions Of This Product
Safety Precautions of This Product ■ Before using the product, read these "Safety Precautions of This Product" carefully for proper use. ■ In order to prevent harm to the user and others and damage to property, the items to be observed are explained below. -
Page 5: 1> Safety Precautions
<1> Safety Precautions (1) Precautions on operation ● The case of the detector is a plastic molding. To prevent static electricity from being generated, take measures such as WARNING spraying water on the detector when carrying it. ● Do not touch the terminals of the converter with the power turned on. Otherwise, electric shock may result. - Page 6 ● In case of a failure, replacement or modification of internal parts for recovery by the customer is not allowed. CAUTION ● If a failure occurs, contact your service dealer or Asahi Kasei Technosystem. (4) General precautions ● Never handle the product in any manner not described in this manual.
-
Page 7: 2> Other Precautions
<2> Other Precautions Standard service life of this product The service life of this product is 10 years from the start of use, although it depends on the operating environment of the customer. If used after 10 or more years have elapsed, functions of this product may not be maintained due to aging degradation. -
Page 8: 3> Warranty
<3> Warranty These Warranty Terms (hereinafter referred to as “the Warranty") apply to all cases provided by Asahi Kasei Technosystem Corporation (hereinafter referred to as “ATS”) for this product (Apolarm™ C "detector/converter" and also optional items listed in this manual) only if used in accordance with the instructions in the manual. -
Page 9: Outline
1. Outline In case of an oil leak accident due to unexpected circumstances at a plant that stores a large amount of oil, prompt detection of the accident and immediate and proper response to that are the most important matters in order to minimize the impact of the accident. The "Apolarm™... -
Page 10: Operation Principle
1-2 . Operation principle (1) Detector Detector [CSH-3005 (EX)] Signal converter [ASH-40 (EX)] 変換器［ASH-40(EX)］ 検知器［CSH-3005(EX)］ Input protection 入力保護部 section High frequency 高周波 oscillator circuit 発振回路 Current 電源回路 Power circuit 電流弁別回路 discriminator circuit 電源入力 Power High frequency Comparator 比較器 電流変換回路 input converter circuit Delay circuit 遅延回路... -
Page 11: Specifications
2. Specifications 2-1. Detector Model : CSH-3005 (non-explosion-proof type), CSH-3005EX (explosion-proof type) Oils to detect Crude oil, gasoline, diesel oil, kerosene, heavy oil, lubricating oil, solvents, and animal and vegetable oils * Excluding solidified products Detection oil layer : 3 to 5 mm Structure : CSH-3005 : Water resistant structure (IP67 equivalent) -
Page 12: Signal Converter Storage Box (Option)
Output circuit : Oil leak detection output (1C contact output): not exited when normal System error output (1C contact output): exited when normal Indicator lamp : Oil leak indicator lamp (Green) On when normal / Off when oil leak is detected System error indicator lamp (Red) Off when normal / On when system error occurs Contact capacity... -
Page 13: Components And Functions
3. Components and functions 3-1. Basic components and functions The Apolarm™ C functions in combination with detector (CSH-3005, CSH-3005EX) and converter (ASH-40, ASH-40EX). It can be used in combination with other optional products if needed. [10] ⑤ ⑥ ⑦ ⑧ ⑩... -
Page 14: Components And Functions Of Detector
3-2 . Components and functions of detector (CSH-3005, CSH-3005EX) グランドパッキン Gland packing (1) Structure Operation indicator lamp 動作表示灯 検知器 Detector Cable clamp ケーブルクランプ Welded area 溶接部分 Detection electrode 検知電極 基板 Weight 錘 Float フロート Approx. 300 Φ 約３００Φ Fig. 3-2 (a) Water resistance structure The float consists of three resin moldings and the joint surface are welded. - Page 15 (c) Detection oil layer Regardless of the type of oil that flows, the detection oil layer is almost constant in a range of 3 to 5 mm. Highly viscous oil is detected when the oil layer in contact with all the electrodes becomes 3 to 5 mm in thickness.
-
Page 16: Components And Functions Of Converter
3-3. Components and functions of converter (ASH-40, ASH-40EX) 検知器 Detector connection (1) Outline drawing 接続端子（３Ｐ） terminal (3P) Input protection 入力保護部 section System error システム異常表示灯 indicator lamp Oil leak indicator 漏油検知表示灯 lamp 信号変換器 Signal converter OIL ALARM SYSTEM ALARM Delay Time(sec) 100V 200V ～... -
Page 17: Operation
4. Operation 4-1. Operational description (1) Operation timing chart 21 mA Detector 14 mA output (Current) 4 mA 2 mA Oil leak output Short-circuit Open-circuit Power off (P-N) (P-N) Output by wave/wind (Delay Time) [Oil leak detection] Indicator lamp On (Green) ALARM Closed Contact... -
Page 18: Connection And Installation
5. Connection and installation 5-1. Basic connection (1) Connection diagram Independent D-class 単独 黒 白 grounding Ｄ種接地 Ｐ Ｎ 接続箱 Junction box Explosion-proof area: M3.5 防爆エリア：単独A種接地 Independent A-class grounding 非防爆エリア：単独D種接地 Non-explosion-proof area: Ｇ 納入時接続済み 機器 Connected at the time of delivery. Independent D-class grounding Device 接続を変更しないでください... -
Page 19: Installation
5-2. Installation (1) Installation location selection The leaked-oil layer will be thinner inversely proportional to increased spread diffusion area. Therefore, it is important to collect the oil in one place. Collecting oil in one place facilitates oil recovery and prevents the spread of disasters, greatly contributing to improved reliability of the detector. - Page 20 (b) Example of installation with the guide attached to the detector Empty pit In case of significant water level fluctuation External flaw 外傷防護 protection Apolarm™ guide bar エポラームガイド 補助フロート Ball float エポラームガイド Apolarm™ guide bar 空ピットアタッチメント Low water guard Fig.5-3 Fig.
- Page 21 (3) Notes on installation [1] Relationship between detection oil layer and oil leak amount at detection The oil leak amount to issue the signal is expressed by the following formula: The oil leak amount at detection = (Detection oil layer of detector) x (Pit surface area). Particularly when installing to an oil-water separation tank or a drainage pit with large surface area, it is necessary to consider partitioning with an oil separator, leading to better practical sensitivity as a result.
- Page 22 [7] Detection oil layer for cable load The cable weight is approx. 100 g/m, and is adjusted to detect 4 mm of kerosene when a load of 1 m is applied. Since the detection oil layer is proportional to the depression amount of the electrodes, the detection oil layer will increase when a load is applied to the float.
- Page 23 [13] Prohibition of use on the surface of the sea The detector is not designed for use on the surface of the sea. The following problems may occur when using the detector at sea level. ◇ False alarms are issued due to the strong vertical movement by waves. ◇...
-
Page 24: Construction Connection Diagram
5-3. Construction connection diagram 非防爆形のみ下記対応が可能 The following application is available only for the non-explosion-proof type. * As for the explosion-proof type, the following connection is prohibited. ※防爆形では下記接続は禁止です。 接地が取れず動作が不安定な時には、Ｎ端子を When grounding is not available and operation is unstable, connecting the terminal N to the ground wire is possible. 接地線と繋ぐことができます。... -
Page 25: Maintenance And Inspection
6. Maintenance and inspection For the detector, the principles and structural design requiring only little maintenance are adopted. The product is resistant to slag, electrode contamination, stain, and others. However, in order to ensure that it functions as intended, note the following points. 6-1. -
Page 26: Periodic Inspection
6-2. Periodic inspection (1) The Apolarm™ C is a kind of safety device. In case of oil leak, the product must operate certainly. Therefore, check the functions periodically, once every 1 to 3 months. (2) Periodic inspection items [1] Pit cleanness [2] Float cleanness (around electrode in particular) [3] Presence of error of float and wiring [4] Pull-up test... - Page 27 (3) Detector/converter failure (a) Converter inspection Disconnect the wiring between the terminals P and N of the signal converter, and connect an ammeter and variable resistor (5 to 10 KΩ) as shown below. Variable resistor 可変抵抗器 (5 to 10 KΩ) 5～10kΩ...
-
Page 28: Failure Repair
(4) Blown fuse A fuse is provided in the input protection section of the converter, but it is prohibited for the customer to replace the fuse. (5) Other errors (a) Detection sensitivity deterioration If the detection oil layer thickens after the actual fluid test, clean the electrodes of the detector. If normality is not recovered after that, the detector fails. -
Page 29: Outline Drawing
7. Outline drawing 7-1. Detector: CSH-3005, CSH-3005EX 7-2 . Detector for seawater: CSH-3005C, CSH-3005EXC Approx. 180 約180... -
Page 30: Signal Converter
7-3. Signal converter: ASH-40, ASH-40EX OIL ALARM SYSTEM ALARM Delay Time(sec) 100V 200V ～ ～ 110V 220V 4-2.5R 7-4. Signal converter storage box: ASB-30 Mounting hole 4 to 4.5 4-4.5φ取付け穴 100～ 200～ 110V 220V * The converter is not included in the converter storage box (single package). -
Page 31: Low Water Guard
7-5. Low water guard: TC-SE 1-5Φ孔 Touch plate 1 to 5 タッチプレート 0.8 t Ground terminal 0.8t アースターミナル 45° Profile sketch 姿図 P.C.D330Φ 350Φ M4 set screw セットビスM4 Approx. 290 約290Φ One piece for each foot 各足に１個 278Φ Material: SUS304 材質：ＳＵＳ３０４... - Page 32 Head Office Hibiya Mitsui Tower , 1-1-2 Yurakucho, Chiyoda-ku, Tokyo 100-0006, Japan TEL: +81-3-6699-3927 FAX: +81-3-6699-3922 Nobeoka Office 5-4960 Nakagawara-machi, Nobeoka, Miyazaki, 882-0031, Japan TEL: +81-982-22-6196 FAX: +81-982-22-6061 https://www.asahi-kasei.co.jp/ats/en/...
- Page 33 Oil Leak Detector (SDA-10-3) Operation Manual Section [1] Precautions for application 1-1. Purpose and area of application 1-2. Operation principle 1-3. Connection conditions [2] Operation 2-1. Operators and qualifications 2-2. Application conditions (about X in the examination certification number) 2-3. Retention of intrinsically safe explosion-proof configuration 2-4.
- Page 34 [1] Precautions for application 1-1. Purpose and area of application - This product is used to monitor oil leaks from tanks in oil handling facilities and pump yards. The detector is installed to and used in hazardous and non-hazardous areas and the safety device is installed to non-hazardous areas.
- Page 35 [2] Operation 2-1. Operators and qualifications No special procedures, notifications, licenses, or qualifications are required to operate this device individually. 2-2. Application conditions (about X in the examination certification number) Since the exposed surface of the non-metallic portion of the container of this device does not meet the requirements for avoiding static electricity accumulation, there is a risk of electrostatic charge.
- Page 36 - Industrial Safety and Health Act and Ordinance on Industrial Safety and Health 1. Industrial Safety and Health Act; Article 42 (Restrictions on Transfer) The explosion-proof electrical equipment must not be transferred, leased out, or installed unless they fulfill the standards or safety device equipment requirements established by the Minister of Health, Labour and Welfare.
- Page 37 [3] Assembly and disassembly 3-1. Safety device assembled view Model AS-10-1 Explosion-proof configuration [Exia] IIC Protection class IP20 Rating Not intrinsically safe circuit allowable voltage 250 V AC 50/60 Hz 250 V DC Intrinsically safe circuit Max. voltage 13.65 V Max.
- Page 38 Nameplate 3-4 mooring ring Attached part 3-4 guide ring Attached part Lead wire φ8 hole Model: CSH-1505EX Explosion-proof configuration Exia IICT4Ga Protection class IP20 Material, Dimensions, Weight PVC, 150 (Ø) × 57.5 (H), Approx. 400 g Nameplate Cable length 12 m Approx.
- Page 39 3-3. Disassembly This device is a product of intrinsically safe explosion-proof configuration. Never disassemble it since disassembly by the customer may ruin explosion-proof performance. [4] Maintenance 4-1. Check before and after use Before and after use of this device, check the appearance and cable pulling-out section of the device for abnormality.
