Page 1 Lely Discovery 120 Collector Mobile Barn Cleaner Operator Manual EN - English Original 5.4008.8520.0 C Lely Industries N.V. www.lely.com...
Page 2 in n o vato rs in ag ric u ltu re INTENTIONALLY BLANK...
Page 3 Lely cannot accept liability for any damage that might arise from errors or omissions in this publication. For more information on the right on exclusive use please refer to our trademark notice on www.lely.com. Copyright © 2024 Lely Holding B.V.
Page 4 in n o vato rs in ag ric u ltu re INTENTIONALLY BLANK Trademarks, Copyright and Disclaimer...
Page 5 Wifi configuration changed. 2022/09 UKCA Declaration of conformity added. 2024/12 Added: Lely Sand flush (optional). Added: Hazard statements and safety messages concerning moving machine, manure gas, mixing manure gas, unplug before maintenance, cable protection, wear gloves during cleaning of the tank, risk of bruised fingers during opening and closing of the cover of the machine.
Page 6 in n o vato rs in ag ric u ltu re INTENTIONALLY BLANK List of included Amendments...
Page 7 Store this manual in a safe place for future reference. All information in this manual has been compiled with care. Lely shall not be liable for errors or faults in this manual. The recommendations are meant to serve as guidelines. All instructions, pictures and specifications in this manual are based on the latest information that was available at the time of publication.
Page 8 in n o vato rs in ag ric u ltu re Figure 1. Type and serial number plate We suggest that you complete the table below with the type and serial numbers of your Discovery. This makes sure that you can easily find the information. Type number Serial number Figure 2.
Page 9 The type and serial number plate of the Sand flush (optional) is attached under the cover, on the right side of the pump. Always include the type and serial number of your product, when you contact your local Lely service provider or when you order spare parts.
Page 10 Technician Training All the technicians certified by Lely Industries have completed an approved training program, and passed written and practical examinations during and at the end of the training program. The training is given by...
Page 11 Foreseeable misuse Lely Sand flush ........
Page 12 . . 7-6 7.3.3 Put the Machine Into Operation and Take it Out of Operation with the Lely Control Plus Application ................7-7 Control the Machine with Your Smartphone .
Page 13 ......... . . 8-7 Clean the Lely Sand flush (optional) .
Page 14 in n o vato rs in ag ric u ltu re INTENTIONALLY BLANK Table of Contents...
Page 15 Leaving this designated, enclosed space (e.g. crossing the feed alley to get from one manure alley to another) is not an intended use and therefore not allowed. Application of the Lely Discovery 120 Collector in any way other than the intended use is dangerous and can cause serious injuries or death.
Page 16 Operation in barns with sand bedding The Discovery Collector can be used in barns with sand bedding only when a Lely Sand flush is installed. The effectiveness of manure suction depends on several factors, including the amount and type of sand on the floor, moisture content, manure consistency, air temperature, and humidity.
Page 17 Ensure the machine sprays enough water to keep the manure-sand mixture from becoming too dry. • Operating the machine in barns with sand bedding will increase wear on certain components, such as wall-follow guides, scrapers, skids, wheels and motors, due to abrasive sand. The Lely Discovery Mobile Barn Cleaner...
Page 18 INTENTIONALLY BLANK The Lely Discovery Mobile Barn Cleaner...
Page 19 The machine stops immediately. It also stops taking in manure and sprinkling water. • Stop the machine with the smartphone Open the Lely Control Plus app and connect to the appropriate machine. Draw the slider to the left position. •...
Page 20 Unplug the Lely Sand flush (optional) from the grid in case of an emergency Pull the Sand flush plug from the socket to disconnect the Sand flush from the grid.
Page 21 in n o vato rs in ag ric u ltu re Indicates information that may help the reader, but not hazard related. Safety Decals and Signs Decal / sign Explanation Caution: Risk of injury. Take the machine out of operation when you enter the working area of the machine and do work with livestock.
Page 22 Safety decals Lely Sand flush (optional) The safety decals are visible when the cover is removed from the flush unit. Decal Explanation Caution: Electrocution hazard Risk of electrocution. Unplug or switch off the power before doing maintenance, adjustments or repair.
Page 23 Sand flush (optional). Only trained persons are permitted to operate the machine. • Only a certified Lely technician is allowed to open the control box of the Sand flush (optional). • • A first-aid kit must be available in or near the barn where the machine operates. Store in a highly visible place.
Page 24 • power. Make sure the part is repaired before you put it into operation again. Only original components (see Lely parts list) are allowed to be installed and only certified technicians • are permitted to do corrective maintenance on the Sand flush.
Page 25 The machine, water station, dump pit with safeguards, charging station and Lely Sand flush (optional) are installed by Lely. Do not change anything to the installation. This includes the water supply and the tap water system and the connections to the power supply.
Page 26 Maintenance Safety Only certified technicians are permitted to do corrective maintenance on the machine, charger and • Lely Sand flush (optional). Before doing maintenance, release the manure from the tank. • Make sure no manure mixing is active when you do maintenance on the machine near the dump pit or •...
Page 27 in n o vato rs in ag ric u ltu re 2.10 Safety Devices Safety Devices on the Machine Figure 6. Safety devices KEY: 1. Pause button - 2. Buzzer The pause button is installed on the front under the cover of the machine. When it is pushed the machine is out of operation.
Page 28 in n o vato rs in ag ric u ltu re Safeguard on the Dump Pit Figure 7. Dump pit KEY: 1. Safeguard - 2. Bar The safeguard on a dump pit consists of metal bars that prevent people and animals from falling into the dump pit.
Page 29 in n o vato rs in ag ric u ltu re Figure 8. Dump pit extension frame The fence and the dump pit extension frame installed near a large pit prevents people and animals from falling into the large dump pit. Safety 2-11...
Page 30 in n o vato rs in ag ric u ltu re INTENTIONALLY BLANK 2-12 Safety...
Page 31 Total water bags capacity: 70 L (18.5 US gal). • Optional water bags with a smaller capacity: 42 L (11.1 US gal). For water bags for Lely Sand flush (optional) see specifications for Lely Sand flush. Total water output via nozzles: Max. 3.5 L/min (0.93 gal/min).
Page 32 The machine can operate with these temperatures but the manure must be liquid. • Water temperature range for water filling station and for Lely Sand flush (optional): 0 °C to +35 °C (32 to 95 °f). Humidity: 10 - 95 %, non condensing.
Page 33 in n o vato rs in ag ric u ltu re Table 2. Specifications Charging Station Charging station Dimensions and weight. Width: 483 mm (19.0 in). • Depth: 153 mm (6.0 in). • Height: 915 mm (36.0 in). • Weight: 21.4 kg (47.2 lb) (excluding battery charger). •...
Page 34 in n o vato rs in ag ric u ltu re Table 3. Specifications Water Filling Station Water Filling Station Dimensions and weight. Water filling unit: • Width: 260 mm (10.2 in). • Height: 475 mm (18.7 in). Depth: 490 mm (19.3 in). •...
Page 35 Length: 500 mm (20 in). • Large dump hole No recommendations. (lagoon) Syphon For more information see the documentation of the Lely Sphere, the syphon fits in a hole of: Width: 1200 mm (47 in). • Length: 500 mm (20 in). •...
Page 36 in n o vato rs in ag ric u ltu re Weight: 22 kg (48.5 lb). • Power supply. Input voltage: 230 VAC (50 Hz) or 120 VAC (60 Hz). • Flush time. Short (approximately 20 s). • Medium (approximately 40 s). •...
Page 37 Description General Description 4.1.1 The Lely Discovery This chapter describes the parts of the system. It also explains how the parts work together to clean the barn floor. Figure 9. Overview of the system KEY: 1.
Page 38 • If there is sand in the manure alley causing a buildup of sand in the manure tank, a Lely Sand flush (optional) can be installed. When a Lely Sand flush (optional) is installed, the dump station and the water filling station must be combined.
Page 39 in n o vato rs in ag ric u ltu re Figure 11. Overview of the bottom of the machine KEY: 1. Drain hole - 2. Ultrasonic sensor - 3. Wall guide - 4. Floor guide - 5. Manure inlet - 6. Manure scraper - 7. Wheel drive unit (left and right) - 8.
Page 40 in n o vato rs in ag ric u ltu re Figure 12. Overview of the inside of the machine. KEY: 1. Water bag - 2. Water pump - 3. Water filter - 4. Top cover latch - 5. Vehicle Input Output Box (VIOB) - 6. Battery - 7. Vehicle Control Box (VCB) - 8.
Page 41 Similar functionality can be achieved by using the operational button in the Lely Control Plus application. If an alarm occurs, the LED in the pause button blinks. The alarm must be confirmed with the Lely Control Plus application.
Page 42 Battery. • Charging strips. • ON/OFF switch. • VIOB. • Charging station. • 4.2.2 Lely Control Plus Application The machine is operated with an Android smartphone (a smartphone is not included). The smartphone communicates with the machine via Bluetooth. Description...
Page 43 Never go inside the dump pit safety guards. Falling into the dump pit will cause serious injury or death! The dump pit brackets and safeguards are installed by Lely according to the Lely installation instructions. Do not change anything to the installation of the dump pit! The dump pit is the location where the machine releases the manure from its tank.
Page 44 in n o vato rs in ag ric u ltu re Figure 14. Overview of the dump pit KEY: 1. Dump pit brackets - 2. Dump pit safety frame 4.2.4 Charging Station The machine routes normally starts and ends at the charging station. The machine recharges itself at the charging station.
Page 45 in n o vato rs in ag ric u ltu re Table 8. Power LED Status Charging LED (green) (orange) Mains connected Recharging (>1A) Error Blinking Blinking Figure 15. Charging station KEY: 1. Charging electrodes - 2. Wall unit (including the battery charger) - 3. Charger contact unit - 4. Machine Description...
Page 46 Water Filling Station Risk of contaminated drinking water The water filling station is installed by Lely according to the Lely installation instructions. Do not change anything to the installation of the water filling station to prevent contamination of drinking water! The machine refills the water bags at the water station.
Page 47 4.2.6 Lely Sand flush (optional) Figure 17. Sand flush (optional) KEY: 1. Flush unit - 2. Water hose - 3. Sensor cable - 4. Water station with a sensor - 5. Water bags with a flush valve The Sand flush has the following parts: An inductive sensor (4) to detect if the machine is connected to the water station.
Page 48 in n o vato rs in ag ric u ltu re Software Description Figure 18. Menu structure 4-12 Description...
Page 49 Figure 19. Home page of a machine in operation KEY: 1. Current route number and route action - 2. Menu button Lely Control app - 3. Next route number and start time - 4. Battery status and percentage charged - 5. Number of alarms, warnings and messages - 6. On/Off switch - 7. Menu...
Page 50 Sometimes a temporary status is displayed below this line. After a few seconds the status will return to normal again. Buttons to shows the Lely Control app options. • to put the machine into operation or to take it out •...
Page 51 in n o vato rs in ag ric u ltu re 4.3.2 Manual Control Display Description The Manual Control page shows the buttons to drive the machine manually. The easiest way is to slide the icon of the machine in the direction you want to drive and/or turn (see Manually Drive the Machine to a Location on page 7-10).
Page 52 in n o vato rs in ag ric u ltu re 'Hold manure': The machine does not take new manure in, but holds the manure that is already • in the tank. 'Release manure': The machine releases the manure from the tank. •...
Page 53 This • page will only be used by the Lely technician. Description 4-17...
Page 54 in n o vato rs in ag ric u ltu re Display Description Make sure the machine is connected to the charger in the correct direction. Tap to start driving the route. Buttons Continue dayplanning after route to set a green checkmark •...
Page 55 Only do the procedures that are described in this manual. If the procedure is not written in this manual you must contact your local Lely technician. Buttons Failure info to go to the page with information for lely •...
Page 56 in n o vato rs in ag ric u ltu re 4.3.7 Settings Display Description The page Settings is used to make the following settings: Name: name of the machine. The name of the machine has been • configured during the installation process. •...
Page 57 in n o vato rs in ag ric u ltu re 4.3.7.2 Cloud configuration Display Description The row of LED indicators at the top of the screen display: • • Router: the status of communication between the robot and the router (green: communication is active).
Page 58 in n o vato rs in ag ric u ltu re 4.3.7.3 WiFi Configuration Display Description The row of LED indicators at the top of the screen display: • • Router: the status of communication between the robot and the router (green: communication is active).
Page 59 When the machine is put into operation, it will be controlled by the day planning. When the machine is out of operation, the day planning has no control over the machine and you can control the machine yourself manually with the Lely Control Plus Application. Driving To drive the correct route the machine uses: •...
Page 60 The machine is charged until the next route must be driven according to the day planning. Most efficient for the use of the space in the machine is when the water bags are filled during or after dumping the manure. Operation Lely Sand flush (optional) 5.2.1 Control box Figure 20.
Page 61 in n o vato rs in ag ric u ltu re 2 = Medium flush (approximately 40 s). • 3 = Long flush (approximately 60 s). • The real flush time will be approximately 8 seconds shorter if the water bags were completely emptied during the previous route (see Flush valve in the water bag on page 5-3).
Page 62 in n o vato rs in ag ric u ltu re INTENTIONALLY BLANK Operation...
Page 63 Your smartphone must be paired to the machine (this needs to be done only once for each smartphone). The Lely Control Plus app must be connected to the machine (this needs to be done every time you want to operate your machine with your smartphone) (see Connect the Lely Control Plus app to the Machine on page 7-8).
Page 64 in n o vato rs in ag ric u ltu re INTENTIONALLY BLANK First Use...
Page 65 in n o vato rs in ag ric u ltu re Operating Instructions Open or Close the Top Cover To switch the machine ON and OFF and to do certain maintenance procedures you must open the top cover. Moving machine Risk of injury.
Page 66 in n o vato rs in ag ric u ltu re Open the Top Cover Take the machine out of operation by pushing the PAUSE button (1) (see figure 21 on page 7-2). Figure 21. Open the cover KEY: 1. Button - 2. Bracket - 3. Latch - 4. Cover •...
Page 67 in n o vato rs in ag ric u ltu re Close the Top Cover Make sure the top cover is locked completely after closing it. Cows will try to open the top cover and may damage the machine. Pinching between the cover and the machine. Risk of bruised fingers.
Page 68 in n o vato rs in ag ric u ltu re Push the ON / OFF button (6) (see figure 22 on page 7-4) shortly. Figure 22. Switch the machine ON and OFF KEY: 1. PAUSE button - 2. Safety - 3. CAN LED (green) - 4. CPU2 LED (green) - 5. CPU1 LED (green) - 6. ON/OFF button •...
Page 69 in n o vato rs in ag ric u ltu re Switch the Machine OFF Manually control the Discovery (see page 7-9), drive the machine away from the charging station, the machine must not be connected to the charger to be able to power it down correctly. Alternatively, take the power plug of the charger out of the power outlet.
Page 70 • page 7-6). • With the Put the Machine Into Operation and Take it Out of Operation with the Lely Control Plus Application (see page 7-7). 7.3.2 Put the Machine Into Operation and take it Out of Operation with the PAUSE...
Page 71 The machine can be controlled manually now (see Manually control the Discovery on page 7-9). • 7.3.3 Put the Machine Into Operation and Take it Out of Operation with the Lely Control Plus Application The machine can be put into operation and taken out of operation by sliding the button Operation Status on the home page of the Lely Control Plus application.
Page 72 Control the Machine with Your Smartphone 7.4.1 Connect the Lely Control Plus app to the Machine Every time you want to operate the machine with your smartphone, you need to connect the Lely Control Plus app to the machine. Unexpected movement of machine.
Page 73 (such as, but not limited by, Teamviewer) is strictly forbidden to avoid dangerous situations. When the machine is taken out of operation it can be controlled manually with the Lely Control Plus application on your smartphone.
Page 74 (such as, but not limited by, Teamviewer) is strictly forbidden to avoid dangerous situations. Connect the Lely Control Plus app to the machine (see Connect the Lely Control Plus app to the Machine on page 7-8).
Page 75 (such as, but not limited by, Teamviewer) is strictly forbidden to avoid dangerous situations. Connect the Lely Control Plus app to the machine (see Connect the Lely Control Plus app to the Machine on page 7-8).
Page 76 (such as, but not limited by, Teamviewer) is strictly forbidden to avoid dangerous situations. Connect the Lely Control Plus app to the machine (see Connect the Lely Control Plus app to the Machine on page 7-8).
Page 77 (such as, but not limited by, Teamviewer) is strictly forbidden to avoid dangerous situations. Connect the Lely Control Plus app to the machine (see Connect the Lely Control Plus app to the Machine on page 7-8).
Page 78 (such as, but not limited by, Teamviewer) is strictly forbidden to avoid dangerous situations. Connect the Lely Control Plus app to the machine (see Connect the Lely Control Plus app to the Machine on page 7-8).
Page 79 (such as, but not limited by, Teamviewer) is strictly forbidden to avoid dangerous situations. Connect the Lely Control Plus app to the machine (see Connect the Lely Control Plus app to the Machine on page 7-8).
Page 80 • On the machine, the PAUSE button light blinks. • When the Lely Control Plus application is connected to the machine on the smartphone the alarm list • will pop up. When the machine is connected to the cloud a push notification is sent to the Horizon InHerd Signals •...
Page 81 The alarm is displayed in the signals app at the top of the list. Tap the line of the alarm to read the alarm. In the Lely Control Plus app you can mark the alarm as solved. In the WiFi configuration screen is displayed if the alarm notification is read in Signals.
Page 82 Lely Control Plus Application. Add a Route to the Day Planning Connect the Lely Control Plus app to the machine (see Connect the Lely Control Plus app to the Machine on page 7-8). Tap the menu Dayplanning.
Page 83 Discovery in and out of operation on page 7-5). Replace a Route in the Day Planning by Another Route Connect the Lely Control Plus app to the machine (see Connect the Lely Control Plus app to the Machine on page 7-8).
Page 84 Discovery in and out of operation on page 7-5). Delete a Route from the Day Planning Connect the Lely Control Plus app to the machine (see Connect the Lely Control Plus app to the Machine on page 7-8). Tap the menu Dayplanning.
Page 85 Adjust the timer setting with the switch The first few weeks when the flushing system is in use, Lely advises to set the switch to 3 and use the long flush. When the system has operated correctly for some time, meaning there is limited sand buildup in the manure tank and no problems occur, the amount of water used for flushing can be lowered by setting the switch lower to optimize the system and to save water.
Page 86 in n o vato rs in ag ric u ltu re The sand must be flushed from the manure tank monthly (or more or less often when necessary) as described in the maintenance chapter. Moving vehicle Risk of being crushed. You must prevent that the machine drives into the water station while you work on it.
Page 87 Put the Discovery Collector in operation. 7.5.2 Switch on the Lely Sand flush (optional) Make sure when the flush unit is switched on, the water supply is also opened. If the water supply is closed, the pump will run dry and can be damaged.
Page 88 Before the environmental temperature drops below freezing point, the water reservoir of the water filling station and the water bags in the manure tank of the machine must be drained. Lely Industries N.V. will not take any liability for damage due to frost.
Page 89 PAUSE button (see Put the Machine Into Operation and take it Out of Operation with the PAUSE Button on page 7-6) or with the Lely Control Plus app (see Put the Machine Into Operation and Take it Out of Operation with the Lely Control Plus Application on page 7-7).
Page 90 Manually flush sand from the manure tank. Monthly; if there is sand laying around in the • manure alley and a Lely Sand flush (optional) installed. Clean the moving vehicle signs in the barn and When visibility of the signs is reduced.
Page 91 in n o vato rs in ag ric u ltu re Clean the Machine Electric shock. Risk of severe injury or death. Do not use a high pressure cleaner to clean the machine. Preparation Take the machine out of operation. Manually drive the machine away from the charger to disconnect it.
Page 92 in n o vato rs in ag ric u ltu re Manually drive the machine to a clean and quiet location. Unexpected cow movement. Risk of being crushed or trampled. Block the cow traffic. Block the cow traffic. Switch off the machine. Remove and Clean Figure 24.
Page 93 in n o vato rs in ag ric u ltu re Use a moist cloth to clean the level sensor (1). Installation Install the air filter (5) on the manure tank. Make sure the nails (11) point downwards, the air hole (6) of the air filter fits around the air tube (8), and the ring (7) is in the correct position.
Page 94 in n o vato rs in ag ric u ltu re Do not use a pressure cleaner to clean the ultrasonic sensors. When it is difficult to get the manure off, first make the surface of the ultrasonic sensors wet with a moist cloth, let the water soak the manure for a while and then wipe it off. Do not use sharp objects to clean the ultrasonic sensors.
Page 95 When sand is present in the manure alley and a Lely Sand flush (optional) is installed, the inside of the manure tank must be washed out with a water hose to prevent too much buildup of sand over time.
Page 96 in n o vato rs in ag ric u ltu re Toxic gasses. Risk of losing consciousness. Only remove the air filter from the manure tank when the machine is in a well ventilated area. Be aware of toxic fumes that may release from the manure tank.
Page 97 Manually drive the machine to the charger. Unblock the cow traffic. Put the machine into operation. Clean the Lely Sand flush (optional) Moving vehicle Risk of being crushed. You must prevent that the machine drives into the water station while you work on it.
Page 98 in n o vato rs in ag ric u ltu re Make sure the Discovery Collector is out of operation. Toxic gasses. Risk of losing consciousness. Cover the dump pit and make sure the area is well ventilated before you do work on the Unit.
Page 99 in n o vato rs in ag ric u ltu re Figure 28. Remove or install the plate KEY: 1. Plate - 2. Plate Maintenance 8-11...
Page 100 in n o vato rs in ag ric u ltu re Figure 29. Hoist the machine KEY: 1. Hoisting point - 2. Block (2x) - 3. Hoisting belt 8-12 Maintenance...
Page 101 Test and Adjustment Test the Ultrasonic Sensors Connect the Lely Control Plus app to the machine (see Connect the Lely Control Plus app to the Machine on page 7-8). In the main menu of the Lely Control Plus app tap Testing.
Page 102 in n o vato rs in ag ric u ltu re Tap Real distance driven and set the measured distance. Tap Calibrate. The machine calibrates the wheel diameter for the left and right wheel independently. Examine if the calibrated values are in the range between 280 - 315 mm (11 - 13 in) (the value for new wheels).
Page 103 Multiple causes. Follow the procedure shown on PAUSE button is blinking / an the alarm detail page. alarm is popping up on the Lely Control Plus app). Machine is switched OFF. Switch ON the machine. The machine is standing still (but...
Page 104 Clean the front and/or rear machine are blocked by dirt. sprinkle nozzle. The water hoses leak. Turn off the machine and contact your local Lely service provider. The water pump does not work. Contact your local Lely service provider. The wheels of the machine are The tyres are worn out.
Page 105 'The machine does not sprinkle water'. The wheel diameter is not Calibrate the wheels. correct anymore. The tires are worn out. Contact your local Lely service provider. Ultrasonic sensor(s) do not Clean the ultrasonic sensors. function properly. Ultrasonic sensors, gyroscope or...
Page 106 The manure is too thick or too Spray (more) water. dry. The machine is not taking in The floor guides are worn out. Contact your local Lely service enough manure / the barn is not provider. cleaned well. The manure scraper is worn out.
Page 107 (see Pair Your Smartphone to the Machine on page 6-1). The Lely Control Plus app is not Connect the Lely Control Plus connected to the machine. app to the machine. (see Connect the Lely Control Plus...
Page 108 Check if the power supply to • the power outlet is OK. Green and Yellow LED Battery loader defect. Contact your local Lely service provider. together blink 2 times, followed by a few seconds rest Green and Yellow LED Temperature lower than - 15 Warm the barn and try again.
Page 109 10.2 Troubleshooting table Lely Sand flush (optional) Symptom Possible cause Action The Lely Discovery Collector Too much sand buildup in the Wash out the inside of the starts making “wheelies” (lifting back of the manure tank.
Page 110 This can result in an empty Lely service provider to change header tank. the routes. Water supply is not sufficient Make sure the water supply is...
Page 111 Symptom Possible cause Action sand buildup and possibly driving Contact your local Lely service issues Water bag is damaged provider Water system is leaking Shut down the system immediately and contact your...
Page 112 Lely water station. If not, contact water station Discovery Collector is connected your local Lely service provider.
Page 113 This is only a very limited amount of water. The system is OFF but a lot of Flush valve is broken Contact your local Lely service water is flowing out of the flush provider valve when the machine is...
Page 114 in n o vato rs in ag ric u ltu re INTENTIONALLY BLANK 10-12 Troubleshooting...
Page 115 WEEE directive, require special reuse and recycling processing. For this reason, Lely Industries N.V. has arranged that this product can be recycled at the local recycling/ disposal companies to collect and recycle this product at no cost to you.
Page 116 WEEE directive, require special reuse and recycling processing. For this reason, Lely Industries N.V. has arranged that this product can be recycled at the local recycling/ disposal companies to collect and recycle this product at no cost to you.
Page 117 12 Declarations of conformity Lely Discovery 120 Collector 5.4008.00xx.x Machinery directive 2006/42/EC EN-ISO 12100:2010, EN 60204-1:2006/AC:2010 EN 60950-1:2006/A2:2013, EN 61000-6-2:2005 EN 61000-6-4:2007 06-Nov-17 5.4008.8584.9 Declarations of conformity 12-1...
Page 118 Lely Discovery 120 Collector 5.4008.00xx.x Supply of Machinery (Safety) Regulations 2008 (UK) Electrical Equipment (Safety) Regulations 2016 (UK) Electromagnetic Compatibility Regulations 2016 (UK) EN-ISO 12100:2010, EN 60204-1:2006/AC:2010 EN 60950-1:2006/A2:2013, EN 61000-6-2:2005...
Page 119 in n o vato rs in ag ric u ltu re Declarations of conformity 12-3...
Page 120 in n o vato rs in ag ric u ltu re 12-4 Declarations of conformity...
Page 122 Lely Industries N.V. CornelisFvanFderFLelylaanF1 NL-3147FPB FMaassluis Tel +31F(0)88F-F12F28F221 Fax +31F(0)88F-F12F28F222 www.lely.com...
