User Manual including setting procedures for all devices from the S&G Basic range.

29/04/2019 10:35

28/07/2023 11:49:00

S&G Basic Manual

ERIFIED BY

Full Name

date + signature

Purpose of the document

Plug&Play Access & Revenue Control

For Vehicles and Pedestrians

PPROVED BY

Full Name

date + signature

Table of Contents

Need help?

Do you have a question about the Basic and is the answer not in the manual?

Questions and answers

Summary of Contents for SCAN&GO Basic

Page 1 Full Name Full Name Full Name date + signature date + signature Mario Elia Purpose of the document User Manual including setting procedures for all devices from the S&G Basic range. Plug&Play Access & Revenue Control For Vehicles and Pedestrians...
Page 2: Table Of Contents
3.1.15 How to reboot the scanner controller .................17 3.1.16 How to trigger the output relay of the scanner controller ..........17 Configuring the scanner unit using BASIC AdminTool v4 ............18 3.2.1 Selecting the right com port ..................18 3.2.2 Troubleshooting the USB Serial Port ................19 3.2.3...
Page 3 6.1.5 Settings ........................40 6.1.6 Features and licenses ....................45 6.1.7 Program 1 and Program 2 ..................45 Plug&Play Access & Revenue Control For Vehicles and Pedestrians...
Page 4: Introduction
Virtual Communication (= Virtual Networks). This means that you can determine where, when, how long and how often your barcode tickets are valid without having to network Scan&Go BASIC products with each other via a WiFi or wired data network. Electrical power is enough.
Page 5: Scan&Go Basic Components
The standalone scanner control unit, with integrated CCD scanner and LCD display, interprets Scan&Go Basic 2D code tickets without any communication with Scan&Go Basic printers or a data network. It has one output to which you can connect a physical access.
Page 6: Ticket Generation/Validation
2.2 Ticket generation/validation 2.2.1 SGB-DT1.x (desktop printer) This desktop barcode printer for thermal paper comes with 3 push buttons. Each button generates unique 2D code tickets that include specific predefined access rights/rules: Grey button: Single Use tickets valid for 30 minutes after printing (typically for visitors). Blue button: Multiple Use tickets valid till the end of the day (typically for subcontractors, suppliers, etc…...
Page 7: Scan&Go Basic Idud (Validator)
2.2.2 Scan&Go Basic IDUD (Validator) Scan&Go BASIC IDUD (also referred to as BASIC ID Upgrader/Downgrader or BASIC Validator) consists of an Android tablet (including embedded DAS Validator software) with an integrated scanner, USB- connected to a desktop printer (you may have an IDUD tablet with an integrated printer but that printer is not used).
Page 8: Printer Controller (Printer Column)
2.2.4 Printer controller (printer column) This aluminium column comes with an integrated kiosk printer for thermal tickets connected to a S&G BASIC controller including one output (for connection to a physical access) and one input (presence detection input). Plug&Play Access & Revenue Control...
Page 9: Configuring The Scanner Unit
3 Configuring the scanner unit The scanner unit comes preconfigured but you can customize/modify this default configuration either using the free-of-charge configuration software BASIC AdminTool or a list of barcode command cards and thus apply software-less/offline update procedures. 3.1 Configuring the scanner unit using command cards...
Page 10: How To Link An Additional Desktop Printer To A Scanner Controller
Identity” and a “S&G Basic Printer Identity” card. These unique barcode cards are necessary for a software-less commissioning. Please note that a S&G Basic scanner controller can read barcodes from up to a maximum of 32 printers. In other words, you can create a virtual link between one scanner and a maximum of 32 printers.
Page 11: Configuring The Display Languages
3.1.2 Configuring the display languages In this example, we want the messages to appear in English, French and German. 1. Scan the card “S&G Basic Identity” to the scanner controller until you see the message ‘Please scan: Command card’. 2. Scan the command card « Set languages » until you see the message ‘Set languages’.
Page 12: Configuring The Flow Direction Of A Controlled Access
The default mode is “Exit”. 3.1.4 Exit  Scan the card « S&G Basic Scanner Identity » to the scanner until you see the message ‘Please scan: Command card’.  Then scan the command card « Direction : Exit » until you see the message ‘Access configured as exit’.
Page 13: How To Configure An Access In "Free Access" Mode
3.1.6 How to configure an access in “Free access” mode?  Scan the card « S&G Basic Scanner Identity » to the scanner until you see the message ‘Please scan: Command card’.  Then scan the card “Free access” until you see the message ‘Free access configured’.
Page 14: How To Reset The Scanner Controller (Factory Defaults)
3.1.8 How to reset the scanner controller (Factory defaults)  Scan the card « S&G Basic Scanner Identity » until you see the message ‘Please scan: Command card’.  Then scan command the card “Restore factory defaults” until you see the message ‘Resetting….’.
Page 15: How To Add A Permanent Access Card
3.1.10 How to add a permanent access card  Scan the card « S&G Basic Scanner Identity » until you see the message ‘Please scan: Command card’.  Then scan the command card “Add permanent card” until you see the ‘Please scan: Permanent card’.
Page 16: How To Synchronize The Internal Clocks Of A Desktop Printer And A Scanner Controller
“Timestamp” ticket (If you first want to update the system time of the printer use the configuration software DAS BASIC AdminTool.  Scan the card « S&G Basic Scanner Identity » until you see the message ‘Please scan: Command card’. ...
Page 17: How To Delete The Event Memory Of The Control Unit
3.1.14 How to delete the event memory of the control unit  Scan the card « S&G Basic Scanner Identity » until you see the message ‘Please scan: Command card’.  Then scan the command card “Clear ticket memory” until you see the message “Ticket memory cleared”.
Page 18: Configuring The Scanner Unit Using Basic Admintool V4
3.2 Configuring the scanner unit using BASIC AdminTool v4 DAS BASIC AdminTool is a self-contained PC web application that does not need a working internet connection. However, due to the web technologies used, your firewall or virus scanner could interfere with it. Don't restrict or reduce the security level of DAS BASIC AdminTool, even when requested by your computer and make sure that network port 7100 is available.
Page 19: Troubleshooting The Usb Serial Port
3.2.2 Troubleshooting the USB Serial Port If you are using a USB Serial port converter, and DAS AdminTool can't communicate with the device try the following steps:  Go to start>run and type “devmgmt.msc” (you can type this in the 'Search' box in the start menu of Windows Vista/7/10) Fig 04 ...
Page 20 Fig 07 Plug&Play Access & Revenue Control For Vehicles and Pedestrians...
Page 21: Configuring The Scanner Unit
3.2.3 Configuring the Scanner Unit Make sure to always click on 'Save settings to device' after making modifications!! 3.2.3.1 Device menu Click on 'Devices' at the top left of your screen. You will then see the following: Fig 08 3.2.3.2 System settings Change if necessary the date, time zone, display language and ticket date notation: ...
Page 22 3.2.3.3 Access Control  Access control mode: make your choice out of 3 access control modes:  Enabled (=Default)  Free Access  Permanent closed Free Access mode activates a permanent trigger of the output relay. Please check the compatibility of your physical access with this command. For example, an automatic barrier could be configured to close automatically after a while, even with our permanent open command.
Page 23: Setting Up A Desktop Printer
Blue button: Multiple Use tickets valid till the end of the day (typically for subcontractors, suppliers, etc… ). The default validity of the two push buttons can be modified using the free-of-charge configuration software BASIC AdminTool. Plug&Play Access & Revenue Control For Vehicles and Pedestrians...
Page 24: Printing A Timestamp Ticket With The Desktop Printer (Admin Mode)
4.2 Printing a timestamp ticket with the desktop printer (Admin mode) This is important information if you wish to synchronize the internal clocks of the scanner unit and desktop printer.  Power off the printer  Put the printer in Admin Mode by pressing either the grey or blue push buttons while powering the printer on (keep the button pressed while powering on).
Page 25: Configuring A Desktop Printer Using Basic Admintool V4
4.5 Configuring a desktop printer using BASIC AdminTool v4 Info regarding desktop printers with product code BCP-DT1.6a. In order to be able to communicate with your pc, the switch at the back of this desktop printer must be on position “C”.
Page 26: Tools Menu
4.5.1.1 Preload Ticket Lanuage Select the language you want to print tickets with 4.5.1.2 System settings Change the date, time zone, ticket date notation and ticket title.  Date: when connected to your computer, the Desktop Printer automatically duplicates the computer date ...
Page 27: Configuring The Printer Controller Using Admintool V4
5 Configuring the printer controller using AdminTool v4 5.1 Device menu Click on 'Devices' at the top left of your screen. You will then see the following: 5.1.1 System settings Change if necessary the date, time zone, display language and ticket date notation: ...
Page 28: Kiosk Printer Settings
5.1.2 Kiosk printer settings  Ground loop:  Ticket subtitle: type the the subtitle you want to print on every ticket  Print several tickets: define here the number of tickets you print each time you push this button  Usage credit counts: define here the number of times tickets can be used within their time validity ...
Page 29: Tools Menu
5.2 Tools menu Click on Tools at the top of the page. 5.2.1 Info General information about the embedded firmware version 5.2.2 Trigger an action  Reboot: Click on this button to reboot the device. It will not lose its configuration during the process. 5.2.3 Copy/restore configuration Backup a DAS device configuration and save it to your computer.
Page 30: Logs
5.3 Logs Please ignore this tab. It is of no use anymore. Plug&Play Access & Revenue Control For Vehicles and Pedestrians...
Page 31: Configuring Scan&Go Basic Idud (Validator) Using Admintool V5
DAS barcode ticket (= downgrading). Unlike Scan&Go PRO, BASIC IDUD can only operate in one mode: offline (= swapped-tickets mode also referred to as two-tickets mode). With this mode, the DAS USB desktop printer is mandatory.
Page 32: Installing And Setting Up The Das Id Up-Downgrader Hardware
6.1.2 Installing and setting up the DAS ID Up-Downgrader hardware 1. Power the tablet by plugging-in its plug into a power socket. 2. Power ON the tablet by pressing and holding the ON/OFF button for several seconds until you see the name Android on the display. Connect the tablet with an ethernet cable to the same LAN the computer on which runs Pro- AdminTool is connected to.
Page 33: Configuring The Das Validator Application (Scan&Go Basic Idud)
6.1.3 Configuring the DAS Validator application (Scan&Go BASIC IDUD) The DAS Validator application should start automatically a few seconds after turning on the tablet. If not, start the DAS Validator software application by clicking the DAS Validator shortcut on the home page of the tablet.
Page 34 With this window, click on With this window, click on With this window, click on This window summarizes your choices. Click on Plug&Play Access & Revenue Control For Vehicles and Pedestrians...
Page 35 Once the software is installed, a window will prompt you to finish the installation procedure by choosing whether to launch Das CU5 PCOffline or not. Plug&Play Access & Revenue Control For Vehicles and Pedestrians...
Page 36 6.1.3.1.2 Connecting PROAdminTool with DAS IDUD We assume that your computer is connected to the DAS tablet via your LAN (Wifi or Ethernet). When you start ProAdminTool (PAT) and click on File you will see the following page with only three options under File.
Page 37 6.1.3.1.3 Modifying network settings While being connected to the tablet/controller as described above, you might want to modify its network settings. If so, select the tablet/controller and then click on Edit. You will then see its network information: By unticking the "DHCP" field you can choose your own values for: IP address, Subnet Mask, Gateway, Dns1 and Dns2.
Page 38: File
6.1.4 File After you clicked on Connected, click on File and you’ll see the following: 6.1.4.1 Upload Click Upload when you want to update a connected CU5/tablet with the configuration changes you applied in ProAdminTool. This option is not available when modifying a loaded backup configuration file (without being connected to a controller).
Page 39 6.1.4.5 Change password As already mentioned in this manual, for security reasons any update of a connected tablet/controller using ProAdminTool, must be done within 5 minutes after reboot of the controller/tablet or a scan of the S&G Pro Identity. After these 5 minutes, the S&G Pro Identity must be scanned again or the tablet/controller rebooted or a password entered, before being able to perform a configuration upload.
Page 40 6.1.5 Settings This is what you see after ProAdminTool (PAT) redirected you to the Settings page. You now have access to the tabs Settings, Features&Licenses, and Program1&2. When connected to a DAS IDUD tablet, PAT can show up to 4 tabs with each having their own settings windows.
Page 41 In the unlikely event that a tablet would need to be replaced (for example due to a technical failure), DAS offers you the option of ordering a new tablet with the same DAS ID as that of the tablet that needs to be replaced (but with a new hardware number, of course).
Page 42 Offline/standalone/disconnected CU5 controller/tablets rely on their RTC (Real Time Clock) to determine their system time. Depending on circumstances such as the ambient temperature, their system time values can therefore deviate by an estimated 90 seconds per year. When connected to the internet, CU5 controllers/tablets automatically synchronize their system time with a cloud server, and then start synchronizing all other controllers in the same network.
Page 43 A data network link is not applicable for Basic IDUD. Neve tick this box. A virtual link is necessary for the function “Linked Printer” so that your Basic IDUD tablet would know from which printer controller(s) it is allowed to interpret tickets.
Page 44 The Credits principle is applied differently in the case of networked (Scan&Go PRO) or standalone controllers (Scan&Go BASIC). For networked controllers, Credits is valid for the entire group of controllers. With standalone controllers, Credits is valid for each controller separately.
Page 45 Validator does not check the validity (= rules and/or credits) of the scanned barcode. 6.1.6 Features and licenses The Basic IDUD can have up to two active features & licenses, depending on the mode you are working  Scanner: When this option is deactivated, the IDUD will generate access/exit tickets and/or discount vouchers when pressing one of the virtual push buttons.
Page 46 Then set the start time of each period, select the operating mode and, in case you selected the Normal mode, select a preset too. You have 64 zones to define a typical day or week. Plug&Play Access & Revenue Control For Vehicles and Pedestrians...
