1. INTRODUCTION Dear customer, We would like to congratulate you on your choice and we are pleased to continue our constant work to provide our customers with a simple, reliable and versatile way to improve ergonomics in the workplace. We hope these simple instructions will help you to set up and operate the equipment you have selected.
✓ If the manual is lost or damaged, Tecnospiro Machine Tool, S.L.U. (the contact TECNOSPIRO MACHINE TOOL, Company) informs that all content in this S.L.U. for a replacement. document including, for example, the text, ✓ Reproducing images, graphic designs, brands, trading...
✓ The operator must only use the safety must corrected equipment after having received the immediately. instructions for its use. ✓ Do exceed maximum ✓ Without the proper authorization of working loads indicated in this TECNOSPIRO MACHINE TOOL, S.L.U. INSTRUCTION MANUAL - TROLLEY...
✓ It is recommended that the operator manual as well as in the identification on the equipment structure. have basic knowledge of: Safety procedures, precautions and safe ✓ It is recommended that only one working habits. operator use the equipment at a ✓...
✓ Loads greater than the maximum LEVEL OF TRAINING FOR working load limits (WLL). PERSONNEL WHO WORK WITH THE ✓ Operation in severe conditions (e.g. DEVICE extreme environmental conditions All persons who work with the device must such as freezing, high temperatures, read and understand the documentation in corrosive environment,...
4. GENERAL DESCRIPTION AND TECHNICAL INFORMATION This Trolley was designed to be used with 3arm® and ROSCAMAT® products, as well as compatible accessories, providing greater mobility to your 3arm® or ROSCAMAT® equipment in an easy and safe way. The trolley is designed to move your 3arm equipment within an industrial environment, on a flat surface, and place it precisely in certain working positions.
DIMENSIONS A: 700x700, 800x800 or 900x900 mm. E: Thickness of base [See BASE DIMENSIONS AND THICKNESSES page 10]. X: Corresponds to 130mm or 190mm depending on which rolling support the trolley uses, depending on whether it is Ø100mm or Ø150mm [See TYPES OF ROLLER MOUNTS page 11].
BASE DIMENSIONS AND THICKNESSES Three dimensions are available for the trolley base, 700x700 800x800 and 900x900 The thickness of the base and the number of add-on elements forming it will depend on the end use. The thickness should be chosen depending on the configuration in which the trolley is to be installed in order to guarantee the stability of the assembly.
Page 11
4.3.1 TYPES OF ROLLER MOUNTS The trolley can be provided with rubber or polyamide castors depending on the end-use application. Type A Type B Material Polyamide Rubber General purpose Use of torque tools Applications tools on abrasive surfaces Available WITHOUT brake Trolley 700: Ø100 Wheel size...
TECHNICAL SPECIFICATIONS GENERAL TECHNICAL SPECIFICATIONS Load capacity (1764 Ib) Nominal capacity with wheels Ø100 800Kg (2204 Ib) Nominal capacity with wheels Ø150 1000Kg Working conditions Temperature -10 to +50 °C Relative humidity Max. 70% Environment Industrial environments Nominal capacity: Load that can be transported on the trolley under the conditions specified. This is defined as a load evenly distributed on the platform.
5. INSTALLATION INSTALLATION ✓ The trolley is designed to work on a smooth, horizontal, firm and non-slip surface. ✓ This trolley has been designed for use together with 3arm® and ROSCAMAT® products, as well as 3arm® and ROSCAMAT® compatible accessories. In any case, the integrator, owner and/or end user is responsible for determining the product's suitability for each use, the installation location, specifically defining the task to be performed within the limits set forth in this manual.
Page 14
USE OF EYE BOLT ✓ Remove the eye bolt after completing the installation. ✓ Use of the eye bolt should be restricted to installation, transport or taking out of service phases. ✓ It is completely prohibited to use it if suspending other objects or masses additional to the weight of the trolley itself.
6. ADJUSTMENTS HANDLE ADJUSTMENT In type B configurations, the trolley is provided with a handle, which can be adjusted following the guidelines below. 1- Loosen the adjustment screw shown (6 mm Allen key). 2- Adjust the position of the handle according to preference and working conditions. (6 mm Allen key) 3- Tighten the adjustment screw securely INSTRUCTION MANUAL - TROLLEY...
7. OPERATION MANIPULATION AND USE To operate the trolley, ensure that the parking brakes on each of the castors are not applied. From the operator's position push the trolley horizontally with the hands placed on the handle provided. The trolley should move and be steered using the handle provided. It should move slowly and smoothly.
PARKING BRAKE In the version for general applications, two of the four castors fitted to the trolley can lock the trolley, acting as a parking brake. In the version for torque tool applications, all four castors can lock the trolley, acting as a parking brake To activate the parking brake, follow the guidelines below: 1- With the trolley completely stopped and on a smooth, horizontal surface, use the foot to...
8. STABILITY CALCULATION Assembled PRJ units are designed so that the distance (D) from the centre of gravity (G) of the whole assembly (including the load and the base) to the axis of the column is not greater than 2/3 of the distance L, in accordance with UNE-EN 14238:2005+A1:2010. G = Centre of gravity of the whole assembly.
ACCESSORIES Caution: not all the accessories shown below are compatible. Check the compatibility table [See COMPATIBLE ACCESSORIES page 23]. TROLLEY To move the work unit. It has four orientable wheels. DESCRIPTION DIMENSIONS Trolley 700 700 x 700 mm 27 9/16" x 27 9/16" Trolley 900 900 x 900 mm 35 7/16"...
Page 21
LIFT / PR LIFT • It consists of a telescopic column and a pneumatic cylinder with anti-rotation. DESCRIPTION VERTICAL STROKE Lifter 300 300 mm 11 7/8" Lifter 500 500 mm 19 7/8" Lifter 750 750 mm 29 17/32" Lift 300 PR 300 mm 11 7/8"...
Page 22
EXTENSION Extender that enables the arm's working area to be increased. It can also be installed on other accessories, such as column, lift, beam, etc. ADDITIONAL CODE DESCRIPTION WORK AREA ER0010C0 Extension 500 (1) 500 mm 19 11/16" ER200500 Extension 600 (1) 600 mm 23 5/8"...
GUIDELINES FOR PACKAGING, TRANSPORT AND DISASSEMBLY 12.1 PACKAGING Follow the instructions below for packaging the trolley to change location or to ship it for repair and maintenance. 12.1.1 Preparations Take the trolley out of service. Using securing straps will prevent movement during transport and hence possible damage to the equipment.
Page 25
NOTES DATE DESCRIPTION INSTRUCTION MANUAL - TROLLEY...
CERTIFICATE OF INCORPORATION In accordance with Machinery Directive 2006/42/EC, Annex II B The manufacturer: Company: TECNOSPIRO MACHINE TOOL, S.L.U. Address: P.I.Pla dels Vinyats I, s/n nau 1 City: Sant Joan de Vilatorrada Country: Spain - EU Declares that this product:...
